Quick, secure clamping with lever clamps
Lever clamps provide rapid, repeatable workholding for fixture building, assembly, welding and testing, using the kinematic knee-lever principle to deliver self-locking retention and resist process vibrations. Designed for metalworking applications and made from high-strength materials such as zinc-plated steel or stainless steel, these clamps reduce setup and handling times while enabling high holding forces with minimal operator effort. Available in vertical and horizontal versions as well as thrust bar and closure styles, lever clamps ensure consistent positioning, long service life and enhanced process reliability for serial production. Key advantages include self-locking mechanism, high repeatability, reduced setup time and robust construction.
800N Push-Pull Hand Clamp, M5x35 Actuating Spindle, 970N Holding Force, Blackened Finish - Kukamet
Take advantage of a compact, low-mass clamp that delivers 800 N pressing force and 970 N holding force for reliable part retention; the simple M5x35 pressure spindle and black oxide finish keep maintenance low and integration straightforward. Order directly via Metav Werkzeuge or consult our team for application advice. Push-rod clamp 513 — Kukamet compact clamp with 800 N pressing force The Push-rod clamp 513 is a compact mechanical clamp designed for secure workholding in light-duty fixtures and jigs, offering a robust holding capacity in a small footprint. Compact push-rod clamp for light fixtures 800 N maximum pressing force 970 N holding force for reliable retention Black oxide finish for corrosion resistance Secure retention for light fixtures and jigs The rod-style clamping mechanism provides a measurable retention effect that is well suited to assembly fixtures, inspection jigs and small machining setups. With a rated holding force of 970 N and a separate pressing force of 800 N, the device delivers consistent clamping performance that reduces part movement during operation. This stability translates into fewer rejects and less rework, supporting a more economical production flow without needing heavy-duty equipment. Precise actuation and compact installation Actuation is achieved via the integrated pressure spindle in size M5x35, which enables fine adjustment and secure locking. The compact design, with a mass of 0.095 kg, allows for installation in confined spaces and makes the component particularly suitable where several clamps must be arranged densely. Because the unit is supplied without a mounting foot, it can be built directly into bespoke fixture plates or modular tooling systems, permitting tailored placement and improved accessibility in complex assemblies. Robust surface treatment for workshop use A black oxide finish provides a protective layer that reduces visible wear and offers moderate corrosion resistance in typical workshop atmospheres. This surface treatment helps to preserve functional surfaces and maintains the clamp’s reliable operation over repeated cycles. The finish also minimises reflective surfaces, which is advantageous in inspection areas and optical setups where glare is a concern. Straightforward integration and dependable supply The mechanical simplicity of the clamp minimises service needs: routine checks and occasional spindle lubrication suffice to maintain performance. The compact architecture and standard spindle thread make retrofitting into existing fixtures practical and time-efficient. Backing this hardware is Metav Werkzeuge’s distribution and quality-control presence in Emmerich, ensuring consistent supply and a traceable quality filter for European workshops and small-scale production environments. Contact Metav Werkzeuge for application support on the Kukamet push-rod clamp 513 — call +49 2822 7131930 or email info@metav-werkzeuge.com to confirm suitability for specific fixtures or to request order information. Technical data SKU: B513-1 GTIN: 8680731508741 Manufacturer: Kukamet Weight: 0.095 kg Maximum pressing force: 800 N Maximum holding force: 970 N Pressure spindle: M5x35 Facts Category: Clamp Mounting: without base Finish: black oxide finish Special features Compact design for dense fixture layouts Low mass for minimal load on substructures Suited for light-duty workholding and jigs FAQ What materials is the clamp suited for? The clamp 513 is intended for light-duty workholding and can be used with a wide range of workpiece materials in fixture and jig applications, depending on the specific process and fixturing strategy. How is the clamp adjusted? Adjustment is performed with the integrated M5x35 pressure spindle; the spindle allows fine setting of clamping travel and pressure to match the application. Can the clamp be mounted directly to a fixture plate? Yes, the unit is supplied without a mounting foot so it can be integrated directly into fixture plates or modular tooling systems. Is the surface treatment corrosion resistant? The black oxide finish provides moderate corrosion protection appropriate for typical workshop environments and helps reduce surface reflections. Which SKU should be ordered for this model? Order SKU B513-1 for the Kukamet push-rod clamp 513; reference GTIN 8680731508741 for logistics. Manufacturer: Kukamet Fevzi Çakmak Mah.10644 Sk. No:61-63 42050 Karatay / KONYA TÜRKİYE / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; +49 2822 7131930; eMail: info@metav-werkzeuge.com
80mm Clamping Base Open Mounting Hole M10, Height Extension 80mm - BESSEY
Take advantage of a robust mounting solution that combines a compact design with a clear 80 mm clamping height extension and an M10 fixing thread for reliable machine-side installation; order directly via Metav Werkzeuge or request advice from our consultants for precise application support. BESSEY clamping base 80 mm — open fixing bore, M10 thread BESSEY clamping base 80 mm for BAS compact clamps, designed to provide increased clamping height and straightforward attachment via an open fixing bore suitable for M10 fastening Compact base for BAS clamping systems 80 mm clamping height extension Open fixing bore with M10 thread Compatible with DIN 912 M10 / M12 screws Increased setup flexibility through measurable clamping height The 80 mm clamping height extension offers a measurable advantage when adapting fixtures and jigs to different workpiece geometries. Designed as a clamping base for BAS compact clamps, the unit converts vertical clearance into usable clamping range, reducing the need for additional spacers. The straightforward specification of the height extension and thread means predictable setup times and fewer trial adjustments on the shop floor, which improves overall process efficiency and repeatability. Reliable fastening with standardised threads for quick integration Equipped with an M10 thread and prepared for DIN 912 cylinder screws in sizes M10 / M12, the component integrates with common fastening hardware used across maintenance and production environments. The specification ensures mechanical compatibility with industry-standard screws, enabling secure, vibration-resistant mounting. This standardisation reduces inventory complexity and simplifies procurement, supporting faster tool changeovers and a lower risk of incorrect fasteners being used at the workstation. Compact form factor that supports modular fixturing The product’s configuration for Compact clamp BAS systems and its open fixing bore make it an effective modular element in clamping assemblies. The compact footprint preserves workspace and allows closer placement of clamps for better load distribution. Where space constraints or tight clamping patterns are present, this mounting base helps maintain accessibility while delivering the required stability for machining, assembly, or inspection tasks. Clear benefits for production and workshop environments By combining a compact design, standard thread compatibility and a defined clamping height extension, the component offers an immediate productivity payoff: fewer bespoke adapters and faster fixture assembly. The clarity of technical parameters supports maintenance planning and quality control procedures, helping to ensure that fixtures perform predictably under repeated use. For workshops seeking pragmatic, durable mounting elements, the specification-driven approach lowers the barrier to consistent, repeatable clamping. For bespoke advice on integrating this BESSEY clamping base into existing BAS clamp setups or for ordering and logistics, contact Metav Werkzeuge — fast delivery from Emmerich and technical consultancy available by phone or e‑mail Technical Data Article number: 4123716070NW Label: Aufspannsockel 80mm Befestigungsbohrung offen Gew.M10 BESSEY Product type: Clamping base Manufacturer: BESSEY Version: for Compact clamp BAS; open fixing bore Facts Clamping height extension: 80 mm Thread: M10 For cylinder screw DIN 912: M10 / M12 Packaging unit: 1 Special features Open fixing bore Designed for BAS compact clamp systems Standardised thread compatibility FAQ What is the main function of this clamping base? The clamping base provides an 80 mm increase in clamping height for BAS compact clamps and a stable mounting point via an open fixing bore designed for M10 fastening. Which screws are compatible with the fixing bore? The fixing bore accepts cylinder screws to DIN 912, specifically stated for M10 and M12 sizes to ensure reliable mechanical attachment. Can this base be used with other clamping systems? Although configured for BAS compact clamps, the BESSEY clamping base can be integrated into other modular fixtures where an M10 threaded mounting and 80 mm height extension meet the application requirements. Manufacturer / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; Germany; +49 2822 7131930; info@metav-werkzeuge.com
