Turning Holder (Klemmhalter) — PCLN for CNMG Indexable Inserts

The Turning Holder (Klemmhalter) is a precision toolholder designed for turning operations with CNMG 1204 indexable inserts, providing stable clamping and consistent cutting geometry for workshop machining applications.

• Turning Holder PCLN for CNMG 1204 inserts
• ISO designation PCLNL 1616 compatible
• 100 mm Total Length for stable support
• 95° Cutting Angle for precise left-hand turning
• 16 x 16 mm shank for compact setups

Precision Clamping for Consistent Cuts

The Turning Holder delivers secure clamping tailored to CNMG 1204 inserts, which translates into repeatable machining accuracy and reduced insert movement under load. Built to accommodate the standard PCLNL 1616 interface, this holder minimises tool chatter and ensures that the cutting edge maintains its position throughout the cut. For users unfamiliar with toolholder terminology: the ISO designation indicates the holder's shank and clamp geometry, ensuring compatibility with matching insert types.

Compact Design That Improves Accessibility

A compact 16 x 16 mm shank and a 100 mm Total Length allow the holder to reach confined workzones without sacrificing rigidity, making it suitable for small-lathe and toolroom operations where access is limited. The reduced projection helps lower bending moments on the tool, which directly improves surface finish and tool life. This design advantage benefits machinists who require both reach and control in tight setups.

Geometry Optimised for Left-Hand Turning

Engineered with a 95° Cutting Angle and left-hand cutting direction, the holder positions CNMG inserts at an effective attack geometry for common turning tasks. The cutting-head width of 20 mm supports stable insert seating and efficient chip flow. For operators, this means predictable cutting forces and easier planning of feed and speed parameters; for less experienced users, the clear geometry reduces setup iterations.

Robust Compatibility and Workshop Efficiency

Compatibility with CNMG 1204 inserts and the clear ISO marking simplify inventory management and reduce setup errors. The holder's clamping concept prioritises quick insert changes while maintaining a firm grip under varying cutting conditions. As a result, cycle times can be optimised by reducing downtime for tool replacement, an efficiency gain for production-focused shops.

Intended Users and Typical Applications

This Turning Holder is aimed at professional machinists and small-to-medium production shops that work with indexable carbide inserts for steel and general-purpose turning. Its combination of compact dimensions, standardised ISO interface, and dependable clamping makes it particularly suitable for precision finishing, profiling, and internal facing operations where tool stability and repeatability matter most.

Choose Teknik Makina’s Turning Holder for reliable, workshop-proven clamping and contact METAV Werkzeuge for personalised technical advice and ordering support — eMail: info@metav-werkzeuge.com • Tel: +49 2822 7131930 • WhatsApp: +49 170 2837271

Technical Data

• Designation: Turning Holder
• Brand: Teknik Makina
• SKU: P139TM
• For Inserts: CNMG 1204
• Compatible Inserts: CNMG 1204
• Total Length: 100 mm
• Weight: 0.225 kg
• ISO Designation: PCLNL 1616
• Alternate Designation: H12
• Width: 16 mm
• Height: 16 mm
• Cutting Head Width: 20 mm
• Cutting Angle: 95°
• Cutting Direction: left
• GTIN: 4061905149856
• Manufacturer: Teknik Makina, Nolu Sokak, No 9, Selcuklu, Turkey, eMail: info@teknik-makina.com
• Responsible Person: Metav Werkzeuge GmbH, Parkring 45, 46446 Emmerich, eMail: info@metav-werkzeuge.com
