Precision micrometers for reliable dimensional control
Micrometers deliver precise length and depth measurements in metalworking, enabling repeatable control over component tolerances and process stability. These instruments—available as outside micrometers, inside micrometers and depth micrometers—offer hardened contact faces and fine-thread spindles to ensure long-term accuracy and resistance to wear, with digital versions providing data transfer via USB or Bluetooth for seamless integration into inspection software. Typical uses include measuring small bores, depths and diameters in precision engineering, where features must be defined to micrometre-level accuracy; features such as ratchet thimbles and insulated frames help maintain consistent measuring force and temperature compensation. Choose between robust analog models, IP54-protected digital micrometers or micrometers with an integrated minicomputer for advanced functions like unit conversion, temperature correction and Go/NoGo evaluations.
450-475mm Precision Micrometer With 35mm Anvil Plates, Touchscreen Readout, Wireless/USB, ISO 17025 Calibrated - Microtech Metrology
Take advantage of ISO 17025 calibration, a 0.01 mm accuracy rating and modern data transfer to secure reproducible measurements for medium‑range components; order the instrument directly via Metav Werkzeuge or consult the specialists for integration and traceable documentation. Micrometer — 450–475 mm measuring range, ISO 17025 calibrated, touchscreen display A Micrometer designed for medium‑range dimensional checks in fixture and mould work, combining a large measuring span with digital readout and certified calibration for reliable QC processes. 0.01 mm accuracy for reproducible results Wireless and USB data output for easy logging Touchscreen 1.54" for fast readout and control Calibrated to ISO 17025 with certificate included Reliable accuracy for medium‑range components The instrument is built for consistent results across larger parts: the 0.01 mm accuracy specification secures repeatable tolerances while the measurement span classifies the tool as medium‑range (300–500 mm), making it suitable for assemblies, housings and mould components. Delivered fully calibrated to ISO 17025, the device arrives with a calibration certificate, so traceability is ensured from first use and integration into quality management systems becomes straightforward. Modern data transfer and ergonomic measurement faces Equipped with Wireless and USB outputs and a Touchscreen 1.54" display, the device simplifies digital capture and reduces transcription errors during inspection runs. The measuring faces are Teller Ø35 mm, providing stable contact with broader surfaces, while the non‑rotating spindle minimises radial runout during closing. Together, these features reduce handling time and improve data reliability when transferring results to SPC or inspection software. Workshop toughness coupled with fine resolution Designed for production environments, the digital instrument offers a clear readout resolution of 0.0001 mm while maintaining the stated accuracy of 0.01 mm, balancing sensitivity and industrial robustness. The construction supports frequent handling in machine and metalworking settings and the large anvils ensure stable readings on castings and housings. Traceable calibration from Microtech and supply via Metav Werkzeuge provides a dependable procurement route for long‑term measurement consistency. Contact Metav Werkzeuge for expert advice and a quotation on this ISO 17025‑calibrated Micrometer from Microtech Metrology, including guidance on data integration and certification documentation. Technical data Article number: 110784757 GTIN: 4061905457623 Manufacturer: Microtech Metrology Data Measurement range: 450–475 mm Accuracy: 0.01 mm Display reading (resolution): 0.0001 mm Display: Touchscreen 1.54" Special features Digital instrument with Wireless and USB data output Measuring faces: Teller Ø35 mm Non‑rotating spindle Delivered calibrated to ISO 17025 with calibration certificate Suitable for medium‑range metrology tasks FAQ What is the calibrated accuracy of the micrometer? The micrometer from Microtech Metrology is delivered with an accuracy of 0.01 mm and an ISO 17025 calibration certificate that documents traceability and measurement uncertainty. Which measurement range does this instrument cover? The measuring span is 450–475 mm, placing the device in the medium‑range category suitable for larger fixtures and housing measurements. How are measurement results transferred to inspection software? Measurement data can be exported via the device’s Wireless connection or USB interface for direct import into SPC or QC systems. What are the contact faces like and why do they matter? The instrument uses Teller Ø35 mm measuring faces which offer broad, stable contact for improved repeatability on uneven or larger surfaces. Is a calibration certificate included with delivery? Yes; the micrometer is delivered fully calibrated to ISO 17025 and includes the calibration certificate for documentation and quality assurance purposes. Manufacturer / Responsible: Microtech, Nizhneyurkovska str., 45a, 04080 Kyiv, Ukraine, tool@microtech.tools
450-500mm Bore Micrometer Digital Wireless/USB Output, Ø8mm Measuring Faces, ISO 17025 Calibrated - Microtech Metrology
Combine high-accuracy measurement with secure data transfer and traceable calibration to keep inspection workflows efficient and auditable; the micrometer’s 0.01 mm accuracy, 0.0001 mm display increment and Wireless + USB output support reliable process control. Order the outside micrometer directly via Metav Werkzeuge or consult our specialists for application advice. Outside micrometer – Digital outside micrometer, 450–500 mm, Wireless + USB (Microtech Metrology) The Outside micrometer is a robust digital instrument for precise dimensional inspection of larger components in production, toolroom and quality‑control environments. Digital display, 0.01 mm resolution Wireless + USB data output ISO 17025 calibration with certificate Measuring range 450–500 mm Precise measurement across a wide span reduces rework and uncertainty The instrument delivers repeatable results across a substantial measuring span of 450–500 mm, combining a high nominal accuracy of 0.01 mm with a fine display increment of 0.0001 mm. Such characteristics enable consistent go/no‑go decisions during incoming inspection or final part verification, reducing scrap and rework. The rigid frame and Ø8 mm measuring faces ensure local contact geometry is stable, while the measuring depth of 110 mm allows access to recessed features. For workshop managers and inspection engineers, this translates into fewer measurement cycles and a more predictable production flow. Integrated data transfer streamlines quality documentation Equipped with Wireless and USB data output, the micrometer feeds measurement values directly into digital records and SPC systems, eliminating manual transcription errors and accelerating reporting. The digital interface supports straightforward connection to common inspection software and statistical packages, enabling real‑time logging of measured values and traceable batch reports. As a result, inspection routines become part of the production data stream, allowing rapid identification of trends and early corrective action — a rational improvement to quality assurance practice. Traceable calibration and ready‑to‑use delivery for audit‑critical processes Delivered fully calibrated in accordance with ISO 17025, the tool includes a calibration certificate for immediate archival and audit use. This traceability guarantees that measurements taken with the device are aligned to recognised laboratory standards, simplifying supplier qualification and regulatory documentation. The digital readout and robust construction make the instrument well suited to metrology labs as well as demanding shop‑floor tasks, offering both laboratory confidence and workshop practicality. For reliable large‑range measurement and traceable results, request the Microtech Metrology outside micrometer (SKU 115055007) via Metav Werkzeuge — phone +49 2822 7131930 or email info@metav-werkzeuge.com Technical data Article number: 115055007 GTIN: 4061905041167 Brand: Microtech Metrology Digital: yes Data output: Wireless + USB Facts Measuring range: 450–500 mm Accuracy: 0.01 mm Display increment: 0.0001 mm Measuring faces Ø: Ø8 mm Measuring depth: 110 mm eClass: 21170328 ETIM: EC003590 Special features ISO 17025 calibration with certificate Wireless + USB data transfer Digital outside micrometer (frame type) Category: Micrometers FAQ What measuring range does this instrument cover? The outside micrometer covers a measuring range of 450–500 mm, suitable for larger components and assemblies. Is a calibration certificate provided with the instrument? Yes — the micrometer is supplied fully calibrated to ISO 17025 standard and includes a calibration certificate for traceability and audit purposes. How are measured values exported to a PC or SPC system? Measured values can be transferred via Wireless or USB interfaces; the digital data output supports integration into common inspection and SPC software. What accuracy and reading resolution can be expected? The device specifies an accuracy of 0.01 mm with a display increment of 0.0001 mm, offering a balance of practical accuracy and fine readout detail. For which applications is this instrument intended? It is aimed at production inspection, toolroom metrology and quality control tasks involving larger parts where a wide measuring span and traceable results are required. Manufacturer / Responsible: Microtech, Nizhneyurkovska str., 45a, 04080 Kyiv, Ukraine, tool@microtech.tools
450-500mm Universal Bore Gauge Micrometer Wireless USB, Anvils Not Included - Microtech Metrology
Take advantage of the combination of 0.01 mm accuracy, robust messtiefe 110 mm and integrated Wireless + USB data output for efficient, reproducible measurements of medium-size components; order or request further advice via Metav Werkzeuge. Universal micrometer — 450–500 mm digital frame with Wireless + USB (Microtech Metrology) The Universal micrometer is a large-capacity digital micrometer intended for precise external and step measurements on medium-size assemblies, combining a deep measuring reach with electronic data transfer. Large range 450–500 mm Digital readout 0.01 mm Wireless and USB data output Interchangeable anvil system (anvils sold separately) Reliable high-precision measurement for medium components Equipped with a 0.01 mm resolution, this digital frame delivers stable, repeatable results across its 450–500 mm measuring span. Classification as a medium-range instrument reflects the balance between reach and stiffness required in machine and toolroom environments: sufficient length for larger fixtures and housings while retaining manageable handling characteristics. The specified measuring depth of 110 mm allows access to recessed features and stepped geometries without compromising the micrometer’s mechanical stability. These characteristics reduce measurement variation and support consistent quality control in production and inspection tasks. Seamless data handling to speed up workflows Integrated Wireless + USB data output enables direct capture of measurement values into inspection software or spreadsheets, removing manual transcription and the associated risk of errors. With electronic transfer, traceable measurement logs can be created faster, improving throughput and documentation for batch inspections. The digital electronics and interface therefore serve both accuracy objectives and operational efficiency, supporting rational decisions based on recorded measurements rather than hand-written notes. Flexible setup for varied workshop requirements The instrument’s universal frame accepts interchangeable anvils to adapt to different workpiece geometries; note that anvils are not included and are supplied separately. The robust frame design and digital readout make this micrometer suitable for workshop use where adaptability matters—whether measuring outside diameters, steps or grooves. Precision craftsmanship from the manufacturer underpins dependable mechanical behaviour across the entire measuring range, making the instrument a practical choice when repeatability and adaptability are required. Contact Metav Werkzeuge to discuss configuration options, compatible anvils and integration of Wireless + USB data output into existing inspection routines — Metav Werkzeuge can advise on delivery and application details. Technical data Article number: 115055077 GTIN: 4061905457944 Brand: Microtech Metrology Facts Measuring range: 450–500 mm Resolution / Accuracy: 0.01 mm Measuring depth: 110 mm Data output: Wireless + USB Digital: yes Special features Interchangeable anvils (anvils not included) Universal frame design Category: medium-range micrometer (300–500 mm) Eclass: 21170328 FAQ What measuring range does this micrometer cover? The Universal micrometer covers a measuring range of 450–500 mm, suitable for medium-sized components. Is a calibration certificate supplied with the instrument? The provided product data does not specify an included calibration certificate for the Universal micrometer (SKU 115055077). Are anvils included with delivery? No, the product description states that anvils are not included; the frame accepts interchangeable anvils which are available separately. What depth of features can be measured with this micrometer? The micrometer offers a measuring depth of 110 mm, allowing measurement of recessed and stepped features on larger workpieces. How are measurement values transferred from the instrument? Measurement values can be exported via Wireless + USB data output for direct capture into inspection systems. Manufacturer / Responsible: Microtech, Nizhneyurkovska str., 45a, 04080 Kyiv, Ukraine, tool@microtech.tools
