Secure and precise workholding for metalworking productivity
Workholding devices such as workpiece clamps and chuck systems provide absolute positional stability and vibration damping during milling, turning, drilling and grinding, ensuring parts remain free of play under high CNC cutting and feed forces. By transferring clamping loads into the machine table or spindle without deforming the component, a well engineered workholding solution improves machining accuracy, surface finish and process reliability while reducing set-up times. Modular systems from machine vices and chucks to zero-point systems and specialised fixtures enable fast changeovers and support both serial and single-part production, delivering consistent clamping force, repeatability and enhanced throughput.
0-250mm Pneumatic Precision Machine Vice 6000 kgf Clamping Force, Cast Iron, 0.01mm Accuracy - Vertex
Robust pneumatic actuation combined with a 6000 kgf clamping capacity and a stated accuracy of 0.01 provides the stability required for repeatable machining tasks; order the vice directly via Metav Werkzeuge or consult our specialists for application and configuration support. VMC-6PL Pneumatic precision machine vice — 6000 kgf clamping force, 0.01 accuracy (Vertex) The VMC-6PL is a pneumatic precision machine vice engineered for secure, repeatable clamping in CNC machining applications. Precision clamping with 6000 kgf force Pneumatic actuation for fast cycle times Cast-iron body for thermal stability Faster throughput through reliable clamping The pneumatic clamping mechanism delivers consistent closing and opening cycles, which reduces idle time at each station and supports higher production throughput. With a rated 6000 kgf of clamping force, the unit secures workpieces against vibration and tool load, lowering the risk of movement during heavy cuts. Pneumatic actuation also simplifies integration with machining centres, enabling synchronised cycles and retaining setup accuracy between operations. The combination of significant clamping power and rapid actuation supports both short-run changeovers and longer series production. Accuracy and repeatability for tight tolerances Designed for precision work, the vice offers a stated accuracy value of 0.01, which contributes to reproducible fixturing and predictable part quality. Accuracy in this context relates to jaw alignment and the ability to return to the same datum after multiple cycles; the result is fewer inspection failures and less manual rework. For workshops aiming to meet narrow tolerances, the stable holding and consistent repeatability minimise process variation and support higher first-pass yield on critical components. Durable construction for a stable machining base The frame is manufactured from cast iron, selected for its damping properties and thermal stability in a production environment. The mass (approx. 51 kg) and dimensions (160 x 630 x 163 mm) help resist chatter and maintain alignment during heavy-duty milling and drilling. Robust assembly and straightforward pneumatic connections reduce maintenance demands; routine checks of air supply and seals are typically sufficient to keep the unit operating reliably. The solid build and reliable actuation make this vice suitable for industrial workshops and toolrooms seeking a long-lived clamping solution. Contact Metav Werkzeuge for specification advice and fast supply from Emmerich: info@metav-werkzeuge.com | +49 2822 7131930 | WhatsApp +49 170 2837271 Technical Data Article number: VMC-6PL GTIN: 4061905093173 eClass: 21020601 ETIM: EC002173 Facts Clamping force: 6000 kgf Opening range: 0–250 mm Accuracy: 0.01 Weight: 51 kg Dimensions: 160 x 630 x 163 mm Special features Material: Cast iron Actuation: Pneumatic FAQ What applications is this vice best suited for? The VMC-6PL pneumatic precision machine vice is designed for secure clamping in CNC milling and drilling operations where repeatability and high clamping force are required. What are the clamping force and jaw opening of the vice? Clamping force is rated at 6000 kgf and the opening range is 0–250 mm, allowing a wide variety of workpiece sizes to be held reliably. What material is the vice made from and how heavy is it? The vice is manufactured from cast iron and weighs approximately 51 kg, offering thermal stability and vibration damping for machining tasks. How should the specified accuracy of 0.01 be interpreted? An accuracy of 0.01 refers to the vice’s ability to position and return the jaws consistently, supporting tight tolerances and repeatable fixturing in production processes. Which classification codes identify this product for inventory systems? The unit is listed under eClass 21020601 and ETIM EC002173 and is supplied with GTIN 4061905093173 Manufacturer: Vertex Machinery Works Co., Ltd.; No. 296, Sec. 1, Feng Shih Road, Fengyuan District, Taichung City 420, Taiwan
0-275mm Machine Vice 3,000kgf Clamping Force, 0.01mm Accuracy, Mechanical - Vertex
Take advantage of the combination of high clamping force, precise 0.01 mm repeatability and a compact footprint for reliable machining results; order the unit directly via Metav Werkzeuge or consult Metav’s specialists for application advice. VD-810 Machine Vice by Vertex — 3000 kgf clamping force, 0.01 mm accuracy The VD-810 machine vice is a mechanical clamping unit for demanding machining tasks, offering high clamping force and fine positional accuracy in a compact format. High 3000 kgf clamping force Precise 0.01 mm repeatability Wide 0–275 mm jaw opening Robust 76 kg construction Secure clamping and measurable precision for repeatable results The vice delivers a 3000 kgf clamping force that secures workpieces during milling, drilling and finishing operations, while the 0.01 mm stated accuracy supports tight tolerances and consistent reproducibility. In practice, this level of precision reduces rework and inspection time, since the device maintains jaw alignment and contact under load. The mechanical design focuses on stable force transmission and low backlash, which translates into reliable positioning when working on medium- to heavy-duty components. Fast setup and adaptability that keep production moving With a jaw opening range of 0–275 mm, the clamping unit covers a broad spectrum of component sizes without frequent changeovers. The relatively compact footprint of 615 x 378 x 191 mm and a mass of 76 kg provide a low centre of gravity and resistance to movement during cutting, improving operator confidence and cycle-time stability. Quick mounting to the machine table and straightforward mechanical operation mean less downtime between jobs and easier integration into milling or drilling workflows. Built for workshop endurance and predictable maintenance The vice’s substantial mass and mechanical construction are designed for long service life under continuous use; the heavy build dampens vibration and protects alignment. Routine maintenance is confined to lubrication and inspection of wear components, so planned servicing is simple and cost-effective. The unit’s clear specifications and rugged build support predictable performance across production runs, helping workshops maintain throughput and reduce unexpected stoppages. Contact Metav Werkzeuge in Emmerich to specify the Vertex VD-810 for demanding clamping tasks and benefit from their European quality filter and procurement support Technical data Article number: VD-810 GTIN: 4061905091704 Manufacturer: Vertex Core technical data Clamping force: 3000 kgf Jaw opening: 0–275 mm Accuracy: 0.01 mm Weight: 76 kg Dimensions: 615 x 378 x 191 mm Special features Type: Mechanical eClass: 21020601 ETIM: EC002173 SKU: VD-810 FAQ What clamping force does the vice deliver? The vice provides a clamping force of 3000 kgf, suitable for secure holding during medium- to heavy-duty machining. What is the achievable accuracy and repeatability? Repeatability is specified at 0.01 mm, enabling consistent positioning for precision machining tasks with the Vertex VD-810 machine vice. Which jaw opening ranges are supported? The vice covers a jaw opening from 0–275 mm, accommodating a wide variety of workpiece sizes without additional adapters. Is the vice suitable for integration on standard milling machines? Yes. The mechanical design and footprint are intended for mounting on conventional milling and drilling tables where a heavy, vibration-resistant clamping solution is required. How heavy is the unit and what does that mean for stability? At 76 kg, the mass contributes to stability and reduced vibration during cutting, which helps maintain machining accuracy. Manufacturer: Vertex Machinery Works Co., Ltd.; No. 296, Sec. 1, Feng Shih Road, Fengyuan District, Taichung City 420, Taiwan
0-275mm Machine Vice Large Opening, 60 kN Clamping Force, Cast Iron, 0.01mm Accuracy - Vertex
Benefit from the combination of 60 kN clamping force, a wide 0–275 mm opening and a robust cast‑iron construction for secure, repeatable machining; order the VQC-160 machine vice directly via Metav Werkzeuge or consult the advisers for tailored guidance. VQC-160 Machine vice — 60 kN clamping force, 0–275 mm opening (Vertex) A VQC-160 mechanical machine vice designed for heavy‑duty clamping in milling and machining applications, with a large adjustable opening for versatile setups 60 kN clamping force 0–275 mm adjustable opening Cast‑iron construction High precision 0.01 mm Secure hold that reduces rework and boosts throughput The vice delivers a 60 kN clamping force in a compact footprint, enabling stable fixation of workpieces under machining loads. The cast‑iron body dampens vibration, which helps to protect cutting tools and reduces the risk of chatter marks; this stability translates into fewer rejects and a more consistent surface finish. Designed for production environments, the clamping capability supports efficient material removal rates and a measurable reduction in cycle interruptions. Faster setup and greater process flexibility A wide 0–275 mm opening accommodates a broad range of workpiece sizes, minimising the need for intermediate fixtures and cut‑over time between batches. The mechanical design is offered with an optional hydraulic actuation for operations that demand faster clamping cycles and repeatable clamp pressure. This flexibility makes the vice suitable for different machining tasks while streamlining the workplace layout and setup procedures for higher overall equipment effectiveness. Accuracy and mass stabilise precision machining With a rated 0.01 mm accuracy, the vice provides repeatable positioning that supports tight tolerances and reduces inspection intervals. The substantial mass of 67 kg and the specified dimensions (170 x 554 x 165 mm) combine to create a stable platform that resists movement under load, improving tool life and process reliability. The mechanical construction is engineered to deliver consistent clamping behaviour over long production runs, supporting predictable quality outcomes. For specification advice or to secure a VQC-160 for workshop production, contact Metav Werkzeuge in Emmerich at info@metav-werkzeuge.com or +49 2822 7131930 — the advisers will assist with selection and delivery arrangements Technical data SKU: VQC-160 GTIN: 4061905087875 eClass: 21020601 ETIM: EC002173 Manufacturer: Vertex Facts Clamping force: 60 kN Opening range: 0–275 mm Accuracy: 0.01 mm Weight: 67 kg Dimensions: 170 x 554 x 165 mm Special features Cast iron construction Mechanical design; optional hydraulic actuation Large opening for versatile workpieces FAQ What clamping force does the vice provide? The VQC-160 machine vice provides a clamping force of 60 kN, offering secure fixation for heavy machining operations. What is the opening range of the vice? The opening range is 0–275 mm, allowing accommodation of a wide variety of workpiece sizes without additional fixtures. Is a hydraulic version available? An optional hydraulic actuation is available for the mechanical design to enable faster clamping cycles where required. How accurate is the vice and how does that affect production? The vice is specified to 0.01 mm accuracy; this level of repeatability supports tight tolerances and helps to reduce inspection and rework time in serial production. What material is the vice made from and why does that matter? The vice is constructed from cast iron, which provides mass and vibration damping to improve stability and surface quality during machining. Manufacturer: Vertex Machinery Works Co., Ltd.; No. 296, Sec. 1, Feng Shih Road, Fengyuan District, Taichung City 420, Taiwan
0-280mm Precision Machine Vice Hydraulic/Mechanical 6000kgf Clamping Force Cast Iron 87kg - Vertex
