40mm S32T PWLNR Boring Bar For WNMG 0804 Inserts 32mm Shank, 60mm Cutting Height, 95° Cutting Angle - Teknik Makina
€70.00
Product information "40mm S32T PWLNR Boring Bar For WNMG 0804 Inserts 32mm Shank, 60mm Cutting Height, 95° Cutting Angle - Teknik Makina"
Benefit from the robust S32T PWLNR design combined with compatibility for WNMG 0804 indexable inserts to secure stable turning and predictable tool life. Take advantage of the 32 mm shank and 300 mm overall length for deeper machining with reduced vibration — order via Metav Werkzeuge or consult the team for tailored application advice.
Boring bar PWLN for WNMG indexable inserts (S32T PWLNR, 32 mm shank) by Teknik Makina
The PWLN for WNMG indexable inserts is a right-hand boring bar engineered for secure turning with WNMG 0804 inserts in industrial and workshop turning applications
- S32T PWLNR design for stable clamping
- Compatible with WNMG 0804 indexable inserts
- 32 mm shank diameter for secure mounting
- 300 mm overall length for deep operations
Stable clamping for consistent turning performance
The S32T configuration delivers a compact, rigid toolholder geometry that promotes secure clamping and reduced chatter in interrupted cuts. With a 32 mm shank and the specified ISO designation, the holder provides standardised mounting that simplifies fixture selection and repeatability across setups. Using indexable inserts means only the cutting edge requires replacement, lowering downtime and enabling consistent component tolerances.
Reach deeper with a balanced, vibration‑resistant design
A 300 mm overall length combined with a 40 mm head diameter gives reach for deeper bores while maintaining a controlled mass distribution. The 95° cutting angle and a 60 mm cutting height support efficient chip control and stable engagement in right‑hand cuts. These dimensions make the tool suitable where extended reach is necessary without sacrificing surface finish or dimensional stability in the machined part.
Simplified tool integration and predictable productivity
Marked as S32T PWLNR, the bar fits common toolholders and complements workflows that rely on WNMG 0804 inserts. The standardised insert interface reduces setup complexity and enables quick insert changes to adapt to different materials and cutting conditions. The tool’s measured weight (approx. 1.764 kg) and nominal geometry aid in balancing considerations for spindle and turret operations, supporting steady cycle times.
Practical guidance for selecting inserts and applications
This boring bar accepts WNMG 0804 indexable inserts; the choice of insert grade and geometry determines cutting performance for specific materials and feeds. The right‑hand cutting direction aligns with standard lathe configurations. As the bar is a modular component, selecting an appropriate insert coating, grade and chipbreaker will tailor the combination to priorities such as tool life, surface finish or productivity without altering the holder.
For secure, repeatable turning with a robust 32 mm shank and standard WNMG 0804 compatibility, contact Metav Werkzeuge for application guidance or to arrange procurement through Metav Werkzeuge GmbH in Emmerich
Technical data
- SKU: P362TM
- Manufacturer: Teknik Makina
- Article designation: Boring bar PWLN for WNMG indexable inserts
- ISO designation: S32T PWLNR
Facts
- Shank diameter: 32 mm
- Cutting height: 60 mm
- Overall length: 300 mm
- Head diameter: 40 mm
- Cutting angle: 95°
- Weight: 1.764 kg
- Cutting direction: right
Special features
- Compatible with WNMG 0804 indexable inserts
- Right‑hand boring bar
- Clamping size: 08
FAQ
What insert type does this boring bar accept? The boring bar accepts WNMG 0804 indexable inserts; the insert determines the cutting performance and material suitability.
Is the bar suitable for deep bore operations? Yes. The 300 mm overall length and balanced geometry make the bar suitable for deeper turning operations while maintaining stability.
What is the shank diameter and why does it matter? The shank diameter is 32 mm; a larger shank diameter improves clamping rigidity and reduces deflection during cutting.
Manufacturer: Teknik Cutting Tools, Buyukkayacık OSB Mah.422 Nolu Sokak.No:9, Selcuklu/KONYA/TURKEY / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; Germany; +49 2822 7131930; eMail: info@metav-werkzeuge.com
| Cutting angle: | 95.0 |
|---|---|
| Designation: | Bohrstange |
| Diameter-1: | 40mm |