450mm Precision Micrometer With 35mm Anvil Plates, Touchscreen Display, Wireless/USB, ISO 17025 Calibrated - Microtech Metrology
Benefit from a fully calibrated precision instrument with ISO 17025 traceability, a 0.01 mm accuracy rating and robust disc measuring faces Ø35 mm for reliable measurements on medium‑sized components; order the micrometer directly via Metav Werkzeuge or consult our specialists for integration into existing quality workflows. Microtech Metrology Micrometer — 425–450 mm range, 1.54" touchscreen & Wireless+USB A digital micrometer designed for medium‑range workshop and inspection tasks, combining a generous measuring span with smart data output and certified calibration for traceable results. ISO 17025 calibration certificate included Wireless and USB data output 1.54" touchscreen display 450 mm measuring range Disc measuring faces Ø35 mm Consistent measurement reliability through certified calibration Delivered with an ISO 17025 calibration certificate, this digital micrometer provides a verifiable basis for quality control. The instrument’s stated accuracy of 0.01 mm is supported by a fine reading increment of 0.0001, enabling repeatable checks and traceable reports. For production environments where audit trails and documented measurement uncertainty matter, the calibration certificate reduces administrative effort and simplifies acceptance into internal QA systems. The certification also underpins supplier audits and simplifies compliance with customer specifications. Effortless data capture and error reduction in the measurement chain Equipped with a 1.54" touchscreen and Wireless + USB data interfaces, the instrument minimises manual transcription and streamlines data transfer to SPC or inspection software. The non‑rotating spindle and large disc measuring faces Ø35 mm improve positional stability when measuring flat or delicate parts, reducing operator‑induced variability. Practical connectivity options mean measurement values can be logged directly to a laptop or tablet for real‑time analysis, shortening cycle times in routine dimensional checks. Built for medium-range tasks where reach meets rigidity With a measuring span of 425–450 mm, this micrometer falls into the workshop medium category (300–500 mm), offering the best compromise between reach and stiffness for fixtures, moulds and medium‑sized assemblies. The robust anvil geometry and substantial measuring faces maintain alignment over the instrument’s length, so readings remain reproducible across the full range. For toolrooms and small series production this balance translates to fewer repeat measurements and a more predictable inspection workflow. Integration advantages that support productivity and traceability The combination of digital readout, wireless connectivity and certified calibration positions the micrometer as a practical interface between hands‑on inspection and digital quality systems. Where traceability and documentation are required, the supplied calibration certificate supports archive management; where process control is the priority, direct data export reduces rework and speeds up corrective actions. The overall design supports a smoother handover from measurement to control, increasing throughput without compromising measurement confidence. Contact Metav Werkzeuge in Emmerich to discuss technical integration, delivery options and certified calibration for this Microtech Metrology micrometer; reach Metav’s specialists by eMail at info@metav-werkzeuge.com or by phone on +49 2822 7131930 Technical Data SKU: 110784507 GTIN: 4061905457616 Manufacturer: Microtech Metrology eClass: 21170328 ETIM: EC003590 Facts Measuring range: 425–450 mm Measuring range (max): 450 mm Accuracy: 0.01 mm Reading increment: 0.0001 Display: 1.54" touchscreen Data output: Wireless + USB Digital: yes ISO 17025: calibration certificate included Special features Disc measuring faces Ø35 mm Non‑rotating spindle Fully calibrated delivery with certificate Wireless and USB data interfaces Digital micrometer with touchscreen FAQ Is the instrument delivered with a calibration certificate? Yes. The micrometer from Microtech Metrology is supplied fully calibrated to ISO 17025 standards and includes the calibration certificate for archive and audit purposes. Which measuring range does the micrometer cover and what is its classification? The device covers 425–450 mm, placing it in the medium‑range class (300–500 mm), suitable for fixtures, moulds and medium‑sized assemblies. How are measurement values exported to a PC or SPC system? Measurement data can be transmitted via the micrometer’s Wireless + USB interfaces for direct logging into inspection software or spreadsheets. What level of precision can be expected during routine use? The micrometer specifies 0.01 mm accuracy with a 0.0001 reading increment, providing repeatable results for standard workshop and inspection tasks. Are the measuring faces suitable for delicate surfaces? The disc measuring faces Ø35 mm provide stable contact over larger surface areas and are well suited to flat or fragile components that benefit from distributed contact pressure. Manufacturer / Responsible: Microtech, Nizhneyurkovska str., 45a, 04080 Kyiv, Ukraine, tool@microtech.tools
450mm Setting Gauge Metric 60, Accessories - Microtech Metrology
Take advantage of the combination of 450 mm reach, Metric 60 compatibility and Microtech build quality to simplify medium‑range setup and fixturing tasks; order the setting gauge Einstellmaß directly via Metav Werkzeuge or consult our specialists for application advice. Setting gauge Einstellmaß (450 mm, Metric 60) — Microtech Metrology The setting gauge Einstellmaß is a 450 mm workshop accessory that provides a standardised reference for medium‑range measurement and fixture set‑up in toolrooms and production metrology. Metric 60 compatibility 450 mm measuring length Accessory for precision instruments Robust construction by Microtech Greater reach without sacrificing stiffness The 450 mm measuring length classifies this tool as medium range, offering the best compromise between reach and rigidity for many workshop tasks. In practice, this means longer components such as subassemblies, housings and larger fixtures can be set up and verified with higher repeatability than with shorter standards, while remaining manageable for single‑operator handling. The extended span reduces the need for multiple partial setups and thereby shortens cycle times in routine adjustment and inspection work. Standardised interface for fast integration Compatibility with Metric 60 interfaces ensures straightforward, standardised integration into existing metrology rigs and clamping systems. This feature supports quicker changeovers and reliable interchangeability of reference points across stations. For engineering teams that rely on consistent datum transfer between jigs, gauges and inspection devices, the compatibility delivers measurable time savings and reduces alignment errors during assembly or tool setup. Practical accessory to streamline workflows As an accessory from Microtech Metrology, this setting gauge serves as a stable reference that simplifies alignment tasks and enhances process control. Using a dedicated setting standard for fixture set‑up reduces ad‑hoc measurement steps and helps maintain consistent measurement practice across shifts. The functional design focuses on improving workflow efficiency and supporting quality assurance activities in machine shops and inspection bays. For reliable medium‑range setup tools and tailored advice on integrating the Microtech Metrology setting gauge Einstellmaß into production, contact Metav Werkzeuge for product supply and technical guidance at info@metav-werkzeuge.com or +49 2822 7131930 Technical data Article number: 110710045 GTIN: 4061905459306 Name: Einstellmaß Manufacturer: Microtech Metrology Core technical data Measuring range: 450 mm Special features Metric 60 compatibility Category: Accessory (Zubehör) FAQ What measuring range does the setting gauge cover? The setting gauge provides a 450 mm measuring range, placing it in the medium‑range class suitable for larger workshop components and fixture set‑ups. Is the gauge compatible with Metric 60 systems? Yes, the setting gauge is specified for Metric 60 compatibility, allowing standardised connection and interchangeability with Metric 60 fixtures. Which applications suit this accessory best? This accessory is intended for medium‑range alignment, fixture setup and reference transfers in machine shops, toolrooms and inspection benches where a 450 mm reference span is required. Who manufactures the setting gauge and what is the SKU? The gauge is produced by Microtech Metrology and is listed under SKU 110710045. Can the setting gauge be used together with precision instruments? Yes, the gauge is designed as an accessory for precision instruments and rigs, supporting reproducible setups and consistent datum transfer across inspection and assembly processes. Manufacturer / Responsible: Microtech, Nizhneyurkovska str., 45a, 04080 Kyiv, Ukraine, tool@microtech.tools
450mm Setting Gauge Whitworth 55 Thread Reference - Microtech Metrology
Take advantage of the combination of reliable 450 mm nominal length, Whitworth 55 thread compatibility and workshop-ready design for efficient setup and reproducible results; order the setting gauge directly via Metav Werkzeuge or consult our specialists for application advice. Setting gauge – 450 mm, Whitworth 55 thread (Microtech Metrology) Setting gauge for thread and mounting adjustments, designed for compatibility with Whitworth 55 connections and workshop metrology accessories 450 mm nominal length Whitworth 55 thread specification Accessory for measuring instruments SKU 110720045 for ordering Reliable fit-up for threaded assemblies The gauge provides a consistent reference when aligning and setting up fixtures or threaded components in a workshop environment. With a clear focus on repeatability, the 450 mm nominal length gives a stable span for many standard set-ups while the Whitworth 55 thread specification ensures compatibility with legacy and specialist fittings. This stability reduces rework and shortens machine down-time by enabling quick, reproducible adjustments. The design emphasises straightforward handling and integration with existing metrology tooling so that processes are sped up without compromising outcome quality. Practical benefits for production and maintenance Engineered as an accessory for measurement systems, the device supports faster setup cycles and clearer inspection workflows. The interface following the Whitworth 55 standard helps to avoid misfits when working with older or specialised components, lowering the risk of assembly error. As a tool intended for recurrent use in an industrial environment, the gauge contributes to consistent part quality and predictable process control. The simplified interaction with measurement benches and adaptors translates directly into time saved during changeovers and maintenance routines. Documentation and traceability for quality control Product identification is straightforward: SKU 110720045 and GTIN 4061905460111 make procurement and stock control simple and auditable. As an accessory within metrology setups, the gauge supports traceable workflows by linking a physical reference to batch records and inspection logs. The clear labelling and compatibility reduce administrative overhead when documenting measurement chains and help maintain compliance with internal quality systems. For customers who integrate such references into standard operating procedures, the accessory serves as a practical element of traceability. Choose the Microtech Metrology setting gauge with Whitworth 55 thread for consistent workshop set-ups and contact Metav Werkzeuge for purchasing guidance and technical clarification. Technical data Article number: 110720045 GTIN: 4061905460111 Brand: Microtech Metrology Measurements Length: 450 mm Special features Whitworth 55 thread Category: Accessory for measuring instruments Suitable for workshop and production use FAQ What is the primary application of this setting gauge? The setting gauge is intended as an accessory for metrology and workshop set-ups, used to assist with repeatable alignment and threaded component adjustments in production and maintenance. Is the gauge compatible with Whitworth fittings? Yes, the device follows the Whitworth 55 thread specification to ensure compatibility with corresponding fittings and adaptors. Which identifiers help with procurement and stock control? Use SKU 110720045 and GTIN 4061905460111 when ordering or logging the item in inventory systems. Can this accessory be integrated with existing measurement benches? The accessory is designed for straightforward integration into typical workshop metrology arrangements and complements measuring instruments and fixture systems. Manufacturer / Responsible: Microtech, Nizhneyurkovska str., 45a, 04080 Kyiv, Ukraine, tool@microtech.tools
475mm Gauge for Micrometer Setting With Thermal Protection, Accuracy ±0.005mm - Metav IndustryLine
