Klemmhalter 95° PWLNR 2020 K08 for WNMG 0804 Wendeplatten Innenkühlung Rechtsschneidend - Teknik Makina
€47.00
Product information "Klemmhalter 95° PWLNR 2020 K08 for WNMG 0804 Wendeplatten Innenkühlung Rechtsschneidend - Teknik Makina"
Benefit from a robust clamping solution that combines secure insert retention, compact workshop dimensions and a precise 95° cutting angle for stable turning results; order the PWLN clamping holder directly via Metav Werkzeuge or ask our consultants if needed.
PWLN for WNMG Indexable Inserts – Clamping holder (PWLNR 2020), right-hand
The PWLN for WNMG Indexable Inserts is a right-hand clamping holder engineered for reliable retention of WNMG 0804 inserts in turning applications.
- Right-hand holder for WNMG 0804 inserts
- 95° cutting angle for stable engagement
- 20 mm holder height, 25 mm head width
- 125 mm overall length for extended reach
Precision and process reliability for turning
This clamping toolholder delivers a combination of secure clamping and consistent cutting geometry that supports reliable chip formation and surface finish. The defined 95° cutting angle reduces lateral forces during engagement, which helps to maintain tool life and steady cutting conditions. The design emphasises repeatability: the seat and flank geometry ensure indexable inserts remain positively located during interrupted cuts, so machining cycles can run with fewer interruptions and predictable outcomes.
Compact dimensions for simple integration
With a 20 mm holder height, 25 mm head width and an overall length of 125 mm, the toolholder is dimensioned to fit most standard toolposts while offering sufficient reach for medium-reach turning tasks. The modest 0.43 kg mass lowers static overhang weight, which can assist in reducing imbalance and vibration on smaller lathes. These practical dimensions make the component straightforward to handle in a busy workshop and facilitate quicker setup and changeover, supporting higher uptime and smoother production flow.
Compatibility, designation and mounting clarity
The toolholder carries the ISO designation PWLNR 2020 and is specified for use with WNMG 0804 indexable inserts in right-hand orientation. The configuration is suitable where a firm clamping interface and consistent rake orientation are required for general turning operations. For procurement and logistics, the item is listed under SKU P150TM and is supplied by Teknik Makina; Metav Werkzeuge can advise on workshop fitment and offer the necessary ordering support to integrate the holder into existing tooling systems.
Contact Metav Werkzeuge today at info@metav-werkzeuge.com or call +49 2822 7131930 to discuss the PWLN clamping holder (SKU P150TM) and its suitability for precise turning operations in the workshop
Technical data
- Article number: P150TM
- Manufacturer: Teknik Makina
- ISO designation: PWLNR 2020
- Compatible inserts: WNMG 0804
Facts
- Holder height: 20 mm
- Head width (cutting head): 25 mm
- Holder width: 20 mm
- Cutting height: 30 mm
- Overall length: 125 mm
- Cutting angle: 95°
- Weight: 0.43 kg
Special features
- Right-hand cutting direction
- Designed for WNMG 0804 indexable inserts
- PWLN series clamping concept
- Suitable for standard turning toolposts
FAQ
Which inserts are compatible with this clamping holder?
The PWLN for WNMG Indexable Inserts (SKU P150TM) is designed specifically for WNMG 0804 indexable inserts and secures them in the PWLNR 2020 seat.
Is this holder intended for right-hand turning only?
Yes, the holder is specified for a right-hand cutting direction, providing correct rake and clearance for right-hand turning operations.
What are the most important dimensions to check for machine fitment?
Key dimensions are 20 mm holder height, 25 mm head width, 30 mm cutting height and 125 mm overall length; these determine clearance and reach when mounted on a toolpost.
What advantage does the 95° cutting angle offer?
A 95° cutting angle delivers a stable cutting engagement and predictable force direction, which helps to reduce lateral deflection and supports consistent surface quality.
How is the item identified for ordering and reference?
Reference the SKU P150TM or the ISO designation PWLNR 2020 when ordering or enquiring about the product.
Manufacturer: Teknik Cutting Tools, Buyukkayacık OSB Mah.422 Nolu Sokak.No:9, Selcuklu/KONYA/TURKEY / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; Germany; +49 2822 7131930; eMail: info@metav-werkzeuge.com
| Cutting angle: | 95.0 |
|---|---|
| Designation: | Klemmhalter |
| Diameter-1: | mm |