82° 3500 N Clamping Screw Clamp With Flat Base, Zinc Plated, 4000 N Holding Force - Kukamet
Built for dependable fixturing in workshop and light industrial settings, the combination of a 4,000 N holding force, 3,500 N clamping force and a zinc-plated finish ensures secure, long-lasting performance; order the clamp directly via Metav Werkzeuge or consult our advisors for rapid delivery from Emmerich. Kukamet 841 Screw Clamp — robust lever-style screw clamp with 4,000 N holding force Kukamet 841 is a screw clamp designed for stable fixturing in workshop jigs and production benches, offering a compact footprint and robust mechanical performance. Zinc-plated body for corrosion resistance 4,000 N maximum holding force 3,500 N peak clamping force Flat base for stable fixture at 82° angle Secure clamping that reduces repositioning and rework The clamp delivers a measurable improvement in part retention thanks to its 4,000 N holding force and 3,500 N clamping force, which together provide secure fixation during machining, assembly and test operations. As a lever clamp, it converts operator input into repeatable force, reducing the risk of movement under load; this reliability translates into fewer interrupted cycles and less rework. Technical values such as the 82° working angle and specified forces make it straightforward to compare fixture options and select the right device for production requirements. Compact mounting and corrosion-resistant construction for workshops Designed with a flat base, the unit installs neatly on benches, plates or custom fixtures, keeping the clamping surface close to the workpiece for improved stability. The zinc-plated finish offers enhanced resistance to everyday workshop corrosion, extending functional life in environments where coolant splash or humidity occur. At 2.02 kg, the clamp provides a solid feel without excessive bulk, simplifying handling during setup while maintaining robust mechanical behaviour. Practical procurement and reference information for planners The clamp is suited to repetitive tasks in metalworking, fabrication and fixture building where a reliable mechanical hold is required. For ordering and inventory control, refer to SKU 841-2-D and GTIN 8680731505207 when specifying the product in procurement lists. The clear specification of forces and mounting type supports risk-averse decision-making in production planning and helps maintenance teams keep a consistent set of replacement units on hand. Contact Metav Werkzeuge for tailored advice and secure availability of the Kukamet 841 screw clamp from our Emmerich warehouse — call +49 2822 7131930 or email info@metav-werkzeuge.com Technical Data SKU: 841-2-D GTIN: 8680731505207 Category: Spanner Key Figures Weight: 2.02 kg Maximum clamping force: 3,500 N Maximum holding force: 4,000 N Angle: 82° Materials & Features Material: zinc-plated Mounting: flat base Clamp type: screw clamp Special feature: screw clamp design FAQ What applications are suitable for this clamp? The Kukamet 841 screw clamp (SKU 841-2-D) is intended for workshop jigs, fixture plates and light production work where a repeatable mechanical hold is required. How is the clamp mounted? Mounting is via the flat base, which allows secure attachment to benches or plates; the 82° working angle supports common fixture geometries. Which specifications should be used to compare alternatives? Compare maximum holding force (4,000 N) and maximum clamping force (3,500 N), along with base type and material finish, to assess suitability. Is the finish suitable for damp workshop environments? The zinc-plated surface provides standard corrosion resistance appropriate for many workshop conditions, extending service life compared with bare steel. How is the clamp referenced for ordering and stock control? Use SKU 841-2-D and GTIN 8680731505207 for procurement, stock management and spare-part requests. Manufacturer: Kukamet Fevzi Çakmak Mah.10644 Sk. No:61-63 42050 Karatay / KONYA TÜRKİYE / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; +49 2822 7131930; eMail: info@metav-werkzeuge.com
85° 821 Quick Clamp Vertical Base Screw Clamp, 3.5 kN Thrust / 4 kN Holding, Zinc-Plated - Kukamet
Take advantage of a galvanised, lever-operated clamp that combines compact mounting and dependable holding power for secure fixture integration; order the clamp directly via Metav Werkzeuge or consult our specialists for specification support. Schnellspanner 821 — Galvanised quick-action lever clamp with vertical foot (Kukamet) The Schnellspanner 821 is a compact, vertical-foot quick-action lever clamp designed for robust workpiece retention in industrial fixtures and workshop jigs. Galvanised construction for corrosion resistance Vertical foot for compact fixture mounting Clamping force up to 3,500 N Holding force up to 4,000 N Secure clamping where space is limited The compact design of this lever clamp makes it well suited to tight fixturing situations. Thanks to the vertical foot, the device occupies minimal lateral space while enabling a low-profile attachment to plates or bases. The galvanised finish provides a durable protective layer against corrosion, reducing the frequency of replacement in harsh workshop environments. The unit’s modest mass (0.81 kg) contributes to easier handling during assembly of jigs and keeps overall fixture weight low without compromising structural integrity. High holding performance for reliable production processes Engineered for repeatable securing, the clamp delivers a clamping force of up to 3,500 N and a holding force of up to 4,000 N, values that translate directly into stable workpiece immobilisation under machining or assembly loads. The lever-actuated mechanism converts user input into consistent pressure, helping to reduce set-up time and minimise variability between clamping cycles. For applications where fixture repeatability and process stability are priorities, this quick-action lever clamp provides measurable operational advantages. Robust construction for continuous workshop use Constructed from galvanised steel, the clamp resists surface corrosion and maintains functional surfaces for extended service life. The screw-clamp style arrangement offers fine adjustment of the clamping contact, making it adaptable to slight variations in workpiece height while preserving a secure hold. An 85° operating angle provides predictable ergonomic actuation in confined spaces. Overall, the component is intended as a practical, long-term element of industrial fixtures and manual jigs where reliability and straightforward maintenance are required. Consider Metav Werkzeuge’s Kukamet lever clamp for dependable fixture performance; contact Metav Werkzeuge for application advice or to confirm compatibility with existing jigs — Metav Werkzeuge is ready to assist from its European distribution centre in Emmerich Technical Data Article number: 821-2 GTIN: 8680731504422 Manufacturer: Kukamet Core specifications Weight: 0.81 kg Clamping force (max): 3,500 N Holding force (max): 4,000 N Operating angle: 85° eClass: 21020701 ETIM: EC011973 Features and materials Material: galvanised steel Fastening method: vertical foot Special feature: screw-clamp type Product family: lever/quick-action clamp Included files: product image, catalogue PDF FAQ What is the maximum clamping force of this clamp? The clamp provides a maximum clamping force of 3,500 N, which ensures firm retention in typical fixture and jig applications. How much holding force can be expected during operation? A holding force of up to 4,000 N is specified for this unit, offering reliable resistance against displacement under load. What type of mounting does the clamp use? The clamp is fitted with a vertical foot for compact and low-profile mounting to fixture bases or plates. Is the clamp suitable for use in damp workshop conditions? The galvanised finish enhances corrosion resistance, making the clamp more resilient in environments with occasional moisture, though long-term exposure may require additional protection. Can the clamp be adjusted to different workpiece heights? The screw-clamp style allows fine adjustment of the contact point, enabling compensation for small height variations while maintaining secure clamping. Manufacturer: Kukamet Fevzi Çakmak Mah.10644 Sk. No:61-63 42050 Karatay / KONYA TÜRKİYE / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; +49 2822 7131930; eMail: info@metav-werkzeuge.com