VMC-200HV delivers a compact, force-enhanced clamping solution with 6000 kgf holding power and a wide 0–280 mm jaw opening; ideal for reducing setup time and securing heavy workpieces. Choose precise, robust machining with reliable repeatability and order via Metav Werkzeuge or consult Metav’s specialists for application advice. VMC-200HV Precision Machine Vice — mechanical and hydraulic, 6000 kgf clamping force (Vertex) The VMC-200HV is a compact, force-enhanced precision machine vice designed for secure clamping on milling machines and machining centres, combining mechanical reliability with hydraulic assistance for repeatable setups 6000 kgf clamping force 0–280 mm jaw opening Cast iron body for rigidity 0.01 mm positional accuracy Heavy clamping power for stable machining The primary advantage of this vice is its high clamping capacity: 6000 kgf ensures workpieces remain immobile under heavy cutter loads, which directly reduces vibration and rework. Built with a substantial mass and a cast iron body, the device stabilises the machining process; heavier construction converts into less deflection and improved surface finish. For production environments where cycle time and part consistency matter, this clamping solution delivers measurable improvements in throughput and first-pass yield. Precision that supports tight tolerances Accuracy is a core specification: with 0.01 mm positional fidelity, the vice supports precision machining tasks that demand close tolerances. This figure refers to repeatability of the clamped position rather than cutter accuracy and should be interpreted as the vice’s contribution to overall process precision. The combination of mechanical guides and controlled hydraulic assistance keeps jaw movement consistent, helping to simplify setup and minimise manual adjustment when changing workpieces. Designed for practical integration in machine shops Dimensions of 200 x 700 x 170 mm make the unit compact enough for bench or machine-table mounting while its jaw capacity of 0–280 mm covers a broad range of workpiece sizes. The hybrid mechanical and hydraulic operation provides both robust manual control and the option for hydraulic actuation where quicker clamping cycles or remote operation are required. Identification details such as the SKU and GTIN allow straightforward procurement and inventory tracking for production planners and purchasing departments. Durability, handling and maintenance considerations Constructed from cast iron and weighing 87 kg, the vice offers long-term stability and wear resistance; mass contributes to vibration damping and dimensional stability during prolonged operation. Routine maintenance focuses on lubricant points and periodic inspection of hydraulic seals where fitted, ensuring sustained clamping performance. Installation and handling are straightforward but require suitable lifting or positioning equipment because of the unit’s weight; correct mounting maximises the vice’s life and preserves the declared 0.01 mm repeatability. Contact Metav Werkzeuge for tailored advice on integrating the VMC-200HV into production workflows and benefit from direct supply from our Emmerich facility — email info@metav-werkzeuge.com or call +49 2822 7131930 Technical data SKU: VMC-200HV GTIN: 4061905092466 Brand: Vertex Dimensions: 200 x 700 x 170 mm Weight: 87 kg Clamping force: 6000 kgf Jaw opening: 0–280 mm Repeatability / accuracy: 0.01 mm Material: Cast iron Operation: Mechanical and hydraulic EClass: 21020601 ETIM: EC002173 FAQ What clamping force does the VMC-200HV provide? The VMC-200HV offers a clamping force of 6000 kgf, suitable for heavy-duty milling and secure fixturing. What jaw opening range is available for this vice? The vice supports a jaw opening from 0 to 280 mm, enabling clamping of a wide variety of component sizes. Is the VMC-200HV suitable for mounting on machining centres? Yes, the VMC-200HV is designed for machine-table mounting on milling machines and machining centres, offering stable clamping under cutter loads. How precise is the vice for repeatable production tasks? The device provides a positional repeatability of 0.01 mm, contributing to consistent part quality across production runs. What material is the vice made from and why does that matter? The VMC-200HV is made from cast iron, which enhances rigidity, reduces vibration and improves surface finish during machining. Manufacturer: Vertex Machinery Works Co., Ltd.; No. 296, Sec. 1, Feng Shih Road, Fengyuan District, Taichung City 420, Taiwan
0-280mm Precision Machine Vice, Force-Boosted Compact Mechanical/Hydraulic, 3000 kgf, Cast Iron - Vertex
Take advantage of 3,000 kgf clamping power combined with accuracy 0.01 mm and a compact 0–280 mm jaw opening for reliable, repeatable machining; order the vice directly via Metav Werkzeuge or contact our consultants for application advice. VMC-200M Precision Machine Vice — 3,000 kgf Clamping, 0–280 mm Opening (Vertex) The VMC-200M is a power-enhanced, compact precision machine vice designed for use in milling centres and machine tools where high clamping force and fine positional accuracy are required. High 3,000 kgf clamping force 0–280 mm jaw opening Cast iron body for rigidity Accuracy to 0.01 mm Reliable clamping for consistent machining results The machine vice delivers a 3,000 kgf clamping capacity that stabilises workpieces throughout heavy cuts, reducing vibration and the risk of movement under load. That high clamping force, combined with an accuracy of 0.01 mm, ensures repeatable positioning and minimal rework, which directly supports productivity and quality control in series production. For operators unfamiliar with technical terms: the accuracy figure refers to the vice's ability to maintain the same jaw position within a hundredth of a millimetre after repeated clamps, making it suitable for precision components. Compact footprint that fits production cells With a measured footprint of 200 x 655 x 170 mm and a mass of 86 kg, this vice integrates into machining centres without requiring excessive table space. The compact design retains the necessary mass to absorb cutting forces while allowing flexible placement on the machine table. The reduced footprint helps shops maximise usable table area and arrange multiple fixtures or vices where space is constrained. Durable construction for long service life Constructed from cast iron, the vice body offers inherent damping and structural stability that protect against deformation during heavy-duty work. The combination of robust material and precision manufacturing delivers a service-ready clamping device that withstands the demands of daily shop-floor use. The mechanical and hydraulic operating concept provides options for controlled manual work or power-assisted clamping where consistency and cycle-time improvements matter. Versatility for varied machining tasks A jaw opening of 0–280 mm accommodates a broad range of workpiece sizes, from small precision parts to larger machined components. The vice's design balances strong holding power with precise alignment, allowing effective use in both prototype and production environments. When paired with appropriate fixturing, the vice helps reduce setup time and supports consistent part-to-part results. Contact Metav Werkzeuge to discuss specification details and secure tailored advice for integrating the VMC-200M into existing machining workflows Technical data Article number: VMC-200M GTIN: 4061905095306 Manufacturer: Vertex Core specifications Weight: 86 kg Clamping force: 3,000 kgf Jaw opening: 0–280 mm Accuracy: 0.01 mm Dimensions (L x W x H): 200 x 655 x 170 mm Special features Material: Cast iron Type: Mechanical and hydraulic Designation: power-enhanced and compact ECLASS: 21020601 ETIM: EC002173 SKU: VMC-200M FAQ What clamping force does this vice provide? The VMC-200M offers a clamping capacity of 3,000 kgf, which secures the workpiece during heavy cutting and contributes to consistent machining results. What level of positional accuracy can be expected? The vice maintains positioning to 0.01 mm, ensuring repeatable setups and supporting tight tolerance machining. Will the vice fit on standard milling tables? The compact dimensions and an overall weight of 86 kg allow the vice to be mounted on typical machine tables used in milling centres and similar setups. Is the construction suitable for continuous production use? Constructed from cast iron and designed as a mechanical and hydraulic unit, the vice is built for frequent use and the demands of production environments. What workpiece sizes are supported by the jaw opening? A jaw opening range of 0–280 mm accommodates a wide variety of part sizes, from small precision components to larger workpieces used in batch production. Manufacturer: Vertex Machinery Works Co., Ltd.; No. 296, Sec. 1, Feng Shih Road, Fengyuan District, Taichung City 420, Taiwan
0-283mm Hydraulic Machine Vice Large Opening 40 kN Clamping Force, Cast Iron 0.01mm Accuracy - Vertex
Robust cast-iron construction, 40 kN clamping force and a wide 0–283 mm opening provide secure, repeatable fixturing for heavy machining tasks; order the VQC-125HC directly via Metav Werkzeuge or consult the technical team for configuration and delivery. VQC-125HC Hydraulic Machine Vice — 40 kN clamping force, 0–283 mm opening (Vertex) A VQC-125HC hydraulic machine vice designed for heavy-duty machining, offering a large opening and stable clamping for milling, drilling and grinding operations. Hydraulic actuation for reliable clamping Large opening 0–283 mm for oversized workpieces 40 kN clamping force for stable machining Cast-iron body for vibration damping High positional accuracy 0.01 mm Secure clamping for heavy machining The vice combines a 40 kN clamping force with a cast-iron body to deliver exceptional workpiece stability under load. The substantial clamping force reduces micro-movement during aggressive cutting, which in turn improves surface finish and extends tool life. The heavy construction also contributes to vibration damping, meaning less chatter during high-feed operations and more consistent results across production batches. Adaptability through a wide opening and hydraulic control With an opening range of 0–283 mm, the device accommodates a broad variety of component sizes, making it suitable for flexible job-shop environments as well as dedicated production cells. The hydraulic actuation option speeds up clamping cycles and ensures uniform force across the jaw faces, which shortens set-up times and reduces manual handling. This adaptability supports efficient changeover and consistent fixturing procedures. Precision positioning for finishing and inspection operations Engineered with a positional accuracy of 0.01 mm, the vice enables repeatable seating and alignment of workpieces for precision machining and post-process inspection. The stable clamping and fine positional control minimise rework and help meet tight tolerances, particularly on finishing passes and precision drilling. The unit’s design supports accurate fixturing without complex external aids. Compact footprint with workshop-friendly handling Despite its robust capabilities, the vice maintains a compact footprint—dimensions are 135 x 478.5 x 140 mm—allowing secure mounting on standard machine tables without excessive space demands. Weighing 42.5 kg, the assembly is substantial enough for stability yet manageable for installation and repositioning in a workshop environment. The overall design aims to balance durability with practical workshop logistics. Contact Metav Werkzeuge for a tailored quotation, delivery from our Emmerich warehouse or expert advice on integrating the VQC-125HC into existing machining setups. Technical Data Article number: VQC-125HC SKU: VQC-125HC GTIN: 4061905088285 Manufacturer: Vertex Core technical data Clamping force: 40 kN Opening range: 0–283 mm Accuracy: 0.01 mm Weight: 42.5 kg Dimensions: 135 x 478.5 x 140 mm Special features Material: Cast iron Type: Hydraulic Large opening for oversized workpieces Suitable for milling, drilling and grinding applications FAQ What clamping force does the vice provide? The vice provides a clamping force of 40 kN, ensuring secure fixation during heavy machining. What is the usable opening range of the jaw? The opening range is 0–283 mm, allowing the vice to accommodate a wide range of workpiece sizes. Is the vice suitable for precision finishing operations? Yes, with a positional accuracy of 0.01 mm the vice supports precision finishing and accurate repeatability. What material is the vice body made from? The body is manufactured from cast iron, which enhances vibration damping and stability during cutting. Can the clamping be hydraulically actuated? The unit is offered with hydraulic actuation to provide uniform, reliable clamping cycles. Manufacturer: Vertex Machinery Works Co., Ltd.; No. 296, Sec. 1, Feng Shih Road, Fengyuan District, Taichung City 420, Taiwan
0-283mm Machine Vice Large Opening, 40 kN Clamping Force, Cast Iron, Mechanical - Vertex
