Secure and precise workholding for metalworking productivity
Workholding devices such as workpiece clamps and chuck systems provide absolute positional stability and vibration damping during milling, turning, drilling and grinding, ensuring parts remain free of play under high CNC cutting and feed forces. By transferring clamping loads into the machine table or spindle without deforming the component, a well engineered workholding solution improves machining accuracy, surface finish and process reliability while reducing set-up times. Modular systems from machine vices and chucks to zero-point systems and specialised fixtures enable fast changeovers and support both serial and single-part production, delivering consistent clamping force, repeatability and enhanced throughput.
100mm Vertical Clamp With Solid Holding Arm, 3,300 N Clamping Force, Galvanised - Kukamet
Take advantage of a compact, corrosion-resistant clamp that combines a massive 100 mm holding arm with up to 3,300 N holding force to secure workpieces reliably in repetitive operations. Order the unit via Metav Werkzeuge or contact their consultants for application advice and supply reliability. Vertikalspanner 212 – Vertical clamp with 100 mm arm, galvanised (Kukamet) The Vertikalspanner 212 is a vertical clamp engineered for secure fixture tasks in workshops and light industrial settings, offering a robust holding arm and stable vertical-foot mounting for compact machine tables and benches. Massive 100 mm holding arm Galvanised steel construction Max. holding force 3,300 N Vertical-foot mounting for stability Secure clamping that speeds production cycles A short, powerful clamping device reduces handling time and keeps cycles predictable. The unit’s 3,000 N operating force and 3,300 N holding force mean workpieces remain immobile during machining and assembly, lowering rework rates. In practice, these force values indicate the maximum press and retention capacity measured in newtons, which translates into clear decision criteria for fixture planning and process reliability. The compact mass and firm design help maintain repeatability across many cycles. Compact mounting for stable setups Designed with a vertical-foot mounting, the clamp integrates neatly into machine tables, jigs or inspection benches where height and footprint matter. The galvanised finish protects against corrosion in workshop environments and simplifies maintenance routines by reducing the need for frequent surface care. At a weight of 0.809 kg, the device is easy to position during installation yet contributes meaningful holding power once secured, supporting tidy, space-efficient workstations. Robust construction for everyday workshop use The massive holding arm and simple mechanical principle make the unit suitable for repetitive clamping tasks where reliability is essential. The construction focuses on low-maintenance durability: galvanised components resist environmental wear and the solid arm minimises flex under load, helping to preserve clamping geometry over time. This combination of sturdy design and predictable performance supports process stability in production and repair contexts. For dependable fixture performance, source the Kukamet 212 vertical clamp through Metav Werkzeuge—Metav’s technical advisors are available at info@metav-werkzeuge.com or +49 2822 7131930 to confirm suitability for specific applications Technical data SKU: 212-4-D-C1 GTIN: 8680731501674 eCl@ss: 21041717 ETIM: EC011973 Facts Weight: 0.809 kg Arm length: 100 mm Max. operating force: 3,000 N Max. holding force: 3,300 N Special features Galvanised construction Vertical-foot mounting Massive holding arm Category: Spanner Manufacturer: Kukamet FAQ What maximum holding force does the Vertikalspanner 212 provide? The Vertikalspanner 212 offers a maximum holding force of 3,300 N, suitable for many light industrial clamping tasks. What is the operating (pressing) force of the clamp? The device is rated for a maximum operating force of 3,000 N, indicating the peak press load the mechanism is designed to apply. How is the 212 fixed to a workbench or machine table? The clamp uses a vertical-foot mounting that provides stable attachment on machine tables, fixture plates or benches. Is the surface treatment suitable for workshop environments? Yes, the galvanised finish provides corrosion resistance appropriate for typical workshop conditions, reducing surface maintenance. Which SKU should be referenced when ordering or requesting documentation? Reference SKU 212-4-D-C1 for ordering, spare parts enquiries or technical documentation. Manufacturer: Kukamet Fevzi Çakmak Mah.10644 Sk. No:61-63 42050 Karatay / KONYA TÜRKİYE / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; +49 2822 7131930; eMail: info@metav-werkzeuge.com
100V-240V LED Machine Lamp Waterproof, IP67 - Vertex
Take advantage of the combination of robust ingress protection, wide voltage compatibility and compact weight for dependable workshop illumination. Order the lamp directly via Metav Werkzeuge or consult our advisors for specification matching and immediate supply. VLED-W36 LED machine lamp — waterproof, wide-voltage workshop luminaire by Vertex VLED-W36 is a purpose-built LED machine lamp for resilient task lighting on industrial equipment and production benches, optimised for damp or dust-prone environments IP67-rated waterproof protection Wide 100–240 V input for global use Long 734 mm profile for broad illumination Stable 3.5 kg construction for secure mounting Consistent, high-contrast lighting for safer machining The VLED-W36 provides constant, shadow-reducing illumination that helps operators identify fine details and reduce setup errors. Featuring LED technology and an IP67 rating, the luminaire resists dust ingress and temporary immersion, maintaining light output in challenging conditions. The wide input range of 100–240 V supports a variety of machine tool supplies without additional converters, ensuring uninterrupted operation. This combination of reliability and electrical compatibility minimises downtime and contributes directly to productivity gains on the shop floor. Durable form factor that stays put during production With a length of 734 mm and a mass of 3.5 kg, this machine light offers a substantial yet manageable profile that delivers broad, uniform coverage across workpieces. The weight provides stability for fixed or clamp-mounted arrangements while the compact linear design fits along machine beds and control panels. The device’s ingress protection means routine washdowns and coolant exposure have a limited effect on service life, preserving the quality of illumination and reducing maintenance intervals for production teams. Practical efficiency and workshop-ready versatility Rated equivalent to a 24 W incandescent bulb in terms of useful light output, the LED luminaire delivers clear task illumination with lower thermal impact and immediate start-up. The robust sealing and voltage tolerance make the unit suitable for machine tools, assembly stations and inspection benches where reliable visibility is essential. Beyond technical performance, the product is distributed through Metav Werkzeuge, a supplier that combines wide stock availability with quality screening for the European market, supporting a dependable supply chain for precision workshops. For a waterproof, wide-voltage machine lighting solution from Vertex, contact Metav Werkzeuge in Emmerich for tailored advice and fast supply — eMail: info@metav-werkzeuge.com, Phone: +49 2822 7131930 Technical data Article number: VLED-W36 GTIN: 4061905005695 IP protection: IP 67 Voltage: 100V-240V Weight: 3.5 kg Length: 734 Core data Ingress protection rating: IP67 Input range: 100–240 V Mass: 3.5 kg Profile length: 734 Special features LED illumination Waterproof construction Suitable for machine and bench lighting Equivalent to 24 W incandescent bulb FAQ Is this luminaire suitable for use where coolant sprays occur? The VLED-W36 by Vertex is IP67-rated, which means the luminaire is protected against dust and temporary immersion; it is suitable for environments with occasional coolant exposure. What voltage supplies are supported by the lamp? The unit accepts a 100–240 V input range, allowing direct connection to standard machine supplies across differing regions without additional transformers. How large an area does the light cover on a machine bed? The linear profile of 734 mm provides a broad illumination band suited to long workpieces and extended machine beds, reducing the need for multiple fixtures. Who distributes this product in Europe? Metav Werkzeuge supplies the Vertex VLED-W36 LED machine lamp and maintains stock and a quality filter from its Emmerich location for prompt delivery. Manufacturer: Vertex Machinery Works Co., Ltd.; No. 296, Sec. 1, Feng Shih Road, Fengyuan District, Taichung City 420, Taiwan
100x100x100mm Magnetic Chuck VCP-31 High Pull Force - Vertex
Benefit from a compact, space-saving workholding solution that supports consistent clamping and simplifies setup. The combination of a small footprint, robust build and rapid dispatch ensures reliable shop-floor performance. Order the magnetic clamping block directly via Metav Werkzeuge or ask our consultants for application advice. VCP-31 Magnetic clamping block – compact 100×100×100 mm design, 6.5 kg (Vertex) The VCP-31 magnetic clamping block is a compact magnetic workholding device designed for precise fixturing and efficient clamping tasks in general workshop and light industrial applications. Compact 100×100×100 mm footprint Robust 6.5 kg construction Fast dispatch from Emmerich warehouse Suitable for precise fixturing operations Space-efficient design that optimises workshop layout The small physical footprint of this magnetic workholding unit means a compact footprint with minimal impact on bench or machine table space. With external dimensions of 100×100×100 mm the unit is easy to position and integrate into existing setups, enabling better workflow around milling machines, drill presses or inspection benches. The compact form contributes to a tidier workspace and supports a more organised production cell, which in turn reduces non-productive movement and contributes to measurable time savings during repetitive operations. Stable magnetic clamping for consistent machining accuracy Magnetic clamping delivers steady holding force without the need for complex mechanical fixturing; this reduces setup complexity and improves repeatability. The block’s magnetic clamping principle allows workpieces to be located and released swiftly, lowering setup times and increasing machine uptime. For operations that prioritise positioning accuracy, the design supports consistent contact and minimal movement during machining, helping to protect tool life and maintain process reliability across repeated cycles. Robust build and ready availability for production continuity Constructed for workshop use, the unit’s robust construction and 6.5 kg mass provide stability during routine machining tasks and handling. The physical weight contributes to steadiness on the machine table while its format supports easy handling and storage. With rapid dispatch offered from Metav’s Emmerich facility and the option to order via invoice in the webshop, procurement is straightforward and predictable. The combination of immediate availability and trusted distribution helps avoid production delays and supports steady supply to the shop floor. Choose the Vertex VCP-31 for compact, reliable magnetic workholding and contact Metav Werkzeuge in Emmerich for product details and immediate dispatch. Technical data Article number: VCP-31 GTIN: 4061905085093 ECLASS: 21020807 Facts Dimensions: 100×100×100 mm Weight: 6.5 kg Special features Brand: Vertex Rapid dispatch Orderable on invoice via webshop FAQ What is the primary advantage of a magnetic clamping block? A magnetic clamping block provides fast, repeatable workholding with reduced mechanical setup; the VCP-31 magnetic clamping block supports quicker fixture changes and steadier positioning for repetitive tasks. Is the VCP-31 suitable for small machining centres? Yes. The compact size and stable mass of the VCP-31 make it well suited to small machining centres and bench-top equipment where space and rigidity are important. How is the VCP-31 ordered and delivered? The VCP-31 can be ordered through Metav Werkzeuge’s webshop with invoice billing available; items are dispatched from the Emmerich warehouse to maintain reliable delivery. Can the block be repositioned quickly during setup? Yes. The magnetic workholding principle used in this block enables rapid placement and release, helping to shorten overall setup durations. Manufacturer: Vertex Machinery Works Co., Ltd.; No. 296, Sec. 1, Feng Shih Road, Fengyuan District, Taichung City 420, Taiwan
100x100x100mm Precision Angle Plate, Alloy Steel, Accuracy 0.005mm - Vertex