Take advantage of a setting gauge that combines high precision (±0.005 mm) with robust, thermally protected design over a 475 mm nominal length; this ensures reproducible micrometer adjustments and reliable workshop throughput. Order the gauge directly via Metav Werkzeuge or contact the Metav consultants for technical advice. M304.320.5 — Setting Gauge for Micrometers, 475 mm with Thermal Protection The M304.320.5 is a precision setting gauge designed for adjusting external micrometers and reference measurements in workshop and calibration environments. Accuracy ±0.005 mm (5 µm) Nominal length 475 mm for extended range Thermal protection for stable readings 16 mm diameter for solid contact Precision where consistent reference matters The primary purpose of this reference rod is to provide a stable, verifiable standard for setting external micrometers. With an accuracy of ±0.005 mm (5 µm) and ball-shaped measuring faces, the gauge reduces alignment and contact errors that otherwise introduce traceable uncertainty. The thermal protection minimises expansion effects during routine workshop use, so adjustments stay reproducible across shifts. This translates into fewer rechecks, faster setup cycles and a measurable improvement in process reliability. Geometry and handling tuned for workshop routines At 475 mm nominal length the gauge sits in the medium class for reference tools, offering an excellent balance between reach and rigidity. The solid 16 mm diameter gives a stable contact area for larger micrometer anvils while the ball-shaped measuring faces ensure repeatable point contact without lateral play. Weighing approximately 0.7 kg, the unit is easy to position by one operator yet substantial enough to resist incidental movement, which supports faster and more confident measurement routines on the shop floor. Confidence from a traceable supplier network As an accessory category item from Metav IndustryLine, the gauge benefits from a distribution and quality filter established in Emmerich. That provenance means clear stock visibility and dependable delivery for production-critical tooling. For workshops seeking to standardise micrometer setup and reduce scrap, the reference rod offers both the technical specification and the dealer support that make implementation straightforward. For further clarification on compatibility with existing micrometers, technical specialists are available to advise. Choose the Metav IndustryLine M304.320.5 setting gauge for dependable micrometer adjustment and contact Metav Werkzeuge in Emmerich for tailored ordering or technical guidance via info@metav-werkzeuge.com or +49 2822 7131930 Technical Data Article number: M304.320.5 GTIN: 4054469116747 Tariff number: 90173000 Facts Nominal length: 475 mm Accuracy: ±0.005 mm (5 µm) Weight: 0.7 kg Diameter: 16 mm Special features Thermal protection Ball-shaped measuring faces Accessory for setting external micrometers Category: Accessories FAQ What is the intended use of this setting gauge? The setting gauge M304.320.5 is intended as a reference for adjusting external micrometers and for routine comparative checks in workshops and calibration benches. How precise is the reference and what does ±0.005 mm mean in practice? An accuracy of ±0.005 mm (5 µm) means the reference will keep micrometer settings within a few micrometres of the nominal value, suitable for precision workshop and quality-control tasks. Does the gauge tolerate temperature changes on the shop floor? The thermal protection integrated into the M304.320.5 reduces the effect of ambient temperature fluctuations and helps to maintain stable reference dimensions during normal workshop operations. Are the measuring faces suitable for different micrometer anvil geometries? The ball-shaped measuring faces provide repeatable point contact and are compatible with a wide range of external micrometer anvils for consistent adjustments. Which length class does a 475 mm nominal length correspond to and what is the benefit? A 475 mm nominal length places the gauge in the medium class (300–500 mm), offering a compromise between reach and stiffness that is ideal for larger micrometers and common workshop assemblies. Manufacturer / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; Germany; +49 2822 7131930; info@metav-werkzeuge.com
48-40 TPI Thread Plug, 55° Whitworth Profile - Metav IndustryLine
Take advantage of a reliable reference for Whitworth 55° profiles combined with a compact, lightweight design for efficient inspection workflows; order the thread inserts directly via Metav Werkzeuge or consult the Metav advisers for compatibility details. Thread gauge insert 48–40 TPI, 55° — Thread profile reference for Whitworth 55° inspection by Metav IndustryLine The Thread gauge insert 48–40 TPI, 55° provides a compact reference profile for verifying Whitworth 55° screw threads in metrology and workshop quality control Compatible with Whitworth 55° profiles Nominal pitch 48–40 TPI Precision reference geometry Lightweight 0.1 kg Accurate Whitworth reference for repeatable checks The insert supplies a defined reference profile for Whitworth threads with a nominal pitch of 48–40 TPI and a flank angle of 55°, enabling quick functional checks of mating threads and gauges. As a verification aid, the piece helps to identify thread deformation and wear before parts reach final assembly. The clearly defined geometry reduces subjectivity in visual and tactile comparison, which supports faster go/no‑go decisions on the shop floor and in incoming inspection. Quietly speeds up inspection workflows Designed as a compact accessory for inspection benches and thread measuring setups, the insert is lightweight (approx. 0.1 kg) and easy to position. Integration into standard inspection routines avoids complex setups and shortens cycle times: the fixed profile is immediately usable with comparator gauges, profile projectors or camera inspection systems. The simple form factor lowers handling time and contributes to streamlined throughput without sacrificing control over thread conformity. Stable reference for consistent quality control Using a dedicated profile insert ensures consistent reference geometry across repeated measurements, supporting process stability and documented quality assurance. The item complements existing metrology equipment as an accessory and is suitable where consistent visual or instrumental comparison of Whitworth 55° threads is required. As part of a structured inspection regime, the insert helps to maintain traceable results and to reduce scrap through early detection of non‑conforming threads. Contact Metav Werkzeuge for tailored inspection advice, compatibility checks or to request further technical details via info@metav-werkzeuge.com or +49 2822 7131930 — Metav’s advisers will assist with selection and delivery from Emmerich Technical data Article number: M309.098.1 SKU: M309.098.1 GTIN: 4054469118321 Brand: Metav IndustryLine Specifications Thread: 48–40 TPI Angle: 55° Weight: 0.1 kg Tariff number: 90173000 Features Application: Thread profile reference for Whitworth 55° inspection Category: Accessory for measuring devices Suitable for visual and instrumental comparison FAQ What is the primary use of this insert? The insert serves as a defined reference profile for checking Whitworth 55° threads and is intended for visual and instrumental inspection tasks. Is the insert compatible with standard thread comparators? Yes, the insert is designed as an accessory for thread comparison and can be used alongside standard comparators and inspection fixtures. Can this insert be used for functional gauging? The insert provides a reference geometry for verification; it is intended for inspection and comparison rather than as a hardened go/no‑go gauge. What identification is available for ordering? Order or reference the article number M309.098.1 (SKU M309.098.1) and the brand Metav IndustryLine for precise identification. Does the insert indicate the thread angle and pitch? Yes, the insert corresponds to 48–40 TPI with a 55° flank angle for Whitworth thread profiles. Manufacturer / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; Germany; +49 2822 7131930; info@metav-werkzeuge.com
4–5mm Inside Micrometer With Carbide Measuring Faces, Setting Ring 5mm, 0.004mm Accuracy - Metav IndustryLine
Take advantage of the compact 4–5 mm measuring range, carbide measuring faces and the included 5 mm setting ring for reliable internal measurements in confined bores; order directly via Metav Werkzeuge or consult our specialists for tailored advice. M312.128 inside micrometer — analogue internal measurement, carbide faces (Metav IndustryLine) The M312.128 is an analogue inside micrometer designed for ultra‑compact internal measurement tasks, especially suited to blind‑hole and fine‑mechanical inspection in toolrooms and precision workshops. Carbide measuring faces Includes 5 mm setting ring Analogue reading 0.001 mm Accuracy ±0.004 mm Precision where space is limited The instrument is built for internal measurement in very small bores (4.0–5.0 mm), a range that places it among ultra‑compact precision tools. The analogue scale with a 0.001 mm graduation gives a finely resolved reading, while the stated accuracy of ±0.004 mm provides a quantifiable basis for quality control decisions. Such measurable performance supports reproducible results when checking mating parts, bores in small housings or finish checks on turned components. Durable contact geometry for repeatable results Wearing of contact surfaces is a common cause of drift in repeated checks; the carbide measuring faces on this instrument resist abrasion and retain form under normal workshop use. The hardened contact tips combined with a matt‑chrome scale and vernier ensure legible readings and stable contact behaviour. A supplied 5 mm setting ring allows quick calibration to a known standard, reducing set‑up time and improving day‑to‑day repeatability. Compact design with practical workshop benefits The compact construction minimises deflection during insertion into blind holes and simplifies handling in cramped fixtures. As an analogue micrometer it needs no batteries and offers immediate, tactile feedback during measurement—qualities valued in production gates and toolmaking benches where speed and reliability count. Its suitability for blind‑hole measurement is expressly intended for applications such as small‑bore inspection, component verification and fixture checks. Practical integration and assured supply Integrating this micrometer into routine inspection workflows yields clear efficiency gains: fewer handling steps, faster set‑ups with the setting ring, and durable contacts that reduce rework from worn tooling. Metav IndustryLine supplies the device with industrial distribution from Emmerich, combining a wide product range with local stock and a technical filter before dispatch—an advantage for shops that require dependable, repeatable metrology solutions. For ultra‑compact internal measurements, contact Metav Werkzeuge to procure the Metav IndustryLine M312.128 or request advice from our technical team via info@metav-werkzeuge.com or +49 2822 7131930 for application support and delivery options. Technical data SKU: M312.128 GTIN: 4054469119410 Category: Micrometer (inside measurement) ECLASS: 21170335 Facts Measuring range: 4.0–5.0 mm Resolution (reading): 0.001 mm Stated accuracy: ±0.004 mm Setting ring: 5 mm Special features Carbide measuring faces Scale and vernier matt chrome‑plated Analogue vernier design Suitable for blind‑hole measurement Includes setting ring FAQ Is this instrument suitable for blind‑hole measurements? Yes. The M312.128 inside micrometer is specifically designed for internal and blind‑hole checks and features carbide measuring faces and a compact profile for secure insertion. What level of resolution and accuracy does the instrument deliver? The analogue reading is 0.001 mm with a stated accuracy of ±0.004 mm, allowing routine quality control and fine inspection in small bores. Does the delivery include calibration or a certificate? Standard delivery includes the instrument and the 5 mm setting ring for on‑site zeroing; no ISO 17025 certificate is indicated for this item in the supplied data. What materials are used for the scale and measuring faces? The scale and vernier are matt‑chrome plated, while the contact faces are carbide, chosen for wear resistance and longevity in workshop use. Can this instrument be used in production environments? Yes. The durable contacts, simple analogue operation and included setting ring make it well suited to repeated checks in production and toolroom settings. Manufacturer / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; Germany; +49 2822 7131930; info@metav-werkzeuge.com
4–5mm Three-Point Inside Micrometer Digital Touchscreen Wireless/USB ISO 17025 Calibrated - Microtech Metrology