By combining a 40 kN clamping force, a large 0–283 mm opening and a 0.01 mm repeatability, this vice delivers secure, repeatable workholding for demanding machining tasks; benefit from robust cast iron construction and optional hydraulic actuation for faster set-ups. Order the machine vice directly via Metav Werkzeuge or ask our consultants if needed. VQC-125LC machine vice — mechanical vice with large opening and high clamping force (Vertex) VQC-125LC is a mechanical machine vice designed for heavy-duty milling and drilling operations, offering a wide opening and strong clamping for reliable workholding across a range of components Large 0–283 mm opening 40 kN clamping force Precision 0.01 mm accuracy Robust cast iron construction Secure clamping for heavy machining The vice is engineered to provide stable workholding under high cutting forces. Its 40 kN clamping force ensures components remain fixed during deep milling or aggressive drilling, which reduces rework and improves throughput. The cast iron body absorbs vibrations and maintains alignment over time, so fixtures stay true to the programme and tool life is preserved. For shops seeking consistent part quality, this results in fewer rejects and more reliable cycle times. Faster set-ups and greater flexibility A 0–283 mm opening accommodates larger workpieces and reduces the need for multiple devices or frequent re-fixturing. The mechanical actuation enables precise jaw movement and predictable closing behaviour; an optional hydraulic version is available where quicker clamping or integration with automated systems is required. Fewer set-up steps translate into shorter non-productive time and faster overall job changeovers on small and medium batch production. Precision that supports repeatable results With an indicated accuracy of 0.01 mm, the vice supports tight machining tolerances and repeatable positioning. This level of precision helps maintain concentricity and parallelism between operations, especially where multiple faces are machined in sequence. For operators unfamiliar with technical terms: the figure denotes the vice’s ability to hold parts in essentially the same place from one clamping to the next, which is critical for batch consistency and for reducing inspection time. Built for workshop longevity and simple integration Constructed from cast iron and weighing 40.4 kg, the device combines mass for stability with dimensions suited to bench or machine table mounting. The compact footprint and standard mounting pattern allow straightforward installation into existing machining centres or manual mills. Minimal maintenance is required beyond routine cleaning and lubrication of the lead screw and slideways, offering a low total cost of ownership over its service life. Contact Metav Werkzeuge in Emmerich for specification advice on the Vertex VQC-125LC mechanical machine vice with 40 kN clamping force and a 0–283 mm opening, or request a personalised consultation via info@metav-werkzeuge.com or +49 2822 7131930 Technical Data SKU: VQC-125LC GTIN: 4061905093470 Brand: Vertex Type: Mechanical Facts Opening: 0–283 mm Clamping force: 40 kN Accuracy: 0.01 mm Weight: 40.4 kg Special features Material: Cast iron Optional hydraulic actuation Dimensions: 135 x 451.5 x 140 mm FAQ Which materials can be machined while using this vice? The Vertex VQC-125LC machine vice is suitable for general metalworking and provides stable clamping for steels, stainless steel and non-ferrous alloys; material choice should be matched to tooling and machining parameters. Is a hydraulic variant available for automated workflows? Yes, an optional hydraulic actuation is offered for the VQC-125LC to enable faster clamping cycles and easier integration into automated or high-throughput environments. What is the expected repeatability of the clamping system? The vice is specified with an accuracy of 0.01 mm, reflecting its ability to return workpieces to essentially the same position for repeatable machining operations. How should the vice be maintained? Routine maintenance for the VQC-125LC includes regular cleaning of sliding surfaces, lubrication of the lead screw and checking the jaw faces; these simple steps prolong service life and preserve accuracy. Manufacturer: Vertex Machinery Works Co., Ltd.; No. 296, Sec. 1, Feng Shih Road, Fengyuan District, Taichung City 420, Taiwan
0-290mm Milling Vise 800 Kgf Clamping Force 0.01mm Accuracy, Cast Iron - Vertex
Benefit from a robust cast-iron construction, 0–290 mm opening and 800 kgf clamping force for reliable, precise workholding; combine heavy-duty stability with fine 0.01 mm repeatability. Order the VSM-12 milling vice directly via Metav Werkzeuge or ask our consultants if needed. VSM-12 Milling Vice (Mechanical) — 0–290 mm opening, cast iron A robust VSM-12 mechanical milling vice designed for secure workholding in machine shops and toolrooms. Heavy cast-iron body for vibration damping Opening range 0–290 mm for large workpieces Clamping force 800 kgf for secure fixation Accuracy 0.01 mm for fine positioning Consistent precision for production and prototyping The heavy-duty vice delivers measurable benefits in repeatability and part quality: with a declared accuracy of 0.01 mm, the device supports tight tolerances commonly required in precision milling and fixture work. The mechanical clamping system, specified with a clamping force of 800 kgf, minimises micro-movement under cutting loads and allows consistent machining cycles. For engineers and workshop managers this translates into fewer reworks and predictable cycle times, while the specification-driven design supports integration into CNC and conventional milling setups. Stability that reduces chatter and improves surface finish Constructed from cast iron, the workholding unit provides inherent damping that reduces vibration during cutting operations. The substantial mass (84 kg) and rigid body geometry improve tool life and surface finish by limiting resonant behaviour, particularly when machining harder materials or using long overhangs. The overall construction is intended for workshops that demand stable clamping under moderate to heavy milling conditions, delivering measurable improvements in process reliability and operator confidence. Flexible capacity for varied clamping requirements A generous opening range of 0–290 mm accommodates a wide variety of workpiece sizes, from small fixtures to larger assemblies, making the vice suitable for jobbing shops and production lines. The compact footprint with dimensions 304 x 604 x 198 mm enables efficient table placement while preserving access for tool changes and probing. The combination of a wide opening and precise jaw alignment supports quick setup and repeatable positioning, reducing non-productive time between operations. Designed for durable, low-maintenance operation The mechanical design focuses on robustness and serviceability: wear-critical surfaces are engineered for long life and straightforward maintenance, while the simple drive mechanism enables rapid inspection and replacement of consumable parts. The vice is supplied with machining-oriented features that favour stable clamping and easy integration into existing fixturing strategies. As a result, workshops benefit from a low total cost of ownership through reduced downtime and predictable maintenance intervals. For heavy-duty, precision milling choose the Vertex VSM-12 from Metav Werkzeuge — contact our specialists at info@metav-werkzeuge.com or call +49 2822 7131930 for tailored advice and secure supply from Emmerich. Technical data Article number: VSM-12 GTIN: 4061905083495 Type: Mechanical eClass: 21020601 Facts Opening range: 0–290 mm Dimensions: 304 x 604 x 198 mm Weight: 84 kg Clamping force: 800 kgf Accuracy: 0.01 mm Special features Material: Cast iron Category: Vertex Images: technical drawing, main, detail FAQ What materials can be machined while using this vice? The vice is built in cast iron and suitable for general milling tasks; it supports common metals and composites where a rigid, heavy workholding device is required. How large is the maximum opening and what size workpieces fit? The opening range is 0–290 mm, allowing clamping of both small components and larger assemblies that fall within that span. What level of precision can be expected from the clamping system? The mechanical workholding provides an accuracy of 0.01 mm, enabling fine positional control suitable for precision milling and fixture work. Is the clamping force sufficient for heavy machining operations? With a rated clamping force of 800 kgf, the vice offers secure fixation for many standard and demanding milling operations, reducing part movement under load. Who manufactures the vice and where is it produced? The vice is produced by Vertex and distributed through Metav Werkzeuge for the European market. Manufacturer: Vertex Machinery Works Co., Ltd.; No. 296, Sec. 1, Feng Shih Road, Fengyuan District, Taichung City 420, Taiwan
0-300 mm Hydraulic Machine Vice 7,500 kgf Clamping Force 0.02 mm Accuracy, 680x375x206mm - Vertex
Take advantage of high clamping force and precise repeatability combined with a compact footprint for reliable workholding in demanding production environments; order directly via Metav Werkzeuge or consult the specialists for tailored integration advice. VH-8 Hydraulic machine vice by Vertex — 7,500 kgf clamping force, 0–300 mm opening The VH-8 is a hydraulic machine vice designed for firm, repeatable clamping across a wide opening range, suitable for heavy-duty milling and machining operations. 7,500 kgf clamping force Opening 0–300 mm for large workpieces Accuracy ±0.02 mm for repeatability Robust 110 kg construction Consistent clamping power for stable machining The VH-8 delivers a high clamping force through a controlled hydraulic system, providing 7500 kgf that secures workpieces during interrupted cuts and heavy milling. This level of hold reduces vibration and contributes to a steady tool engagement, which in turn improves surface finish and tool life. The hydraulic actuation enables consistent pressure across cycles, minimising variability between setups and supporting reliable throughput in batch production environments. Integration into existing machine tool workflows is simplified by the vice's compact control of clamping action. Flexible opening and robust build for diverse parts A wide opening range of 0–300 mm allows the vice to accommodate varied component sizes without frequent fixture changes, cutting set-up time and increasing machine utilisation. The vice’s substantial mass — 110 kg — and robust construction deliver resistance to movement under load, supporting accurate machining of asymmetric or tall workpieces. The physical dimensions permit assessment of fit on most milling tables; the solid build also reduces the need for supplementary bracing in many applications. Designed for repeatable mechanical performance, the unit streamlines workholding for mixed-production environments. Precision engineering that reduces rework and increases output With an accuracy specification of 0.02 mm, the vice enables precise, repeatable clamping that helps to maintain tight tolerances across serial parts and reduces the incidence of rework. The geometry and surface contact design of the vice contribute to predictable reference points for measurement and machining, supporting quality assurance processes. Backed by Vertex's manufacturing standards and the distribution expertise of Metav Werkzeuge, the product forms part of a dependable workholding solution that supports process stability and long-term operational reliability. For tailored technical advice or to arrange procurement via Metav Werkzeuge — including verification of machine compatibility and delivery options from Emmerich — contact Metav Werkzeuge at info@metav-werkzeuge.com or call +49 2822 7131930; Metav's specialists can advise on installation and integration. Technical data Article number: VH-8 GTIN: 4061905088933 ETIM: EC002173 ECLASS: 21020601 Brand: Vertex Facts Opening range: 0–300 mm Clamping force: 7500 kgf Weight: 110 kg Accuracy: 0.02 mm Dimensions: 680 x 375 x 206 mm Special features Type: Hydraulic Product: Hydraulic machine vice Category: Vertex Images available: technical drawing, main view, detail view FAQ What maximum clamping force does the vice provide? The VH-8 hydraulic machine vice provides a clamping force of 7,500 kgf, designed for heavy-duty workholding applications. Which opening range should be expected for larger parts? The vice offers an opening range of 0–300 mm, allowing accommodation of a wide variety of workpiece sizes without extensive fixture changes. How precise is the clamping repeatability? Repeatability and positioning are specified at an accuracy of 0.02 mm, supporting tight tolerances in serial machining. Is the VH-8 suitable for continuous production use? The robust construction and hydraulic actuation of the VH-8 make it well suited to continuous or batch production where consistent clamping is required. What physical data are important to check before installation? Check the vice weight (110 kg), dimensions (680 x 375 x 206 mm) and table clearance to ensure secure mounting and compatibility with the machine tool. Manufacturer: Vertex Machinery Works Co., Ltd.; No. 296, Sec. 1, Feng Shih Road, Fengyuan District, Taichung City 420, Taiwan
0-300 mm Hydraulic Milling Vise, Precision 0.01 mm, 59.1 kg - Vertex