Reliable fixturing and consistent perpendicular alignment are achieved through the combination of 0.005 mm accuracy, robust alloy steel construction and a compact 100 x 100 x 100 mm footprint. Benefit from repeatable set-ups and reduced rework; order the part directly via Metav Werkzeuge or consult our specialists for fixture integration. VRS-44 Precision Clamping Angle by Vertex — 0.005 mm accuracy, alloy steel A compact precision clamping angle, the VRS-44 is designed for secure right-angle fixturing and accurate alignment in workshop and production jigs. High-precision 0.005 mm tolerance Solid alloy steel construction Compact 100 x 100 x 100 mm footprint Reduce setup time with dependable accuracy Precision in fixturing directly reduces measurement error and downstream rework. With a specified accuracy of 0.005 mm, the unit provides a quantifiable basis for repeatable perpendicular alignment; this level of precision corresponds to very small deviations in right-angle set-ups, ensuring consistent component positioning during machining or inspection. For workshops that value throughput and first-pass yield, the measurable accuracy translates into fewer alignment checks and faster cycle starts, supporting efficient production rhythms. Robust construction for stable clamping Manufactured from alloy steel, the component offers high structural rigidity that stabilises clamped parts under machining forces. The material choice delivers mechanical strength that helps maintain geometry under load, which in turn preserves the initial alignment and reduces the likelihood of distortion during processing. The weight and material properties contribute to steadiness during cutting or measuring operations, improving repeatability without the need for frequent recalibration. Small footprint, flexible workshop integration The compact dimensions of 100 x 100 x 100 mm combine with a mass of 3.7 kg to produce a durable yet easily positioned fixture element. This balance of size and mass is advantageous where bench space is limited or where multiple clamping elements must be arranged within a single jig. The modest footprint supports modular layouts and quick reconfiguration of clamping assemblies, enabling smoother transitions between jobs and better utilisation of existing workholding systems. Simple integration into clamping and inspection workflows Designed for clamping technology and fixturing applications, the VRS-44 fits into standard workshop workflows and metrology rigs without requiring specialised mounts. The clear technical parameters and catalogue identifiers facilitate procurement and inventory control, while the solid construction supports repeated mounting cycles. For production environments aiming to increase consistency, the device offers a practical way to improve alignment stability and reduce stoppages caused by mis-fixtured parts. Talk to Metav Werkzeuge in Emmerich for tailored advice on integrating Vertex VRS-44 components into existing fixtures and to request application-specific recommendations Technical data SKU: VRS-44 GTIN: 4061905085499 Manufacturer: Vertex Facts Accuracy: 0.005 mm Dimensions: 100 x 100 x 100 mm Weight: 3.7 kg Special features Material: Alloy steel eClass: 21020601 FAQ What accuracy can be expected from this clamping angle? The Vertex VRS-44 precision clamping angle delivers an accuracy of 0.005 mm, providing very small angular deviation for reliable right-angle fixturing. Which material is the component made from and why does it matter? The unit is produced from alloy steel; this material gives the clamping angle structural rigidity that helps maintain alignment under machining loads. Is the VRS-44 suitable for compact fixture layouts? Yes, with dimensions of 100 x 100 x 100 mm and a mass of 3.7 kg, the VRS-44 is designed for efficient placement in confined jig or bench spaces. Can the clamping angle be used in metrology setups as well as production jigs? The design and documented accuracy make the VRS-44 suitable for both inspection fixtures and production clamping applications where repeatable right-angle alignment is required. How is the product identified for ordering and inventory purposes? The component is listed under SKU VRS-44 with GTIN 4061905085499, simplifying procurement and stock management for production and maintenance teams. Manufacturer: Vertex Machinery Works Co., Ltd.; No. 296, Sec. 1, Feng Shih Road, Fengyuan District, Taichung City 420, Taiwan
100x130mm Precision Cross Table 0.02mm Accuracy, 35 Kg Load Capacity - Vertex
Benefit from the combination of 0.02 mm accuracy, a compact working table and a 35 kg load capacity for repeatable, efficient set-ups. Order the precision cross slide directly via Metav Werkzeuge or consult our specialists for application advice. Vertex VCT-407 Precision Cross Slide Table — 100 x 180 mm work table, 3/8" T-slot The VCT-407 precision cross slide table delivers fine-positioning and secure fixturing for machining, measuring and inspection tasks in compact workshops and toolrooms. Compact 100 x 180 mm working table High positioning accuracy 0.02 mm 3/8" T-slot for secure fixturing 35 kg maximum load capacity Accurate, repeatable positioning for precision tasks The design centres on reliable, measurable accuracy: the table offers a documented 0.02 mm positional resolution, supporting tasks where tight tolerances matter. The 100 x 180 mm working surface provides a stable platform for small components and measuring fixtures, while the compact 100 x 130 mm base reduces occupied bench space. These characteristics translate into fewer re‑set operations, shortened cycle times and a predictable throughput for batch work and single‑part inspection routines. Secure clamping and a footprint suited to small workshops A dedicated 3/8" T-slot across the work surface allows standard fixtures, clamps and modular tooling to be mounted quickly and securely. The table's mass of 12 kg and the engineered top geometry contribute to damping of vibration during manual machining and inspection, which helps preserve measurement integrity. With a rated maximum load of 35 kg, the cross slide accommodates a wide range of vice sizes and component weights while maintaining positional stability. Engineered to speed up workflow and inspection processes By combining a compact format with repeatable micro‑positioning, the unit reduces setup complexity for milling, drilling jigs and quality‑control benches. The integrated feed screws and guideways ensure smooth, controllable motion that supports fine adjustments without overcomplicated mechanisms. For production and workshop managers this means improved first‑pass yield and fewer corrective operations, a clear rational gain for time‑critical or high‑precision tasks. Practical durability and integration into existing tooling Constructed for daily workshop use, the cross slide fits easily into retrofit and small‑format machining applications where floor space is limited but precision is required. The table couples well with standard inspection equipment and clamping systems, enabling a straightforward integration into measuring stations or manual machining centres. As a Vertex product, the unit aligns with established quality expectations and offers traceable specification data for procurement and process documentation. Discuss how the Vertex VCT-407's 0.02 mm positioning can raise process reliability — contact Metav Werkzeuge in Emmerich at info@metav-werkzeuge.com or +49 2822 7131930 for tailored advice and procurement assistance Technical data Article number: VCT-407 GTIN: 4061905083327 Product type: Precision cross table Core specifications Table size: 100 x 180 mm Base size: 100 x 130 mm Accuracy: 0.02 mm Maximum load: 35 kg Weight: 12 kg eClass: 21041714 Features & compatibility T-slot: 3/8" Manufacturer: Vertex SKU: VCT-407 Suitable for workshop machining and inspection fixtures FAQ What level of positional accuracy can be expected from the table? The table provides a positional accuracy of 0.02 mm, which supports fine adjustments for precision machining and inspection tasks with repeatable results. Which workpiece sizes does the table accommodate? With a working surface of 100 x 180 mm and a maximum load of 35 kg, the table suits small to medium parts and can carry common inspection vices and modular fixtures. Is the surface compatible with standard clamping elements? Yes, the 3/8" T-slot is compatible with commonly used clamps and tooling blocks, allowing rapid and secure fixturing. How heavy is the unit and what does that mean for stability? Weighing 12 kg, the unit offers sufficient mass for bench‑top stability while remaining manageable for integration into small machines and inspection benches. Can this cross slide be used for both machining and metrology tasks? The combination of a compact work surface, fine positioning and secure T‑slot fixturing makes the unit suitable for manual machining aids and precision inspection set‑ups. Manufacturer: Vertex Machinery Works Co., Ltd.; No. 296, Sec. 1, Feng Shih Road, Fengyuan District, Taichung City 420, Taiwan
100x140x65mm Machine Vise Modular Precision 0.01mm, 8.5kg - Vertex
Take advantage of compact stability and repeatable 0.01 mm precision to keep small-batch milling and drilling running smoothly; order directly via Metav Werkzeuge or contact our consultants for tailored advice. Vertex VMP-44D — Modular machine vice with 0.01 mm accuracy The Vertex VMP-44D is a modular machine vice designed for precise workholding in milling and drilling, combining a compact footprint with a robust mass for steady clamping. Modular design for flexible configurations Precision holding with 0.01 mm accuracy Compact footprint: 100 x 140 x 65 mm Robust mass: 8.5 kg for steady clamping Maintain tight tolerances with reliable repeatability The VMP-44D delivers repeatable precision thanks to its specified 0.01 mm accuracy, which supports fine machining tasks and inspection-related registers. For production scenarios where identical fits and alignment matter, such repeatability reduces set-up iterations and scrap rates. The construction emphasises a true clamping interface and predictable behaviour under load, so programmed toolpaths and hand-operated operations alike benefit from consistent part positioning. Explaining the term: 0.01 mm indicates the vice can position and retain a workpiece with deviations typically within one hundredth of a millimetre, making it suitable for demanding small-component work and finishing passes. Adapt setups quickly to match process needs A modular layout allows configuration changes without replacing the entire unit, enabling fast adaptation between different jobs and fixtures. Modular clamping elements can be reconfigured to accommodate varied workpiece geometries, shortening downtime between set-ups and improving machine uptime. The vice’s design supports integration into existing fixturing strategies on vertical and horizontal machines, offering a versatile way to consolidate tooling inventory. This flexibility means fewer bespoke fixtures, so process planners gain operational efficiency and a clearer route to standardised workflows. Compact mass that improves stability and handling With external dimensions of 100 x 140 x 65 mm and a mass of 8.5 kg, the vice strikes a balance between a small footprint and the inertia needed to resist chatter during cutting. The relatively high mass for its size increases damping and reduces vibrational transfer into the workpiece, which helps achieve superior surface finishes and longer tool life. Its compact form enables use on machines with limited table space or in multi-fixture layouts, while still providing the steady clamping required for precision operations. A practical technical drawing and close-up images are available for planners to verify mounting and clearances before integration. Contact Metav Werkzeuge for expert guidance on the Vertex VMP-44D modular machine vice and to discuss compatibility with specific fixtures and machines; Metav Werkzeuge’s specialists in Emmerich are available by phone or email to support procurement and technical questions. Technical Data Article number: VMP-44D GTIN: 4061905083211 ETIM: EC002173 ECLASS: 21020601 Type: Modular Dimensions: 100 x 140 x 65 mm Weight: 8.5 kg Accuracy: 0.01 mm Facts SKU: VMP-44D Category: Vertex Mass: 8.5 kg Footprint: 100 x 140 x 65 mm Precision: 0.01 mm Special features Modular design for flexible setups Supplied images: technical drawing and detail photos Brand: Vertex FAQ What level of accuracy can be expected from the vice? The vice delivers an accuracy of 0.01 mm, which allows for highly repeatable positioning suitable for fine milling and drilling tasks with the Vertex VMP-44D modular machine vice. Are the dimensions suitable for compact machine tables? Yes, the compact footprint of 100 x 140 x 65 mm and a mass of 8.5 kg make the vice appropriate for machines with limited table space or for multi-fixture arrangements. Can the vice be reconfigured for different workpieces? The modular design enables flexible configuration of clamping elements, allowing adaptation to varied part geometries without replacing the entire unit. What visual documentation is available for planning integration? Technical drawings and close-up detail images are provided for the VMP-44D to assist planners in verifying mounting, clearances and fixture compatibility. Manufacturer: Vertex Machinery Works Co., Ltd.; No. 296, Sec. 1, Feng Shih Road, Fengyuan District, Taichung City 420, Taiwan
100x140x65mm Modular Machine Vise, Precision 0.01mm, 8.5kg - Vertex