85° Quick-Acting Toggle Clamp Horizontal Base, Screw-Type, Zinc-Plated, 3500N Push/4000N Hold - Kukamet
Take advantage of the combination of robust clamping performance, a corrosion-resistant zinc-plated finish and compact handling to keep assembly and jigging tasks efficient; order directly via Metav Werkzeuge or consult the sales team for technical advice. Kukamet 822 Quick Clamp – Zinc-plated, 3,500 N clamping force The Kukamet 822 is a quick-action clamp engineered for workshop and light industrial fixturing, offering a screw-clamp design with a horizontal foot for stable mounting. Zinc-plated corrosion protection 3,500 N clamping force capacity Horizontal foot for fixed mounting Consistent clamping for reliable production flow The primary advantage of a quick-action clamp with a 3,500 N rated clamping force is predictable, repeatable holding during machining and assembly. The screw-type mechanism provides controlled pressure while the specified 4,000 N holding force reduces the risk of workpiece movement under load. This translates into fewer setup checks and less rework, supporting a smoother manufacturing rhythm and measurable time savings per batch. Durable finish suited to demanding shop environments A zinc-plated surface finish protects the clamp against corrosion and routine workshop wear, extending service intervals and preserving clamping geometry. For operations where humidity or occasional coolant exposure occurs, the plated surface maintains function without complex maintenance routines. The corrosion resistance contributes to longer tool life, which in turn lowers lifetime costs and supports uninterrupted production. Stable mounting and ergonomic handling for repeated tasks The clamp’s horizontal foot mounting offers a secure base when fixed to jigs, benches or machine tables, improving alignment stability compared with temporary or handheld clamping. The lever-style action combined with the screw-clamp characteristic balances rapid engagement with fine adjustment capability, enabling efficient cycle times while still allowing precise pressure control for delicate components. Compact design that supports versatile workshop use At approximately 0.83 kg and with an 85° operational angle, the unit is lightweight yet robust enough for repeated use in fixtures and assembly stations. The compact footprint preserves bench space and integrates into multi-clamp setups without obstructing adjacent operations. Where shop floor layout and accessibility matter, the appliance’s size and mounting method make it a practical choice for versatile fixture design. Contact Metav Werkzeuge today for availability and tailored application guidance on the Kukamet 822 quick clamp, shipped from Emmerich with expert advice tailored to production needs. Technical data Article number: 822-2 GTIN: 8682843521793 Brand: Kukamet Facts Weight: 0.83 kg Max clamping force: 3,500 N Max holding force: 4,000 N Angle: 85° ECLASS: 21020701 ETIM: EC011973 Material & features Zinc-plated Horizontal foot mounting Screw-clamp design Category: Clamps SKU: 822-2 FAQ What clamping force can be expected from this clamp? The Kukamet 822 quick clamp delivers a rated clamping force of 3,500 N and a maximum holding force of 4,000 N, suitable for many assembly and light machining tasks. Is the clamp suitable for fixed jig mounting? Yes, the clamp’s horizontal foot is designed for secure fixed mounting to jigs, benches or machine tables to provide stable fixturing. How durable is the surface finish in workshop conditions? The zinc-plated finish on the Kukamet 822 protects against corrosion and routine wear, making it well suited to standard workshop environments. Can the clamp be used where precise pressure control is needed? The screw-clamp characteristic provides controlled tightening and fine adjustment, allowing precise pressure management during sensitive assembly operations. What is the weight and typical application area for this clamp? With a weight of 0.83 kg, the clamp is compact and practical for fixture setups, assembly stations and light industrial applications where space and accessibility matter. Manufacturer: Kukamet Fevzi Çakmak Mah.10644 Sk. No:61-63 42050 Karatay / KONYA TÜRKİYE / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; +49 2822 7131930; eMail: info@metav-werkzeuge.com
86mm Vertical Clamp Massive Holding Arm And Safety Lock, 100° Angle - Kukamet
Combine robust clamping performance with a compact 86 mm arm and a secure safety lock for reliable, repeatable holding in production environments. Order the vertical clamp directly via Metav Werkzeuge or consult our specialists for integration advice. 241 Vertical Clamp by Kukamet — 86 mm arm, safety lock The 241 Vertical Clamp is a heavy‑duty vertical clamping solution for workshop and production use, designed for stable fixture mounting with a horizontal foot. Massive holding arm with safety lock 86 mm arm for compact installation Horizontal foot for stable mounting Up to 6,000 N holding force Secure, repeatable clamping for high‑throughput work The clamp delivers dependable holding performance thanks to an 86 mm arm and a 6,000 N holding force, which together provide a secure grip on parts during machining and assembly. The specified 2,000 N actuation force controls the closing movement precisely, reducing the risk of part movement and rework. For operators and production planners, this means fewer interruptions and a more predictable process flow; the mechanical parameters are given as objective benchmarks that support capacity planning and fixture design. The robust force values ensure the device is suitable for repetitive cycles in light to medium industrial applications. Compact mounting that simplifies fixture design With a horizontal foot and a compact profile the clamp is engineered to integrate into existing jigs and workholding plates without consuming excessive space. The compact footprint reduces interference with tooling and allows denser fixture layouts, which can shorten cycle times and increase throughput. The unit’s blackened finish offers a corrosion‑resistant surface that maintains appearance and function in workshop conditions while keeping maintenance demands low. At a weight of 2.278 kg, the component balances mass for stability with ease of handling during installation. Safety features and durable construction to cut downtime A massive holding arm coupled with a mechanical safety locking mechanism secures the clamped part even if external loads change, helping to prevent accidental release and potential damage. The sturdy construction is designed to withstand frequent operation while the locking feature simplifies safety assessments for fixtures. Built for longevity, the clamp’s components are finished to resist everyday wear, which reduces replacement frequency and supports continuous production. The combination of secure locking and rugged design contributes to reliable uptime and lower total cost of ownership over the life of the fixture. For precise clamping from a trusted brand, request the Kukamet 241 via Metav Werkzeuge in Emmerich — our specialists are available to advise on suitability and installation for specific production setups. Technical data SKU: 241-6-D-L-C1 GTIN: 8682843520703 ETIM: EC011973 eClass: 21041717 Facts Arm length: 86 mm Angle: 100° Weight: 2.278 kg Max actuation force: 2,000 N Max holding force: 6,000 N Special features Blackened finish Horizontal foot mounting Massive holding arm Safety locking mechanism Category: Clamp FAQ What clamping force can be expected from this product? The 241 Vertical Clamp provides up to 6,000 N holding force, with a maximum actuation force of 2,000 N, offering secure retention for many workshop applications. Can the clamp be mounted on a standard fixture plate? Yes, the clamp is designed for horizontal foot mounting and integrates easily into common fixture plates and jigs used in production. Is the finish suitable for humid workshop environments? The clamp’s blackened finish gives enhanced resistance to corrosion compared with bare metal, supporting use in typical workshop conditions. Is the 86 mm arm suitable for larger workpieces? The 86 mm arm is optimised for compact installations; for larger or more complex parts, fixture layout should be evaluated to ensure reach and clearance are sufficient. Manufacturer: Kukamet Fevzi Çakmak Mah.10644 Sk. No:61-63 42050 Karatay / KONYA TÜRKİYE / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; Germany; +49 2822 7131930; eMail: info@metav-werkzeuge.com
