M9×1.25mm Thread Gauge Ring Right-Hand, DIN 13 6g, Hardened Gauge Steel - Metav IndustryLine

Take advantage of a purpose-built verification tool that combines hardened gauge steel, DIN 13 tolerance class 6g and a compact M9 × 1.25 mm right‑hand thread form for reliable in‑process assessment; order the gauge directly via Metav Werkzeuge or consult the Metav team for application advice.

Go thread ring gauge M9 x 1.25 mm (DIN 13, 6g) — hardened gauge steel, right‑hand

A Go thread ring gauge M9 x 1.25 mm (DIN 13, 6g) for fast verification of metric ISO standard threads in production and quality control.

• Hardened gauge steel construction
• DIN 13 tolerance class 6g
• For metric ISO threads M9 x 1.25 right‑hand
• Lightweight 0.07 kg for easy handling

Rapid verification for metric ISO threads

The Go ring gauge serves as a simple, deterministic check for whether a manufactured external thread conforms to the specified metric ISO profile. Built to DIN 13 and tolerance class 6g, the gauge gives a clear pass/fail result: the tested thread either enters the ring (go) or it does not. This binary outcome greatly reduces subjective judgement on the shop floor and shortens inspection time, which translates into faster throughput and fewer reworked parts. The gauge's size and profile are matched precisely to an M9 × 1.25 mm metric thread, including pitch and flank form, so compatibility with ISO‑standard components is ensured.

Durable construction for repeatable measurements

Manufactured from hardened gauge steel, the ring offers long service life under regular workshop use and resists wear that would otherwise change the acceptance limit. At just 0.07 kg, the tool is both robust and easy to handle during frequent checks without fatigue. The material choice and heat treatment provide a stable reference geometry; as a result, reproducibility of go decisions is high and measurement uncertainty is minimised. For traceability, the product is listed with GTIN and tariff classification information that supports incoming inspection procedures and inventory control.

Practical benefits for production and quality workflows

Integrating a physical go gauge into a production routine reduces reliance on time‑consuming dimensional measurements where a simple acceptance decision suffices. The ring gauge is ideal for line‑side checks, first‑piece inspections and quick verification during assembly. Using a dedicated verification tool like this one enhances process control, avoids unnecessary scrappage and supports compliance with internal quality plans. For engineering teams that document conformity to standards, the clear specification to DIN 13 and the defined 6g tolerance class provide an auditable basis for acceptance criteria.

Select the Metav IndustryLine Go thread ring gauge for dependable thread verification and contact Metav Werkzeuge for tailored advice and delivery from Emmerich.

Technical data

• Article number: M315.109
• GTIN: 4054469123905
• Tariff number: 90173000

Facts

• Thread size: M9 × 1.25 mm
• Tolerance class: 6g
• Weight: 0.07 kg
• Standard: DIN 13

Special features

• Material: gauge steel, hardened
• Function: Go (acceptance) ring gauge for external threads
• Thread direction: right‑hand
• Categories: gauges, measuring pins

FAQ

What does a "Go" ring gauge check for?
A go ring gauge checks whether an external metric ISO thread meets the lower limit for material removal and profile form; the Go thread ring gauge M9 x 1.25 mm (DIN 13, 6g) allows a quick go/no‑go decision for M9 × 1.25 mm external threads.

Is this gauge compliant with an industrial standard?
Yes, the ring is specified to DIN 13 and manufactured to the 6g tolerance class relevant for metric ISO‑thread verification.

What material is the ring gauge made from?
The gauge is made from hardened gauge steel, chosen to maintain profile accuracy and resist wear during repeated checks.

Can this gauge be used for left‑hand threads?
No, this particular tool is manufactured for right‑hand metric threads only; left‑hand forms require a dedicated ring gauge.

How is the tool identified in stock and documentation?
The item is listed under article number M315.109 and GTIN 4054469123905 for inventory and traceability purposes.

Manufacturer / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; Germany; +49 2822 7131930; info@metav-werkzeuge.com