Take advantage of modular configuration and 0.01 mm repeatability combined with a compact footprint for consistent productivity on small machining centres; order directly via Metav Werkzeuge or consult their specialists for tailored setup advice. VMP-4L Modular Machine Vice by Vertex — 0.01 mm accuracy, compact 100×140×65 mm VMP-4L is a modular machine vice designed for precision clamping on milling machines and machining centres, offering flexible fixturing in confined workshop spaces. Modular configuration for flexible setups High repeatability with 0.01 mm accuracy Compact footprint 100×140×65 mm Solid mass for improved stability 8.5 kg Precision that reduces rework and raises throughput The vice delivers 0.01 mm repeatability, a level of accuracy that translates directly into fewer setup adjustments and less rework during small-batch production. By reducing dimensional variation at the clamping stage, machining cycles remain consistent and predictable. The combination of precision and mass dampening contributes to improved surface finish and minimal vibration during cutting; for many applications this means higher first-pass yield and lower inspection overhead. Modular design for rapid reconfiguration and versatility A modular concept allows swift changes between clamping configurations, shortening machine downtime between jobs. Modules can be combined or re-arranged to accept different workpiece geometries, enabling efficient transitions from one part family to another. The adaptable design supports a variety of fixturing strategies without the need for multiple dedicated vices, thereby conserving fixture investment and floor space while maintaining process stability. Save bench space without compromising capability With a compact footprint of 100×140×65 mm, the vice is intended for benches and machine tables where space is at a premium. Its small envelope makes it suitable for machine shops that run simultaneous setups or need multiple clamping points on a single table. Despite the reduced size, the unit’s 8.5 kg mass provides the stability required for routine milling and drilling operations, combining a modest physical profile with the robustness expected in production environments. Built for professional workshops and dependable repeatability Manufactured by Vertex, the vice is engineered to support repeatable production processes where tight tolerances matter. The precision mechanics and modular approach make the unit appropriate for toolrooms, prototyping departments and light production runs that demand reproducible clamping without complex bespoke tooling. The clear technical specification simplifies integration into existing workflows and supports traceable quality outcomes. Contact Metav Werkzeuge in Emmerich to discuss the Vertex VMP-4L modular machine vice and confirm the optimal configuration for the production environment — email info@metav-werkzeuge.com or call +49 2822 7131930 Technical Data Article number: VMP-4L GTIN: 4061905092626 Manufacturer: Vertex Facts Dimensions: 100×140×65 mm Accuracy: 0.01 mm Weight: 8.5 kg Special features Type: Modular Product name: Machine vice ECLASS: 21020601 ETIM: EC002173 FAQ What level of accuracy can be expected from this vice? The vice offers an accuracy of 0.01 mm, making the Vertex VMP-4L suitable for applications where tight dimensional control and repeatability are required. Is the VMP-4L suitable for use on small milling machines? Yes, the compact 100×140×65 mm footprint and robust mass of 8.5 kg make the VMP-4L appropriate for small milling machines and machining centres where space is limited. How does the modular concept benefit production workflows? The modular design allows rapid reconfiguration of clamping setups, reducing downtime between jobs and enabling flexible fixturing strategies for varied part geometries with the Vertex modular machine vice. What mounting or fixturing options are available for this vice? The VMP-4L is designed for machine-table mounting and flexible fixturing; for specific mounting patterns and fixture compatibility consult the technical drawing or Metav Werkzeuge’s product documentation. Who manufactures the product and where can I obtain further specifications? The vice is manufactured by Vertex; detailed specifications, technical drawings and configuration advice are available through Metav Werkzeuge and Vertex product literature. Manufacturer: Vertex Machinery Works Co., Ltd.; No. 296, Sec. 1, Feng Shih Road, Fengyuan District, Taichung City 420, Taiwan
100x150mm Hydraulic Machine Vice Modular, 20 KN Clamping Force, 0.01mm Accuracy - Vertex
Take advantage of a robust, hydraulic clamping solution with a modular design and 20 kN clamping force for secure, repeatable workholding; the compact footprint and high positional accuracy support efficient machining cycles. Order the VNC-100FV directly via Metav Werkzeuge or contact the consultants for tailored advice. VNC-100FV Hydraulic Machine Vice — modular hydraulic clamping, 20 kN force VNC-100FV is a hydraulic machine vice designed for secure, high-precision clamping in industrial machining and fixture applications. Hydraulic clamping for high holding power Modular design for flexible setup 20 kN clamping force for demanding tasks High positional accuracy 0.01 mm Durable cast-iron construction Reliable clamping that speeds up production The hydraulic clamping mechanism delivers consistent clamping force, reducing the need for manual retightening and minimising cycle interruptions. With a 20 kN rated clamping force and a compact height of 103 mm, this vice combines strong holding capacity with a low profile that fits many machining fixtures. The hydraulic actuation translates into faster set-up times and a secure grip on workpieces, which helps maintain throughput and reduce scrap rates. For production environments seeking dependable repeatability, this clamping unit offers a measurable improvement in operational efficiency. Precision and repeatability tailored to workshop standards Built for accurate positioning, the vice provides a stated accuracy of 0.01 mm, supporting precise finishing and tight-tolerance machining. The robust cast-iron body stabilises the clamped part and dampens vibration, which contributes to surface finish quality and tool life. The vice’s design emphasises repeatable outcomes: once set, the hydraulic system maintains pressure uniformly across cycles, so component-to-component variance is minimised. For toolrooms and production cells where consistent results influence downstream processes, this unit supports quality assurance objectives. Compact, modular format for versatile fixturing Offered in two base sizes, 100 x 150 mm and 100 x 228 mm, the vice adapts to different workpiece dimensions while keeping the machining envelope economical. The modular design enables integration with various fixtures and table arrangements, allowing jigs and subplates to be configured around a standard clamping core. At a mass of 19 kg, the unit is heavy enough to stay stable under load yet light enough to be repositioned when workflows change. This flexibility reduces the number of different workholding devices required and streamlines workstation layout. Long-term reliability and workshop compatibility Engineered for industrial use, the vice focuses on durability and low-maintenance operation. The hydraulic clamping system reduces mechanical wear associated with repeated manual torquing, and the cast-iron construction resists deformation under load. Routine inspection of hydraulic connections and seals is standard practice to sustain performance, while the vice’s straightforward geometry simplifies jaw replacement and machining of custom soft jaws. For operations aiming to lower total cost of ownership, the combination of rugged construction and serviceable components supports prolonged, dependable service. Choose the VNC-100FV for secure, precise clamping and contact Metav Werkzeuge for specification support and delivery from Emmerich to the workshop bench Technical data Article number: VNC-100FV GTIN: 4061905083235 ETIM: EC002173 Brand: Vertex Core specifications Height: 103 mm Weight: 19 kg Clamping force: 20 kN Accuracy: 0.01 mm Base dimensions: 100 x 150 mm and 100 x 228 mm Materials & features Body material: cast-iron Type: hydraulic Design: modular ECLASS: 21020601 FAQ What clamping force does this vice provide? The VNC-100FV offers a clamping force of 20 kN, suitable for demanding machining and secure workholding. What accuracy can be expected from this clamping solution? The vice delivers an accuracy of 0.01 mm, supporting tight-tolerance machining and consistent repeatability with the VNC-100FV. Which sizes are available for the vice base? This clamping unit is available with base options 100 x 150 mm and 100 x 228 mm to suit different workpiece formats. What material is the vice body made from? The VNC-100FV features a cast-iron body that provides stability and vibration damping during machining. How heavy is the unit and will it fit compact setups? The vice weighs 19 kg and has a low profile height of 103 mm, making it suitable for compact fixtures and tight machine envelopes. Manufacturer: Vertex Machinery Works Co., Ltd.; No. 296, Sec. 1, Feng Shih Road, Fengyuan District, Taichung City 420, Taiwan
100x150x100mm Precision Angle Clamp, Alloy Steel, Accuracy 0.005mm - Vertex
Take advantage of the combination of ±0.005 mm repeatability, alloy steel construction, and a compact footprint to ensure precise, stable clamping during inspection and setup. Order the part directly via Metav Werkzeuge or consult the team for application-specific advice. VRS-46 Precision Angle Plate by Vertex — Alloy steel, ±0.005 mm accuracy The VRS-46 is a compact precision angle plate designed for secure right-angle clamping and alignment tasks in inspection, setup and small-series production environments ±0.005 mm positional accuracy Alloy steel construction for durability Compact 100 x 150 x 100 mm footprint Stable 4.5 kg mass for vibration damping Consistent alignment for reliable measurement results The angle plate offers high-precision location control with an accuracy of ±0.005 mm, which translates into reproducible part alignment during inspection and machining setup. This level of precision reduces the need for repeated adjustments and shortens inspection cycles, providing a measurable increase in throughput. For users less familiar with metrology, accuracy here describes the maximum deviation expected when positioning a workpiece; lower values mean closer adherence to the intended geometry and fewer rejects. Robust build that stabilises the process Manufactured from alloy steel, the component combines toughness with the mass required to dampen machine vibration. The unit weight of 4.5 kg contributes to a secure, non-resonant clamping base that improves measurement stability and reduces micro-movements under probing or light machining forces. This durability supports long service intervals and consistent performance across daily use, making it suitable for workshops that demand both reliability and low maintenance overheads. Space-saving design that integrates easily into workflows With external dimensions of 100 x 150 x 100 mm, the plate occupies a modest bench area while providing a true right-angle reference for setup and inspection tasks. The compact footprint allows installation on granite plates, machine tables or fixture stacks without extensive reorganisation of the workspace. Reduced setup time and straightforward positioning mean faster part turnaround and a smoother process chain, supporting a cost-effective use of floor space and operator time. Contact Metav Werkzeuge today to discuss how Vertex’s VRS-46 precision angle plate can improve setup repeatability from our Emmerich warehouse and to arrange technical consultation or stock enquiries Technical Data Article number: VRS-46 GTIN: 4061905086892 Manufacturer: Vertex Facts Dimensions: 100 x 150 x 100 mm Weight: 4.5 kg Accuracy: 0.005 mm ECLASS: 21020601 Materials & Features Alloy steel construction Compact design for easy integration SKU: VRS-46 FAQ What level of positional accuracy does the angle plate provide? The VRS-46 precision angle plate provides an accuracy of ±0.005 mm, enabling tight positional repeatability for inspection and setup tasks. Which material is the plate made from and why does that matter? The plate is made from alloy steel, chosen for its strength and mass, which help to dampen vibration and maintain stable clamping under probing or light machining. What are the external dimensions and is it suitable for small benches? The external dimensions are 100 x 150 x 100 mm, making the unit suitable for compact benches, granite plates and tight workshop layouts. How does the weight affect performance during measurement? At 4.5 kg, the mass improves stability and reduces micro-movements during measurement, which enhances repeatability and lowers measurement uncertainty. Is this plate suitable for inspection and for production setup? Yes, the design and accuracy of this angle plate make it suitable for both inspection and small-series production setup where precise right-angle referencing is required. Manufacturer: Vertex Machinery Works Co., Ltd.; No. 296, Sec. 1, Feng Shih Road, Fengyuan District, Taichung City 420, Taiwan