Take advantage of hydraulic clamping, a broad 0–300 mm jaw opening and 0.01 mm repeatability to improve machining throughput and part quality; order the VHO-8 directly via Metav Werkzeuge or consult our specialists for application advice. VHO-8 Hydraulic Milling Vise by Vertex — 0–300 mm opening, 0.01 mm accuracy The VHO-8 Hydraulic Milling Vise is a hydraulically actuated machine vice designed for secure clamping during milling and general machining of medium-sized workpieces, offering precise positioning and stable holding across repetitive cycles. Hydraulic clamping for consistent force 0–300 mm jaw opening for versatile workpieces High repeatability with 0.01 mm accuracy Stable 59.1 kg mass for vibration damping Achieve consistent clamping for repeatable precision Hydraulic actuation provides a steady and reproducible clamping force that reduces variation between cycles and helps maintain machining tolerances. The machine vice’s hydraulic operation eliminates manual torque inconsistencies common with mechanical screws, resulting in improved process stability. With a documented 0.01 mm accuracy this system supports tight tolerance work, so set-up times and scrap rates are reduced while cycle reliability increases. Stability and rigidity that protect surface finish and tool life A substantial mass contributes directly to machining stability: the vice’s 59.1 kg mass helps dampen vibrations during heavier milling passes, keeping the workpiece motion minimal. The broad 0–300 mm jaw opening accommodates a range of component sizes without compromising clamping integrity. This combination of mass and jaw capacity benefits surface finish and extends tool life by reducing chatter and uneven loading during cuts. Simple integration into production workflows and predictable maintenance Designed for machine-tool environments, the hydraulic vice fits automated and manual milling setups where repeatability and uptime matter. The hydraulic principle reduces operator effort during clamping and unclamping, which speeds up workholding cycles. Routine checks of the hydraulic supply and seals will ensure ongoing performance; when maintained, the unit delivers consistently measurable results that align with industrial production demands. For assured machining accuracy with Vertex hydraulic clamping, contact Metav Werkzeuge for tailored guidance and procurement of the VHO-8 through our technical sales team Technical data SKU: VHO-8 GTIN: 4061905087509 Manufacturer: Vertex Key specifications Dimensions: 1060 x 240 x 138 mm Jaw opening: 0–300 mm Accuracy / repeatability: 0.01 mm Weight: 59.1 kg ECLASS: 21020601 ETIM: EC002173 Features & suitability Hydraulic clamping Intended for milling and general machining use Stable mass for improved vibration damping FAQ What level of positional accuracy can be expected from this hydraulic vice? The VHO-8 hydraulic milling vise provides a repeatability of 0.01 mm, enabling precise positioning for machining tasks with tight tolerances. Which workpiece sizes are supported by the jaw opening? The vice accepts workpieces within a 0–300 mm jaw opening, making it suitable for a broad range of medium-sized components used in milling operations. Is the VHO-8 suitable for heavy machining passes? The combination of hydraulic clamping and a 59.1 kg mass gives the VHO-8 good stability under typical milling loads, helping to reduce vibration during heavier cuts. How does hydraulic clamping benefit production compared with mechanical vises? Hydraulic clamping on the VHO-8 ensures consistent force across cycles, lowers operator variability and reduces setup time, which supports higher throughput and fewer dimensional deviations. Can the vice be integrated into automated milling centres? Yes, the VHO-8 is designed for machine-tool applications and can be integrated into automated and manual milling workflows where reliable, repeatable clamping is required. Manufacturer: Vertex Machinery Works Co., Ltd.; No. 296, Sec. 1, Feng Shih Road, Fengyuan District, Taichung City 420, Taiwan
0-300 mm Precision Machine Vise Modular Hydraulic Option, 2000 kgf Clamp Force - Vertex
Achieve consistently accurate workholding with a vice that combines high clamping force, fine repeatability and modular flexibility; the 2000 kgf clamp capacity, 0–300 mm opening and 0.01 mm positional accuracy support stable machining and reduced rework. Order the unit via Metav Werkzeuge or contact our consultants for application advice. VMP-7B Precision Machine Vice (Mechanical, 0–300 mm opening) — Vertex The VMP-7B Precision Machine Vice is a modular, mechanically operated vice engineered for high-precision workholding in milling and machining centres, with an optional hydraulic configuration for automated clamping sequences High-precision clamping to 0.01 mm accuracy Modular design with optional hydraulic upgrade 2000 kgf clamping force for secure holding Adjustable 0–300 mm opening for versatile parts Consistent accuracy that reduces rework With a rated accuracy of 0.01 mm, the VMP-7B delivers the positional repeatability required for precise machining operations. The combination of fine adjustment and a substantial clamping force means components remain firmly located during heavy cuts, which reduces tool deflection and minimises scrap rates. This performance benefit is particularly valuable for batch production, where consistent part geometry from cycle to cycle directly improves throughput and lowers downstream quality checks. The specification for tight tolerance control is expressed in industry-standard figures to enable confident planning for fixture design and process capability studies. Flexible configuration for diverse production tasks The vice’s modular design allows adaptation to a range of setups: it operates mechanically by default, with an optional hydraulic upgrade available for automated processes. The clear 0–300 mm opening range accommodates varied workpiece sizes, reducing the need for multiple bespoke fixtures. By selecting a mechanical vice that can be converted to hydraulic operation, workshops gain a cost-effective path to automation without extensive retooling. The modular approach shortens changeover times and supports mixed production runs, so machining centres can switch between prototypes and high-volume batches with minimal disruption. Robust construction for reliable long-term performance Built from alloy steel, the vice combines material strength with mass—approximately 48.3 kg—to dampen vibration and provide a stable foundation for demanding cuts. The compact footprint (145 x 555 x 118 mm) delivers rigidity without excessive space consumption on the machine table. Robust construction reduces the frequency of adjustments and the need for corrective maintenance, supporting continuous operation in industrial environments. For workshops seeking dependable clamping across a range of materials, the vice’s mechanical simplicity and durable components translate into lower lifecycle costs and predictable machine performance. Discuss application requirements with Metav Werkzeuge in Emmerich — our specialists will advise on the Vertex VMP-7B precision machine vice and its hydraulic options; contact info@metav-werkzeuge.com or call +49 2822 7131930 Technical Data SKU: VMP-7B GTIN: 4061905090356 ECLASS: 21020601 ETIM: EC002173 Facts Opening: 0–300 mm Clamping force: 2000 kgf Accuracy: 0.01 mm Weight: 48.3 kg Dimensions: 145 x 555 x 118 mm Special features Material: alloy steel Modular design, optional hydraulic version Type: mechanical Brand: Vertex FAQ What level of repeatability can be expected from this vice? The VMP-7B precision machine vice by Vertex provides a rated accuracy of 0.01 mm, ensuring high repeatability suitable for precision milling and machining tasks. Can the vice be upgraded to hydraulic clamping later? Yes, the vice is modular and can be configured with an optional hydraulic upgrade to enable automated clamping sequences on production lines. Which workpiece sizes are compatible with the VMP-7B? The adjustable opening range of 0–300 mm accommodates a wide variety of part dimensions, making the vice suitable for both small fixtures and larger components. Is the VMP-7B suitable for heavy cutting operations? With a clamping force of 2000 kgf and a mass of 48.3 kg, the vice offers the stability required for demanding cuts while maintaining precision. What material is the vice made from and how does that affect performance? Constructed from alloy steel, the vice combines strength and mass for improved vibration damping and long-term durability in industrial use. Manufacturer: Vertex Machinery Works Co., Ltd.; No. 296, Sec. 1, Feng Shih Road, Fengyuan District, Taichung City 420, Taiwan
0-300mm Hydraulic Machine Vice 4,500 kgf Clamping Force, 63 kg - Vertex
Combining 4500 kgf clamping force with 0.02 mm repeatability ensures secure, high-precision clamping for stable machining; order the vice directly via Metav Werkzeuge or consult our advisers for application guidance. Hydraulic Machine Vice VH-6 — Hydraulic clamping vice with 4500 kgf and 0–300 mm opening (Vertex) The Hydraulic Machine Vice VH-6 is a hydraulic clamping vice designed for reliable, high-force workholding on machine tables, offering a 0–300 mm opening for versatile part sizes. 4500 kgf clamping force 0–300 mm opening range Precision 0.02 mm accuracy Robust 63 kg mass Secure clamping that reduces setup time The vice delivers 4500 kgf of clamping capacity, providing a consistently firm hold that minimises part movement during heavy cutting. High clamping force reduces the need for repeated adjustments and shortens setup cycles, which increases throughput on milling and drilling tasks. The hydraulic actuation provides smooth pressure application, so clamping is both repeatable and reliable even under variable cutting loads. Built for precision and repeatable accuracy Designed with a focus on repeatability, the vice achieves 0.02 mm positional accuracy, which supports tight tolerances in serial production. Precision seating and a rigid base dampen vibration and improve surface finish, turning clamping into an integral part of the machining process rather than a limiting factor. For users less familiar with technical terms: repeatability refers to the vice’s ability to return a workpiece to the same position each time, ensuring consistent results across runs. Versatile capacity for a broad range of parts With a 0–300 mm opening and a compact footprint, this hydraulic vice accommodates a wide variety of component sizes while keeping the work area clear. The solid 63 kg construction gives a low centre of gravity and resists tip or shift when machining tall or uneven parts. The vice’s geometry is suitable for both one-off jobs and batch production, making it a practical choice for job shops and production lines that require flexible clamping solutions. Practical maintenance and workshop integration Hydraulic operation simplifies clamping control and reduces mechanical wear compared with purely mechanical vises. Routine maintenance is limited to basic checks of the hydraulic connections and seals; regular inspection keeps performance stable over time. Where necessary, spare parts and service guidance are available from Vertex and our distribution partners, ensuring that the vice remains a long-term asset in the workshop. Choose the Vertex VH-6 for robust, repeatable clamping — contact Metav Werkzeuge for tailored advice and supply from our Emmerich facility at info@metav-werkzeuge.com or +49 2822 7131930 Technical data SKU: VH-6 GTIN: 4061905086984 Manufacturer: Vertex Facts Weight: 63 kg Opening: 0–300 mm Clamping force: 4500 kgf Accuracy: 0.02 Special features Hydraulic operation Type: Hydraulic eClass: 21020601 ETIM: EC002173 FAQ How much clamping force does the vice provide? The vice provides a clamping force of 4500 kgf, suitable for heavy-duty machining and secure workholding on vertical and horizontal machining centres. What opening range is available for different part sizes? The vice covers an opening range of 0–300 mm, allowing flexible clamping of small to medium-sized components. What level of positional accuracy can be expected? Repeatability is specified at 0.02 mm, offering consistent placement for operations that require close tolerances. Is the vice suitable for production environments with frequent set-ups? Yes, the hydraulic actuation and robust build of the VH-6 make it well suited to repeated set-ups and batch production where repeatability and speed are priorities. Who manufactures the vice and what is the SKU? The vice is manufactured by Vertex and sold under SKU VH-6; Vertex supplies the original components and documentation. Manufacturer: Vertex Machinery Works Co., Ltd.; No. 296, Sec. 1, Feng Shih Road, Fengyuan District, Taichung City 420, Taiwan
0-300mm Hydraulic Machine Vice Forward-Tilting, 4500 kgf Clamping Force, 88kg - Vertex
Benefit from the combination of 4,500 kgf clamping force, 0–300 mm opening and a forward-tilting design for secure, flexible machining; order directly via Metav Werkzeuge or consult our specialists for application advice. VHT-6 Hydraulic Machine Vice by Vertex — 4,500 kgf clamping force, 0–300 mm opening The VHT-6 is a hydraulic machine vice engineered for high-precision workholding in machining centres and milling applications, offering heavy-duty clamping and a forward-tilting function for angled setups 4,500 kgf clamping force Opening range 0–300 mm Forward-tilting design for angled machining 0.01 mm positional accuracy Secure heavy-duty clamping for consistent machining results The hydraulic workholding system delivers reliable clamping with a rated 4,500 kgf force, ensuring stable fixation of workpieces during heavy cutting and repetitive production runs. Hydraulic actuation reduces manual effort and maintains consistent pressure, which improves surface finish and tool life compared with manual vises. With a declared positional accuracy of 0.01 mm, the vice supports tasks where tight tolerances are required; this level of precision contributes directly to reduced rework rates and predictable process outputs. Flexible tilting and compact footprint to speed setup A forward-tilting jaw assembly allows angled machining without complex re-fixturing, cutting set-up time on multi-axis programmes. The unit’s overall footprint of 800×300×290 mm and a mass of 88 kg give a low centre of gravity for stable clamping while remaining compact enough for standard machine tables. The 0–300 mm opening accommodates a broad range of part sizes, enabling flexible batch changes and fewer toolings for mixed production — a pragmatic benefit in small to medium workshops and production cells. Precision integration into the production environment Designed for shop-fitment and reliable repeatability, the vice’s hydraulic operation promotes uniform clamping cycles and lowers operator variation. Mechanical wear is reduced through controlled actuation, which supports longer intervals between maintenance when