Take advantage of high measurement repeatability and streamlined data transfer for reliable bore inspection in precision workshops; the combination of 0.003 mm accuracy, a Colour 1.5" touchscreen and Wireless + USB output keeps inspection cycles fast and traceable. Order the Three‑Point Internal Micrometer directly via Metav Werkzeuge or ask our consultants if needed. Three‑Point Internal Micrometer – digital internal measuring instrument with Colour 1.5" touchscreen (Microtech Metrology) The Three‑Point Internal Micrometer is a compact digital instrument designed for precise internal diameter measurement in the micro range, ideal for fine mechanical assemblies and small‑bore quality checks. ISO 17025 calibrated with certificate included Wireless and USB data output Colour 1.5" touchscreen display Measuring range 4.0–5.0 mm, 0.003 mm accuracy Precision where the smallest tolerances count This digital three‑point measuring device delivers a high degree of reproducibility thanks to its rated accuracy of 0.003 mm and a fine reading resolution of 0.0001 mm. The instrument targets the micro measurement class, with a measuring range of 4.0–5.0 mm, so it is particularly suitable for inspection tasks where small diameters and tight tolerances occur. The three‑point contact geometry ensures consistent centring in bores, reducing measurement scatter that typically arises from misalignment. For inspection routines that demand documented evidence, the tool’s metrological performance supports reliable pass/fail decisions in production control. Faster logging and fewer transcription errors Equipped with a Colour 1.5" touchscreen, the instrument simplifies on‑device checks and rapid readouts, while Wireless and USB outputs enable direct transfer of measurement data into quality management systems. This digital workflow reduces manual transcription, shortens inspection cycles and supports traceability chains. The compact display and intuitive controls lower training time for operators, and the immediate digital export allows measurements to be recorded centrally for statistics or long‑term process monitoring, enhancing throughput without sacrificing accuracy. Designed for everyday workshop and laboratory use Built for frequent handling, the device includes an adjustment ring to fine‑tune contact settings and a measurement depth of 22.5 mm, giving access to relatively deep bores for its size class. Delivered fully calibrated to ISO 17025, the instrument arrives with the corresponding calibration certificate, which simplifies acceptance into accredited inspection procedures and quality documentation. The combination of robust three‑point measuring geometry, digital readout and calibrated traceability makes this micrometer a practical choice for precision workshops, small series production and laboratory verification tasks. Contact Metav Werkzeuge for a technical consultation, request the ISO 17025 calibration certificate and arrange delivery from our Emmerich facility Technical data Article number: 133700510 GTIN: 4061905074165 Manufacturer: Microtech Metrology ETIM: EC003590 Facts Measuring range: 4.0–5.0 mm Measuring depth: 22.5 mm Accuracy: 0.003 mm Reading resolution: 0.0001 mm Digital: yes Special features ISO 17025 calibration certificate included Colour 1.5" touchscreen display Data output: Wireless + USB Adjustment ring included Compact three‑point internal measuring system FAQ What is the measuring range of this internal micrometer? The device measures internal diameters from 4.0 to 5.0 mm, designed for micro‑scale bore inspection. Is the instrument supplied calibrated? Yes, the micrometer is delivered fully calibrated to ISO 17025 and includes the calibration certificate for traceable quality records. How are measurement results exported? Measurement data can be transferred via Wireless or USB output for direct logging into quality or SPC systems. For which applications is this instrument best suited? The instrument is intended for fine mechanical parts, small‑bore inspections, watchmaking components and laboratory checks where tight tolerances and documentation are required. What is the measurement depth and how does it affect use? With a measurement depth of 22.5 mm, the instrument can access relatively deep bores for its size, widening its practical use in small assemblies. Manufacturer / Responsible: Microtech, Nizhneyurkovska str., 45a, 04080 Kyiv, Ukraine, tool@microtech.tools
5 mm Replacement Jaws Pair Set For Uni-Micrometers, Paired Delivery - Metav IndustryLine
Take advantage of high interchangeability, compact 5 mm shank mounting and matched measuring faces to ensure fast, repeatable tool changes and minimal setup time; order the insert pairs directly via Metav Werkzeuge or consult the measurement specialists if technical compatibility guidance is required. Insert Pair for Uni-Microm Micrometer — accessory set, 7 pairs, 5 mm shank (Metav IndustryLine) The Insert Pair for Uni-Microm Micrometer supplies matched measuring faces for compact micrometer holders and is intended as an accessory for precision workshop and inspection applications Precision-ground measuring faces 5 mm shank for compact holders Compatible with Uni-Microm micrometers Supplied as matched pairs for repeatability Repeatable precision for small-part inspection The set provides precision-ground measuring faces delivered as matched pairs, which reduces assembly variation when changing contact faces. Matching ensures consistent contact geometry and therefore repeatability across successive measurements, a clear advantage in serial inspection or jig-based checks. The compact 5 mm shank is designed for small-holder systems and allows quick swapping without altering the measurement stack height, helping to keep process variation low and inspection throughput high. Quick fit and reliable compatibility Designed as an accessory for Uni-Microm micrometers, the inserts fit holders with a 5 mm reception and are intended for applications where frequent face changes are required. The modular format shortens downtime during tooling swaps and simplifies spare-part logistics. Material compatibility and face geometry are optimised for fine mechanical measurement tasks, so the accessory set supports both routine workshop checks and repeat quality control steps with minimal adjustment. Practical stocking and workshop benefits The set comprises seven paired inserts, supplied per pair to preserve matched alignment and simplify inventory rotation. With a low individual mass, the items are easy to handle and store; the compact format suits bench-top environments and measurement fixtures. Supplied under the Metav IndustryLine range, the accessory benefits from centralised distribution from Emmerich, improving availability for European workshops and supporting reliable replenishment when spares are required. For Metav IndustryLine inserts and compatibility advice, request the matching insert pairs via Metav Werkzeuge or ask the measurement specialists for guidance on integration and delivery Technical Data SKU: M309.088 GTIN: 4054469117935 Manufacturer: Metav IndustryLine Eclass: 21170324 Customs tariff number: 90173000 Weight: 0.1 kg Facts Shank diameter: 5 mm Set composition: 7 pairs Delivery format: supplied as matched pairs Category: Accessory for measuring instruments Special features Compatible with Uni-Microm micrometers Precision-ground measuring faces Compact design for small-holder systems Supplied in pairs for repeatable alignment FAQ How many insert pairs are included in the set? The set contains seven pairs; each pair is supplied matched to preserve alignment and repeatability. What shank diameter do the inserts use? The inserts use a 5 mm shank suitable for compact Uni-Microm holders. Are the inserts delivered individually or in pairs? The inserts are supplied as matched pairs to ensure consistent contact geometry. Is this accessory compatible with standard micrometer holders? The accessory is designed for Uni-Microm micrometers with a 5 mm reception; compatibility with other systems depends on holder design. What is the product SKU for ordering or inventory? The SKU for ordering and inventory is M309.088 Manufacturer / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; Germany; +49 2822 7131930; info@metav-werkzeuge.com
5 mm Special Ball Insert For Indirect Gear Tooth Thickness Measurement, Module 2.75 - Metav IndustryLine
Take advantage of a compact, purpose‑built contact geometry and matched delivery to speed up gear inspection cycles while preserving measurement consistency; purchase directly from Metav Werkzeuge or consult our technical advisors for application guidance. Special ball insert, 5 mm — accessory for indirect gear tooth thickness measurement (module 2.75) — Metav IndustryLine The Special ball insert 5 mm is a precision measurement accessory intended for indirect assessment of gear tooth thickness on gears with module 2.75, providing a compact contact element for controlled flank engagement. 5 mm diameter contact ball For module 2.75 gear measurement Delivered as a matched pair Compact, lightweight accessory Improved repeatability for tooth thickness checks The compact 5 mm contact radius provides a defined point of engagement that simplifies the conversion from contact measurement to tooth thickness when using indirect methods. By standardising the contact geometry, this accessory reduces variability caused by inconsistent probe contact and helps achieve more reproducible results across repeated checks. The careful sizing is particularly useful where small changes in measured chord length must be translated into accurate tooth thickness values for quality control. Workflow benefits for inspection and maintenance Supplied delivered in pairs, the insert set supports quick replacement and matching between left and right flanks or between successive measurement sessions, which reduces instrument downtime. The lightweight, compact design minimises additional inertia on the measuring head and supports faster cycle times in routine inspection work. As a dedicated accessory for indirect tooth thickness measurement, it streamlines processes in metrology labs and workshop inspection points without requiring major fixture changes. Trustworthy provenance and practical application As part of the Metav IndustryLine portfolio, this precision contact component is manufactured to support consistent measurement routines and to integrate into established gear‑inspection workflows. The geometry is optimised for indirect tooth thickness measurement on module 2.75 gears, offering a pragmatic balance between contact definition and accessibility in confined gear spaces. For complex measurement setups or unusual gear profiles, Metav Werkzeuge’s consultants can advise on adaptor options and best practice for converting contact readings into verified tooth thickness values. Choose the Metav IndustryLine 5 mm ball insert for reliable gear tooth checks and contact Metav Werkzeuge in Emmerich for tailored advice and procurement: info@metav-werkzeuge.com / +49 2822 7131930 Technical data Article number: M309.189 GTIN: 4054469118666 Diameter: 5 mm Module: 2.75 Weight: 0.1 kg Tariff number: 90173000 Core figures Diameter 5 mm Module 2.75 Mass 0.1 kg Article number M309.189 Special features Delivery: pairwise Application: indirect tooth thickness measurement for gears Category: Accessory for measuring devices Compact contact geometry for defined engagement FAQ How does the insert enable indirect tooth thickness measurement? The insert provides a defined contact point; measurements of chord or flank positions made with this Special ball insert 5 mm are converted, by established calculation methods, into tooth thickness values for module 2.75 gears. Which gear module is this accessory intended for? This accessory is optimised for module 2.75 applications and is intended as a precision contact element for indirect tooth thickness checks. Is this item supplied individually or as a set? The component is delivered as a matched pair, supporting immediate use for flank‑to‑flank comparisons or rapid replacement during inspection routines. What identifiers should be quoted when ordering? Please refer to article number M309.189 and GTIN 4054469118666 when specifying this Metav IndustryLine accessory. Can this insert be used with standard gear inspection fixtures? The insert is designed as an accessory for indirect tooth thickness measurement; compatibility with a specific fixture depends on the instrument’s holder and mounting interface—check the adapter requirements against M309.189 before installation. Manufacturer / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; Germany; +49 2822 7131930; info@metav-werkzeuge.com
5-100mm Digital Micrometer With Movable Anvil 0.001mm Readout, Ø6.5mmx30° Measuring Faces, Friction Ratchet, Delivered In Case - Metav IndustryLine
Take advantage of the high-resolution 0.001 mm display, robust carbide measuring faces and a friction thimble for repeatable contact — ideal for production control and incoming inspection. Order the instrument directly via Metav Werkzeuge or ask the consultants for application advice. M302.215 Digital micrometer — 5–100 mm, 0.001 mm resolution (Metav IndustryLine) A M302.215 is a digital micrometer designed for precise dimensional checks in workshop and production environments, covering a measuring range from 5 to 100 mm with fine incremental readout. 0.001 mm digital resolution Carbide measuring faces Ø6.5 mm x 30° Friction thimble for uniform measuring force RB 4.1 data output ready Reduce rejects with measurable precision The instrument delivers a 0.001 mm display resolution combined with a stated accuracy of ±0.005 mm, which translates into reliable control limits for routine quality checks. This level of precision supports tighter tolerances in assembly lines and helps lower scrap rates by catching deviations early. The 5–100 mm range covers common bench and production dimensions, so larger series parts can be inspected without changing tools. The included setting gauge ensures zeroing and baseline verification are straightforward and fast. Durable contact and consistent handling for repetitive tasks A friction thimble provides a controlled, repeatable measuring force that reduces operator influence on results; this contributes directly to process stability during batch inspections. The carbide measuring faces (Ø6.5 mm x 30°) resist wear from frequent contact, extending the instrument’s service life and preserving measurement reliability. A painted, rigid frame stabilises the geometry during handling and supports consistent alignment over the measuring stroke. Ready for data collection and workshop workflows Equipped with an electronic readout and RB 4.1 data output, the device integrates with digital data-loggers and SPC systems to remove transcription errors and speed up reporting. The display offers ON/OFF/SET and ABS/INC/UNIT functions for quick switching between absolute and incremental modes and unit changes. A 2 mm spindle pitch gives predictable axial movement per spindle rotation, aiding fine adjustment during setting or verification. The instrument’s weight and construction reflect a robust build suitable for bench use and routine handling. Choose Metav IndustryLine’s digital micrometer for production-grade accuracy and dependable shop-floor integration — contact Metav Werkzeuge in Emmerich for specification matching and reliable European supply. Technical data Article number: M302.215 GTIN: 4054469151892 Brand: Metav IndustryLine Category: Messschrauben Data output: RB 4.1 Digital display: ON/OFF/SET; ABS/INC/UNIT Facts Measuring range: 5–100 mm Resolution: 0.001 mm Accuracy: 0.005 mm Spindle pitch: 2 mm Measuring faces: Ø6.5 mm x 30° Weight: 2.3 kg Special features Painted frame Carbide measuring faces Friction thimble (ratchet) Setting gauge included Digital output interface RB 4.1 ABS/INC/UNIT readout functions FAQ What is the display resolution and accuracy of this micrometer? The digital readout shows 0.001 mm increments and the instrument specification lists an accuracy of ±0.005 mm for the M302.215 digital micrometer. Are the measuring faces durable for frequent use? Yes, the M302.215 is fitted with carbide measuring faces (Ø6.5 mm x 30°) that are designed for wear resistance in regular shop-floor inspection. Does the micrometer provide consistent measuring force? A friction thimble (ratchet) is integrated to ensure a uniform measuring force and more reproducible results across repeated measurements. Can measurement data be transferred to a computer system? The device supports RB 4.1 data output, enabling integration with data-loggers and SPC systems for automated collection and reporting. Is a zero reference or setting gauge included? A setting gauge is included to facilitate zeroing and quick verification of the micrometer before use. Manufacturer / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; Germany; +49 2822 7131930; info@metav-werkzeuge.com