100x38x13mm Axial Drive Smooth Jaws Pair, For VNC-FV - Vertex
Reliable clamping and consistent part finish are delivered through the combination of an axial drive and smooth jaw faces, supplied as a paired set and sized for quick exchange. The compact dimensions and lightweight construction support efficient set-up and handling; order the VNC-4PJ jaws via Metav Werkzeuge or consult our advisors for specification support. VNC-4PJ — Smooth jaws with axial drive for VNC‑FV chucks (Vertex) The VNC-4PJ is a paired set of axial‑drive smooth jaws designed for precision clamping with VNC‑FV chucks, suitable for finishing and delicate work where surface quality and repeatability are essential. Axial drive for compact actuation Smooth jaw faces for delicate finishes Supplied as a paired set Compact dimensions 100×38×13 mm Lightweight 1.3 kg for easy handling Secure clamping and improved surface quality The axial‑drive mechanism provides a direct, compact actuation path that reduces lateral play and stabilises the clamping force, ensuring repeatable gripping and consistent part concentricity. Paired with smooth jaws, the contact area minimises marking on softer or finished surfaces, which preserves component aesthetics and reduces post‑machining operations. This combination is particularly advantageous for short production runs or precision finishing where handling damage must be avoided. Fast changeover and workshop efficiency With compact dimensions of 100 × 38 × 13 mm and a weight of 1.3 kg, the jaw set enables quick swapping on VNC‑FV chucks, shortening fixture change times and increasing machine uptime. The paired supply supports balanced clamping without additional matching work, allowing a smooth transition between setups. The low mass helps to reduce handling strain and simplifies inventory management for repair or replacement parts. Versatile application across materials The smooth face design is intended for workpieces requiring minimal surface alteration; it is suitable for finishes on softer metals and operations where visible marking is unacceptable. Where firmer grip is required, the axial‑drive configuration can be combined with alternative jaw types on the same chuck body, offering process flexibility while maintaining the benefits of the compact actuation system. Reliability and specification clarity for procurement Manufactured by a recognised supplier, the jaw set supports clear procurement decisions through defined dimensions and a standard SKU for ordering. Technical compatibility with the VNC‑FV chuck system reduces the risk of mis‑ordering or retrofit problems. The product’s compact form factor and paired delivery are practical choices for workshops prioritising quality control and efficient stock rotation. For technical advice or to source the Vertex VNC-4PJ axial‑drive smooth jaws, contact Metav Werkzeuge — reachable by email at info@metav-werkzeuge.com or by phone on +49 2822 7131930 — our consultants will assist with compatibility and delivery from Emmerich Technical Data Article number: VNC-4PJ GTIN: 4061905092480 Manufacturer: Vertex Facts Dimensions: 100 × 38 × 13 mm Weight: 1.3 kg ECLASS: 21130302 Special features Paired supply Axial drive mechanism Smooth jaw faces Intended for VNC‑FV chuck systems FAQ What chuck does this jaw set fit? The VNC‑4PJ paired smooth jaws are designed specifically for use with VNC‑FV chuck systems and are supplied with a standard SKU for easy identification. Can the smooth jaws be used on delicate aluminium components? Yes, the smooth jaw faces of the VNC‑4PJ reduce surface marking and are suitable for finishing or handling softer metals such as aluminium. Is the jaw set supplied as a complete pair? The product is delivered paarweise (supplied as a paired set) to ensure balanced clamping without additional matching work. What are the dimensions and weight for handling and storage planning? The VNC‑4PJ measures 100 × 38 × 13 mm and weighs 1.3 kg, aiding quick handling and compact storage. Who is the manufacturer of this jaw set? This jaw set is produced by Vertex and listed under SKU VNC‑4PJ for straightforward procurement. Manufacturer: Vertex Machinery Works Co., Ltd.; No. 296, Sec. 1, Feng Shih Road, Fengyuan District, Taichung City 420, Taiwan
100x49x37mm L-Angle Stop For VQC Vices - Vertex
Take advantage of the compact footprint, precise positioning and solid mass for dependable repeatability in series workholding; order the genuine Vertex accessory via Metav Werkzeuge or consult the Metav team for application advice. L-stop (VQC-100FPM) for VQC vises — Compact 100 x 49 x 37 mm, Vertex L-stop (VQC-100FPM) is a compact angle stop designed to provide repeatable end-stopping and positioning on VQC series vises, optimising set-up time for batch clamping and machining operations. Compact 100 x 49 x 37 mm format Compatible with VQC series vises Solid mass for stable workholding (0.81 kg) Precise, repeatable positioning for series work Faster, more repeatable setups for series production The L-stop delivers a straightforward way to secure workpieces at a defined datum, reducing setup variation and cycle time. With clear dimensions of 100 x 49 x 37 mm, the stop integrates into existing VQC jaw arrangements and fixtures without the need for custom adapters. The fixed geometry supports consistent referencing which benefits automated and manual workflows alike, improving throughput while maintaining tight positional control. Stability and durability that support machining accuracy Weighing 0.81 kg, the stop provides the necessary mass to resist movement during clamping and light machining, contributing to stability and consistent clamping force transfer. Although the exact material is not listed in the product data, the measured weight and compact form factor indicate a robust accessory suitable for standard workshop use. The design reduces micro-movements at the workpiece interface, directly supporting dimensional accuracy and repeatable results in production runs. Seamless integration with VQC workholding systems Engineered for the VQC series, this angle stop fits into common jaw and fixture layouts used in precision workshops, enabling quick installation and straightforward indexing. Compatibility with VQC vises simplifies inventory and tooling strategies, allowing faster changeovers and less time spent on alignment. The compact nature of the stop also preserves accessible clamping zones and keeps the machining envelope clear, which is essential for efficient tool paths and safe handling. Order genuine Vertex L-stop (SKU VQC-100FPM) via Metav Werkzeuge for reliable workholding and consistent production results — contact Metav Werkzeuge in Emmerich for tailored advice at info@metav-werkzeuge.com or by phone on +49 2822 7131930 Technical data Article number: VQC-100FPM GTIN: 4061905092640 ECLASS: 21029210 Data Dimensions: 100 x 49 x 37 mm Weight: 0.81 kg Special features Compatible with VQC series vises Designed as an angle stop for repeatable positioning Manufacturer: Vertex FAQ What is the L-stop intended for and which vises is it compatible with? The L-stop is intended as an angle stop for repeatable workpiece positioning and is specifically compatible with VQC series vises. What are the external dimensions of the accessory? The stop measures 100 x 49 x 37 mm. What is the mass of the accessory and how does that affect use? The accessory weighs 0.81 kg; the mass contributes to stability during clamping and helps reduce movement under load. What is the product SKU and GTIN for ordering and stock checks? The SKU is VQC-100FPM and the GTIN is 4061905092640. Manufacturer: Vertex Machinery Works Co., Ltd.; No. 296, Sec. 1, Feng Shih Road, Fengyuan District, Taichung City 420, Taiwan
100x50mm V-Block Pair With Clamping Strap, 5.9 kg - Vertex
Take advantage of stable support, a compact 100 x 50 mm base and an integrated clamping strap to speed up inspection workflows while maintaining repeatable results; order via Metav Werkzeuge or ask our advisors for technical guidance. Prism pair with clamping strap — Vertex support for cylindrical inspection The prism pair with clamping strap is designed to support cylindrical workpieces during measurement and light machining, providing a secure and reproducible datum for gauges and measuring fixtures. Robust paired-prism support Includes clamping strap for fixation Compact 100 x 50 mm base footprint Engineered for repeatable accuracy Built for precision, the paired prisms deliver a stable reference when checking round or cylindrical components on inspection benches. The mass and geometry minimise micro-movement, improving repeatability of tactile and optical measurements. With a substantial resting weight of 5.9 kg, the unit resists vibration and offers a reliable platform for comparative gauging and fixture setup, reducing rework and inspection time. Small footprint, big workshop advantages The compact 100 x 50 mm base allows the support set to be positioned on small tables and inside inspection jigs without consuming valuable bench space. The integrated clamping strap secures the component quickly, eliminating frequent re-adjustments and helping to maintain concentricity during checks. This design supports efficient workflows in busy metrology areas and small production lines where space and time efficiency matter. Practical handling and integration into production Delivered by Vertex, the set adapts easily to inspection routines and assembly stations; the paired supports are suitable for repeat checks and short-run turning operations where consistent axial alignment is required. The straightforward geometry makes the unit easy to pair with dial indicators, micrometers or measuring microscopes, improving throughput without adding complexity. Metav’s role as a quality filter for the European market ensures consistent supply and traceable provenance for precision tools. Discuss supply and technical compatibility with Metav Werkzeuge in Emmerich — contact our specialists at info@metav-werkzeuge.com or +49 2822 7131930 to arrange delivery of the Vertex VBC-196 prism pair from stock Technical Data Article number: VBC-196 GTIN: 4061905085888 Manufacturer: Vertex Facts Weight: 5.9 kg Base: 100 x 50 mm eClass: 21160304 Special features Includes clamping strap Designed for support of cylindrical workpieces Brand: Vertex FAQ What is the base footprint of the prism pair? The base measures 100 x 50 mm, providing a compact footprint for bench and jig use. Does the set include a clamping strap? Yes, the product includes an integrated clamping strap for secure fixation of cylindrical components. How heavy is the support set? The unit weighs 5.9 kg, which helps to damp vibrations and maintain stable support during measurement. Which applications suit this prism pair best? The set is intended for supporting and aligning cylindrical workpieces during inspection, gauging and light machining tasks on inspection benches. What are the ordering identifiers for this product? The item is supplied as Vertex VBC-196, GTIN 4061905085888. Manufacturer: Vertex Machinery Works Co., Ltd.; No. 296, Sec. 1, Feng Shih Road, Fengyuan District, Taichung City 420, Taiwan
100x50x25mm Lamella V-Block Pair, Set of 2 - Vertex
Combining compact dimensions, robust construction and reliable repeatability, this lamellar prism set delivers stable radial clamping for inspection and light machining tasks. Benefit from a compact 100×50×25 mm footprint and a solid 1.3 kg mass for improved stability — order directly via Metav Werkzeuge or consult our specialists for application advice. Lamellar blocks and prisms — compact lamellar prism set by Vertex, 100×50×25 mm Lamellar blocks and prisms designed to provide precise radial support and repeatable clamping for cylindrical components in inspection, measuring and light machining applications Compact 100×50×25 mm footprint Solid 1.3 kg mass for stable clamping Engineered for repeatable radial alignment Stable, precision clamping for small-diameter components The lamellar prism set offers an effective solution when consistent radial positioning is required. The segmented contact surface adapts to cylindrical contours and reduces point loading, resulting in improved repeatability and diminished risk of deformation. With a 100×50×25 mm footprint and a solid 1.3 kg mass, the blocks provide a low centre of gravity that enhances stability during measurement or light machining. For workshops that require dependable fixturing without large fixtures, this configuration supports efficient setup and reliable inspection results. Practical benefits for measurement and light machining workflows These blocks are intended to simplify clamping in routine quality control and finishing operations. The lamellar design minimises workpiece marking and ensures even contact pressure, which is particularly beneficial for delicate or precision-ground shafts. The compact form factor allows integration into existing benches or portable inspection rigs, saving space while maintaining high precision. The design supports quick placement and secure support, reducing non-productive time and helping maintain consistent process quality across batches. Designed for repeatable results and easy integration Manufactured by Vertex and supplied as a matched set, the assembly provides uniform reference points for repeat inspections and short-run production checks. The combination of segmented contact geometry and substantial mass means the components resist lateral movement and vibration during measurement. Where traceability and reproducibility matter, the matched pair supports consistent datum points and simplifies the alignment workflow. The robust approach instils confidence in measurement data and helps to standardise processes across workstations. Contact Metav Werkzeuge for tailored advice on application and delivery from our Emmerich site — our consultants will advise on suitability and lead times for the Vertex lamellar prism set Technical data Article number: VCP-1 GTIN: 4061905086069 Dimensions: 100×50×25 mm Weight: 1.3 kg Set: Yes Core data Footprint: 100×50×25 mm Mass: 1.3 kg Pieces per set: 2 SKU: VCP-1 Special features Type: Lamellar prism Brand: Vertex Intended use: Radial clamping and support of cylindrical workpieces Suitable for inspection and light machining FAQ What is the primary application of these lamellar blocks and prisms? The lamellar blocks and prisms (Vertex lamellar prism, SKU VCP-1) are intended for radial clamping and stable support of cylindrical workpieces during inspection and light machining operations. Are the prisms supplied as a matched pair? Yes, the product is supplied as a set with two matched pieces to ensure consistent datum referencing and repeatable alignment. How do the lamellae improve clamping compared with solid V‑blocks? The segmented lamellar contact adapts to the shaft profile, reducing point loads and workpiece marking while improving repeatability and contact distribution for delicate or precision-ground components. Manufacturer: Vertex Machinery Works Co., Ltd.; No. 296, Sec. 1, Feng Shih Road, Fengyuan District, Taichung City 420, Taiwan