compared with purely mechanical clamping systems. Identification data such as SKU VHT-6 and GTIN 4061905091216 simplify procurement and inventory processes, while the combination of robust mass and finely adjustable opening supports accurate positioning on machine tables and in automated fixtures. A partner for practical productivity and procurement Sourcing through a specialist distributor adds value beyond the product alone: Metav represents a quality filter for the European market and supplies precision equipment with dependable logistics from Emmerich. With a broad catalogue and long-standing sector experience, the supplier offers streamlined access to spares and accessories, and supports straightforward integration into existing workflows. This pragmatic approach helps reduce supplier count, shortens lead times and strengthens production reliability across industrial and workshop environments. For procurement and technical questions regarding the Vertex VHT-6 hydraulic machine vice, contact Metav Werkzeuge in Emmerich: email info@metav-werkzeuge.com or call +49 2822 7131930 for tailored advice and delivery options Technical Data SKU: VHT-6 GTIN: 4061905091216 Manufacturer: Vertex Type: Hydraulic eClass: 21020601 ETIM: EC002173 Data Dimensions: 800×300×290 mm Opening range: 0–300 mm Clamping force: 4,500 kgf Positional accuracy: 0.01 mm Weight: 88 kg Special features Forward-tilting jaw Hydraulic actuation FAQ What clamping force does the vice provide? The Vertex VHT-6 hydraulic machine vice provides a clamping force of 4,500 kgf, designed for heavy-duty machining and secure fixation. What is the maximum opening of the vice? The vice offers an opening range of 0–300 mm, allowing accommodation of a wide variety of part sizes in milling and machining centre applications. How precise is the workholding? Positional repeatability is specified at 0.01 mm, supporting high-accuracy machining and consistent production quality when using the VHT-6. Is the vice suitable for angled machining operations? Yes, the forward-tilting jaw permits angled setups, enabling angled machining without the need for additional fixturing or complex repositioning. What identification helps with ordering and stock control? Order and inventory references include SKU VHT-6 and GTIN 4061905091216, which simplify procurement and traceability. Manufacturer: Vertex Machinery Works Co., Ltd.; No. 296, Sec. 1, Feng Shih Road, Fengyuan District, Taichung City 420, Taiwan
0-300mm Hydraulic Machine Vice Side-Tilting, 4,500 kgf Clamping Force, 93.96 kg - Vertex
Take advantage of the combination of robust 4,500 kgf clamping, a 0–300 mm jaw opening and side-tilt flexibility for reliable heavy-duty workholding; order the vice directly via Metav Werkzeuge or consult our specialists for application advice. Vertex VHT-6U — Hydraulic machine vice with 4,500 kgf clamping and 0–300 mm opening The Vertex VHT-6U is a hydraulic machine vice designed for secure workholding in milling and machining applications, offering high clamping force and side-tilt capability for angled setups. Hydraulic operation with high clamping force 4,500 kgf clamping capability for heavy work 0–300 mm jaw opening for versatile parts Side-tilting design for angled machining Reliable clamping for continuous machining The Vertex VHT-6U brings hydraulic actuation and a rated 4,500 kgf clamping force to demanding machining tasks, ensuring workpieces remain immobile under heavy cuts. The force is delivered via a compact hydraulic mechanism that reduces operator effort and shortens cycle times, supporting higher spindle loads and consistent machining results. This level of holding power translates into fewer interruptions for re-clamping and a measurable improvement in throughput for production environments. Flexible positioning for complex geometries With a jaw travel of 0–300 mm, the vice accommodates a broad range of component sizes without frequent fixture changes. The side-tilting feature extends the vice’s versatility by allowing angled setups directly on the machine table, eliminating time-consuming external fixturing for simple angular operations. This flexibility supports multi-operation workflows and reduces setup complexity for one-off jobs and small batches alike, helping to keep machining sequences efficient and predictable. Accuracy and stability where precision matters Designed to deliver repeatable results, the clamping system's specification lists an accuracy of 0.01 mm, backed by a substantial body mass of 93.96 kg that increases rigidity and dampens vibration during machining. The combination of fine positional accuracy and inherent stability supports close-tolerance milling and finishing operations. For shops upgrading from manual vises, the increased rigidity and precision translate into improved surface quality and reduced scrap rates. Integration into the workshop and maintenance considerations Constructed for straightforward integration with standard machine tables, the vice’s dimensions (940 x 225 x 235 mm) and hydraulic operation simplify installation and routine use. The robust design reduces the need for frequent adjustment and contributes to longer service intervals, while the side-tilt mechanism offers quick orientation changes without additional adapters. For assistance with compatibility, mounting or application-specific recommendations, Metav Werkzeuge provides technical guidance and product selection support to match the vice to machining processes. Contact Metav Werkzeuge for tailored specification advice on the Vertex VHT-6U hydraulic machine vice and to discuss suitability for specific machining applications Technical Data Article number: VHT-6U GTIN: 4061905092435 Manufacturer: Vertex Core specifications Opening range: 0–300 mm Clamping force: 4,500 kgf Accuracy: 0.01 mm Weight: 93.96 kg Special features Type: Hydraulic Tilting: side-tilting Dimensions: 940 x 225 x 235 mm eClass: 21020601 ETIM: EC002173 FAQ What clamping force does the vice provide? The Vertex VHT-6U hydraulic machine vice delivers a clamping force of 4,500 kgf, suitable for heavy-duty milling and high-load operations. What jaw opening range is available? The vice offers a jaw opening range of 0–300 mm, enabling secure clamping of a wide variety of part sizes. Is the vice suitable for angled machining? Yes. The side-tilting design allows the vice to be inclined for angled setups, simplifying workholding for bevels and compound fixtures. What level of precision can be expected? The vice has an accuracy specification of 0.01 mm, providing repeatable positioning for close-tolerance operations. How heavy is the unit and what does that mean for stability? The vice weighs 93.96 kg; the substantial mass increases rigidity and vibration damping, which improves machining stability and surface finish. Manufacturer: Vertex Machinery Works Co., Ltd.; No. 296, Sec. 1, Feng Shih Road, Fengyuan District, Taichung City 420, Taiwan
0-300mm Pneumatic Precision Machine Vice 9,000 kgf Clamping Force, Cast Iron - Vertex
Take advantage of a combination of high clamping power and fine positional accuracy to keep machining processes secure and repeatable. The pneumatic actuation paired with a cast iron body provides fast cycles and vibration damping for stable results. Order the vice directly via Metav Werkzeuge or consult our specialists for application-specific advice. VMC-8PL Pneumatic precision machine vice — 9,000 kgf clamping, 0–300 mm opening (Vertex) A VMC-8PL pneumatic precision machine vice designed for secure workholding and rapid cycle times in milling and machining centres. Precision repeatability 0.01 mm 9,000 kgf clamping force Pneumatic actuation for quick cycles Cast iron body for vibration damping Consistent precision that reduces rework The vice delivers 0.01 mm positional accuracy, ensuring repeatable clamping for batch production and fine finishing operations. High repeatability minimises the need for repeated alignment, which reduces downtime and helps maintain consistent dimensional tolerances on machined parts. For operations where micrometre-level consistency matters, the precise guidance and robust jaw alignment make the unit suitable for series work and smaller lot sizes alike. High clamping force and fast pneumatic cycles boost throughput With a rated 9,000 kgf of clamping force and pneumatic actuation, the unit secures heavy or asymmetrical workpieces quickly while keeping cycle times low. Pneumatic control provides immediate clamping and release, supporting automated or semi-automated workflows and allowing feeders or pallet systems to operate without delay. The combination of strong hold and fast actuation improves machining stability and reduces the likelihood of part movement during heavy cutting. Robust construction for long-term workshop performance Built from cast iron, the clamping unit absorbs cutting vibrations and resists distortion under load, contributing to better surface finish and tool life. The substantial mass—approximately 79 kg—and compact dimensions (200 x 710 x 173 mm) create a stable mounting platform for milling tasks. The body material and construction are tailored for industrial use, giving a reliable foundation that stands up to repeated cycles and demanding production environments. Simple integration and practical handling on the shop floor The design accommodates openings from 0–300 mm, covering a wide range of component sizes without the need for frequent fixture changes. The pneumatic system simplifies actuation interfaces and is compatible with standard shop compressed-air supplies; the vice can be incorporated into CNC fixtures or manual setups. Clear mechanical function and serviceable components make maintenance predictable, while the vice’s compact footprint supports efficient use of machine table space. For application advice or to secure supply of the Vertex VMC-8PL pneumatic vice from Metav Werkzeuge’s Emmerich stock, contact Metav Werkzeuge for tailored procurement and technical guidance Technical data SKU: VMC-8PL GTIN: 4061905093876 Manufacturer: Vertex Facts Dimensions: 200 x 710 x 173 mm (L x W x H) Weight: 79 kg Opening range: 0–300 mm Clamping force: 9,000 kgf Accuracy: 0.01 mm Type: Pneumatic Material: Cast iron Special features Pneumatic actuation High clamping force Cast iron body for damping ECLASS: 21020601 ETIM: EC002173 FAQ What level of accuracy can be expected from this vice? The vice achieves an accuracy of 0.01 mm, delivering the positional repeatability required for precision machining with minimal rework. Is the VMC-8PL suitable for heavy milling operations? Yes, the 9,000 kgf clamping force and robust cast iron construction make the VMC-8PL appropriate for heavy cuts and stabilising asymmetric workpieces. What is the clamping range and how flexible is it? The unit covers an opening range of 0–300 mm, providing flexibility for a variety of component sizes without frequent fixture swaps. Can the vice be integrated into automated fixtures? Pneumatic actuation supports rapid cycles and straightforward integration into automated or semi-automated fixtures; the unit is designed to work with standard compressed-air systems. Who manufactures the vice and what is the model reference? The vice is manufactured by Vertex and sold under the model reference VMC-8PL (SKU VMC-8PL, GTIN 4061905093876). Manufacturer: Vertex Machinery Works Co., Ltd.; No. 296, Sec. 1, Feng Shih Road, Fengyuan District, Taichung City 420, Taiwan
0-300mm Precision Machine Vice Modular Hydraulic Option, 2000 kgf Clamping Force - Vertex
