32mm Boring Bar PWLN For WNMG 0804 Inserts 95° Cutting Angle, Internal Coolant - Teknik Makina
€63.00
Product information "32mm Boring Bar PWLN For WNMG 0804 Inserts 95° Cutting Angle, Internal Coolant - Teknik Makina"
Take advantage of the combination of internal coolant, robust clamping for WNMG 0804 indexable inserts and a compact 32 mm diameter for reliable internal turning — secure supply and expert advice from Metav Werkzeuge for seamless tool integration and stable production.
A25S PWLNL boring bar — PWLN for WNMG indexable inserts, 32 mm, left‑hand, internal coolant (Teknik Cutting Tools)
A compact A25S PWLNL boring bar designed for internal turning with PWLN geometry for WNMG indexable inserts, suited to precision turning tasks and stable chip control
- Internal coolant for controlled chip removal
- Compatible with WNMG 0804 indexable inserts
- 32 mm diameter with 25 mm shank
- Left‑hand orientation for negative rake operations
Stable internal turning with assured insert support
The A25S PWLNL boring bar is engineered to deliver rigidity where it matters most, enabling repeatable internal turning cycles with reduced vibration. Its compatibility with WNMG 0804 indexable inserts provides a familiar, economical insert family for a wide range of operations. The tool's geometry and secure clamping reduce insert movement and maintain cutting stability, which translates into fewer rejections and more predictable cycle times. Built-in coolant channels support uninterrupted cutting and help manage temperatures at the cutting edge, improving tool life and surface integrity.
Controlled chip evacuation and consistent finishes
Integrated internal coolant and a defined 95° cutting angle help to direct chips away from the cutting zone and to maintain a stable machining environment. This results in improved surface finish and reduced need for secondary operations. The left‑hand cutting orientation is useful for specialised set‑ups or reversing toolholders and ensures the bar performs as intended in left‑hand turning applications. With a cutting height of 50 mm, the geometry supports effective cutting forces while keeping chip form manageable, helping to reduce machine downtime and improving overall process reliability.
Compact dimensions for easy integration and repeatability
Designed for straightforward installation, the tool's 32 mm diameter and 25 mm shank allow easy mounting in standard holders while providing the stiffness required for internal work. The 250 mm overall length balances reach and rigidity for many common bores, and the modest mass (0.911 kg) aids in maintaining spindle balance when correctly mounted. The ISO designation A25S PWLNL and clear specification for PWLN for WNMG inserts make tooling planning and procurement transparent and efficient, reducing setup time and simplifying inventory management.
Discuss how the Teknik Cutting Tools boring bar with internal coolant and WNMG compatibility can improve machining stability — contact Metav Werkzeuge in Emmerich for tailored advice and reliable supply: info@metav-werkzeuge.com / +49 2822 7131930
Technical data
- Article number: AP370TM
- SKU: AP370TM
- Brand: Teknik Cutting Tools
- ISO designation: A25S PWLNL
- Designation: PWLN for WNMG indexable inserts
Core measurements
- Diameter: 32 mm
- Shank diameter: 25 mm
- Overall length: 250 mm
- Cutting height: 50 mm
- Weight: 0.911 kg
- Cutting angle: 95°
Special features
- Internal coolant
- Left‑hand cutting direction
- Compatible with WNMG 0804 indexable inserts
- PWLN insert geometry
- eClass: 21180806
FAQ
Which insert type fits this boring bar? The boring bar accepts WNMG 0804 indexable inserts using the PWLN geometry specified for the A25S PWLNL tool, ensuring stable clamping and predictable chip formation.
Is the coolant internal or external? The tool features internal coolant, routed to the cutting edge to support chip evacuation and temperature control during internal turning operations.
What are the key dimensions for mounting? Key dimensions include a 32 mm tool diameter, a 25 mm shank diameter and a 250 mm overall length, which together determine compatibility with common toolholders and bar supports.
Can this boring bar be used for heavy interrupted cuts? The bar's design emphasises rigidity and secure insert clamping; while it supports stable cutting, suitability for heavy interrupted cuts depends on machine power, holder stiffness and the chosen insert grade.
What does the left‑hand orientation mean in practice? Left‑hand cutting direction indicates the bar is configured for turning operations where the cutting action proceeds in a left‑hand sense relative to the spindle — appropriate for designated left‑hand toolholders and setups.
Manufacturer: Teknik Cutting Tools, Buyukkayacık OSB Mah.422 Nolu Sokak.No:9, Selcuklu/KONYA/TURKEY / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; Germany; +49 2822 7131930; eMail: info@metav-werkzeuge.com
| Cutting angle: | 95.0 |
|---|---|
| Designation: | Bohrstange |
| Diameter-1: | 32mm |