5-12N Rachet Force Tester For Micrometers With 25/50/75mm Extensions - Metav IndustryLine
Reliable ratchet-force verification with a clear 5–12 N measuring range and detachable 25/50/75 mm extensions improves process control and reduces the risk of inaccurate micrometer readings; compact 0.13 kg construction makes bench handling straightforward. Order the M401.035 directly via Metav Werkzeuge or ask our consultants for application advice and specification support. Ratchet Force Gauge for Micrometers with 25, 50 and 75 mm Extensions — measuring range 5–12 N, Metav IndustryLine The Ratchet Force Gauge for Micrometers with 25, 50 and 75 mm Extensions is a purpose-built accessory for testing and documenting the measuring force of micrometer ratchets in workshop and quality‑control environments. Measuring range 5–12 N Includes 25, 50 and 75 mm extensions Compact and lightweight at 0.13 kg For testing micrometer ratchet force Consistent ratchet-force verification for quality control A clear, limited measuring window centred on 5–12 N provides unambiguous pass/fail criteria when checking micrometer ratchet behaviour, supporting routine quality checks and calibration workflows. The instrument functions as a dedicated force gauge that records whether the ratchet mechanism applies the expected contact pressure; this focused performance reduces measurement uncertainty in repetitive inspections and helps maintain component tolerances across production batches. The design emphasises reproducibility so that results from repeated tests remain comparable and traceable. Adaptable reach for different spindle geometries The accessory set includes three detachable extensions (25 mm, 50 mm and 75 mm) which extend the usable reach for threaded spindles and long micrometer anvils, enabling testing of ratchets with an effective measuring spindle reach of up to 100 mm. The modular extension concept allows the same gauge to be used across a range of micrometer formats without modifying the instrument itself, saving time in toolrooms and reducing the need for multiple dedicated fixtures. This adaptability supports diverse inspection tasks while keeping tool inventory concise. Bench-friendly handling that promotes repeatability At just 0.13 kg, the unit remains easy to position on a workbench or in a test jig, lowering operator fatigue and simplifying setup for frequent checks. The lightweight format combined with a compact footprint aids controlled application of force during each test cycle, contributing to repeatable results. Where procedures demand documented checks, the gauge provides a consistent mechanical reference for verifying ratchet behaviour and can be integrated into standard operating procedures for incoming inspection or in‑process verification. Practical fit into workshop and lab routines As an accessory for micrometer ratchet testing, the device streamlines a common source of measurement error by ensuring ratchet torque and measuring force remain within specified limits; this reduces rework and supports overall product quality. The straightforward functionality makes it suitable for small-scale workshops as well as industrial quality departments that require a robust routine check without complex instrumentation. The compact accessory set is straightforward to store, carry and deploy wherever quick, reliable ratchet checks are required. For reliable micrometer ratchet testing with the Metav IndustryLine M401.035, contact Metav Werkzeuge for purchase and application advice at info@metav-werkzeuge.com or call +49 2822 7131930 Technical Data SKU: M401.035 GTIN: 4054469143644 eClass: 27201590 Category: Measuring instruments > Accessories Manufacturer: Metav IndustryLine Facts Measuring range: 5–12 N Weight: 0.13 kg Extensions: 25 mm / 50 mm / 75 mm Tariff number: 90178090 Special features Accessory for testing micrometer ratchet measuring force Includes extension rods for use up to 100 mm spindle reach Compact, bench‑suitable design for repeatable testing Intended for workshop and quality‑control routines FAQ How does the gauge indicate whether a micrometer ratchet meets its specification? The Ratchet Force Gauge for Micrometers with 25, 50 and 75 mm Extensions measures the applied ratchet force within a defined window (5–12 N) and provides a clear mechanical reference for pass/fail assessment during routine checks. Which micrometer types can be tested with the M401.035? The M401.035 is designed as an accessory for micrometer ratchets and, with its detachable 25/50/75 mm extensions, accommodates a broad range of spindle geometries and standard ratchet micrometers used in workshops and quality labs. Are the extension rods supplied with the unit? Yes, the set includes 25 mm, 50 mm and 75 mm extension rods so the gauge can be used immediately for ratchet checks across different spindle reaches. Can this gauge be used for documentation in quality control procedures? The gauge delivers repeatable mechanical checks that are suitable for inclusion in quality‑control routines; results from the Ratchet Force Gauge can be recorded as part of inspection reports to demonstrate compliance with internal requirements. What is the article number for ordering and inventory? The product is listed under SKU M401.035 and sold via Metav IndustryLine, GTIN 4054469143644 is provided for inventory management. Manufacturer / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; Germany; +49 2822 7131930; info@metav-werkzeuge.com
5-20mm Three-Point External Micrometer 0.01mm Graduation Carbide Faces Ratchet, Supplied in Case - Metav IndustryLine
Take advantage of a compact instrument that combines three‑point measurement, carbide measuring faces and a reproducible ratchet stop for reliable profile checks in series inspection; order via Metav Werkzeuge or contact the Metav consultants for application advice. M309.021 Three‑point screw micrometer — 5–20 mm, 0.01 mm graduation (Metav IndustryLine) The M309.021 is a three‑point outside screw micrometer designed for accurate measurement of triangular and multi‑edge small parts in precision workshops and quality control labs. Three‑point measuring for profile edges Carbide measuring faces for long wear life 0.01 mm graduation with ±0.005 mm accuracy Precision where profile measurement is essential The instrument employs a three‑point measurement arrangement that centres on polygonal cross‑sections, delivering consistent contact on triangular or pentagonal workpieces. With a 0.01 mm graduation and an indicated accuracy of ±0.005 mm, the device separates readable scale resolution from true measurement uncertainty — the fine graduation supports quick read‑outs while the tighter measurement tolerance ensures dependable conformity checks. This combination reduces the need for repeated setups and shortens inspection cycles in production routines. Durable construction for repeatable results A ratchet stop guarantees a uniform measuring force, eliminating variability from operator pressure and improving reproducibility across repeated checks. The contact faces are made of carbide, providing abrasion resistance when used on harder materials and maintaining measuring geometry over many cycles. The frame is painted and the measuring drum is matt‑chromed, offering corrosion protection and a low‑glare surface for clearer reading. Classified as a compact, micro‑range instrument with a 5–20 mm span, it is particularly suited to fine‑mechanical and small‑part environments where tool handling and space are limited. Practical advantages for workshop inspection This analog screw micrometer focuses on the essentials that streamline quality control: rapid profile verification, robust contact faces and a controlled measuring force that together reduce scrap and rework. The compact dimensions make it an efficient companion in dedicated inspection benches or handheld checks during setup. Supplied ready for use in a protective case for safe transport, the unit supports routine calibration workflows and straightforward integration into established inspection procedures. For application support or to procure the Metav IndustryLine M309.021 three‑point screw micrometer directly, contact Metav Werkzeuge in Emmerich for tailored advice and reliable delivery. Technical data SKU: M309.021 GTIN: 4054469117560 Category: Screw micrometers (Messschrauben) Manufacturer: Metav IndustryLine Facts Measuring range: 5–20 mm Graduation (reading): 0.01 mm Stated accuracy: ±0.005 mm Setting increment: 5 mm TARIC / customs code: 90173000 Special features Three‑point outside measuring Carbide measuring faces (HM) Ratchet stop for constant measuring force Painted frame and matt‑chromed measuring drum Analog (nonius) instrument Supplied in a protective case Suitable for triangular and multi‑edge workpieces FAQ What is the measuring range of this micrometer? The M309.021 screw micrometer measures from 5 mm to 20 mm, making it suitable for micro‑range profile checks. How precise is the M309.021 in practical use? The instrument has a graduation of 0.01 mm and a stated measurement accuracy of ±0.005 mm, which supports fine profile assessments and repeatable inspection results. Are the measuring faces durable for regular workshop use? Yes, the measuring faces are made of carbide, offering high wear resistance so the M309.021 maintains geometry and reliability during frequent use. Does the micrometer include features to ensure repeatable measurements? A ratchet stop is fitted to ensure a consistent measuring force, helping to eliminate variability associated with hand pressure during measurements. Is the M309.021 delivered ready for safe transport? The micrometer is supplied in a protective case suitable for transport, ensuring secure handling between workstations or to inspection locations. Manufacturer / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; Germany; +49 2822 7131930; info@metav-werkzeuge.com
5-30mm Bore Micrometer With Microcomputer Colour 2.4" Touchscreen, IP65 - Microtech Metrology
Benefit from compact yet robust measurement that combines high repeatability, reliable workshop protection and flexible data transfer for streamlined quality control. The compact 5–30 mm range and 0.004 mm resolution make this instrument ideal where fine tolerances matter. Order the micrometer (Micrometer for internal measurements) directly via (Metav Werkzeuge) or ask our consultants if needed. Micrometer for internal measurements — 2.4‑inch colour touchscreen, Wireless+USB (Microtech Metrology) The micrometer for internal measurements is a compact, high-resolution instrument intended for precision checks of small bores and internal features in workshops and inspection benches. 2.4‑inch colour touchscreen display Wireless and USB data output IP65 protection for workshop conditions 0.004 mm resolution for repeatable readings Fast, repeatable results where accuracy matters The instrument delivers 0.004 mm resolution across a measuring range 5–30 mm, which translates into highly repeatable readings during routine quality checks. The compact measuring faces (Ø2 mm) reduce contact area for confined bores and ensure stable seating inside small features; this minimises measurement scatter and shortens inspection time. Such precision supports process control in small-part assembly and metrological checkpoints, turning single checks into verifiable records suitable for traceable documentation. Built for daily workshop use and harsh environments A IP65 rating provides protection against dust ingress and water jets, so measuring workpieces at the machine or bench is possible without additional shielding. The solid construction and compact form factor place this tool within the micro‑range class of measuring instruments, making it especially suitable for fine mechanical applications such as watchmaking, small hydraulic components or precision fittings. The included setting ring eases zeroing and routine checks, reducing downtime during shift changes and calibration cycles. Digital connectivity that speeds data workflows Equipped with Wireless and USB outputs alongside a 2.4‑inch touchscreen, the unit simplifies transfer of measurement data into inspection software or spreadsheets without manual transcription. The colour touchscreen improves legibility of results and menus, while the dual data channels enable integration into both mobile measuring routines and fixed data-capture stations. This connectivity reduces administrative overhead and supports faster statistical evaluation or SPC input directly from the measurement step. Practical integration and partner support for procurement Compact dimensions and direct data export make this instrument straightforward to fold into an existing inspection process, whether used at the bench or integrated into a quality-control station. Metav’s service network and product range allow procurement of matching accessories and calibration services from a single source, helping to maintain instrument availability and traceability. For purchasers seeking a reliable supplier, this product combines technical suitability with a partner able to support sourcing and aftermarket needs. For specification advice or to arrange supply from Emmerich, contact Metav Werkzeuge about the Microtech Metrology micrometer and discuss integration options with our technical consultants. Technical data Article number: 133800308 GTIN: 4061905457746 Manufacturer: Microtech Metrology Category: Micrometers Digital: Yes Core specifications Measuring range: 5–30 mm Resolution / accuracy: 0.004 mm Measuring faces: Ø2 mm Protection class: IP65 Display: 2.4‑inch colour touchscreen Data output: Wireless + USB Features / Accessories Includes setting ring Colour touchscreen for clear readings Wireless and USB connectivity Compact micro‑range design for small bores Suitable for workshop and inspection use FAQ How precise is the micrometer and what tolerances can it check? The Micrometer (Microtech Metrology, SKU 133800308) provides 0.004 mm resolution, making it suitable for quality checks and dimensional control where sub‑hundred‑micrometre accuracy is required. Is this instrument made for internal measurements only? Yes, the design and Ø2 mm measuring faces are optimised for internal diameter checks and confined bores, enabling stable contact in small features. How is measurement data exported from the device? Data can be exported via Wireless or USB, and the 2.4‑inch touchscreen simplifies on‑device review before transfer into inspection systems or spreadsheets. Can the micrometer be used at the machine or in damp environments? The IP65 protection rating allows use in dusty or splash‑prone workshop conditions, supporting measurement at the production line or next to machining operations. What is included in the delivery? Delivery includes the micrometer, a setting ring for zeroing/verification and standard packaging as supplied by Microtech Metrology. Manufacturer / Responsible: Microtech, Nizhneyurkovska str., 45a, 04080 Kyiv, Ukraine, tool@microtech.tools