88mm Clamp Height Compact Clamp 40mm Reach Closed Mounting Hole - BESSEY
Take advantage of the 88 mm clamping height and 40 mm reach combined with an aluminium pressure shoe and closed fixing bore to secure workpieces in tight spaces; order the clamp directly via Metav Werkzeuge or consult our specialists for application advice. BESSEY BAS compact clamp — 88 mm clamping height, 40 mm reach The BESSEY BAS compact clamp is a workshop-grade compact clamp designed for secure clamping in confined or recessed areas, featuring an aluminium pressure shoe and a closed fixing bore for reliable attachment. 88 mm clamping height for deeper workpieces 40 mm reach for tight or recessed areas Aluminium pressure shoe for gentle contact Closed fixing bore for secure mounting Reliable clamping where space is limited This compact clamp delivers a notable combination of clamping height and reach, with an effective 88 mm clamping height and 40 mm projection that allow secure gripping of thicker or offset components in narrow setups. The measured values translate directly into fewer repositioning steps on the bench, improving workflow efficiency. For production environments where floor space and fixture room are constrained, the compact construction reduces the need for larger, more cumbersome clamps while maintaining consistent clamping force and repeatability. Prevents damage while keeping parts stable Equipped with an aluminium pressure shoe, the clamp ensures even distribution of contact pressure and reduces marking on softer surfaces such as coated panels or finished timber. The pressure shoe acts as a cushioning interface while still transmitting sufficient force for metalworking and assembly tasks. Where component finish is critical, this feature helps preserve surface integrity without sacrificing grip — a practical balance between protection and performance that benefits both prototype workshops and small-batch production. Secure attachment and straightforward integration The clamp’s closed fixing bore provides a secure mounting option for permanent or semi-permanent fixture layouts, simplifying fixture design and reducing setup time. Built on the BAS series architecture, the device supports fast retrofitting into existing jigs and benches thanks to its compact footprint and standardised attachment geometry. Durable construction and a design focused on ease of use make it suitable for repetitive tasks in maintenance, fabrication and precision assembly, where consistent clamping and quick repositioning are required. Contact Metav Werkzeuge to discuss the suitability of the BESSEY BAS compact clamp for specific applications or to arrange supply from our Emmerich warehouse — our team will provide technical guidance and delivery options. Technical data Article number: 4123716040NW Manufacturer: BESSEY Product type: Compact clamp Label: BAS clamping height 88 mm, reach 40 mm Packaging unit: 1 Facts Clamping height: 88 mm Reach: 40 mm Type: BAS SKU: 4123716040NW Special features Aluminium pressure shoe Closed fixing bore Compact design for restricted spaces FAQ What is the maximum clamping height of this clamp? The clamp provides a clamping height of 88 mm as specified for the BESSEY BAS compact clamp (SKU 4123716040NW). Can the clamp be mounted permanently to a jig or fixture? Yes — the closed fixing bore enables secure mounting for permanent or semi-permanent fixture setups. Is the pressure shoe suitable for delicate surfaces? The aluminium pressure shoe on the BAS series offers gentle contact to reduce marking while maintaining reliable grip. For which workshop tasks is this compact clamp most suitable? The clamp is ideal for operations in confined spaces such as recessed assemblies, light fabrication and precision bench work where a compact footprint is required. Manufacturer: BESSEY; Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; Germany; +49 2822 7131930; info@metav-werkzeuge.com
88mm Vertical Clamp 750N Clamp Force, Massive Holding Arm, Zinc Plated - Kukamet
A compact, robust solution for fixture work: the galvanised vertical toggle clamp delivers a massive 88 mm holding arm, a 750 N clamping force and up to 1,000 N holding capacity, combining secure workpiece retention with low installation footprint. Order directly via Metav Werkzeuge or consult the technical team for integration advice. 213 Vertical Toggle Clamp — galvanised, 750 N clamping force The 213 Vertical Toggle Clamp is a compact vertical clamp designed for secure workpiece holding in assembly and fixture applications, optimised for confined spaces and repeated clamping cycles. Galvanised finish for corrosion resistance Massive 88 mm holding arm Up to 1,000 N holding force Angled foot mounting for rigid fixing Reliable clamping that keeps production moving The vertical toggle clamp is engineered for consistent, repeatable holding in jigs and fixtures, offering a 750 N clamping force and a 1,000 N holding capacity that reduce slippage and rework. The galvanised finish provides corrosion resistance for longer service life in mixed workshop environments. Thanks to the compact 88 mm arm and a low mass of 0.17 kg, the device integrates into tight assemblies without adding undue inertia to moving fixtures, supporting efficient cycle times and reliable part positioning. Easy mounting and low-maintenance operation Mounting is simplified by the angled foot base plate, allowing secure attachment to fixture plates and workbenches while keeping the clamp profile low. The massive holding arm design improves force distribution and contact stability, which decreases wear on clamping surfaces and extends maintenance intervals. The galvanised material reduces the need for additional coatings, making the clamp a durable choice for small-batch production and repeated manual handling tasks. Designed for predictable performance in jigs and fixtures Suitable for assembly, welding jigs and general clamping tasks, this vertical toggle clamp delivers repeatable results across production runs. The toggle mechanism provides fast actuation and a positive locked state under load, supporting both operator-led and semi-automated processes. Clear numeric specifications—arm length, clamping and holding forces, and unit weight—enable straightforward selection for engineers and toolmakers seeking to match clamping performance to component geometry and process forces. Contact Metav Werkzeuge for procurement and technical integration: call +49 2822 7131930 or email info@metav-werkzeuge.com for tailored advice and availability Technical data Article number: 213-1-D-C2 GTIN: 8680731505856 Model: 213 Brand: Kukamet Data Arm length: 88 mm Weight: 0.17 kg Max clamping force: 750 N Max holding force: 1,000 N Classification: eClass 21041717, ETIM EC011973 Special features Material: Galvanised Mounting: Angled foot Massive holding arm Type: Vertical toggle clamp SKU: 213-1-D-C2 FAQ What is the primary application for this clamp? The 213 Vertical Toggle Clamp by Kukamet is intended for fixture and jig applications where a compact vertical clamp with reliable holding capacity is required; SKU 213-1-D-C2 identifies this model. How much force does the clamp provide? Maximum clamping force is 750 N and the holding capacity is 1,000 N for the 213 Vertical Toggle Clamp from Kukamet. What material and finish are used? The clamp is made in a galvanised finish, offering corrosion resistance suited to workshop and light industrial environments. How is the clamp mounted? Mounting is via an angled foot base plate to permit rigid fixing to fixture plates or benches while minimising the overall profile. Is the arm length suitable for tight assemblies? The 88 mm arm provides a compact reach while allowing secure workpiece engagement, making the clamp suitable for confined assembly and production jigs. Manufacturer: Kukamet Fevzi Çakmak Mah.10644 Sk. No:61-63 42050 Karatay / KONYA TÜRKİYE / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; +49 2822 7131930; eMail: info@metav-werkzeuge.com
88mm Vertical Clamp 750N Closing Force, Massive Clamp Arm, Angle Foot, Black Oxide Finish - Kukamet