Take advantage of the combination of high clamping force, fine repeatability and a modular configuration for flexible machining operations; order the vice directly via Metav Werkzeuge or consult our specialists for a tailored setup. Precision machine vice VMP-8B — 2000 kgf clamping force, 0–300 mm opening (Vertex) The Precision machine vice VMP-8B is a mechanical, modular vice designed for secure clamping of workpieces in milling and machining operations, offering an optional hydraulic upgrade for automated production environments 2000 kgf clamping force for secure holding 0–300 mm opening for large workpieces Hardened alloy steel construction Modular design, hydraulic option available Consistent clamping for repeatable machining quality The VMP-8B delivers 2000 kgf of clamping force combined with 0.01 mm accuracy, ensuring workpieces remain stable under cutting loads and thermal influence. High clamping force reduces vibration and tool deflection, which directly improves surface finish and dimensional repeatability. For production and jobbing shops where rework costs are significant, the precise hold offered by this vice translates into measurable reductions in scrap and downtime while supporting tighter tolerances and faster cycle times. Robust construction that lowers maintenance needs Built from alloy steel with hardened contact surfaces, this vice is engineered for extended service life in industrial environments. The solid construction and careful material selection resist wear and maintain jaw alignment over prolonged use, reducing frequency of adjustments and maintenance interventions. The mass and rigidity of the assembly contribute to process stability; by choosing a durable clamping solution, workshops benefit from fewer interruptions and predictable throughput in daily machining tasks. Flexible configuration to suit varied production demands The modular concept allows the vice to be configured as a purely mechanical unit or upgraded with a hydraulic option to support automated clamping cycles. The 0–300 mm opening accommodates a wide range of part sizes, while modular interfaces enable integration with bespoke fixtures or quick-change systems. This adaptability supports mixed-production environments, where rapid reconfiguration between jobs is essential to maintain high machine utilisation and minimise non-productive time. Practical dimensions and handling for workshop integration With compact footprint dimensions of 170 x 595 x 135 mm and a unit mass of 73.2 kg, the vice is designed to mount securely to milling tables and machining centres without excessive space claims. The mass contributes to stability, but attention to correct anchoring is recommended to preserve repeatability. The vice’s geometry facilitates alignment and fixturing, and its modular layout simplifies upgrades or parts replacement. Clear specification of mounting hole positions and interfaces supports fast installation and integration into existing workflows. Contact Metav Werkzeuge for configuration advice, delivery options from Emmerich and assistance selecting the ideal setup for production requirements with Vertex equipment Technical Data SKU: VMP-8B GTIN: 4061905092664 Manufacturer: Vertex Facts Clamping force: 2000 kgf Opening range: 0–300 mm Accuracy: 0.01 mm Weight: 73.2 kg Dimensions: 170 x 595 x 135 mm Type: Mechanical Special features Material: alloy steel Modular design, hydraulic option available Designed for precision machining Eclass: 21020601 ETIM: EC002173 FAQ What level of repeatability can be expected from the vice? The VMP-8B achieves repeatability on the order of 0.01 mm, making the vice suitable for precision milling and machining tasks that demand consistent positioning. Can the vice be upgraded to hydraulic clamping later? Yes, the vice features a modular design and can be supplied or retrofitted with the hydraulic option to enable automated clamping cycles. Is the VMP-8B suitable for large workpieces? The vice provides an opening range of 0–300 mm, allowing secure clamping of a broad variety of part sizes typically encountered in jobbing and production shops. What is the construction material and how does it affect durability? Constructed from alloy steel with hardened contact surfaces, the vice is built to resist wear and maintain alignment, which reduces maintenance intervals and extends service life. How heavy is the vice and what should be considered for mounting? The unit weighs 73.2 kg; proper anchoring to the machine table and consideration of machine load limits are recommended to ensure stability and repeatable performance. Manufacturer: Vertex Machinery Works Co., Ltd.; No. 296, Sec. 1, Feng Shih Road, Fengyuan District, Taichung City 420, Taiwan
0-300mm Precision Machine Vice Modular Hydraulic Option, 4,500 kgf Clamping Force - Vertex
Benefit from the combination of 0.01 mm precision, 4,500 kgf clamping force and a modular, optionally hydraulic design for consistent, repeatable machining performance; order the VMP-6BH directly via Metav Werkzeuge or consult our specialists for configuration advice. VMP-6BH Precision Machine Vice — Hydraulic, 4,500 kgf Clamping (Vertex) The VMP-6BH is a modular precision machine vice with optional hydraulic actuation, engineered for secure, high-accuracy clamping in milling and machining centres. Precision 0.01 mm accuracy Hydraulic clamping 4,500 kgf Opening range 0–300 mm Alloy steel, robust construction Stable clamping that secures tolerances and productivity The vice delivers 0.01 mm accuracy, providing the measurable repeatability required for precision machining. High clamping force of 4,500 kgf reduces part movement and vibration under cutting loads, enabling tighter tolerances and fewer reworks. Where cycle time and surface finish are critical, this stability translates directly into higher first-pass yield and predictable process windows. The arrangement and contact faces are optimised to maintain grip while minimising distortion of delicate workpieces. Modular design for flexible machine integration A modular construction allows adaptation to different set-ups and the option of hydraulic actuation for automated clamping processes. The vice’s opening 0–300 mm range accommodates a wide span of workpiece sizes without the need for frequent jaw changes, while the compact footprint (125 x 520 x 100 mm) and a weight of 29 kg support straightforward mounting on machining tables and rotary fixtures. This flexibility reduces tooling swaps and supports smoother workflow integration across jobs and machines. Robust materials for continuous industrial use Manufactured from alloy steel, the vice is built to withstand the demands of production environments; wear resistance and structural integrity prolong service life and reduce maintenance intervals. The solid construction supports consistent performance under repeated clamping cycles and harsh shop-floor conditions. Specifying durable materials and proven machining vice architecture helps protect capital investment and reduces total cost of ownership through fewer replacements and less downtime. Clear specification and traceability for procurement Identification and classification data simplify procurement and integration: SKU VMP-6BH, GTIN 4061905091353, eClass 21020601 and ETIM EC002173 provide standardised references for ordering and system planning. The vice’s technical profile—accuracy, clamping force, material and dimensional data—allows engineering teams to perform process simulations and fixture design with confidence. If specification is uncertain, Metav consultants are available to advise on the appropriate configuration for specific machining tasks. Contact Metav Werkzeuge to specify the Vertex VMP-6BH with 4,500 kgf hydraulic clamping for seamless integration into production—email info@metav-werkzeuge.com or call +49 2822 7131930 Technical data SKU: VMP-6BH GTIN: 4061905091353 Brand: Vertex Type: Hydraulic Model description: Precision machine vice, modular, optionally hydraulic Facts Accuracy: 0.01 mm Clamping force: 4,500 kgf Opening range: 0–300 mm Weight: 29 kg Dimensions: 125 x 520 x 100 mm eClass: 21020601 ETIM: EC002173 Special features Material: Alloy steel Modular design Optional hydraulic actuation Suitable for machine-shop clamping applications SKU VMP-6BH FAQ What clamping force does the vice provide? The vice provides a clamping force of 4,500 kgf, ensuring secure hold for heavy cutting operations with the Vertex VMP-6BH precision machine vice. What accuracy can be expected during machining? An accuracy of 0.01 mm is specified for the VMP-6BH, allowing consistent repeatability suitable for precision milling and finishing tasks. What is the usable jaw opening range? The vice offers an opening range of 0–300 mm, enabling accommodation of a wide variety of component sizes without frequent jaw changes. Is the vice available with hydraulic clamping? Yes, the VMP-6BH is modular and available with optional hydraulic actuation for automated or remote clamping applications. Which material is the vice made from and how does that affect durability? Constructed from alloy steel, the vice provides enhanced strength and wear resistance for continuous industrial use and long service life. Manufacturer: Vertex Machinery Works Co., Ltd.; No. 296, Sec. 1, Feng Shih Road, Fengyuan District, Taichung City 420, Taiwan
0-300mm Precision Machine Vice, Modular Hydraulic Option, 4,500 kgf Clamp Force, 43 kg - Vertex
Take advantage of high clamping force and repeatable accuracy to improve machining throughput; the modular, optionally hydraulic configuration also reduces fixture changeover time. Order the Precision Machine Vice VMP-7BH directly via Metav Werkzeuge or ask our consultants for specification support. Precision Machine Vice VMP-7BH (Hydraulic, Modular) – Vertex The Precision Machine Vice VMP-7BH is a modular hydraulic clamping solution for heavy-duty machining and CNC applications, designed to combine stable workholding with quick reconfiguration for varied production tasks. Hydraulic clamping up to 4500 kgf Adjustable opening 0–300 mm Repeatable accuracy to 0.01 mm Consistent clamping for reliable machining The vice’s hydraulic actuation provides a constant, high clamping force rated at 4500 kgf, which secures components with minimal elastic deformation. Hydraulic clamping reduces the need for repeated manual adjustment and keeps pressure even during long cycles, lowering the risk of part movement and costly rework. Constructed from alloy steel, the assembly increases structural rigidity, so cutters maintain intended cutting paths and tool life is optimised. Modular layout for flexible production flows A modular concept enables adaptation between plain mechanical setups and a complete hydraulic configuration, allowing one base unit to serve multiple fixture needs. The 0–300 mm opening range covers a broad span of component sizes, reducing inventory of specialised vices and simplifying shop-floor logistics. At 43 kg, the vice provides mass where it matters, damping vibrations and supporting stable clamping under dynamic machining loads. Precision that reduces inspection overhead Designed for repeatable positioning with accuracy to 0.01 mm, this workholding device supports interchangeable fixturing and consistent dimensional results across batches. Precision surfaces and controlled pressure distribution minimise distortion during clamping, which results in fewer measurement deviations and a higher proportion of first-pass acceptable parts. The VMP-7BH therefore contributes to predictable cycle times and improved overall equipment effectiveness. For tailored advice on hydraulic clamping from Vertex and secure delivery via Metav Werkzeuge in Emmerich, request specification support from our consultants. Technical data Article number: VMP-7BH GTIN: 4061905094729 Brand: Vertex Facts Opening range: 0–300 mm Clamping force: 4500 kgf Accuracy: 0.01 mm Weight: 43 kg Dimensions: 145 x 555 x 118 mm Special features Modular design, optional hydraulic modules Type: Hydraulic Material: alloy steel ECLASS: 21020601 ETIM: EC002173 FAQ What is the opening range of the vice? The opening range for the Precision Machine Vice VMP-7BH is 0–300 mm, suitable for a wide variety of component sizes. How much clamping force does the vice provide? The VMP-7BH supplies up to 4500 kgf of clamping force via its hydraulic system. Which material is used for the vice body? The vice is manufactured from alloy steel, chosen for its strength and resistance to deformation. What level of positional accuracy can be expected? The unit delivers repeatable accuracy to 0.01 mm, supporting high-precision machining and interchangeability. What are the weight and overall dimensions of the unit? The vice weighs 43 kg and measures 145 x 555 x 118 mm, offering a stable base for heavy machining operations. Manufacturer: Vertex Machinery Works Co., Ltd.; No. 296, Sec. 1, Feng Shih Road, Fengyuan District, Taichung City 420, Taiwan
0-305 mm Hydraulic Machine Vice With Large Jaw Opening, 60 kN Clamping Force, Cast Iron - Vertex
Take advantage of the combination of robust 60 kN clamping force, a 0–305 mm opening and a cast-iron body for secure, repeatable machining results; order the unit directly via Metav Werkzeuge or consult our specialists for specification support. VQC-160MH Hydraulic machine vice by Vertex — 60 kN clamping, 0–305 mm opening The VQC-160MH is a hydraulic machine vice engineered for heavy-duty clamping in milling centres and machine tools, offering a large opening for oversized workpieces. 60 kN clamping force for secure holding Large 0–305 mm opening for big workpieces Cast-iron body for stability and damping 0.01 mm positioning accuracy for tight tolerances Stable clamping for demanding machining A high clamping force is the baseline for reliable machining. The vice’s 60 kN clamping capacity combined with a cast-iron construction provides a stable contact surface that reduces chatter and improves surface finish. For shops that process larger components, the 0–305 mm opening minimises setup constraints and allows longer or bulkier parts to be held without intermediate fixtures. The mass of the unit contributes to dampening, which supports more consistent cutting results and reduces rework. Faster setups with the hydraulic configuration The hydraulic design speeds up repetitive clamping cycles while maintaining consistent clamp pressure, which reduces variation between jobs. A hydraulically actuated clamping device simplifies part loading and unloading on automated or semi-automated cells and helps maintain steady cycle times. This mechanical consistency translates into process reliability and lower scrap rates, making the vice a practical choice where uptime and throughput are priorities. Precision where it matters most Positioning and repeatability are key for precision work: the device offers 0.01 mm accuracy, enabling narrow tolerances to be met without complex secondary operations. That level of precision suits both prototype work and small-batch production where dimensional conformity is essential. The vice integrates well into CNC workflows, providing the rigid, repeatable clamp point required for high-quality milling, drilling or finishing steps. Choose the Vertex VQC-160MH hydraulic machine vice for robust, accurate clamping—contact Metav Werkzeuge for procurement advice or technical clarification at info@metav-werkzeuge.com or by phone at +49 2822 7131930 Technical data SKU: VQC-160MH GTIN: 4061905092459 Manufacturer: Vertex Facts Clamping force: 60 kN Opening range: 0–305 mm Accuracy: 0.01 mm Weight: 66 kg Dimensions: 170 x 610.5 x 165 mm Special features Material: cast iron Type: hydraulic design Large opening for oversized workpieces Suitable for integration in machine tools FAQ What is the maximum workpiece size this vice can hold? The vice accommodates workpieces up to a 0–305 mm opening range, allowing for larger or irregular parts in milling and machining operations. Is the clamping force adjustable on the VQC-160MH? The VQC-160MH provides a rated 60 kN clamping force; hydraulic systems enable consistent pressure application and can be regulated via the machine’s hydraulic control when required. What material is the vice body made from and why does it matter? The body is made of cast iron, chosen for its rigidity and vibration-damping properties, which improve machining stability and surface finish. Can this vice be used on automated machining centres? Yes, the hydraulic configuration and robust design make the vice suitable for automated or semi-automated machining environments where repeatable clamping is required. How precise is the clamping and positioning? The device offers 0.01 mm accuracy, ensuring that tight tolerances are achievable and maintained across repeated setups. Manufacturer: Vertex Machinery Works Co., Ltd.; No. 296, Sec. 1, Feng Shih Road, Fengyuan District, Taichung City 420, Taiwan