5-30mm External Micrometer Digital, 0.005mm Accuracy, Ø2mm Measuring Faces, IP65, With Setting Ring - Microtech Metrology
Take advantage of the combination of precise digital readout, protected IP65 construction and sub‑0.01 mm repeatability to streamline internal measurement tasks; order the digital inside micrometer directly via Metav Werkzeuge or consult our specialists for application advice. Digital inside micrometer — Microtech Metrology, 5–30 mm, IP65 Digital inside micrometer for fast, repeatable internal measurements in workshops and inspection benches Digital readout with 0.001 mm resolution Measurement range 5–30 mm IP65 protection for dust and moisture Delivered with setting ring for calibration Precision where small tolerances matter The instrument is designed to deliver repeatable internal measurements across a compact measuring span. With a declared accuracy of 0.005 mm and a display resolution of 0.001 mm, the gauge suits quality control tasks that demand better-than-standard tolerances. The digital readout reduces reading errors and the nominalised measurement process supports reproducible results in short-cycle inspection or setup tasks. The protection class IP65 safeguards electronics against coolant spray and shop dust, maintaining reliability in industrial environments. Compact design for fine internal work The measuring faces are small (Ø 2 mm), enabling access to narrow bores and fine features while preserving contact stability. Classified in the micro range (max. 10–100 mm), this form factor balances stiffness and reach for components such as small housings, bore gauges and precision fittings. The device is supplied with a setting ring to simplify zeroing and transfer standards, so the instrument can be integrated into routine calibration intervals without extensive fixturing. The combination of compact anvils and a solid frame minimises deflection during measurement. Practical benefits for production and inspection Integration into inspection workflows is straightforward: the digital readout and compact footprint accelerate measuring cycles, reducing throughput time in batch checks. The instrument is suitable for lab and shop‑floor use where high resolution and a low measurement uncertainty are required. Traceability is facilitated by regular calibration using the included setting ring; for accredited certificates, third‑party laboratory calibration can be arranged. The device is presented as a pragmatic solution for precision internal measurement needs that value speed, robustness and repeatability. For precise internal measurement requirements, request the Microtech Metrology digital inside micrometer from Metav Werkzeuge — contact our Emmerich team at info@metav-werkzeuge.com or +49 2822 7131930 to confirm application fit and delivery options. Technical data Article number: 133800301 GTIN: 4061905457739 Manufacturer: Microtech Metrology Key specifications Measuring range: 5–30 mm Resolution (display): 0.001 mm Accuracy: ±0.005 mm Measuring faces diameter: Ø2 mm Protection class: IP65 Features and accessories Digital readout Supplied with setting ring for calibration Suited to internal measurements Category: Micrometers FAQ What accuracy can be expected from this instrument? The Microtech Metrology digital inside micrometer provides an accuracy of ±0.005 mm with a display resolution of 0.001 mm, making it suitable for high‑precision internal measurements. Is the gauge suitable for use in a production environment? Yes; the IP65 protection rating and digital readout make the gauge robust enough for shop‑floor use while keeping readings fast and reproducible. Does the micrometer come calibrated? The instrument is delivered with a setting ring for straightforward calibration and verification; accredited calibration can be arranged separately if an official certificate is required. What types of bores and components is this instrument best for? With Ø2 mm measuring faces and a 5–30 mm range, the gauge is optimised for small bores, micro components and precision fittings where access and minimal contact area are necessary. Manufacturer / Responsible: Microtech, Nizhneyurkovska str., 45a, 04080 Kyiv, Ukraine, tool@microtech.tools
5-55mm Inside Micrometer Double Measuring Jaws 0.01mm Resolution With Setting Ring, Factory Standard Case - Metav IndustryLine
Take advantage of precise internal measurements, robust mechanical design and included adjustment accessories for reliable inspection results; order the instrument directly via Metav Werkzeuge or consult our specialists for application support. M311.053 Internal micrometer — double anvils, 0.01 mm reading (Metav IndustryLine) A M311.053 internal micrometer designed for accurate measurement of internal diameters in precision workshops and inspection environments Internal measuring range 5–55 mm Mechanical reading with 0.01 mm resolution Double measuring anvils for secure contact Includes setting ring and protective case Precision where measurement counts The M311.053 delivers industrial-grade precision for internal diameter checks. With a mechanical reading of 0.01 mm and a verified accuracy of ±0.006 mm, the instrument supports repeatable results for batch inspection and small-series production. The analogue design ensures direct, latency-free readings and a tactile measuring feel that many technicians prefer for fine adjustments. These specifications translate into measurable time savings during setup and confidence in pass/fail decisions on the shop floor. Robust contact geometry and user-oriented features The micrometer’s double measuring anvils provide a stable contact geometry inside bores and recesses, reducing rocking and improving concentricity during measurement. A dedicated setting ring is included for quick zeroing and routine checks, while the measuring drum matt chrome-plated finish resists glare and simplifies reading under workshop lighting. The analogue mechanism is compact and serviceable, enabling straightforward maintenance and long service life under normal industrial use. Compact range for fine mechanical work Classified in the micro class (compact measuring range up to 100 mm), this instrument covers the measuring range 5–55 mm and is particularly suited to small bores, precision components and detailed inspection tasks in toolmaking, instrument making and precision engineering. The supplied protective case (plastic or wooden) facilitates safe transport and storage between measurement stations, preserving the calibrated condition of the instrument and accessories. Straightforward operation and traceable basis Operation is deliberately simple: the mechanical spindle and vernier-style drum give immediate feedback without software or batteries, and the supplied setting ring supports quick verification routines. The device is produced to the stated factory standard (Werksnorm), providing a clear traceable basis for routine quality checks. For shops that require a no-frills, dependable measuring tool for internal diameters, this mechanical solution reduces complexity while maintaining a high level of metrological performance. For precise internal measurements with a reliable mechanical instrument, request specification advice or place an order through Metav Werkzeuge — Metav IndustryLine specialists are available by phone or e‑mail to assist with selection and delivery arrangements. Technical data Article number: M311.053 GTIN: 4054469119076 Manufacturer: Metav IndustryLine Category: Micrometers (internal measuring) Standard: Werksnorm Facts Measuring range: 5–55 mm Reading / Resolution: 0.01 mm Accuracy: ±0.006 mm Setting measure: 30 mm Tariff code: 90173000 Analogue / mechanical instrument Special features Double measuring anvils Includes setting ring Measuring drum matt chrome-plated Delivered in protective case (plastic or wooden) Mechanical operation, no batteries required FAQ What internal diameters can this instrument measure? The instrument measures internal diameters across the 5–55 mm range and is intended for precision internal checks within that span. Is a calibration certificate supplied with the micrometer? The device is manufactured to the stated factory standard (Werksnorm); a separate factory calibration procedure is applied as part of production. How does the double-anvil design help measurements? Double measuring anvils increase contact stability inside bores, reducing tilt and improving repeatability when taking multiple readings. What is included in the delivery package? Delivery comprises the micrometer, the setting ring for zeroing, and a protective case for safe transport and storage. Is the instrument battery-powered or digital? This is an analogue, mechanical micrometer with a drum reading; no batteries or electronic data output are required. Metav IndustryLine: Manufacturer / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; Germany; +49 2822 7131930; info@metav-werkzeuge.com
5-6mm Three-Point Internal Micrometer Color Touchscreen, Wireless/USB, ISO 17025 Calibrated - Microtech Metrology
The compact digital three-point internal micrometre delivers traceable results for small bores by combining a 5.0–6.0 mm measuring range, a measuring depth of 22.5 mm and an ISO 17025 calibration certificate; order the instrument directly via Metav Werkzeuge or consult the technical team for specification matching. Three-point internal micrometre — Digital three-point internal measuring instrument, 5.0–6.0 mm, Microtech Metrology The three-point internal micrometre is a precision instrument for repeatable inside measurements on miniature bores and internal geometries in precision engineering and watchmaking applications. Colour 1.5" touch display Wireless + USB data output ISO 17025-calibrated delivery Precision engineered for miniature bores This instrument is designed for high-fidelity measurements in very small internal diameters. The device covers a 5.0–6.0 mm measuring range and belongs to the Micro class of micrometres, which is dedicated to extremely compact gauges that demand maximum stiffness and minimal deflection. The three-point measurement principle centres the contact force and minimises eccentricity, producing more consistent readings than single-contact alternatives. With an accuracy ±0.004 mm, the instrument meets the needs of fine mechanical assembly and quality control where every micrometre counts. Digital readout and seamless data transfer A 1.5" colour touchscreen provides clear numerical readouts and menu navigation, reducing interpretation errors on shop floors and in inspection benches. Measurement results can be exported via Wireless + USB, enabling direct logging to inspection software or temporary storage for SPC workflows. The electronic display offers the practical resolution required for detailed checks while the data interface supports integration into paperless documentation chains, shortening the time between measurement and analysis. Traceable calibration for reliable decision-making Delivered with a full calibration certificate performed to ISO 17025, the micrometre arrives ready for use in traceable inspection routines. The ISO 17025 calibration documents measurement uncertainty and conformity, supporting internal audits and supplier quality checks. This level of verification reinforces confidence in acceptance criteria and reduces the need for immediate re-calibration, allowing the instrument to be introduced directly into quality control processes. Handling, adjustment and workshop suitability The tool includes an adjustment ring, which permits fine zeroing and adaptation to inspection jigs without additional fixtures. A measuring depth of 22.5 mm balances reach and stability when accessing shallow internal geometries, while the compact construction aids single-handed operation for rapid serial checks. Robust casing and clear display ergonomics make the instrument suitable for both bench inspection and controlled workshop environments, where reproducibility and operator comfort influence throughput. Contact Metav Werkzeuge for Microtech Metrology micrometre availability and to request the ISO 17025 calibration certificate; reach out via info@metav-werkzeuge.com or call +49 2822 7131930 to align the instrument with specific inspection requirements Technical data Article number: 133700610 GTIN: 4061905074172 Eclass: 21170335 ETIM: EC003590 Manufacturer: Microtech Metrology Facts Measuring range: 5.0–6.0 mm Measuring depth: 22.5 mm Accuracy: ±0.004 mm Display: Colour 1.5" touchscreen Special features Digital output: Wireless + USB Adjustment ring included Delivered with ISO 17025 calibration certificate Category: Micro class internal micrometre FAQ How precise is the measurement on this instrument? The instrument achieves an accuracy of ±0.004 mm, making it suitable for fine mechanical inspections within its 5.0–6.0 mm range. Is a calibration certificate included with delivery? Yes — the micrometre is supplied with a calibration certificate issued to ISO 17025 standards. What data output options are available for inspection logging? Measurement data can be exported wirelessly or via USB for integration into inspection software and SPC workflows. Can the micrometre reach into deeper bores? The measuring depth is 22.5 mm, which supports access to shallow internal geometries typical in miniature components. Which product and brand does the FAQ refer to? These answers refer to the Microtech Metrology three-point internal micrometre, article number 133700610. Manufacturer / Responsible: Microtech, Nizhneyurkovska str., 45a, 04080 Kyiv, Ukraine, tool@microtech.tools