Take advantage of a compact, heavy-duty workholding solution that combines a heavy-duty holding arm, safety locking mechanism and measurable clamping performance for reliable fixture assembly. Order the clamp directly via Metav Werkzeuge or consult the Metav team for integration advice. Kukamet Vertical Clamp 213 — 88 mm arm and safety lock A robust Vertical Clamp 213 engineered for secure, repeatable workholding in workshop jigs and light production where compact clamps are required Heavy-duty holding arm Safety locking mechanism Max holding force 1,000 N Angle-foot mounting Secure clamping with defined force values for predictable results The Vertical Clamp 213 delivers precisely defined mechanical performance: a holding force of 1,000 N and a pressing force of 750 N, allowing process planners to specify fixture loads with confidence. The compact 88 mm arm ensures a small footprint on the workbench while preserving effective leverage. Measured values simplify calculations for fixture life and torque requirements, supporting production planning and quality assurance. Safer operation and consistent repeatability in every cycle A safety locking mechanism prevents unintentional release once the clamp is engaged, reducing the risk of part movement during machining or assembly. The heavy-duty arm provides rigidity under load, translating into consistently reproducible clamping positions and reduced setup variation. For production environments where repeatability is crucial, these features reduce rework and support stable process capability. Compact mounting and resilient surface treatment for long service life Designed with an angle-foot mounting, the clamp is straightforward to integrate into existing plates and jigs without complex adapters. The blackened finish offers corrosion resistance while maintaining a low visual profile on tooling assemblies. At just 0.15 kg, the unit adds minimal mass to fixtures, which benefits quick-change systems and modular tooling concepts by keeping moving masses low. Practical applications and straightforward identification for procurement Suitable for workshop fixtures, assembly jigs and light production clamps, this device is a compact solution where space is limited but reliable clamping is required. The robust construction and locking feature make it suitable for repeated manual and semi-automated operations. Identification for ordering and stock management is simplified by the SKU B213-1-D-L-C2, making the clamp easy to specify in procurement lists and ERP systems. Select the Kukamet Vertical Clamp 213 via Metav Werkzeuge for dependable workholding and direct support from our Emmerich-based team — call +49 2822 7131930 or email info@metav-werkzeuge.com Technical data SKU: B213-1-D-L-C2 Model: Vertical Clamp 213 Mounting: Angle-foot mounting Arm length: 88 mm Weight: 0.15 kg Material/finish: blackened finish Core data Max pressing force: 750 N Max holding force: 1,000 N Arm length: 88 mm Weight: 0.15 kg ECLASS: 21041717 ETIM: EC011973 Special features Heavy-duty holding arm Safety locking mechanism Angle-foot mounting Blackened finish FAQ What clamping and holding forces does this clamp provide? The clamp offers a pressing force of 750 N and a holding force of 1,000 N, values specified for the Vertical Clamp 213 for planning and verification. How is the clamp mounted to a fixture plate? Mounting is via an angle-foot arrangement, which allows straightforward fastening to plates and jigs without special adapters. Does the clamp include a safety mechanism to prevent accidental release? Yes, the device features a safety locking mechanism that secures the clamp in the engaged position to prevent unintended opening. Is the finish corrosion resistant for workshop use? The clamp has a blackened finish that provides surface protection suitable for workshop and production environments. What is the product identifier for ordering and inventory? The clamp is listed under SKU B213-1-D-L-C2 for procurement and inventory tracking. Manufacturer: Kukamet Fevzi Çakmak Mah.10644 Sk. No:61-63 42050 Karatay / KONYA TÜRKİYE / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; +49 2822 7131930; eMail: info@metav-werkzeuge.com
88mm Vertical Clamp Massive Holding Arm With Safety Lock, 750N Clamp Force - Kukamet
Robust galvanised construction combined with a massive holding arm and a safety lock provides dependable clamping under repeated use; benefit from up to 1,000 N holding force and a compact 88 mm arm for precise fixturing — order the Vertikalspanner 213 directly via Metav Werkzeuge or ask our consultants if needed. Vertikalspanner 213 – Kukamet vertical lever clamp with galvanised arm and safety lock Vertikalspanner 213 is a compact vertical lever clamp designed for reliable fixture work and secure holding where repeatable clamping is required Galvanised steel for corrosion resistance Massive 88 mm holding arm with safety lock Angle-base mounting for stable installation Durable construction for repeatable clamping accuracy Built for demanding fixture applications, this vertical lever clamp features a galvanised finish that protects against corrosion while preserving smooth operation. The combination of a massive holding arm and a safety lock ensures consistent positioning and prevents accidental release during assembly or machining processes. Measured forces of 750 N clamping and 1,000 N holding deliver quantifiable performance that supports predictable cycle times and reduced rework. The compact arm length of 88 mm is suited to confined spaces without compromising leverage. Simple integration and low-maintenance operation The clamp’s angle base allows secure mounting to brackets, plates or jig fixtures, enabling fast installation and stable alignment in a variety of setups. Galvanised steel construction minimises surface wear and simplifies maintenance routines, reducing downtime between production runs. With a lightweight build at just 0.15 kg, this lever clamp is easy to handle during assembly while its robust design supports repeated actuations — a practical choice for workshops and production cells seeking durable, low-cost fixturing components. Reliable choice for workshop and industrial fixturing As a lever clamp for fixturing and holding tasks, this unit is particularly well suited to repetitive assembly, light machining jigs and inspection fixtures where secure retention and quick actuation are priorities. The proven mechanical setup with a massive arm and safety lock reduces the risk of slips and improves operator confidence at the workstation. The simple, measurable specifications make this clamp easy to specify for engineering drawings and parts lists, supporting efficient procurement and predictable assembly performance. For tailored advice and to arrange supply of the Kukamet Vertikalspanner 213 through Metav Werkzeuge, please contact our team at info@metav-werkzeuge.com or +49 2822 7131930 to discuss technical details and ordering options. Technical data Article number: 213-1-D-L-C2 GTIN: 8682843520321 Model: 213 Facts Arm length: 88 mm Weight: 0.15 kg Max clamping force: 750 N Max holding force: 1,000 N eClass: 21041717 ETIM: EC011973 Special features Material: Galvanised steel Mounting: Angle base Massive holding arm Safety lock Category: Spanner FAQ What maximum holding force does the clamp provide? The Kukamet Vertikalspanner 213 offers a holding force of up to 1,000 N and a clamping pressure of 750 N, allowing specification for reliable fixture retention. Is the clamp suitable for use in humid or workshop environments? Yes, the galvanised finish on the Vertikalspanner 213 provides corrosion protection suited to general workshop conditions and reduces surface maintenance. How is the clamp mounted to a fixture or plate? Mounting is via an angle base, allowing straightforward attachment to brackets or fixture plates for stable alignment. Does the clamp include a safety feature to prevent accidental release? The clamp is equipped with a mechanical safety lock and a massive holding arm to secure the clamped part during handling and operation. Manufacturer: Kukamet Fevzi Çakmak Mah.10644 Sk. No:61-63 42050 Karatay / KONYA TÜRKİYE / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; +49 2822 7131930; eMail: info@metav-werkzeuge.com
88mm Vertical Clamp Three-Point Massive Holding Arm, 750N Clamp Force - Kukamet
Take advantage of a solid 88 mm holding arm, an angle base for secure mounting and measurable clamping and holding forces up to 750 N and 1,000 N respectively for reliable fixture stability on small assemblies; order the clamp directly via Metav Werkzeuge or consult our specialists for application advice. Vertical clamp 213 — compact toggle clamp with 88 mm arm and angle base (Kukamet) The Vertical clamp 213 is a compact toggle clamp engineered for secure workpiece retention in metalworking fixtures, assembly jigs and repetitive production tasks. Solid 88 mm holding arm Angle base for stable mounting Holding force up to 1,000 N Blackened finish for durability Secure, measurable clamping for repeatable production The clamp delivers clearly defined retention through a combination of a clamping force of 750 N and a holding force of 1,000 N, values that are particularly useful when fixtures must resist lateral or vibrational loads. The difference between clamping and holding force is explained here: clamping force refers to the axial pressure applied during engagement, while holding force describes residual retention once the tool is locked. This distinction helps specify the correct fixture element for processes where consistent part orientation is critical. The device is classed as a toggle clamp, allowing rapid engagement and reliable repeatability across cycles. Space-saving design with