1000mm Depth Caliper Digital Color 2.4" Touchscreen Wireless USB IP54, ISO 17025 Calibrated - Microtech Metrology
€999.00
Product information "1000mm Depth Caliper Digital Color 2.4" Touchscreen Wireless USB IP54, ISO 17025 Calibrated - Microtech Metrology"
Take advantage of a traceably calibrated instrument, robust protection and wide measuring range to keep large-part inspection efficient and reproducible; the integrated Wireless and USB outputs streamline data capture for quality control. Order the depth caliper directly via Metav Werkzeuge or ask our consultants if needed.
Microtech Metrology Depth Caliper — 0–1000 mm range, IP54 protection
The Depth Caliper is a microcomputer-controlled digital depth gauge designed for workshop metrology and inspection tasks that demand long-range, traceable measurements.
- 0–1000 mm measuring range
- Colour 2.4" touchscreen display
- Wireless and USB data output
- ISO 17025 calibrated with certificate
Traceable accuracy for large-format inspection
A calibration traceable to ISO 17025 ensures measurement results that meet laboratory-grade requirements while the instrument retains workshop practicality. The gauge offers an indicated accuracy of ±0.05 mm with a display resolution of 0.01 mm, providing a reliable balance between speed and precision for routine quality checks. Delivering a formal calibration certificate with each unit supports quality-system documentation and auditability, reducing administrative effort when integrating the tool into established inspection procedures.
Robust range and mechanically stable design
With a measuring span of 0–1000 mm, this instrument sits in the category for larger calipers where stiffness and reproducibility are crucial. The long-beam concept is optimised for measuring substantial components such as housings, fixtures and larger assemblies; the IP54 rating gives protection against workshop dust and splash water, while handcrafted measuring jaws maintain consistent contact geometry over long measurements. These characteristics minimise measurement scatter and make the instrument suitable for use in manufacturing environments where repeatable depth readings over long ranges are required.
Efficient data workflow and workshop integration
Equipped with a Colour 2.4" touchscreen and dual Wireless/USB outputs, the caliper removes the need for manual transcription and accelerates transfer into inspection software or SPC systems. The combination of intuitive display, electronic data output and durable construction supports fast sampling procedures and reduces operator influence on results, so process control becomes more efficient. Supplied as a digital depth gauge with comprehensive calibration documentation, the unit fits seamlessly into documented quality chains and inspection stations.
Contact Metav Werkzeuge to request a fully certified Microtech Metrology depth caliper with ISO 17025 certificate and integrated Wireless/USB outputs for streamlined inspection workflows.
Technical data
- Article number: 1432011007
- GTIN: 4061905039102
- Manufacturer: Microtech Metrology
Numbers / Core technical data
- Measuring range: 0–1000 mm
- Resolution: 0.01 mm
- Indicated accuracy: ±0.05 mm
- Display size: 2.4 inches
- Protection class: IP54
- Calibration: ISO 17025 certificate included
Special features / Design
- Colour 2.4" touchscreen display
- Wireless and USB data output
- Handcrafted measuring jaws
- Digital instrument (electronic readout)
- Long-range depth measurement suitable for large components
FAQ
What measuring range does the instrument cover?
The depth caliper covers a measuring range of 0–1000 mm and is intended for larger workshop and inspection tasks.
Is the caliper delivered with a calibration certificate?
Yes, the instrument is delivered fully calibrated with an ISO 17025 calibration certificate included.
What data outputs are available for integration?
The unit provides both Wireless and USB data outputs for connection to inspection software or SPC systems.
How resistant is the instrument to workshop conditions?
The caliper carries an IP54 rating for protection against dust ingress and splash water, suitable for standard workshop environments.
Are the measuring jaws factory-finished?
The caliper features handcrafted measuring jaws designed for stable contact and consistent measurement geometry over long distances.
Manufacturer / Responsible: Microtech, Nizhneyurkovska str., 45a, 04080 Kyiv, Ukraine, tool@microtech.tools