5.5-6.5mm Three-Point Internal Micrometer, Self-Centring, 0.005mm Accuracy, Supplied in Case - Metav IndustryLine
Taking advantage of the combination of self-centring three-point contact, hardened measuring faces and sub‑0.01 mm resolution, this instrument offers reproducible internal measurements for fine mechanical work; order the Three‑point internal micrometer M836.703 directly via Metav Werkzeuge or ask our consultants for application advice. Three-point internal micrometer M836.703 — self-centring, 5.5–6.5 mm range (Metav IndustryLine) Three-point internal micrometer M836.703 is a self-centring internal measuring instrument designed for micro‑diameter measurements in fine mechanical and precision workshop applications. Self-centring three-point measuring jaws Measurement range 5.5–6.5 mm Resolution 0.001 mm for fine readings Hardened measuring faces for durability Precision where small errors matter The instrument delivers an accuracy of ±0.005 mm with a readout resolution of 0.001 mm, making it suitable for demanding inspection tasks in small components. Classified in the micro range, this gauge is intended for measurements up to 10 mm where stiffness and repeatability are crucial; the short span reduces bending and improves reproducibility when checking tiny bores, collars or precision fittings. The numerical specifications and mechanical layout provide a clear, rational basis for selecting this tool for high‑precision assemblies and quality control routines. Built for centred, repeatable internal measurements The self‑centring three‑point contact removes much of the operator‑induced offset that can occur with two‑point probes. Three equidistant contact points automatically centre inside bores, reducing alignment errors and simplifying measurement procedures. Combined with hardened measuring faces, wear is minimised and service intervals are extended, so accuracy is maintained over time. The mechanical (analogue) readout offers proven robustness and eliminates dependency on power supplies, supporting continuous use in workshop environments where reliability matters. Practical integration into the workshop workflow Designed for fine mechanical tasks, the gauge is compact and easy to handle, supporting rapid inspection cycles without compromising precision. The construction allows measured values to be recorded directly in quality documentation or entered into inspection software where needed. As a Metav IndustryLine instrument, it aligns with a supply chain focused on dependable availability and European distribution. For operators seeking a straightforward, durable measuring solution, benefits include reduced rework, clearer acceptance criteria and predictable inspection throughput. Contact Metav Werkzeuge in Emmerich for tailored technical advice or to arrange supply of the Metav IndustryLine three-point internal micrometer M836.703 and related precision tools Technical Data Article number: M836.703 GTIN: 4061905041266 eCl@ss: 21170335 ETIM: EC003590 Designation: Three-point internal micrometer Facts Measuring range: 5.5–6.5 mm Resolution: 0.001 mm Accuracy: ±0.005 mm Analog readout: mechanical Special features Self-centring three-point contact Hardened measuring faces Category: Micrometers / internal measuring instruments Manufacturer: Metav IndustryLine FAQ What measurement range does this gauge cover? The Three‑point internal micrometer M836.703 covers a measuring range of 5.5–6.5 mm, suited to micro‑diameter inspections. How precise is the instrument in everyday use? This Metav IndustryLine instrument offers a resolution of 0.001 mm and an accuracy of ±0.005 mm under normal workshop conditions. Are the measuring faces durable for frequent use? Yes, the gauge features hardened measuring faces that resist wear and help maintain accuracy during repeated measurements. Is the centring mechanism suitable for irregular bores? The self‑centring three‑point contact provides automatic centring in most regular bores; the Three‑point internal micrometer M836.703 is optimised for circular internal diameters and small deviations. Manufacturer / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; Germany; +49 2822 7131930; info@metav-werkzeuge.com
5.5-7 mm Thread Micrometer Anvil Set 60° Tip D=5 mm - Metav IndustryLine
Take advantage of precise contact geometry and a compact measuring range for reliable thread checks; the 60° profile and 5.5–7.0 mm span make this insert pair ideal for rapid, repeatable inspection of small metric threads. Order the insert pair directly via Metav Werkzeuge or consult our specialists for application advice. Insert pair for thread micrometer M309.090.6 – 5.5–7.0 mm, 60° profile A insert pair for thread micrometer designed for measuring metric threads from 5.5–7.0 mm with a 60° flank angle and 5 mm measuring face diameter. Precision 60° thread profile Measuring range 5.5–7.0 mm 5 mm measuring face diameter Accurate thread geometry for consistent measurement results The insert pair provides a defined 60° profile, matching the standard metric thread geometry and therefore ensuring correct contact with the flanks during inspection. This profile reduces systematic deviation that can occur when using generic tips and supports consistent readings on a dedicated thread micrometer. The compact measuring span addresses small-diameter threads where precise flank contact is critical, so the insert pair becomes a targeted solution for repeatable quality checks in production and inspection environments. Compact range and compatibility that simplify metrology workflows With a measuring span of 5.5–7.0 mm and a 5 mm measuring face, the inserts are optimised for small to medium metric thread sizes and intended as accessory components for thread micrometers. The insert pair format allows rapid replacement and inspection without recalibrating the entire instrument, improving process throughput. Where quick interchangeability and unambiguous fitment are required, these inserts support efficient measurement cycles and reduce downtime between different thread checks. Practical handling and inspection considerations The inserts are supplied as a matched pair to preserve the reference geometry necessary for reliable comparative measurements. Using dedicated inserts for a specific diameter range limits wear patterns and helps maintain measurement stability over time. For routine quality assurance, keep the inserts clean and store them in a protected holder when not in use; this preserves the contact faces and maintains the expected contact geometry for accurate readings across many measurement cycles. Suitable uses and typical application scenarios This accessory is aimed at metrology departments, tool rooms and quality-control benches where metric thread form verification is required. Typical applications include final inspection of small fasteners, spot checks during production runs and verification tasks in maintenance workshops. The clear definition of range and profile makes the insert pair a practical choice when a thread micrometer must deliver reproducible, traceable results on threads within the specified span. Contact Metav Werkzeuge for technical confirmation or to order the M309.090.6 insert pair; our Emmerich team can advise on compatibility and process integration Technical data SKU: M309.090.6 GTIN: 4054469118086 Weight: 0.1 kg Measuring range: 5.5–7.0 mm Flank angle: 60° Measuring face diameter: 5 mm Tariff number: 90173000 ECLASS: 21170324 Numbers / Core technical data Weight (kg): 0.1 Measuring span (mm): 5.5–7.0 Angle (°): 60 Face diameter (mm): 5 GTIN: 4054469118086 Special features / Design Matched insert pair for thread micrometers 60° metric thread profile Compact range for small-diameter threads Accessory category: metrology / measuring equipment Intended for repeatable, bench-level inspections FAQ What thread sizes can be measured with these inserts? The insert pair covers metric threads in the 5.5–7.0 mm range and is intended for use with thread micrometers that accept 5 mm measuring faces. Are these inserts supplied as a matched set? Yes, the product is delivered as a matched insert pair (SKU M309.090.6) to preserve contact geometry and ensure repeatable readings. Which flank angle do the inserts use and why does it matter? The inserts feature a 60° flank angle, matching standard metric thread geometry; this ensures correct flank contact and reduces systematic measurement error. Can these inserts be used across different micrometer brands? Compatibility depends on the micrometer's insert holder and face diameter; the inserts are designed for holders that accept a 5 mm measuring face—consult Metav Werkzeuge for compatibility details. Manufacturer / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; Germany; +49 2822 7131930; info@metav-werkzeuge.com
50 mm Built-In Micrometer With 0.002 mm Vernier, 8 mm Spindle, 100 Division, Flat Measuring Faces, DIN 863 - Metav IndustryLine
Take advantage of the combination of precise inset design, a 49 mm large drum for effortless reading and a carbide measuring spindle for durable contact; order the micrometer directly via Metav Werkzeuge or ask our consultants if needed. Metav IndustryLine M303.171 inset micrometer – 50 mm, large 49 mm drum The Metav IndustryLine M303.171 is an inset micrometer designed for compact installation and fine mechanical measurement tasks, offering a 0–50 mm range and a prominent drum for rapid, reliable readings. Large 49 mm measuring drum for clear reading Carbide measuring spindle for wear resistance Fine reading: 0.002 mm resolution Precise inset measuring where space is limited The inset design places high-accuracy measurement capability into confined or mounted fixtures, making this instrument well suited to precise assembly and inspection jigs. Featuring a 0–50 mm measuring range, the device falls into the micro category for compact micrometers, where stiffness and control over short measuring spans are decisive. The carbide measuring spindle provides a hard-wearing contact face that resists deformation, which maintains measurement integrity over repeated use and reduces recalibration frequency. Compliance with DIN 863 assures that the device meets recognised workshop standards for mechanical micrometers. Large drum and fine graduation for faster, dependable readings A 49 mm drum significantly increases the readable scale area, which reduces eye strain and speeds up routine measurements in production. The instrument features a 100-division drum combined with a fine reading specification of 0.002 mm, enabling precise interpretation of small increments without complex conversion. The 8 mm spindle diameter and a measured spindle pitch of 1 mm contribute to a robust feel and consistent travel per revolution, supporting repeatable results when used in repetitive inspection tasks. This arrangement improves throughput in quality control while keeping operator workload low. Built for workshop durability and straightforward integration Constructed for installation use, the instrument’s flat-parallel measuring faces and solid spindle construction ensure stable contact geometry and long-term repeatability. The analogue, mechanical design eliminates dependency on batteries and electronic interfaces, simplifying integration into fixed gauges or measuring stations. The relatively light mass supports easy handling during assembly and when fitting into panels or fixtures. Where traceable calibrations are required, standard workshop procedures apply; Metav IndustryLine supplies instrument data and specification details to support in-house quality processes. Choose the Metav IndustryLine M303.171 for reliable inset measurement with a large drum and robust carbide spindle — contact Metav Werkzeuge for product matching and installation advice. Technical Data Article number: M303.171 GTIN: 4054469115788 Category: Micrometer screw (inset design) Weight: 0.7 kg Standard: DIN 863 Tariff number: 90173000 Facts Measuring range: 0–50 mm Resolution / fine reading: 0.002 mm Drum diameter: 49 mm Spindle diameter: 8 mm Spindle pitch: 1 mm Special features Carbide measuring spindle Analogue mechanical readout 100-division drum graduation Flat-parallel measuring faces Designed for inset/panel mounting FAQ What measuring range does this instrument cover? The instrument covers a 0–50 mm measuring range and is classified in the micro category for compact, high-precision tasks; the Metav IndustryLine M303.171 is tailored to short-span measurements. Is the reading resolution suitable for fine workshop checks? Yes. The M303.171 provides a fine reading of 0.002 mm, combined with a 100-division drum and a large 49 mm drum face for easier interpretation during inspection routines. What material is used for the measuring spindle? The measuring spindle is made with a carbide contact surface, ensuring wear resistance and prolonged dimensional stability under repeated use. Manufacturer / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; Germany; +49 2822 7131930; info@metav-werkzeuge.com