simple mounting and robust arm Featuring an angle base, the clamp is intended for secure attachment to flat plates or fixture rails and supports compact layout designs where tabletop space is at a premium. The 88 mm arm length provides a balance of reach and compactness, enabling access to shallow pockets and small components without introducing excessive mechanical leverage. Thanks to its low mass, the unit integrates into automated or semi-automated stations with minimal added inertia, while the solid holding arm construction reduces flexing under load and contributes to consistent positioning in short-cycle production. Workshop-ready finish and application versatility A blackened finish protects exposed surfaces against corrosion and workshop wear, making the clamp suited to harsh environments where oil, coolant or particulate matter are present. The robust arm and simple lever mechanism are optimised for repetitive clamping in operations such as small-part machining, assembly and fixture building. Because the design focuses on durability and quick handling rather than fine adjustment, it is especially appropriate where fast cycle times and dependable retention are the priority. Maintenance is straightforward: periodic inspection, light lubrication of the pivot points and secure fastening of the mounting screws preserve performance. Choose the Kukamet 213 for durable, compact clamping and contact Metav Werkzeuge for tailored advice or order placement: info@metav-werkzeuge.com · +49 2822 7131930 Technical data SKU: B213-1-D-C2 GTIN: 8682843522417 Manufacturer: Kukamet Facts Arm length: 88 mm Clamping force (max): 750 N Holding force (max): 1,000 N Weight: 0.17 kg eClass: 21041717 ETIM: EC011973 Special features Angle base mounting Solid holding arm Blackened finish Model designation: 213 Category: Clamps Toggle clamp (lever clamp) FAQ What holding and clamping forces does the Vertical clamp 213 provide? The Kukamet Vertical clamp 213 offers a clamping force of up to 750 N and a holding force of up to 1,000 N, suitable for light to medium fixture applications. Is the clamp suitable for use in machining fixtures with coolant exposure? Yes; the blackened finish on the Vertical clamp 213 provides enhanced surface protection, making it appropriate for workshop environments where coolant or light contamination occurs. How is the Vertical clamp 213 mounted? Mounting is performed via the angle base, which allows stable attachment to flat plates or fixture rails for compact, secure installation of the clamp. Can the clamp be used in automated stations or moving fixtures? Due to its low weight and robust lever mechanism, the Vertical clamp 213 can be integrated into automated or semi-automated fixtures where fast, repeatable clamping is required. Where can further technical details or ordering assistance be obtained? Detailed application advice and ordering support are available from Metav Werkzeuge; refer to the contact information provided in the product description for email and telephone assistance. Manufacturer: Kukamet Fevzi Çakmak Mah.10644 Sk. No:61-63 42050 Karatay / KONYA TÜRKİYE / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; +49 2822 7131930; eMail: info@metav-werkzeuge.com
90mm Horizontal Clamp M4x25 Push Spindle, 450 N Clamp Force, 520 N Holding Force - Kukamet
Combining a compact lever design, a 450 N clamping force and a horizontal foot for straightforward fixture mounting, this clamp delivers reliable, space-saving workholding for small jigs and assemblies. Order the part directly via Metav Werkzeuge or consult the product specialists for tailored integration advice. Kukamet 111 Horizontal lever clamp — horizontal foot, blackened finish The Kukamet 111 is a compact horizontal lever clamp designed for secure, repeatable workholding in fixtures and jigs where space is limited. Compact horizontal lever clamp Horizontal foot mounting Clamping force 450 N Holding force 520 N Secure clamping with clear performance benefits The compact lever mechanism provides a precise balance between size and performance. With a clamping force of 450 N and a holding force of 520 N, the unit is engineered to keep small components steady during assembly or light machining tasks. The horizontal configuration with a dedicated horizontal foot allows the clamp to be integrated into flat fixture bases without adding vertical obstruction, meaning better access for tools and operators while maintaining consistent pressure across the clamped part. Durable finish and compact construction for workshop longevity A blackened finish offers corrosion resistance and a low-reflective surface that suits industrial environments. The low mass of the device (approx. 0.042 kg) reduces inertia on moving fixtures and supports agile jig design. The combination of robust lever mechanics and a corrosion-resistant surface means the clamp is suitable for repetitive use cycles, helping to reduce maintenance intervals and support continuous production. Fast integration and specification-ready details Fitted with an M4x25 pressure spindle, the clamp is ready for straightforward mechanical integration into predrilled plates or bespoke fixtures. The compact footprint and standardised spindle thread simplify retrofits and new fixture designs alike. For planners and engineers this means predictable installation times and reliable repeatability in positioning; for workshop operatives it means fewer adjustments and faster set-up at the bench or in small production cells. Contact Metav Werkzeuge today for procurement or technical integration advice on this Kukamet horizontal lever clamp and benefit from expert guidance from our Emmerich-based team Technical data SKU: B111-0 GTIN: 8682843522134 ETIM: EC011973 ECLASS: 21041719 Core specifications Clamping force: 450 N Holding force: 520 N Weight: 0.042 kg Angle: 90° Materials & features Material: blackened finish Mounting: horizontal foot Pressure spindle: M4x25 Model designation: 111 Brand: Kukamet FAQ What is the maximum clamping force of this horizontal clamp? The Kukamet 111 horizontal lever clamp (SKU B111-0) delivers a maximum clamping force of 450 N and a holding force of 520 N. How is the clamp mounted in a fixture? Mounting is via a horizontal foot arrangement; the compact base is suited to flat fixture plates and jigs where horizontal attachment is required. What spindle thread does the clamp use for adjustments? Adjustment and contact are provided by an M4x25 pressure spindle, allowing straightforward replacement and compatibility with common fixture hardware. Is the finish suitable for industrial environments? The unit features a blackened finish that improves surface corrosion resistance and reduces glare in typical workshop conditions. Can the clamp be used in tight or space-constrained fixtures? Yes, the compact lever design and horizontal mounting allow installation in confined areas while maintaining consistent clamping performance. Manufacturer: Kukamet Fevzi Çakmak Mah.10644 Sk. No:61-63 42050 Karatay / KONYA TÜRKİYE / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; +49 2822 7131930; eMail: info@metav-werkzeuge.com
90mm Horizontal Clamp With Massive Holding Arm, 850N Thrust / 1000N Hold Force - Kukamet
Combine compact design with robust clamping performance: the solid holding arm and angled base deliver dependable fixture mounting and high clamping force for repeatable production. Order the clamp directly via Metav Werkzeuge or consult our specialists for application advice. Horizontal clamp 113 — Kukamet horizontal clamp with 90 mm arm and 1,000 N holding force A sturdy Horizontal clamp 113 designed for horizontal fixturing and reliable workpiece retention in jigs and fixtures. Solid holding arm, 90 mm length Max. holding force 1,000 N Pressing force up to 850 N Angled base for fixture mounting Secure clamping for precision fixtures The Horizontal clamp 113 combines a solid holding arm with clearly specified forces to provide predictable clamping behaviour in series production. The distinction between pressing force (850 N) and holding force (1,000 N) gives planners measurable data for fixture design: pressing force defines the actuation load, while holding force indicates the maximum sustained grip on the workpiece. This transparent specification supports process planning and reduces setup iteration, contributing to shorter cycle times and higher first-pass yield. Compact footprint that fits tight jigs With a 90 mm arm and a light overall mass, the clamping device is suited to constrained fixture layouts where space optimisation matters. The angled base enables secure mounting on fixture plates or subplates without additional adapters, simplifying assembly and saving space in multi-clamp arrangements. A restrained form factor paired with a robust arm translates into efficient use of bench or fixture real estate while maintaining the clamping reach required for many machining