0-310 mm Hydraulic Milling Vice High Precision 0.01 mm, 1140x280x163mm - Vertex
Take advantage of hydraulic clamping and a 0–310 mm opening to secure diverse workpieces with consistent force and a repeatability of 0.01 mm for reliable machining results; order or request advice via Metav Werkzeuge for tailored delivery and configuration. VHO-6 Hydraulic milling vice by Vertex — hydraulic clamping, 0–310 mm opening The VHO-6 is a hydraulic milling vice engineered for precise, repeatable clamping in milling machines and machining centres, offering a robust solution for medium to large workpieces. Hydraulic clamping for consistent force Wide opening range 0–310 mm High repeatability with 0.01 mm accuracy Solid build, approx. 94.3 kg mass Precision that keeps production on target Hydraulic actuation provides a constant clamping force, which is essential when tolerances are tight and cycle times are short. The vice delivers repeatability down to 0.01 mm, reducing the need for frequent re-measurement and rework; this level of stability benefits finishing passes and tool life by keeping the workpiece position consistent relative to the cutter. Where dimensional consistency is a priority, the controlled clamping of a hydraulic unit minimises deformation compared with uneven manual tightening, supporting a smoother production flow and fewer rejects. Flexible workholding for varied workpieces A wide opening of 0–310 mm accommodates a broad range of part sizes without the need for multiple fixtures, cutting setup time between jobs. The vice’s footprint of 1140 x 280 x 163 mm is designed to fit standard machine tables while offering generous jaw travel, enabling secure clamping of both longer components and compact blocks. This versatility helps consolidate fixturing inventory and simplifies job planning: one vice can cover several part families, improving throughput and reducing handling complexity on the shop floor. Stability and durability to withstand machining forces A substantial mass of 94.3 kg gives the vice excellent inertial stability, damping vibration and improving surface finish during heavy milling operations. The hydraulic operation ensures repeatable clamping force cycle after cycle, while the robust construction is intended for continuous use in industrial environments. Compared with simpler screw vices, hydraulic units like this one allow faster clamping/unclamping sequences and more consistent pressure distribution across the jaws, which protects delicate geometries and extends fixture life. Routine inspection of seals and hydraulic connections keeps performance reliable with straightforward maintenance. For hydraulic clamping from Vertex and tailored advice on integrating the VHO-6 into existing machining cells, contact Metav Werkzeuge for specification support and delivery from our Emmerich quality hub Technical Data Article number: VHO-6 GTIN: 4061905093753 Manufacturer: Vertex Type: Hydraulic Facts Opening range: 0–310 mm Accuracy: 0.01 mm Weight: 94.3 kg Dimensions: 1140 x 280 x 163 mm Special features Hydraulic operation eClass: 21020601 ETIM: EC002173 Category: Vertex SKU: VHO-6 FAQ What level of accuracy can be expected from this vice? The vice achieves a repeatability of 0.01 mm, ensuring consistent positioning for precision milling and reducing the need for repeated setups. Is the VHO-6 suitable for heavy milling operations? Yes, the VHO-6 hydraulic milling vice has a mass of 94.3 kg and a stable design intended to withstand substantial machining forces while maintaining clamping consistency. What size of workpiece can be clamped? The vice offers a 0–310 mm opening range, accommodating a wide range of part sizes from compact blocks to longer components within that jaw travel. How does hydraulic clamping benefit machining compared with mechanical screw vices? Hydraulic clamping delivers uniform pressure and faster cycle times; the VHO-6 provides repeatable force application that helps protect part geometry and improves surface finish. Which standard classifications apply to this vice? Relevant classifications include eClass 21020601 and ETIM EC002173 for product grouping and specification reference. Manufacturer: Vertex Machinery Works Co., Ltd.; No. 296, Sec. 1, Feng Shih Road, Fengyuan District, Taichung City 420, Taiwan
0-310mm Tilting Hydraulic Machine Vice Power/Quick Option, Cast Iron Body - Vertex
Benefit from the combination of a hydraulic Power clamping system, a cast-iron body for reliable vibration damping and a wide 0–310 mm jaw opening for versatile workholding. Order the machine vice directly via Metav Werkzeuge or consult our specialists for tailored application advice. VUT-6NC Machine Vice — Hydraulic Power, tilting, Vertex The VUT-6NC is a hydraulic, tilting machine vice designed for secure clamping during milling and machining operations across a wide variety of workpiece sizes and shapes. Hydraulic Power model with tilting function Cast-iron body for vibration damping Jaw opening 0–310 mm for versatile clamping Compact footprint: 449×560×469 mm Reliable clamping that raises throughput A hydraulic Power clamping mechanism delivers a repeatable, consistent clamping force that reduces setup variation and minimises rework. The wide 0–310 mm jaw opening accommodates varied component sizes, which shortens changeover time and supports higher throughput on production benches and CNC milling centres. For operations where cycle reliability matters, the stable hydraulic actuation maintains force without frequent manual re-adjustment, improving process stability and part quality. Robust construction for improved surface finish and tool life A cast-iron body provides effective vibration damping, which helps to protect cutting edges and to reduce chatter marks on finished components. The material choice lowers transmitted vibrations to both the machine and the clamped workpiece, producing a cleaner surface finish and extending tool life. Built-in robustness also supports heavier clamping demands typical in industrial workshops, making the vice suitable for demanding continuous use. Tilting function for angled and multi-plane machining The integrated tilting capability enables angled clamping without repeated re-fixturing, allowing operations such as compound-angle milling or drilling to proceed with fewer setups. This flexibility reduces overall setup time and increases first-pass accuracy for complex parts. The tilting mechanism is particularly useful for prototypes and small batch runs where adaptability is essential and re-clamping would otherwise introduce error. Compact footprint, simple workshop integration With overall dimensions of 449×560×469 mm and a nominal height of 757 mm, the vice fits readily on machining tables while still offering a substantial clamping range. The space-saving design supports efficient workshop layout and straightforward integration into existing fixtures. Supplied in Vertex engineering, the unit complements standard milling workflows and helps to centralise precision clamping without extensive machine modification. For precision clamping with hydraulic Power and tilting versatility, contact Metav Werkzeuge in Emmerich for a bespoke recommendation — email info@metav-werkzeuge.com or call +49 2822 7131930 for expert guidance and supply options Technical Data Article number: VUT-6NC GTIN: 4061905094354 Manufacturer: Vertex Type: Hydraulic (Power) Material: Cast iron Dimensions: 449×560×469 mm Height: 757 mm Jaw opening: 0–310 mm ECLASS: 21020601 ETIM: EC002173 Facts Jaw opening: 0–310 mm Dimensions (W×D×H): 449×560×469 mm Height: 757 mm GTIN: 4061905094354 Special features Tilting (kippbar) Hydraulic Power version Alternate Quick version available Cast-iron construction SKU: VUT-6NC FAQ What clamping range does the vice offer? The VUT-6NC provides a jaw opening range of 0–310 mm, allowing secure clamping of small to medium-sized workpieces. Is the vice suitable for heavy-duty milling operations? Yes, the cast-iron construction and hydraulic Power actuation make this Vertex machine vice well suited to heavy-duty milling and repeated industrial use. Can angled machining be performed without re-clamping? The integrated tilting function enables angled operations directly in the vice, reducing the need for repeated re-clamping and saving setup time. Which versions are available for different workshop needs? The product is offered in a Hydraulic (Power) version; an alternative Quick version is listed for workshops prioritising faster manual adjustment. How does the material choice affect machining results? Cast iron provides effective vibration damping, improving surface finish and protecting cutting tools during machining with the Vertex machine vice. Manufacturer: Vertex Machinery Works Co., Ltd.; No. 296, Sec. 1, Feng Shih Road, Fengyuan District, Taichung City 420, Taiwan
0-350 mm Precision Machine Vice, 3,000 kgf Clamping Force, Cast Iron, Mechanical/Hydraulic - Vertex
Take advantage of a robust 3,000 kgf clamping force combined with compact cast iron construction and 0.01 mm repeatability to maintain stable, high-precision machining. Order the precision machine vice directly via Metav Werkzeuge or ask our consultants if needed. VMC-160ML Precision Machine Vice — force-enhanced, compact design with 3,000 kgf clamping force VMC-160ML Precision Machine Vice is a compact, force-enhanced vice designed for secure clamping on milling machines and machining centres, suitable where high holding power and consistent accuracy are required 3,000 kgf clamping force Adjustable opening 0–350 mm High accuracy 0.01 mm Robust cast iron construction Consistent accuracy for repeatable machining results The vice delivers 0.01 mm accuracy, providing the kind of dimensional stability that reduces rework and scrap on repeat runs. This level of precision means tolerances are held cycle after cycle, which benefits programmed machining operations and measurement-controlled production. By stabilising the workpiece position, tool paths run reliably and inspection effort is reduced, making the vice a sound component in process chains where part-to-part consistency matters. Secure clamping that supports heavier cuts A 3,000 kgf clamping force ensures the workpiece is held firmly during heavy milling or intermittent cutting. The force-amplified design—available in both mechanical and hydraulic actuation—translates operator input into substantial holding power while limiting slippage and vibration. The result is improved surface finish and extended tool life because cutting forces are absorbed by the clamping system rather than transmitted into part movement or chatter. Compact footprint with versatile opening range With an opening range of 0–350 mm and dimensions of 160 x 695 x 168 mm, the vice balances a small workshop footprint with practical adaptability for different workpiece sizes. Weighing 67 kg, it mounts easily to most machine tables without excessive loading, yet offers the reach required for many common components. The compact layout supports flexible fixturing strategies and rapid changeovers, helping production lines remain agile without sacrificing stability. Designed for integration and low-maintenance operation Constructed from cast iron for vibration damping and long service life, the clamping assembly is engineered for straightforward integration into existing fixturing setups. The combination of robust materials and the vice’s structural design reduces the need for frequent adjustments, while mechanical and hydraulic operation modes allow choice according to workshop practice. The VMC-160ML is therefore suited to both jobbing shops and series production where predictable uptime is essential. Contact Metav Werkzeuge today to discuss how the Vertex VMC-160ML can increase holding stability in machining operations; our Emmerich-based consultants will advise on suitability, mounting and options for seamless integration Technical Data SKU: VMC-160ML GTIN: 4061905095313 eClass: 21020601 ETIM: EC002173 Core specifications Clamping force: 3,000 kgf Opening range: 0–350 mm Accuracy: 0.01 mm Weight: 67 kg Dimensions: 160 x 695 x 168 mm Materials & features Material: Cast iron Type: Mechanical and hydraulic Brand: Vertex FAQ What clamping force does the vice provide? The vice provides a clamping force of 3,000 kgf, delivering the holding power required for heavy milling and interrupted cuts with minimal slippage. Is the VMC-160ML suitable for different machine types? Yes, the VMC-160ML precision machine vice is designed for use on milling machines and machining centres and integrates with standard machine-tabling systems. How precise is the clamping across repeated operations? Repeatability is specified at 0.01 mm, ensuring consistent positioning and reducing the need for frequent remeasurement during production runs. What materials is the vice made from and why does that matter? The vice is made from cast iron, which provides vibration damping and structural stability, supporting better surface finishes and longer tool life. How heavy is the vice and what are the installation implications? The vice weighs 67 kg; this allows stable mounting on most machine tables while remaining manageable for workshop handling and fixture planning. Manufacturer: Vertex Machinery Works Co., Ltd.; No. 296, Sec. 1, Feng Shih Road, Fengyuan District, Taichung City 420, Taiwan