50 mm Digital Inset Micrometer 0–50 mm x 0.001 mm, Carbide Faces, Ratchet Stop, DIN 863 - Metav IndustryLine
Take advantage of the combination of high-resolution measurement, carbide wear resistance and digital data output to keep inspection processes fast and reliable. Order the M302.093.C directly via Metav Werkzeuge or ask our consultants if additional integration advice is required. M302.093.C Digital Built-in Micrometre — 0–50 mm, 0.001 mm resolution — Metav IndustryLine The M302.093.C is a compact built-in micrometre designed for precise thickness and diameter checks in production and testing environments, ideal where space and repeatability matter 0.001 mm resolution for fine measurements Carbide measuring faces for wear resistance Integrated ratchet for constant measuring force RB 4.1 data output for process integration High-precision measurement for consistent quality This built-in instrument offers a measuring range of 0–50 mm with a reading step of 0.001 mm, delivering the fine granularity required for modern quality control. The specified measurement accuracy of 0.006 mm provides a verifiable basis for tolerance checks and acceptance decisions, while conformity with DIN 863 ensures the device fits established workshop and inspection workflows. These characteristics translate directly into fewer rejected parts and shorter set-up times when incorporated into standard inspection routines. Durable contact and reliable repeatability Wear-critical surfaces are fitted with carbide (HM) measuring faces, ensuring long service life and steady performance under frequent use. A built-in ratchet guarantees a constant measuring force, reducing variability introduced by manual operation and improving repeatability across operators. The instrument features plan-parallel contact faces and a robust spindle of 6.5 mm, giving a stable contact geometry that helps sustain measurement stability over thousands of cycles. Built-in format and digital integration for modern workflows Designed for panel or fixture mounting, the unit’s built-in design eases integration into test benches and production lines. The digital display provides ON/OFF, ABS/INC, UNIT and SET controls for straightforward operation, while the RB 4.1 data output permits direct transfer of measured values to data loggers, SPC systems or custom interfaces — supporting traceable results and automated documentation. The compact mechanism and an overall weight of 0.5 kg simplify handling and installation within confined assemblies. Practical benefits for workshop and production use The functional combination of a compact form factor and precise electronics makes this instrument suitable for final inspection, in-process checks and embedded measurement tasks where space is limited but accuracy remains essential. The mounting option 12 h7 facilitates secure integration into fixtures. Supplied as a built-in device, it reduces mechanical adaptation time and helps speed up machine acceptance and routine checks on the production floor. Discuss integrating the M302.093.C into existing inspection fixtures with Metav Werkzeuge — contact Metav Werkzeuge for technical consultation and reliable supply from Emmerich. Technical data Article number: M302.093.C GTIN: 4054469114545 Manufacturer: Metav IndustryLine Category: Micrometres Measuring range: 0–50 mm Resolution: 0.001 mm Accuracy: 0.006 mm Measuring faces: Carbide (HM), plan-parallel Spindle diameter: 6.5 mm Mounting: 12 h7 Display: ON/OFF, ABS/INC, UNIT, SET Data output: RB 4.1 Weight: 0.5 kg Standard: DIN 863 Key figures Measuring range min: 0 mm Measuring range max: 50 mm Reading in inches: 0.00005 in Weight: 0.5 kg Spindle: 6.5 mm Accuracy figure: 0.006 mm Special features Built-in design for panel or fixture mounting Carbide measuring faces for extended wear resistance Ratchet stop for consistent measuring force Digital readout with selectable absolute/incremental modes RB 4.1 data interface for digital process integration FAQ Is the M302.093.C suitable for integration into production fixtures? Yes. The M302.093.C built-in micrometre by Metav IndustryLine has a 12 h7 mounting interface and an RB 4.1 data output, which facilitates secure fixture mounting and data transfer to process systems. What level of accuracy can be expected from this instrument? The device is specified with an accuracy of 0.006 mm and a resolution of 0.001 mm, making the M302.093.C suitable for standard workshop inspection and many precision production applications. Are the measuring faces resistant to wear from frequent use? Yes. The micrometre is fitted with carbide (HM) measuring faces, providing increased wear resistance and longer intervals between service or replacement. How is the digital readout operated and what functions are available? The digital display includes ON/OFF, ABS/INC, UNIT and SET functions for routine measurement modes and zeroing, and it supports incremental and absolute measurements for flexible use. Can measurement values be recorded automatically? Measurement values can be exported via the RB 4.1 data output, enabling connection to statistical process control software or data loggers for automated documentation. Manufacturer / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; Germany; +49 2822 7131930; info@metav-werkzeuge.com
50 mm Setting Gauge For Bore Measurement, Lapped Measuring Faces, 0.3 kg - Metav IndustryLine
Take advantage of a compact, 50 mm reference length with finely lapped measuring faces and a machining tolerance of ±0.002 mm to ensure repeatable internal-measurement setups; order the setting gauge directly via Metav Werkzeuge or consult our specialists for application advice. Setting gauge for internal measurement, 50 mm — Metav IndustryLine, finely lapped faces for precision referencing The Setting gauge for internal measurement, 50 mm is a purpose-built reference tool for precise internal bore set-up and calibration tasks in workshops and inspection rooms. Finely lapped measuring faces 50 mm reference length Tolerance ±0.002 mm Compact Micro-class reference Reliable reference for small-bore measurement setups A compact reference standard with a 50 mm nominal length, this gauge provides a stable basis for adjusting internal measuring instruments. The finely lapped measuring faces minimise surface irregularities and ensure consistent contact geometry during each adjustment, which reduces setup variation. With a machining tolerance of ±0.002 mm, the device supplies a traceable dimensional benchmark that shortens instrument configuration times and improves process repeatability. The consequence is fewer measurement-related rejects and a smoother quality-control workflow. Built for fine mechanics and workshop calibration tasks Classified in the Micro class (10–100 mm), this reference is tailored to fine-mechanical work where stiffness, compactness and handling matter. The small footprint keeps lever arms short, which lowers the risk of bending or torsion during use and supports reliable alignment of internal probes. As an accessory intended for internal measurement referencing, the component complements bench micrometres and comparators, helping maintain calibration intervals and reducing the need for repeated trial-and-error adjustments. Integrates into setup routines to save time and increase confidence By serving as a fixed dimensional baseline, the gauge streamlines the correction of two-point internal measuring devices and similar instruments, making routine set-ups faster and less error-prone. The robust face finish reduces wear and provides consistent tactile feedback when seating measuring anvils, which supports reproducible contact force across multiple cycles. The clear numerical tolerance and compact form factor make this gauge a practical addition to inspection kits where quick, reliable referencing is required, supporting both production and laboratory environments. Choose the Metav IndustryLine 50 mm setting gauge via Metav Werkzeuge for assured internal-measurement referencing and contact our Emmerich advisers for tailored application guidance Technical data Article number: M311.081 GTIN: 4054469119182 EClass: 21170102 Customs tariff number: 90173000 Numbers / Core technical data Reference length: 50 mm Accuracy / tolerance: 0.002 mm Special features Finely lapped measuring faces Intended as internal-measurement reference Category: Accessory FAQ How accurate is the setting gauge for internal measurement? The setting gauge for internal measurement is manufactured to a tolerance of ±0.002 mm, providing a precise reference for internal-measurement set-ups. Can this gauge be used for calibration of internal micrometres? Yes. The setting gauge serves as a compact reference standard suitable for adjusting and checking internal measuring instruments (SKU M311.081). What class of measurement range does this gauge belong to? The device is in the Micro class (10–100 mm), making it well suited to fine-mechanical tasks and compact inspection setups. What are the primary benefits of the lapped faces? Finely lapped measuring faces ensure consistent contact geometry, reduced wear and improved repeatability during repeated set-ups. Manufacturer / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; Germany; +49 2822 7131930; info@metav-werkzeuge.com
Precision micrometers built for repeatable accuracy
Micrometers—also referred to as micrometer screw gauges or micrometer callipers—are compact, robust instruments for fast, highly accurate length measurement of small to medium workpieces. Designed for routine use on the shop floor, these tools combine mechanical reliability with options for digital data capture, making them indispensable where repeatable tolerances matter.
How micrometers work and where they belong in production
Micrometers operate on a finely threaded spindle that brings two measuring faces into alignment with the workpiece; many designs follow the Abbe comparator principle so that the measuring axis and scale are collinear, reducing tilting errors. Typical outside micrometers (bühlermessschrauben) provide readings down to 1/1000 mm (0.001 mm) in analogue form; internal micrometers and specialised two- or three-point gauges enable accurate diameter and bore measurements, while depth micrometers cover depths from 0–300 mm. Hardened carbide (HM) measuring faces are standard to prevent wear and maintain accuracy over time. Digital variants offer easy reading, unit switching (mm/inch) and data output via USB, RS interface or Bluetooth; advanced models with an integrated minicomputer support Go/NoGo checks, temperature compensation and wireless transmission up to 50 m.
Practical benefits that improve shop‑floor performance
- Reduced rework and higher first-pass yield thanks to repeatable accuracy and carbide-tipped measuring faces.
- Faster, safer measurement cycles by using the ratchet/coupling to limit measuring force to 5 N to 10 N, protecting both part and instrument.
- Flexible inspection workflows with analogue, digital and minicomputer options, including wireless data transfer and mm/inch toggle.
- Versatile coverage with outside, internal, depth and built-in micrometers offering measuring ranges from a few millimetres up to 300 mm and resolution down to 2 µm (internal) or 0.003 mm (standard depth micrometers).
- Durable operation in workshop environments: mechanical models resist dust and moisture, while digital versions are available with IP54 protection.
Metav — a precision partner you can rely on
Metav combines decades of technical expertise with a broad, quality-filtered product range from its Emmerich hub. Over 48,000 customers trust Metav’s offer of more than 250,000 products, which simplifies procurement and secures reliable supply for industry, trade and specialist retailers. For buyers seeking micrometers with consistent performance and traceable data capture, Metav’s selection and technical support make it a practical, long-term choice.
In short
Micrometers provide robust, highly repeatable measurement for external, internal and depth applications, available in analogue, digital and minicomputer formats to match precision requirements and data‑management needs.
FAQ
How precise are micrometers for internal measurements?
Internal micrometers in the micrometers category can achieve accuracies around 2 µm when correctly used; digital and minicomputer models improve readout convenience and data integration for traceable inspection results.
When is a digital micrometer preferable to an analogue one?
Choose a digital micrometer when easy readout, unit conversion (mm/inch), or data transmission is required. Digital models with IP54 rating also offer dust and splash protection, while analogue micrometers remain the most robust option in harsh environments.
What measuring force should be used to ensure consistent results?
The recommended measuring force for micrometers is 5 N to 10 N. Use the ratchet or friction thimble to apply this consistent force and rely on the insulating sleeve to minimise heat transfer from the hand.
Can depth micrometers measure small bores and tight features?
Yes. Depth micrometers use a fine needle or flat measuring face and, with suitable extensions, cover narrow or deep features; standard depth micrometers typically span 0–300 mm with accuracies near 0.003 mm, while specialised digital systems offer even higher resolution.