100x90x200mm Adjustable Jaw Chuck, 900 kgf Clamping Force, Includes M12x75L & M12x125L Accessories - Vertex
Take advantage of an adjustable workholding solution that combines a 900 kgf clamping force with a robust 14 kg construction for stable machining and reduced setup time; accessories are included to speed installation. Order the clamping jaws directly via Metav Werkzeuge or ask our consultants if needed. Clamping Jaws FV-450 — adjustable clamping jaws with 900 kgf force (Vertex) The Clamping Jaws FV-450 are an adjustable workholding component designed to secure parts reliably during machining and workshop processes. Adjustable clamping design for precise positioning 900 kgf rated clamping force for secure fixation Accessories included: two M12x75L and two M12x125L Robust 14 kg construction for vibration damping Stable hold for high-precision machining The FV-450 offers a 900 kgf rated clamping force, delivering a consistently secure grip that supports repeatable machining operations. The adjustable design enables fine positional correction without additional fixtures, helping to reduce set-up time and minimise scrapped parts. The relatively heavy, 14 kg body contributes to overall stability by absorbing vibration and improving surface finish during milling or turning. This combination of force and mass is particularly beneficial where consistent fixation is required to maintain tight tolerances. Quick mounting and reduced downtime Integration into existing set-ups is simplified by the supplied fasteners — M12x75L and M12x125L bolts — which allow for immediate assembly into common clamping systems. The packaged hardware removes uncertainty during procurement and shortens the time from receipt to production. The unit's compact footprint, at 100 x 90 x 200 mm, supports use in constrained fixtures while preserving a reliable clamping range. This results in faster changeovers and more predictable production cycles. Built for dependable service and straightforward handling The construction emphasises robustness and user-friendly maintenance; mass and geometry are designed to lower wear on contact faces and prolong service intervals. The declared clamping force describes the maximum holding capacity under correct installation and is a practical measure when comparing workholding components for demanding tasks. Regular inspection of mating surfaces and the supplied mounting bolts keeps performance consistent and ensures the fixture remains a dependable element of production. Suitable for workshop and production environments These jaws are engineered as a versatile workholding solution suitable for general workshop use and industrial production lines where secure fixation is essential. The compact size combined with substantial clamping force makes the component appropriate for a broad range of tasks, from precision finishing to repetitive machining operations. Where fixture space is limited but reliable hold is non-negotiable, the FV-450 provides a balance of stability, ease of integration, and operational reliability. Contact Metav Werkzeuge for specification advice or to arrange supply of the FV-450 and benefit from our Emmerich quality filter and expert consultation Technical data Article number: FV-450 GTIN: 4061905095344 SKU: FV-450 Facts Weight: 14 kg Clamping force: 900 kgf Dimensions: 100 x 90 x 200 mm Special features Adjustable design Accessories included: 2x M12x75L and 2x M12x125L Brand: Vertex FAQ What clamping force is provided and what does it mean for machining? The FV-450 delivers a clamping force of 900 kgf, which indicates the maximum holding capacity when correctly mounted; this level of force supports secure fixation for many milling and turning operations and improves repeatability. Are mounting bolts supplied with the jaws? Yes, the delivery contains the specified fasteners: two M12x75L and two M12x125L, permitting immediate installation into compatible fixtures. What are the physical dimensions and weight of the unit? The component measures 100 x 90 x 200 mm and weighs 14 kg, a combination that aids stability and vibration damping during machining. Is the FV-450 suitable for small fixtures or compact machines? The compact footprint combined with a high clamping force makes the FV-450 appropriate for constrained fixtures where a secure hold is required without a large baseplate. Which brand manufactures this workholding component? This product is supplied by Vertex and sold via Metav Werkzeuge as a robust, workshop-ready clamping solution. Manufacturer: Vertex Machinery Works Co., Ltd.; No. 296, Sec. 1, Feng Shih Road, Fengyuan District, Taichung City 420, Taiwan
100° Vertical Clamp 130mm Arm, 2,000N Thrust, 6,000N Holding Force, Massive Arm & Safety Lock - Kukamet
Take advantage of the combination of robust clamping mechanics, a massive holding arm and a compact 130 mm reach to secure small to medium workpieces reliably. Order the vertical clamp directly via Metav Werkzeuge or consult our advisors for application-specific guidance. Vertical clamp 241 — vertical lever clamp with 130 mm arm and 6,000 N holding force (Kukamet) The Vertical clamp 241 is a vertical lever clamp designed for secure workholding in machining, assembly and fixture applications where repeatable clamping and quick operation are required. Massive holding arm and safety lock 130 mm lever arm for extended reach Horizontal-foot mounting for stable installation Holding force 6,000 N; actuation force 2,000 N Predictable clamping performance for reliable production The vertical lever design delivers consistent clamping with defined opening and closing movement that reduces setup time in series work. The combination of an engineered lever mechanism and a massive holding arm ensures a high safety margin for fixture tasks; holding force and actuation force specifications are clearly defined to support process planning. The robust kinematics of the clamp make it suitable for repetitive cycles, allowing a steady production rhythm and minimising rework caused by shifting workpieces. Simple installation that matches existing jigs and fixtures Engineered for workshop compatibility, the clamp features a horizontal-foot mounting which permits direct bolting to plates or subframes used in machining fixtures and jigs. The 130 mm lever arm provides extended reach while keeping the overall footprint compact, enabling use in constrained setups. The nominal angle of 100° indicates the operating travel and helps when aligning fixtures; this information aids in evaluating clearance and interaction with other tooling components. Built to endure daily workshop use Constructed with a durable blackened finish, the clamp resists wear in standard workshop environments and preserves precise motion over time. The integrated safety lock secures the lever in the clamped position, reducing the risk of accidental release during handling or transport of assemblies. With a product mass of 2.402 kg the unit balances rigidity with manageable weight for fixture assemblies and transport between workstations. The mechanical simplicity supports maintenance and long service intervals, providing a dependable workholding solution. Contact Metav Werkzeuge for fitting advice or to request a quotation for the Kukamet Vertical clamp 241 and ensure the selected clamp meets specific fixture requirements. Technical data SKU: 241-6-D-L-C2 GTIN: 8682843520710 Brand: Kukamet Facts Arm length: 130 mm Angle: 100° Actuation force (max): 2,000 N Holding force (max): 6,000 N Weight: 2.402 kg Special features Vertical lever clamp type Horizontal-foot mounting Massive holding arm and safety lock Blackened finish FAQ How much clamping force does the vertical clamp provide? The Vertical clamp 241 offers a maximum holding force of 6,000 N with an actuation force of 2,000 N, suitable for a wide range of fixture tasks. Is the clamp suitable for bolting directly to a fixture plate? Yes, the clamp’s horizontal-foot mounting allows direct bolting to plate-mounted jigs and subframes commonly used in machining fixtures. What is the effective reach of the lever arm? The lever provides a 130 mm arm length, giving extended reach for workpieces while keeping the unit compact for dense fixture arrangements. Does the clamp include a locking device for transport or handling? The unit features an integrated safety lock that secures the lever in the clamped position to prevent accidental release. What finish and durability can be expected in workshop environments? The clamp is supplied with a blackened finish designed to withstand typical workshop wear and preserve consistent motion over prolonged use. Manufacturer: Kukamet Fevzi Çakmak Mah.10644 Sk. No:61-63 42050 Karatay / KONYA TÜRKİYE / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; Germany; +49 2822 7131930; eMail: info@metav-werkzeuge.com
100° Vertical Clamp 2000 N Actuation, Three-Point Massive Arm Safety Lock, Black Oxide Finish - Kukamet
Take advantage of the combination of high holding force, a compact 130 mm arm and a secure safety lock for reliable, repeatable workholding. Order the vertical clamp directly via Metav Werkzeuge or consult our specialists for application advice. 242 Vertical clamp (Kukamet) — 130 mm arm, 6,000 N holding force 242 Vertical clamp is a vertical toggle clamp designed for secure workholding in metalworking, fabrication and general workshop fixtures, offering high holding force and robust construction for demanding production tasks. Massive holding arm with safety lock 6,000 N maximum holding force 130 mm robust clamping arm Blackened finish for corrosion resistance Secure workholding for demanding operations The vertical toggle clamp provides 6,000 N holding force paired with a 2,000 N clamping force, delivering stable retention even under heavy machining or pressing operations. The solid holding arm and integrated safety lock reduce the risk of accidental release during secondary operations, supporting continuous production runs with fewer interruptions. The clamp’s vertical mounting foot allows straightforward integration into jigs and fixtures, while the 100° opening angle offers working clearance that balances access with secure engagement. Compact design that saves space without sacrificing strength With a 130 mm arm and a compact footprint, the unit occupies little bench or fixture space while still providing substantial mechanical advantage. The clamp’s overall mass and blackened finish contribute to durability and resistance to everyday workshop wear. At approximately 2.402 kg, the device is easy to position during assembly of fixturing systems yet heavy enough to remain stable once mounted. The combination of compact dimensions and high holding values supports denser tooling layouts and efficient shop-floor use. Robust construction that supports consistency and safety Machined components and a massive holding arm ensure long-term dimensional stability and repeatable clamping behaviour, which reduces rework and saves setup time. The safety locking mechanism keeps the clamping element secured when engaged, offering an added layer of process safety for manual and semi-automated workflows. These design features make the clamp suitable for repeated cycles in production environments where consistency and operator confidence are essential. Choose the Kukamet 242 vertical clamp for dependable high-force workholding and contact Metav Werkzeuge for tailored ordering information and application guidance. Technical data SKU: 242-6-D-L-C2 GTIN: 8682843520888 Article number: 242 Manufacturer: Kukamet Weight: 2.402 kg Core data Arm length: 130 mm Maximum holding force: 6,000 N Maximum clamping/pressing force: 2,000 N Opening angle: 100° Mounting type: vertical foot Finish: blackened Features & materials Massive holding arm Safety locking mechanism Robust construction for fixture integration Suitable for industrial workshop use FAQ What is the maximum holding force of the clamp? The Kukamet 242 vertical clamp provides a maximum holding force of 6,000 N, with a separate clamping/pressing capacity of 2,000 N for securing workpieces. How is the clamp mounted to a fixture? Mounting is via a vertical foot, allowing the unit to be bolted directly to jigs, base plates or bench fixtures for stable integration. Is the clamp suitable for repeated production cycles? Yes, the 242 is designed with a massive holding arm and robust construction to ensure repeatable clamping behaviour across many cycles. What finish does the clamp have and why does it matter? The clamp has a blackened finish, which improves surface resistance to corrosion and reduces visible wear in workshop environments. What are the physical dimensions and weight to consider for fixture design? The clamping arm is 130 mm long and the unit weighs approximately 2.402 kg, values useful for planning fixture layout and load-bearing capacity. Manufacturer: Kukamet Fevzi Çakmak Mah.10644 Sk. No:61-63 42050 Karatay / KONYA TÜRKİYE / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; +49 2822 7131930; eMail: info@metav-werkzeuge.com