and assembly tasks. Durable finish and dependable operation Durability is delivered through a blackened finish and a massive holding arm, designed for repeated actuation and consistent integrity under production loads. The combination of specified forces and materials supports use across standard metalworking and assembly applications, providing long service life with minimal maintenance. Identifiers such as SKU B113-1-D-C2 and GTIN 8682843522202 make procurement and inventory management straightforward, while the measurable technical data allow integration into tooling documentation and quality records. Discuss integration of the Kukamet Horizontal clamp 113 with Metav Werkzeuge in Emmerich — request tailored advice by phone +49 2822 7131930 or by e‑mail at info@metav-werkzeuge.com Technical data SKU: B113-1-D-C2 GTIN: 8682843522202 Brand: Kukamet Finish: blackened finish Facts Arm length: 90 mm Angle: 90° Weight: 0.156 kg Max. holding force: 1,000 N Max. pressing force: 850 N ECLASS: 21041719 ETIM: EC011973 Special features Mounting type: angled base Solid holding arm Material: blackened, burnished steel Category: clamp FAQ What is the difference between pressing force and holding force? Pressing force is the actuation load of the clamp; holding force is the maximum sustained grip. The Horizontal clamp 113 lists 850 N pressing force and 1,000 N holding force so fixture design can be dimensioned accurately. Which mounting options are available for this clamp? The unit features an angled base for direct fixture mounting; the design is intended for plate or subplate installation in jigs and fixtures. Is the clamp suitable for frequent cycle applications? Yes. The robust construction, solid holding arm and protective blackened finish are intended for repeated actuation in production environments where consistent retention is required. How is the clamp identified for ordering and stock control? Use SKU B113-1-D-C2 or GTIN 8682843522202 when ordering or registering the component in inventory systems. Manufacturer: Kukamet Fevzi Çakmak Mah.10644 Sk. No:61-63 42050 Karatay / KONYA TÜRKİYE / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; +49 2822 7131930; eMail: info@metav-werkzeuge.com
90mm Horizontal Clamp With Massive Holding Arm, Safety Lock, 850N Thrust/1000N Hold, Zinc-Plated - Kukamet
Take advantage of a compact, zinc-plated lever clamp that combines a massive holding arm with a safety lock for secure, repeatable workholding; benefit from measurable clamping and holding forces to stabilise assembly processes. Order directly via Metav Werkzeuge or consult our specialists for integration advice. Horizontal Clamp 113 — Kukamet horizontal lever clamp with 90 mm arm and safety lock The Horizontal Clamp 113 is a compact horizontal lever clamp designed for secure, repeatable workholding in light assembly, jigs and fixtures Massive holding arm and safety locking mechanism Zinc-plated finish for corrosion resistance Angled-foot mounting for simple fixture attachment 1000 N holding force with compact 90 mm arm Secure, measurable clamping for consistent production The clamp delivers a clearly defined combination of holding force and actuation reliability, making it suitable for repetitive tasks where consistency matters. With a maximum holding force of 1000 N and an operational clamping force of 850 N, the device reduces part movement during joining, drilling or light machining operations. The robust construction and safety lock minimise unintentional release, improving process safety and reducing rework. These quantifiable values support predictable cycle times and easier quality control during series production. Compact mounting that simplifies fixture design Designed with a 90 mm arm and an angled foot mounting, the clamp integrates into tight jigs and fixtures without adding unnecessary bulk. The 90° operating angle and low unit weight of 0.155 kg allow multiple clamps to be positioned close to the workpiece for even pressure distribution. The angled foot lets the clamp be secured to plates or frames with standard fasteners, shortening setup time and simplifying retrofitting into existing assemblies. Reduced complexity in fixturing translates into faster changeovers and higher uptime. Durable finish and construction for low maintenance A zinc-plated finish protects the clamp’s surfaces against corrosion in workshop environments, while the massive holding arm provides long-term mechanical stability under frequent use. The simple lever mechanism requires minimal upkeep and the built-in safety locking feature reduces the risk of accidental opening during handling. This combination supports sustained performance in daily shop-floor use and contributes to lower total cost of ownership through reduced downtime and fewer replacements. Choose Kukamet’s Horizontal Clamp 113 for reliable, compact clamping and contact Metav Werkzeuge in Emmerich for supply and technical advice at info@metav-werkzeuge.com or +49 2822 7131930 Technical Data SKU: 113-1-D-L-C2 GTIN: 8680731505757 ECLASS: 21041719 ETIM: EC011973 Designation: Horizontal clamp 113 Core technical data Arm length: 90 mm Angle: 90° Maximum clamping force: 850 N Maximum holding force: 1000 N Weight: 0.155 kg Materials & special features Material: zinc-plated steel Mounting: angled foot Massive holding arm Safety locking mechanism Compact lever clamp design FAQ What is the maximum holding capacity of the clamp? The Kukamet Horizontal Clamp 113 provides a maximum holding force of 1000 N and a clamping force of 850 N for secure workholding. How is the clamp mounted to a fixture? The unit is fitted with an angled foot mounting designed for straightforward attachment to plates or fixture bases. Which materials is the clamp suitable for in assembly fixtures? The clamp is intended for light assembly and fixturing applications across common workshop materials; its zinc-plated finish supports use in standard industrial environments. Is a safety mechanism included to prevent accidental opening? Yes, the clamp incorporates a safety locking mechanism to prevent unintended release during handling and operation. What are the identifying codes for ordering or inventory? Refer to SKU 113-1-D-L-C2 and GTIN 8680731505757 when ordering or checking stock Manufacturer: Kukamet Fevzi Çakmak Mah.10644 Sk. No:61-63 42050 Karatay / KONYA TÜRKİYE / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; +49 2822 7131930; eMail: info@metav-werkzeuge.com
90mm Horizontal Clamp With Safety Lock, M12x80 Pressure Spindle, Angled Base - Kukamet
Take advantage of a galvanised body, a positive safety locking mechanism and adjustable pressure via the M12x80 spindle for reliable, repeatable clamping in assembly and jigging. Order the clamp directly via Metav Werkzeuge or request tailored advice from our consultants for integration into production workflows. 113 Horizontal toggle clamp by Kukamet — galvanised, safety-lock model 113 Horizontal toggle clamp designed for secure horizontal clamping in production and workshop fixtures Galvanised steel construction Safety locking mechanism included Max clamping force 4,500 N Angle-base mounting for stable fit Consistent, high-force clamping for production needs The robust, galvanised construction delivers long-term resistance to corrosion and wear, making this clamp suitable for repetitive industrial use. With a maximum clamping force of 4,500 N and a holding capacity of 5,000 N, the unit converts operator input into a secure hold, reducing rework and downtime. The mechanical behaviour is predictable: the toggle action maintains pressure even under vibration, which supports consistent part positioning and repeatable cycle times on production lines. For operations that require durable, low-maintenance clamping, this model provides a dependable mechanical solution. Built-in safety locking reduces accidental release Equipped with a safety locking mechanism, the clamp prevents unintended opening during machining or handling, improving workshop safety and process reliability. The lock engages positively once the handle is closed, so clamps remain secure when subjected to shocks or material shifts. This feature not only lowers the risk of damaged parts but also supports compliance with internal safety routines by adding a physical safeguard where procedural checks alone may be insufficient. The result is fewer interruptions and a more confident assembly workflow. Fine adjustment and secure mounting for versatile use Adjustment is straightforward: the M12x80 spindle provides precise pressure setting and compensates for part tolerances, enabling controlled clamping pressure without specialised tools. The angle base (Winkelfuß) ensures stable attachment to fixtures, plates or jigs and simplifies alignment in tight spaces. Together, these details make retrofitting into existing tooling layouts uncomplicated and permit adaptable clamping distances while retaining