M9 x 1.25 Thread Go Ring Right-Hand, Hardened Gauge Steel, DIN 13 6g - Metav IndustryLine

Take advantage of the combination of precise conformity to DIN standards, hardened construction and compact handling for consistent thread inspections and fewer assembly issues; order the gauge via Metav Werkzeuge or consult our sales team for suitability and delivery.

Thread ring gauge M9 x 1.25 mm — DIN 13, tolerance 6g (Metav IndustryLine)

A thread ring gauge M9 x 1.25 mm designed for rapid verification of external metric ISO threads in production and incoming‑inspection environments.

• Hardened gauge steel for long service life
• DIN 13 standard, tolerance class 6g
• M9 x 1.25 mm metric ISO thread
• Right‑hand thread, workshop inspection ready

Ensure correct fit and reduce assembly rework

A limit ring for direct go/no‑go inspection delivers a simple, objective decision during routine checks. Compliant with DIN 13 and specified to tolerance class 6g, this ring verifies whether an external metric ISO thread meets the required form and pitch before parts proceed to assembly. Using a dedicated thread ring avoids subjective judgements and shortens inspection time: a pass/fail outcome replaces time‑consuming measurements, helping to reduce downstream rejects and improve first‑pass yield.

Durable construction for frequent shop‑floor checks

Manufactured from hardened gauge steel, the ring is built to withstand repetitive engagement with threaded parts while maintaining its limit dimensions. The robust material and heat treatment ensure low wear over many cycles, preserving the reference condition that quality checks rely upon. At approximately 0.1 kg, the component is compact and easy to handle during rapid inspections, yet solid enough to resist deformation under normal use. The right‑hand orientation and ISO metric form make it immediately compatible with standard production threads.

Integrate quickly into production and inspection workflows

The ring is a practical tool for assembly plants, toolrooms and quality control stations where throughput and traceability matter. Identifiers such as the SKU M315.209 and GTIN allow straightforward inventory management and traceability across inspection records. As a fixed limit gauge, it complements measuring instruments and can be used as the frontline quality gate: misplaced or non‑conforming parts are identified early, saving machining time and assembly resources. The clear conformity to international norms supports supplier audits and routine quality documentation.

For robust, standards‑based thread inspection choose the Metav IndustryLine ring gauge—contact Metav Werkzeuge in Emmerich for technical clarification or to arrange delivery via info@metav-werkzeuge.com or +49 2822 7131930

Technical Data

• Article number: M315.209
• GTIN: 4054469125565
• Weight: 0.1 kg
• Material: hardened gauge steel
• Thread size: M9 x 1.25 mm
• Standard: DIN 13, 6g

Data

• Tolerance class: 6g
• Tariff number: 90173000

Special features

• Right‑hand metric ISO thread
• Limit ring for go/no‑go inspection
• Compact, shop‑floor friendly design

FAQ

What is the primary use of this ring gauge?
The ring serves as a fixed limit gauge for quick go/no‑go checks of external metric ISO threads; the thread ring gauge M9 x 1.25 mm confirms conformity to DIN 13, 6g.

Which thread standard does it verify?
It verifies metric ISO threads manufactured to DIN 13 with a tolerance of 6g, suitable for right‑hand external threads.

Is the gauge suitable for production‑line inspection?
Yes, the robust hardened gauge steel construction and compact weight make the ring appropriate for frequent, rapid checks on the shop floor.

How is the gauge identified in inventory systems?
The item is listed as SKU M315.209 and carries GTIN 4054469125565 for clear traceability.

Can this ring be used for non‑standard or left‑hand threads?
This particular version is for right‑hand metric ISO threads; for other thread forms or left‑hand variants, consult the product range for the corresponding ring gauge.

Manufacturer / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; Germany; +49 2822 7131930; info@metav-werkzeuge.com