100° Vertical Clamp 86mm Arm Massive Holding Arm With Safety Lock, 2000N Closing Force 6000N Holding Force - Kukamet
Take advantage of the combination of a massive holding arm, 6,000 N holding force and a secure safety lock to keep workpieces immobile during machining; order the clamp directly via Metav Werkzeuge or ask the consultants for application advice. Vertikalspanner 242 – vertical clamp with 6,000 N holding force and safety lock (Kukamet) The Vertikalspanner 242 is a heavy-duty vertical clamp designed for precise workholding in machining and assembly tasks. Massive holding arm and safety lock 6,000 N holding force for secure retention 86 mm arm length for compact applications Vertical-foot mounting for stable set-up Secure high-force retention minimises rework and cycle time This vertical workholding solution delivers a clear technical advantage: a holding force of 6,000 N combined with a clamping force of 2,000 N, which separates the functions of retention and operative clamping. The distinction matters in production: the higher holding force keeps the component stationary during secondary operations, while the clamping force provides reliable actuation during the clamp cycle. Built around a massive holding arm and a proven locking mechanism, the unit reduces vibration and movement that cause rejects, improving process reliability and repeatability. Stable positioning and compact footprint for dense fixturing The clamping element is fitted to a vertical foot for straight-down mounting and an 86 mm arm that balances reach with a small footprint. A 100° working angle gives versatile clamp travel while the assembly weight of 2.278 kg provides stability without unnecessary mass. The compact dimensions make the clamp suitable for tightly packed fixtures and multi-station jigs, enabling efficient use of table space and simpler tooling layouts. The blackened finish resists corrosion in everyday workshop conditions and keeps visual contrast low for inspection. Enhanced safety and workshop productivity through robust design A positive safety lock prevents unintentional release, supporting safe operator routines and machine cycles. The robust build and mechanical simplicity reduce maintenance requirements and downtime compared with more complex hydraulic or pneumatic alternatives. Manufactured for repetitive industrial use, this clamp is appropriate for machining, assembly and general fixture work where reliable retention and quick manual or lever actuation are required. The design choices embedded in the clamp translate to fewer stoppages, faster set-ups and a steadier production flow. Secure the Kukamet Vertikalspanner 242 via Metav Werkzeuge for dependable, workshop-ready clamping; contact Metav Werkzeuge in Emmerich for specification support at info@metav-werkzeuge.com or by phone on +49 2822 7131930 Technical data Article number: 242-6-D-L-C1 GTIN: 8682843520871 Manufacturer: Kukamet Facts Weight: 2.278 kg Arm length: 86 mm Working angle: 100° Max clamping force: 2,000 N Max holding force: 6,000 N ECLASS: 21041717 ETIM: EC011973 Special features Mounting: vertical foot Material/finish: blackened finish Massiver Haltearm (massive holding arm) Safety lock included Category: clamp / spanner FAQ What forces does the clamp provide? The Vertikalspanner 242 offers a maximum holding force of 6,000 N and a clamping force of 2,000 N, enabling secure retention and effective clamping in one unit. How is the clamp mounted to a fixture? The unit is designed for vertical-foot mounting, allowing direct downward attachment to plates or fixture bases for compact, stable installation. Is the clamp suitable for dense fixture layouts? Yes; the 86 mm arm length and compact design make the clamp suitable for tight fixturing where space optimisation is required. Does the clamp include a safety mechanism? A positive safety lock is integrated to prevent accidental release and to support safe operation during machining cycles. Which environments is the finish suitable for? The blackened finish provides routine protection in workshop environments and reduces glare during inspection processes. Manufacturer: Kukamet Fevzi Çakmak Mah.10644 Sk. No:61-63 42050 Karatay / KONYA TÜRKİYE / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; +49 2822 7131930; eMail: info@metav-werkzeuge.com
100° Vertical Clamp Horizontal Base, Safety Lock, 7,000 N Thrust, Black Oxide - Kukamet
Take advantage of the combination of compact design, 7,000 N clamping force and an integrated safety lock for secure, repeatable fixture work; order the clamp directly via Metav Werkzeuge or consult our specialists for integration support. 221 Vertical Clamp by Kukamet — 7,000 N clamping force, safety lock The 221 Vertical Clamp is a compact lever clamp intended for secure vertical clamping in workshop fixtures and production jigs, featuring a horizontal-foot mounting for stable installation. 7,000 N clamping force Integrated safety lock Horizontal-foot mounting Blackened finish Reliable clamping where repeatability matters The 221 combines a robust clamping capacity with a compact footprint, delivering a maximum clamping force of 7,000 N in a light construction of 1.07 kg. This makes the device suitable for tight fixture arrangements where powerful, repeatable clamping is required without adding bulk. The mechanical actuation is designed to produce a consistent clamping result with each cycle, supporting efficiency and reducing time spent on re‑adjustment during serial production. Easy installation and space-saving integration A horizontal-foot mounting provides a straightforward means of attaching the clamp to tooling plates, jigs or machine tables. The fixed mounting angle of 100° offers a defined kinematic position, enabling predictable part loading and simple alignment in assembly fixtures. Because the clamp is compact and light, it can be integrated into existing setups with minimal modification, helping to shorten setup times and maintain production flow. Built-in safety and durable surface treatment The clamp is delivered with a safety lock that secures the clamping arm in the closed position, preventing accidental release under vibration or handling. The external surface is finished in a blackened finish, a wear‑resistant treatment that reduces surface reflections and contributes to long service life under workshop conditions. Routine maintenance is uncomplicated thanks to the straightforward mechanical design, which supports dependable operation across many cycles. Practical fit for workshop and production use Designed as a lever clamp for fixtures and jigs, this model is suitable for machine shops, assembly lines and toolrooms that require fast, repeatable part securing. The combination of compact dimensions, reliable locking and a defined mounting interface reduces assembly complexity and supports consistent cycle times, which in turn contributes to measurable process stability on the shop floor. Contact Metav Werkzeuge to discuss how the Kukamet 221 vertical clamp can be integrated into existing fixtures, request detailed drawings, or obtain a tailored quotation from our Emmerich team Technical data SKU: 221-4-L GTIN: 8682843520406 Manufacturer: Kukamet Key figures Max. clamping force: 7,000 N Weight: 1.07 kg Clamping angle: 100° eClass: 21041717 ETIM: EC011973 Features & materials Horizontal-foot mounting With safety lock Blackened finish Lever clamp type FAQ What maximum force does the clamp provide? The 221 vertical clamp delivers a maximum clamping force of 7,000 N for secure holding in fixtures. How is the clamp attached to a fixture? Attachment is by a horizontal-foot mounting that provides a stable, fixed interface for jig plates and tooling. Does the clamp include a safety device? Yes — the clamp is equipped with an integrated safety lock to prevent unintentional opening during operation. What is the weight and handling advantage of this clamp? Weighing 1.07 kg, the unit is lightweight yet robust, enabling easy integration into compact fixture designs without adding unnecessary mass. Is the surface finish suitable for workshop use? The clamp’s blackened finish is a durable surface treatment intended for daily workshop conditions and long service life. Manufacturer: Kukamet Fevzi Çakmak Mah.10644 Sk. No:61-63 42050 Karatay / KONYA TÜRKİYE / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; +49 2822 7131930; eMail: info@metav-werkzeuge.com
100° Vertical Clamp Three-Point With Safety Lock, Black Oxide 11,000 N - Kukamet
Combine high clamping power with a compact vertical design and an integrated safety locking mechanism for dependable workholding in fixtures and jigs. Order the vertical clamp directly via Metav Werkzeuge or consult the Metav team for selection and supply. 222-6-L Vertical toggle clamp — Vertical clamp with 11,000 N clamping force by Kukamet The 222-6-L is a vertical toggle clamp engineered for secure, repeatable workholding in industrial jigs and fixtures. 11,000 N clamping force Integrated safety locking mechanism Upright base for vertical mounting Blackened finish for surface protection Reliable high-force clamping for repeatable production The 11,000 N specification denotes a robust clamping force suitable for demanding assembly, welding and machining tasks where fixed, vibration-resistant workholding is required. The lever-actuated toggle mechanism converts operator input into a firm, locked position that maintains pressure without continuous manual effort. The built-in safety locking prevents accidental release during handling or machining, supporting consistent cycle times and reducing rework. For installers and shop managers, the advantage is clear: stable fixation that minimises part movement and improves tolerances. Compact vertical mounting that saves bench space Designed with an upright base, the clamp is intended for vertical installation on fixture plates and tooling blocks where horizontal footprint is limited. The unit’s 100° pivot provides a wide open position for easy loading and closes to a secure locked stance for processing. At approximately 2.025 kg, the assembly balances solidity with manageable mass for fixture integration. These attributes simplify retrofitting into existing work-holding setups and allow dense packing of clamps on small fixtures without compromising accessibility. Durable finish and straightforward integration into fixtures The component’s blackened finish provides surface protection against wear and mild corrosion, extending service life in workshop environments. The clamp is supplied with a vertical foot for secure mounting and a lever-style actuator that links directly into standard jigs. Installation requires common fasteners and basic alignment; once mounted, the toggle action delivers repeatable engagement and a tactile locked position. For operations seeking dependable, low-maintenance clamping, this configuration offers a pragmatic balance of robustness and simplicity. For secure, high-force clamping from Kukamet, specify the 222-6-L when contacting Metav Werkzeuge; Metav Werkzeuge in Emmerich can provide advice, product availability and fast supply — email info@metav-werkzeuge.com or call +49 2822 7131930 for tailored assistance. Technical data SKU: 222-6-L GTIN: 8682843520536 Brand: Kukamet eClass: 21041717 ETIM: EC011973 Facts Maximum clamping force: 11,000 N Weight: 2.025 kg Pivot/angle: 100° Special features Vertical mounting with upright base Safety locking mechanism integrated Blackened finish Lever-operated toggle clamp Suitable for jigs and fixtures FAQ What maximum force does the clamp deliver? The clamp provides a maximum clamping force of 11,000 N, enabling firm fixation for assembly and machining operations with the 222-6-L vertical toggle clamp from Kukamet. Is the clamp suitable for vertical fixture mounting? Yes. The design features an upright base specifically for vertical mounting, making it appropriate for compact jigs and stacked fixture plates. Does the clamp include a safety mechanism to prevent accidental opening? A safety locking mechanism is integrated, which secures the clamp in the closed position and reduces the risk of unintended release during processing. What surface protection does the clamp have? The component is supplied with a blackened finish that offers wear resistance and basic corrosion protection suitable for typical workshop conditions. How heavy is the unit and how does that affect installation? The clamp weighs approximately 2.025 kg, giving it the mass required for stable workholding while remaining simple to mount into tooling plates and fixtures. Manufacturer: Kukamet Fevzi Çakmak Mah.10644 Sk. No:61-63 42050 Karatay / KONYA TÜRKİYE / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; Germany; +49 2822 7131930; eMail: info@metav-werkzeuge.com