0-350mm Tilting Milling Vice 1600 kgf Clamping Force, Cast Iron, 152x300x290mm - Vertex
The combination of a robust cast iron body, 1600 kgf clamping force and a tilting function ensures stable, repeatable clamping for precision milling; this reduces setup time and secures machining accuracy. Order the milling vice directly via Metav Werkzeuge or ask our consultants if needed. Vertex VWT-6B Tilting Milling Vice with 1600 kgf Clamping Force The Vertex VWT-6B is a mechanical milling vice designed for secure workholding in machining centres and manual mills, featuring a tilting function for angled clamping and a wide 0–350 mm jaw opening Tilting design for angled clamping 0–350 mm opening for large workpieces 1600 kgf clamping force for secure fixation Cast iron body for vibration damping Accuracy 0.01 mm for repeatable results Stable construction for consistent precision A heavy cast iron chassis and a mass of 79.7 kg give the vice excellent damping properties, which directly improves surface finish and tool life by reducing chatter. The specified accuracy of 0.01 mm describes the unit’s repeatability under normal clamping conditions; this level of precision supports tight-tolerance work and reduces the need for secondary alignment operations. The high clamping force (1600 kgf) keeps parts firmly located during high-feed passes, so set-up integrity is maintained throughout production runs. Versatile angled clamping to simplify setups The integrated tilting function permits secure clamping at common machining angles, enabling complex fixtures to be replaced by a single device. With a jaw opening of 0–350 mm, the vice accommodates a wide range of stock sizes, limiting the number of different vises required in a busy shop. For shops that switch frequently between prototypes and small-series production, this flexibility shortens changeover time and supports a more efficient workflow. Practical installation and operation for workshop use As a mechanical vice, the VWT-6B combines straightforward operation with robust mechanics that are easy to service. The vice’s weight and footprint provide a stable foundation on the machine table; straightforward clamping adjustments keep cycle times low. Routine maintenance is limited to lubrication of sliding surfaces and periodic inspection of the screw mechanism, which helps preserve the vice’s accuracy and service life without complex procedures. Why this vice supports efficient production Choosing a heavy, tilting vice like this reduces fixturing complexity and increases machining throughput: fewer repositions, fewer setups and less scrap. The design emphasises operational reliability and predictable results, which is particularly valuable for workshops supplying repeatable parts to industry. Combined with Metav Werkzeuge’s distribution and quality-assurance approach, this vice forms part of a dependable workholding strategy that aligns precision with everyday workshop demands. For precise, repeatable milling with angled clamping, contact Metav Werkzeuge in Emmerich for tailored advice and reliable supply arrangements Technical data SKU: VWT-6B GTIN: 4061905089336 Brand: Vertex Type: Mechanical Core specifications Weight: 79.7 kg Jaw opening: 0–350 mm Clamping force: 1600 kgf Accuracy: 0.01 mm Dimensions: 152 x 300 x 290 mm Features & materials Material: Cast iron Feature: Tilting (kippbar) design eClass: 21020601 ETIM: EC002173 FAQ What materials are suitable for clamping with this vice? The VWT-6B vice, made from cast iron, is suitable for securely clamping a wide range of metallic workpieces typically used in milling operations; compatibility depends on the chosen jaws and clamping accessories. What range of part sizes can be accommodated? With a jaw opening of 0–350 mm, the Vertex VWT-6B can handle small fixtures up to larger blocks typical of medium machining tasks without additional fixture work. How does the tilting function improve setup flexibility? The tilting function on the VWT-6B allows angled clamping without elaborate fixtures, reducing setup time and enabling operations that would otherwise require custom fixturing. Is the vice suitable for heavy-duty milling? The 1600 kgf clamping force and the heavy cast iron construction make the VWT-6B appropriate for many heavy-duty milling applications where secure fixation and vibration damping are required. What regular maintenance is recommended to preserve accuracy? Routine lubrication of sliding surfaces and inspection of the screw mechanism will help maintain the VWT-6B’s accuracy of 0.01 mm and ensure long-term reliability. Manufacturer: Vertex Machinery Works Co., Ltd.; No. 296, Sec. 1, Feng Shih Road, Fengyuan District, Taichung City 420, Taiwan
0-355 mm Mechanischer Maschinenschraubstock mit groĂźer Ă–ffnung, 60 KN Klemmkraft, Gusseisen - Vertex
Die Kombination aus hoher Klemmkraft, großer Öffnung und solider Gusseisen-Bauweise gewährleistet dauerhaft präzise Spannungen und sichere Bearbeitungsergebnisse. Bestellen Sie den Maschinenschraubstock VQC-160L direkt über Metav Werkzeuge oder fragen Sie unsere Beratung bei Bedarf an. VQC-160L Maschinenschraubstock von Vertex Der VQC-160L ist ein mechanischer Maschinenschraubstock für präzise Spannarbeiten mit großer Öffnung und hoher Klemmkraft. Maschinenschraubstock »VQC-160L« von Vertex Gusseisen-Gehäuse für hohe Stabilität Klemmkraft 60 kN für sichere Fixierung Spannbereich 0–355 mm für große Werkstücke Genauigkeit 0,01 mm für präzise Bearbeitung Robuste Bauweise für konstante Genauigkeit Die massive Gusseisen-Konstruktion sorgt für niedrige Vibrationen und hohe Formstabilität, wodurch sich die Genauigkeit 0,01 mm im Arbeitsprozess realisieren lässt. Diese Stabilität reduziert Nacharbeit und erhöht die Wiederholgenauigkeit bei Serienteilen. Durch das Gewicht von 72,5 kg bleibt der Spannstock auch bei dynamischer Bearbeitung fester und bietet so unmittelbaren Nutzen für anspruchsvolle Zerspanungsprozesse. Große Öffnung und starke Klemmkraft für vielseitige Aufgaben Der Spannbereich 0–355 mm in Kombination mit einer Klemmkraft 60 kN ermöglicht das Spannen von großen und unregelmäßigen Werkstücken sowie das sichere Fixieren bei hohen Schnittkräften. Anwender profitieren von weniger Rüstzeiten, da unterschiedliche Werkstücke ohne aufwendige Spannhilfen aufgenommen werden können. Die mechanische Bauart erlaubt außerdem eine klare, reproduzierbare Bedienung ohne komplexe Steuerung. Eignung für Werkstatt und industrielle Fertigung Der Maschinenschraubstock richtet sich an Metallbearbeiter, Werkzeugbauer und industrielle Fertigungsbetriebe, die Wert auf Präzision und Robustheit legen. In Kombination mit CNC- und konventionellen Fräs- oder Schleifmaschinen sorgt der Spannstock für stabile Bearbeitungsbedingungen. Die kompakte Abmessung 174x634x165 mm ermöglicht eine einfache Integration auf Werkbänken und Maschinentischen. Leistungsfähigkeit, Wartung und optionale Ausstattung Der mechanische Antrieb ist wartungsarm und bietet eine lange Lebensdauer bei planmäßiger Pflege. Optional ist die Ausführung mit großer Öffnung, wahlweise hydraulisch, verfügbar, was den Bedienkomfort und die Spannkraftregelung weiter erhöht. Klare Wartungsintervalle und die robuste Materialwahl machen den Spannstock zu einer wirtschaftlichen Investition für dauerhafte Produktionsprozesse. Empfehlung: Entscheiden Sie sich für den Maschinenschraubstock VQC-160L von Vertex als zuverlässige Lösung für präzise Spannaufgaben; Metav liefert direkt aus Emmerich und berät Sie gern per eMail info@metav-werkzeuge.com oder Telefon +49 2822 7131930. Produktmerkmale Artikelnummer: VQC-160L Marke: Vertex Typ: Mechanisch Material: Gusseisen Fakten Gewicht: 72,5 kg Abmessung: 174x634x165 mm Klemmkraft: 60 KN Öffnung: 0-355 mm Genauigkeit: 0,01 Besonderheiten Gehäusematerial: Gusseisen Bauart: Mechanisch mit großer Öffnung, wahlweise hydraulisch eClass: 21020601 ETIM: EC002173 FAQ Wie groß ist der Spannbereich des Schraubstocks? Der Spannbereich beträgt 0–355 mm und ermöglicht mit dem VQC-160L von Vertex das Aufnehmen auch größerer Werkstücke. Welche Klemmkraft liefert der Maschinenschraubstock? Der Schraubstock erreicht eine Klemmkraft von 60 kN, wodurch hohe Schnittkräfte sicher abgefangen werden. Aus welchem Material ist der Spannstock gefertigt? Das Gehäuse besteht aus Gusseisen, was dem VQC-160L hohe Stabilität und Vibrationsdämpfung verleiht. Für welche Anwender ist der VQC-160L geeignet? Der VQC-160L richtet sich an Metallbearbeiter, Werkzeugbauer und Fertigungsbetriebe, die robuste und präzise Spanntechnik benötigen. Ist der Schraubstock auch in einer hydraulischen Variante erhältlich? Ja, es gibt eine Ausführung mit großer Öffnung, die wahlweise hydraulisch ausgeführt werden kann, um Bedienkomfort und Regelbarkeit zu erhöhen. Hersteller: Vertex Machinery Works Co., Ltd.; No. 296, Sec. 1, Feng Shih Road, Fengyuan District, Taichung City 420, Taiwan
Secure components with reliable workpiece clamps
Workpiece clamps, also known as workholding clamps or workholding devices, form the essential mechanical interface between machine and part in industrial fabrication. They keep components absolutely play-free, positionally accurate and vibration-resistant during milling, turning, drilling or grinding.
How workpiece clamps ensure process stability
A correctly specified clamping concept transfers the high cutting and feed forces of modern CNC machines into the machine table or spindle without deforming the part. The right combination of mechanical, hydraulic, pneumatic or magnetic solutions enables fast, repeatable setups and supports automated part change where required. Typical applications range from single-part turning to high-volume series milling and complex five-axis machining.
Concrete production benefits at a glance
- repeatable positioning: reduces scrap and rework
- high clamping forces: withstands aggressive cutting without part movement
- reduced set-up time: modular systems and quick-change features speed throughput
- improved surface finish: vibration damping for finer results and tighter tolerances
- flexible compatibility: vices, chucks, clamping plates and zero-point systems for diverse geometries
Why Metav's range is the practical choice
Metav combines decades of specialist know-how with a broad, handpicked range that democratises precision for workshops and industry alike. Based in Emmerich, Metav acts as a quality filter for the European market and supplies more than 250,000 products from precision metrology to complete workshop equipment. With the trust of over 48,000 customers, Metav offers a single-source approach that reduces supplier complexity and secures dependable delivery to your workbench.
Technical data
- function: mechanical interface between machine and workpiece
- primary requirements: absolute positional accuracy; vibration reduction; high clamping forces
- technologies: mechanical, hydraulic, pneumatic, magnetic
- typical components: machine vices; chucks; clamping plates; zero-point systems; pratzen; clamping jaws
- application areas: milling; turning; drilling; grinding; automated part change systems
- production benefits: reduced set-up time; enhanced process security; optimised series and single-part production
The practical summary
Workpiece clamps bring the stability and repeatability required to meet tight tolerances and excellent surface quality, making them indispensable across machining operations. Choosing the right workholding clamps and modular workholding devices is a decisive step towards higher productivity and consistent part quality.
FAQ
What types of workpiece clamps are suitable for automated machining?
Workholding clamps with quick-change modules, hydraulic actuation or magnetic systems are commonly used for automated machining. These workholding devices enable fast, repeatable part changes and integrate with zero-point systems.
How do workpiece clamps affect surface finish and tolerances?
A stable clamping concept minimises vibration and part movement; this improves surface finish and supports achieving narrow tolerances when using high-precision workpiece clamps or workholding devices.
Can the same workpiece clamps handle different part geometries?
Modular workholding clamps and adaptable clamping jaws allow flexible fixturing for varied geometries; combining vices, clamping plates and pratzen increases versatility on the shopfloor.
