M9x1 Thread Go Gauge Metric ISO Fine Right-Hand Hardened Gauge Steel DIN 13, 6g - Metav IndustryLine

Ensure repeatable thread inspection with hardened gauge steel construction and conformity to DIN 13 (6g); the compact M9 × 1 mm ring weighs just 0.04 kg for easy handling during routine checks. Order the gauge directly via Metav Werkzeuge or ask our consultants if needed.

Thread Ring M9 × 1 mm (DIN 13, 6g) — Right‑hand Thread Gauge — Metav IndustryLine

The Thread Ring M9 × 1 mm is a hardened limit gauge designed for fast verification of M9 × 1 metric ISO fine threads in production and inspection environments.

• Hardened gauge steel construction
• Conforms to DIN 13 tolerance 6g
• For M9 × 1 mm metric ISO fine threads
• Right‑hand thread verification

Consistent conformity for reliable pass/fail inspection

This ring gauge provides a compact, reliable method for pass/fail verification of fine metric threads. Built to DIN 13 with a 6g tolerance, it distinguishes acceptable thread profiles from rejects without the need for dimensional arithmetic at the bench. The standardised tolerance class ensures results are comparable across batches and suppliers, reducing ambiguity in acceptance criteria and supporting a reproducible quality workflow on the shop floor.

Robust material and low‑effort handling for long service life

Machined from hardened gauge steel, the ring resists wear under repeated use and preserves the reference profile over time. The lightweight construction (approx. 0.04 kg) and compact form factor allow single‑hand operation for quick in‑process checks, while the hardened surface reduces the frequency of replacement—delivering lower life‑cycle costs and less downtime for routine inspections.

Intended use and practical integration into inspection routines

Designed for inspection of metric ISO fine threads, the ring serves as a go/no‑go control in incoming inspection, production sampling and final checks. Its right‑hand orientation matches common threaded components, enabling immediate assessment of thread form and pitch. For documentation, the ring can be referenced by its SKU (M315.209.4) when recording inspection results or ordering replacements, supporting traceability in quality records.

Contact Metav Werkzeuge for expert advice on the Metav IndustryLine thread ring and to arrange supply or batch requirements — Metav Werkzeuge offers tailored guidance from its Emmerich quality hub

Technical Data

• Article number: M315.209.4
• GTIN: 4054469125572
• Weight: 0.04 kg
• Thread size: M9 × 1 mm
• Standard: DIN 13 (6g)
• Material: hardened gauge steel
• Tariff number: 90173000

Data

• eClass: 21170214
• Category: Gauges / Thread rings
• Orientation: Right‑hand thread
• SKU: M315.209.4

Special features

• For metric ISO fine threads
• Limit gauge — go/no‑go functionality
• Compact, low‑mass design for easy handling
• Manufacturer range: Metav IndustryLine

FAQ

What tolerance class does the ring use and what does it mean?
The ring follows DIN 13 with tolerance 6g, which defines the permissible thread form and pitch variation for a standard metric fine thread and allows clear go/no‑go assessment against that industry reference.

Is this thread ring suitable for production sampling?
Yes, the ring is intended for routine production and incoming inspections to verify conformity of M9 × 1 metric ISO fine threads and to provide immediate pass/fail feedback.

What material is the gauge made from and why is that important?
The gauge is made from hardened gauge steel, chosen for wear resistance and dimensional stability so the reference profile remains reliable over extended use.

Is a calibration certificate supplied with the ring?
The product is supplied as manufactured to the stated standard; a calibration certificate is not included by default unless explicitly specified for a particular delivery.

How should the ring be identified in documentation or orders?
Use the designation Thread Ring M9 × 1 mm and SKU M315.209.4 when recording inspection results or placing replacement orders to ensure exact matching.

Manufacturer / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; Germany; +49 2822 7131930; info@metav-werkzeuge.com