100° Vertical Clamp With 118mm Arm, Massive Holding Arm And Safety Lock, 1500N Closing Force – Kukamet
Take advantage of the massive holding arm and safety locking mechanism together with a compact 118 mm reach to secure workpieces reliably under repeat production conditions; order supply and technical advice directly via Metav Werkzeuge for uninterrupted workshop use. Vertikalspanner 241 — Vertical clamp with 5,000 N holding force and horizontal foot (Kukamet) The Vertikalspanner 241 is a vertical clamp designed for secure workpiece fixation in workshop and industrial clamping systems, offering a compact footprint and robust mechanical locking for repetitive processes. Massive holding arm for stable fixation Safety locking mechanism for repeatable clamps 5,000 N holding force for heavy-duty use Secure clamping that reduces rework and downtime The Vertikalspanner 241 combines a massive holding arm with a rated holding force of 5,000 N and a clamping force of 1,500 N, delivering measurable stability for demanding jobs. The high holding force minimises micro-movement during machining or assembly, which reduces rework and improves first-pass quality. For production planners this means fewer interruptions and more consistent cycle times; the device converts mechanical specification into tangible operational reliability. Safer, faster cycles through mechanical locking A dedicated safety locking mechanism ensures the clamped position remains fixed until intentionally released, supporting repeatable operation and reducing the risk of accidental release during handling. The clamp is supplied with a horizontal foot for straightforward mounting to fixtures or machine tables, and the 100° operating angle gives a clear actuation path. These mechanical design choices favour predictable behaviour in jigs and fixtures and make integration into existing setups straightforward. Compact dimensions for flexible integration With an arm length of 118 mm and a weight of approximately 1.362 kg, the device offers a compact solution where space is restricted without compromising strength. The blackened surface finish provides a matt, corrosion-resistant appearance that is easy to maintain under workshop conditions. The short reach and moderate mass simplify retrofitting to conveyors, assembly stations or dedicated clamping plates while preserving the high clamping and holding performance required in repetitive manufacturing. For dependable clamping in series production, specify the Kukamet Vertikalspanner 241 via Metav Werkzeuge and request supply or integration advice at info@metav-werkzeuge.com or by phone on +49 2822 7131930 Technical Data SKU: 241-4-D-L-C2 GTIN: 8682843520642 eClass: 21041717 ETIM: EC011973 Facts Arm length: 118 mm Clamping force, max: 1,500 N Holding force, max: 5,000 N Angle: 100° Weight: 1.362 kg Special features Horizontal foot mounting Massive holding arm Safety locking mechanism Material finish: blackened Category: Spanner FAQ What holding and clamping forces does the device provide? The Vertikalspanner 241 offers a holding force of 5,000 N and a clamping force of 1,500 N, making it suitable for robust fixture applications where secure retention is essential. Can the clamp be mounted to existing fixture plates? Yes, the unit is designed with a horizontal foot for direct mounting to fixture plates or machine tables, enabling simple integration into existing clamping solutions. Is a safety lock included and how does it help? The clamp features a safety locking mechanism that secures the clamped position until intentionally released, improving repeatability and reducing the risk of unintended opening during handling. What are the dimensions relevant for layout planning? Key dimensions are an arm length of 118 mm and an overall weight of about 1.362 kg; these figures help assess available space and load capacity for retrofitting. What surface finish and material appearance should be expected? The device is supplied with a blackened finish that provides a matt, workshop-suitable surface with improved resistance to corrosion and wear over plain steel. Manufacturer: Kukamet Fevzi Çakmak Mah.10644 Sk. No:61-63 42050 Karatay / KONYA TÜRKİYE / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; +49 2822 7131930; eMail: info@metav-werkzeuge.com
100° Vertical Clamp With 1500 N Thrust, Massive Holding Arm & Safety Lock, Blackened - Kukamet
Robust vertical clamping with a solid holding arm, integrated safety lock and clear force ratings ensures reliable fixture performance; benefit from precise, repeatable operation and durable blackened finish. Order the Kukamet 242 vertical toggle clamp directly via Metav Werkzeuge or consult our specialists if technical advice is required. 242 Vertical Toggle Clamp (Vertical Mount) — 1,500 N clamping force, solid holding arm — Kukamet The 242 is a vertical toggle clamp intended for secure vertical mounting in jigs and fixtures, combining a long, robust arm with an integrated safety locking mechanism for stable workpiece retention. Solid 168 mm holding arm Integrated safety locking Max clamping force 1,500 N Max holding capacity 5,000 N Consistent clamping performance for serial production The clamp delivers a defined max clamping force of 1,500 N and a holding capacity of 5,000 N, values that support reliable fixation under cyclical loads. Specified force figures allow planners to size fixtures accurately and to predict repeatability across batches. The 100° operating angle stabilises the toggle action, while the substantial arm length contributes to an extended lever for accessible clamping positions. These measurable attributes translate directly into fewer reworks and steadier process control on assembly lines or in machining fixtures. Built for repeatability and operator safety Constructed with a solid holding arm and an integrated safety locking device, the clamp reduces the risk of unintentional release during handling or vibration. The blackened finish offers surface protection and a low-reflective appearance suited to workshop environments. With a mass of approximately 1.456 kg, the component balances robustness and manageable handling during fixture mounting. The combination of mechanical locking and sturdy construction supports long service intervals and dependable performance in repetitive production tasks. Simple vertical mounting and straightforward integration Designed for vertical foot mounting, the unit fits directly onto plates and subframes where vertical actuation is required. The clamp’s geometry and mounting arrangement simplify alignment within jigs, shortening setup time and enabling consistent reference positions. Labelled with SKU 242-4-D-L-C3 for inventory control, the device integrates seamlessly into modular tooling systems and standard fixture plates, allowing planners to harmonise clamping points across multiple workstations without complex adaptations. For specification support or ordering of the Kukamet 242 vertical toggle clamp, contact Metav Werkzeuge in Emmerich for detailed product advice and delivery information: info@metav-werkzeuge.com or +49 2822 7131930 Technical data Article number: 242-4-D-L-C3 GTIN: 8682843523780 Manufacturer: Kukamet Core specifications Arm length: 168 mm Operating angle: 100° Max clamping force: 1,500 N Max holding capacity: 5,000 N Weight: 1.456 kg Special features Finish: blackened Mounting: vertical foot Solid holding arm Safety locking mechanism Model type: vertical toggle clamp FAQ What maximum clamping and holding forces does the clamp provide? The Kukamet 242 vertical toggle clamp offers a maximum clamping force of 1,500 N and a holding capacity of 5,000 N, providing clear parameters for fixture design and load assessment. Is the clamp suitable for vertical mounting in jigs and fixtures? Yes. The device is configured for vertical foot mounting and a 100° operating angle, making it suitable for integration into vertically actuated fixtures. What materials and finish are used? The clamp features a blackened finish, providing surface protection and a subdued appearance appropriate for workshop use. Does the unit include a safety lock for unattended operations? An integrated safety locking mechanism is provided to prevent accidental release during vibration or handling, supporting safer repetitive work cycles. How is the clamp identified for ordering and inventory? The product is listed under SKU 242-4-D-L-C3 and GTIN 8682843523780 for procurement and stock-keeping purposes. Manufacturer: Kukamet Fevzi Çakmak Mah.10644 Sk. No:61-63 42050 Karatay / KONYA TÜRKİYE / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; +49 2822 7131930; eMail: info@metav-werkzeuge.com
100° Vertical Clamp With 5000N Holding Arm, 1500N Thrust, Safety Lock - Kukamet
The combination of a 5,000 N holding arm, a secure safety lock and a compact horizontal mounting makes this vertical clamp a reliable choice for repeatable clamping operations; benefit from consistent workpiece retention and straightforward installation. Order the clamp directly via Metav Werkzeuge or consult our advisers for specification support. Vertikalspanner 222-4-C-L vertical clamp with 5,000 N holding arm — Kukamet The Vertikalspanner 222-4-C-L is a vertical clamp engineered for secure workpiece fixation in machining and assembly settings, offering a high holding capacity and a safety locking mechanism for safe, repeatable operation 5,000 N holding arm force Integrated safety lock Compact 1.31 kg body Horizontal base with 100° angle Reliable retention that reduces rework A solid holding force of 5,000 N gives the clamping device the capacity to keep workpieces secure under lateral and lifting loads, which reduces re-fixturing and scrap. The incorporated safety lock prevents unintentional release during machining cycles, increasing process reliability and operator confidence. For production environments where repeatability matters, the combination of robust retention and a mechanical lock translates into fewer interruptions and more consistent throughput. Space-saving mounting with flexible positioning Designed with a horizontal base, the clamp mounts neatly to fixtures and machine tables, permitting compact integration into existing jigs. The 100° angle offers practical clearance for levers while keeping the footprint small. At only 1.31 kg, the unit is light enough for retrofit installations and for use in modular clamping setups, yet sturdy in function. This makes the device suitable for tight workstations and fixtures where conserving space without compromising clamping performance is essential. Efficient operation and workshop durability The clamp delivers a 1,500 N pressing force, a parameter that describes the actual clamping pressure applied to the workpiece; this value is balanced to provide firm contact without overstressing delicate parts. The lever clamp action gives fast cycle times and ergonomic handling, supporting higher productivity on repetitive tasks. A blackened finish adds basic surface protection against wear and handling marks. The Vertikalspanner 222-4-C-L combines quick operation with long-term consistency, making it a pragmatic choice for assembly, light machining and inspection fixtures Choose Kukamet quality and the 5,000 N holding arm — contact Metav Werkzeuge for specification support and procurement at info@metav-werkzeuge.com or +49 2822 7131930 Technical data SKU: 222-4-C-L GTIN: 8682843520499 eClass: 21041717 ETIM: EC011973 Manufacturer: Kukamet Facts Weight: 1.31 kg Holding force (max): 5,000 N Pressing force (max): 1,500 N Angle: 100° Special features Horizontal base Hold arm with 5,000 N holding force Safety locking mechanism Blackened finish FAQ How is the clamp mounted and aligned? The clamp is fixed via the horizontal base; the compact design enables direct attachment to fixtures and machine tables and alignment is achieved by positioning the base and securing with fixture fasteners. What safety features prevent accidental release? A mechanical safety lock secures the hold arm in the clamped position; this locking function is integral to the design and prevents unintended opening during handling or machining. What do holding force and pressing force mean for application design? Holding force (5,000 N) indicates maximum static retention capacity; pressing force (1,500 N) describes the clamping pressure applied to the workpiece. Use these values when calculating fixture loads and workpiece contact requirements for the Vertikalspanner 222-4-C-L. Is the clamp suitable for retrofitting into existing jigs? Yes. The compact weight (1.31 kg) and horizontal base make the device suitable for retrofit applications and modular fixturing where space and weight considerations are important. What surface protection does the clamp have? The clamp is supplied with a blackened finish, providing resistance to handling wear and a uniform appearance appropriate for workshop use. Manufacturer: Kukamet Fevzi Çakmak Mah.10644 Sk. No:61-63 42050 Karatay / KONYA TÜRKİYE / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; +49 2822 7131930; eMail: info@metav-werkzeuge.com
100° Vertical Clamp With 6000N Holding Arm, 2000N Thrust, Safety Lock - Kukamet
Take advantage of the combination of 6000 N holding arm, 2,000 N clamping force and a compact, horizontal mounting for reliable fixture security in repetitive production. Order the vertical toggle clamp directly via Metav Werkzeuge or ask our consultants if needed. 221-6-C-L Vertical toggle clamp by Kukamet — 6,000 N holding arm and safety lock 221-6-C-L is a vertical toggle clamp designed for fixed‑position fixturing and repetitive assembly tasks, offering firm retention and integrated safety for industrial use. 6000 N holding arm with safety lock 2,000 N clamping force for firm fixation Horizontal base for secure installation Black blued finish, robust corrosion resistance Secure, reproducible clamping for production environments The clamp delivers a consistent clamping force that supports repeatable production results. With a holding arm rated at 6000 N and a defined clamping force of 2,000 N, the device secures workpieces during machining, welding or assembly operations, reducing rework and downtime. The mechanical design converts lever motion into reliable retention, making the component suitable for jigs and fixtures where process stability is essential. The specification supports planners seeking measurable performance and predictable outcomes in small to medium series production. Integrated safety features protect parts and operators A safety lock is fitted to prevent unintended release once the clamp is engaged, which improves operator safety and safeguards delicate components. The clamp’s lever mechanism includes a positive locking position that resists vibration and shock; this is particularly relevant for dynamic shopfloor conditions. The roughly 100° operating angle provides a clear open and closed position, simplifying visual inspection and reducing the likelihood of incorrect engagement during cycle changes. This combination of features enhances process reliability and contributes to a safer working environment. Compact format for flexible bench and fixture mounting Engineered with a horizontal base and a compact footprint, the clamp integrates into fixtures with minimal space demand while maintaining a robust mounting surface. The unit’s black blued finish offers enhanced surface protection and a professional appearance suited to industrial settings. At approximately 2.34 kg, the clamp balances solidity with ease of handling during fixture assembly. Its lever‑style operation facilitates quick manual clamping without additional tooling, enabling rapid set‑up changes and improved workflow efficiency on assembly lines and testing stations. For secure fixturing solutions, contact Metav Werkzeuge to discuss the Kukamet 221-6-C-L vertical toggle clamp and receive tailored advice from our technical team in Emmerich. Technical data SKU: 221-6-C-L GTIN: 8682843520437 Manufacturer: Kukamet Facts Holding force: 6000 N Clamping force (max): 2,000 N Weight: 2.34 kg Operating angle: 100° EClass: 21041717 ETIM: EC011973 Special features Horizontal base (waagerechter Fuß) Black blued finish (Schwarz brüniert) Safety lock fitted (Sicherheitsverriegelung) Lever‑style vertical toggle clamp design Holding arm with 6000 N holding capacity FAQ What clamping and holding forces does this clamp provide? The Kukamet vertical toggle clamp (SKU 221-6-C-L) offers a holding arm capacity of 6000 N and a maximum clamping force of 2,000 N, giving clear numerical guidance for fixture design. Is the clamp suitable for vibration-prone environments? Yes, the clamp’s integrated safety lock and positive lever engagement make the Kukamet 221-6-C-L suitable for applications where vibration or shock could otherwise cause unintended release. How is the clamp mounted to a fixture? The unit is supplied with a horizontal base for secure installation; the compact footprint supports straightforward bolt mounting into jigs and fixture plates. What surface protection does the clamp feature? The clamp is finished in a black blued surface treatment, providing improved resistance to corrosion and a durable industrial appearance. Can the clamp be used for repetitive manual operations? Designed as a lever‑style vertical toggle clamp, the 221-6-C-L is optimised for manual, repetitive clamping tasks in assembly and testing stations and supports quick engagement and release. Manufacturer: Kukamet Fevzi Çakmak Mah.10644 Sk. No:61-63 42050 Karatay / KONYA TÜRKİYE / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; +49 2822 7131930; eMail: info@metav-werkzeuge.com
100° Vertical Clamp With Massive Holding Arm, 1500 N Thrust, 5000 N Hold Force - Kukamet
Take advantage of a compact, high‑force clamping solution that combines a sturdy 168 mm holding arm, a 5,000 N maximum holding capability and a secure safety lock for reliable fixture work. Order the clamp directly via Metav Werkzeuge or request further technical clarification from our consultants for seamless integration into jigs and production setups. Kukamet Vertical Clamp 241 — horizontal base, 168 mm arm, 1,500 N pressing force The 241 vertical clamp is a vertical clamping device intended for fixture and machining tasks where a compact footprint and dependable hold are required. Solid 168 mm holding arm for stable clamping Horizontal base for secure bench mounting 1,500 N pressing force for precise operation Integrated safety lock for operator protection Consistent, measurable clamping performance for production use The vertical clamp delivers quantifiable results: a 5,000 N holding force paired with a 1,500 N pressing force ensures repeatable workholding during machining, assembly and testing sequences. The 168 mm arm provides reach without excessive overhang, enabling secure contact with workpieces while maintaining tool‑clearance. The horizontal base facilitates rigid bench or fixture mounting, reducing vibration and minimising setup variability. These technical characteristics support predictable cycle times and lower scrap rates in series production. Robust engineering that reduces downtime and improves safety Constructed with a black blued finish and a massive holding arm, the mechanism resists wear in routine shop environments and keeps adjustments stable over long runs. The integrated safety lock prevents accidental release during loading and transport, while a 100° opening angle allows fast part insertion and removal on jigged assemblies. At a net weight of 1.456 kg the unit combines solidity with ease of handling for assembly‑line tool changers or manual fixtures, delivering durability without unnecessary bulk. Practical benefits for jigs, fixtures and small production cells The clamp’s compact dimensions and straightforward mounting make it suitable for dedicated jigs, test rigs and machining fixtures where space is at a premium but holding must not be compromised. The clamping device supports consistent positioning and reduced rework, contributing to higher first‑pass yields and lower throughput variability. Technical buyers gain the advantage of a standardised component that integrates into existing setups, simplifying spare‑parts lists and maintenance schedules while enabling stable process control. For reliable, repeatable clamping choose the Kukamet vertical clamp 241 and arrange supply or tailored technical advice via Metav Werkzeuge in Emmerich at info@metav-werkzeuge.com or +49 2822 7131930 Technical data Article number: 241-4-D-L-C3 GTIN: 8680731508994 Brand: Kukamet Model: 241 Facts Arm length: 168 mm Weight: 1.456 kg Pressing force max: 1,500 N Holding force max: 5,000 N Opening angle: 100° Special features Material / finish: black blued finish Mounting: horizontal foot for bench mounting Design: massive holding arm Safety: integrated safety lock FAQ What are the maximum holding and pressing forces? The Kukamet vertical clamp 241 provides a holding force of 5,000 N and a pressing force of 1,500 N, specified for stable fixture retention. How is the clamp mounted in a fixture? Mounting is via a horizontal foot intended for secure bench or jig attachment, facilitating rigid bench mounting and straightforward integration. Which design features enhance operator safety? The 241 features a massive holding arm and an integrated safety lock that prevents unintended release during loading and handling. What size reach does the clamp offer? The clamping arm has a reach of 168 mm, balancing access to the workpiece with compact installation requirements. Is the clamp suitable for production jigs and small series? Yes; the compact footprint, predictable clamping forces and robust finish make the clamp well suited to jigs, fixtures and small production cells where repeatability is essential. Manufacturer: Kukamet Fevzi Çakmak Mah.10644 Sk. No:61-63 42050 Karatay / KONYA TÜRKİYE / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; +49 2822 7131930; eMail: info@metav-werkzeuge.com
Secure components with reliable workpiece clamps
Workpiece clamps, also known as workholding clamps or workholding devices, form the essential mechanical interface between machine and part in industrial fabrication. They keep components absolutely play-free, positionally accurate and vibration-resistant during milling, turning, drilling or grinding.
How workpiece clamps ensure process stability
A correctly specified clamping concept transfers the high cutting and feed forces of modern CNC machines into the machine table or spindle without deforming the part. The right combination of mechanical, hydraulic, pneumatic or magnetic solutions enables fast, repeatable setups and supports automated part change where required. Typical applications range from single-part turning to high-volume series milling and complex five-axis machining.
Concrete production benefits at a glance
- repeatable positioning: reduces scrap and rework
- high clamping forces: withstands aggressive cutting without part movement
- reduced set-up time: modular systems and quick-change features speed throughput
- improved surface finish: vibration damping for finer results and tighter tolerances
- flexible compatibility: vices, chucks, clamping plates and zero-point systems for diverse geometries
Why Metav's range is the practical choice
Metav combines decades of specialist know-how with a broad, handpicked range that democratises precision for workshops and industry alike. Based in Emmerich, Metav acts as a quality filter for the European market and supplies more than 250,000 products from precision metrology to complete workshop equipment. With the trust of over 48,000 customers, Metav offers a single-source approach that reduces supplier complexity and secures dependable delivery to your workbench.
Technical data
- function: mechanical interface between machine and workpiece
- primary requirements: absolute positional accuracy; vibration reduction; high clamping forces
- technologies: mechanical, hydraulic, pneumatic, magnetic
- typical components: machine vices; chucks; clamping plates; zero-point systems; pratzen; clamping jaws
- application areas: milling; turning; drilling; grinding; automated part change systems
- production benefits: reduced set-up time; enhanced process security; optimised series and single-part production
The practical summary
Workpiece clamps bring the stability and repeatability required to meet tight tolerances and excellent surface quality, making them indispensable across machining operations. Choosing the right workholding clamps and modular workholding devices is a decisive step towards higher productivity and consistent part quality.
FAQ
What types of workpiece clamps are suitable for automated machining?
Workholding clamps with quick-change modules, hydraulic actuation or magnetic systems are commonly used for automated machining. These workholding devices enable fast, repeatable part changes and integrate with zero-point systems.
How do workpiece clamps affect surface finish and tolerances?
A stable clamping concept minimises vibration and part movement; this improves surface finish and supports achieving narrow tolerances when using high-precision workpiece clamps or workholding devices.
Can the same workpiece clamps handle different part geometries?
Modular workholding clamps and adaptable clamping jaws allow flexible fixturing for varied geometries; combining vices, clamping plates and pratzen increases versatility on the shopfloor.