full mechanical strength. Suitable for workshops and production lines alike Engineered for daily use, the clamp balances performance and user-friendly handling. The moderate weight (1.84 kg) and compact footprint allow it to be mounted where accessibility and space are considerations, while the galvanised finish supports longevity in workshop environments. Whether integrated into a welding jig, assembly station or testing fixture, the clamp delivers repeatable holding performance that supports throughput and reduces process variability. Contact Metav Werkzeuge for specification matching or to request a tailored quotation for the Kukamet 113 clamp; phone +49 2822 7131930 or eMail info@metav-werkzeuge.com Technical Data Article number: 113-5-L GTIN: 8680731501070 Manufacturer: Kukamet Category: Clamp Facts Max clamping force: 4,500 N Max holding force: 5,000 N Spindle size: M12x80 Weight: 1.84 kg ETIM: EC011973 ECLASS: 21041719 Special features Galvanised steel construction Angle-base mounting (Winkelfuß) Safety locking mechanism Catalogue PDF available FAQ What is the maximum clamping force of this clamp? The Kukamet 113 horizontal toggle clamp provides a maximum clamping force of 4,500 N and a holding capacity of 5,000 N. Can the clamping pressure be adjusted for delicate parts? Yes — the M12x80 spindle enables fine adjustment of the applied pressure to suit sensitive components while keeping the clamp stable. Is the clamp suitable for use in humid or corrosive workshop environments? The galvanised finish on the 113 clamp offers enhanced resistance to corrosion, making it suitable for standard workshop conditions and where occasional moisture exposure occurs. How is the clamp mounted to a fixture or jig? The clamp uses an angle base for secure mounting; the base allows straightforward attachment to plates or jigs and aids alignment in confined spaces. Does the clamp include a mechanism to prevent accidental release? Yes, the unit features a positive safety locking mechanism that holds the handle in position and prevents unintended opening during operations. Manufacturer: Kukamet Fevzi Çakmak Mah.10644 Sk. No:61-63 42050 Karatay / KONYA TÜRKİYE / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; Germany; +49 2822 7131930; eMail: info@metav-werkzeuge.com
90° 1000 N Horizontal Clamp With Massive Holding Arm And Safety Lock, Galvanised - Kukamet
Benefit from a durable combination of a 93 mm holding arm, galvanised finish and a secure safety latch for dependable clamping in repeat production; order the clamp directly via Metav Werkzeuge or consult the technical advisors for selection and delivery. Horizontal toggle clamp 111 by Kukamet — horizontal clamp with 93 mm arm and safety latch 111 is a compact horizontal toggle clamp designed for reliable 90° workpiece retention in assembly, jigs and fixture applications, featuring a galvanised body and a heavy-duty holding arm. Horizontal mounting with 90° clamping angle Massive holding arm and safety latch Galvanised for corrosion resistance Holding force up to 1,000 N Consistent clamping power for repeatable processes The unit delivers a precise combination of clamping force 850 N and holding force 1,000 N, which translates into dependable retention during repetitive operations and reduces the likelihood of part movement or rework. The toggle action converts small handle movement into significant locking force via the toggle mechanism, enabling rapid clamping cycles and consistent results on the production line. This mechanical advantage supports efficient throughput without reliance on complex actuators. Corrosion-resistant construction with integrated safety A galvanised finish protects the clamp against corrosion in standard workshop environments, extending service life and retaining reliable function over time. The massive holding arm and the built-in safety latch ensure locked parts remain secure even under vibration or intermittent loading, providing both process security and operator reassurance. Where visible locking is required, the latch gives a clear mechanical indication that the clamp is engaged. Space-saving design that simplifies fixture layout With a 93 mm arm and horizontal foot mounting, the clamp occupies minimal space on a fixture plate while providing a defined 90° clamping angle for perpendicular retention. The low-profile configuration and light weight (approx. 0.1 kg) allow multiple units to be arranged densely on jigs or modular tooling racks without adding significant mass. For engineers planning fixture layouts, the compact form factor facilitates flexible placement and fast part changeovers. Secure production with Kukamet build quality — contact Metav Werkzeuge for procurement, specification support and supply from Emmerich at info@metav-werkzeuge.com or by phone on +49 2822 7131930 Technical data SKU: 111-1-D-L-C2 GTIN: 8680731505290 Manufacturer: Kukamet Facts Arm length: 93 mm Clamping force: 850 N Holding force: 1,000 N Angle: 90° Weight: 0.1 kg Special features Material: Galvanised Mounting: Horizontal foot Massive holding arm Safety latch Category: Clamp FAQ What maximum holding force does this clamp provide? The 111 horizontal toggle clamp offers a holding force of up to 1,000 N, giving robust retention for many assembly and fixturing tasks. Is the clamp suitable for use in humid workshop environments? Yes, the galvanised finish on the 111 provides corrosion resistance suited to standard workshop and light industrial conditions. How much travel does the clamp arm offer and what is its length? The clamp features a 93 mm arm length; travel is determined by fixture geometry and the toggle stroke of the unit. Can the clamp be secured visibly when engaged? The integrated safety latch provides a positive mechanical lock and a clear indication when the clamp is engaged. What mounting arrangement is required for installation? The unit is supplied for horizontal foot mounting and is designed to secure workpieces at a 90° clamping angle. Manufacturer: Kukamet Fevzi Çakmak Mah.10644 Sk. No:61-63 42050 Karatay / KONYA TÜRKİYE / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; Germany; +49 2822 7131930; eMail: info@metav-werkzeuge.com
90° 1000 N Horizontal Clamp With Safety Lock, Stainless Steel - Kukamet
Take advantage of a compact clamp that pairs stainless steel durability with a safety locking mechanism and reliable clamping performance to streamline fixture work and reduce rework. Order this horizontal toggle clamp directly via Metav Werkzeuge or consult our specialists for selection support. Horizontal toggle clamp 112 — Kukamet horizontal clamp with stainless steel body and safety lock The Horizontal toggle clamp 112 secures workpieces at a 90° clamping angle for fixtures and jigs in repetitive assembly and light machining operations. Stainless steel construction Integrated safety lock Up to 1,000 N clamping force Vertical-foot mounting, 90° clamping Consistent clamping where accuracy matters This horizontal toggle clamp delivers reliable repeatability in production environments by converting operator motion into a defined 1,000 N clamping force with a holding capability of 1,200 N. The 90° clamping orientation stabilises parts in fixtures and simplifies alignment, reducing cycle time and the need for frequent repositioning. Clear mechanical action and a defined clamping stroke support consistent process quality and fewer rejects, which benefits small-batch assembly as well as serial production. Durability engineered for busy workshops Constructed from stainless steel, the unit resists corrosion and stands up to daily handling and cleaning regimes typical in busy workshops. The integrated safety lock prevents accidental release under vibration or during handling, improving operator safety and process security. At approximately 0.225 kg, the clamp is lightweight for easy integration into portable jigs while remaining robust enough for repeated use, lowering maintenance requirements and total life-cycle cost. Fast installation and broad fixture compatibility Designed for vertical-foot mounting, the clamp accepts an M6x40 spindle for simple attachment to plates and bases, streamlining assembly of bespoke fixtures. The compact footprint and standard fixing dimensions ease retrofitting into existing tooling layouts and enable quick fixture changes on the shop floor. Clear mechanical function and standardised interfaces help accelerate tooling set-up and reduce downtime, supporting more efficient production flows. For secure, repeatable clamping solutions from Kukamet, contact Metav Werkzeuge for specification advice and fast supply from our Emmerich hub — eMail info@metav-werkzeuge.com or call +49 2822 7131930 Technical data Article number: S112-2-L GTIN: 8680731508963 Manufacturer: Kukamet Core technical data Max clamping force: 1,000 N Holding force: 1,200 N Angle: 90° Weight: 0.225 kg Spindle thread: M6x40 Special features Material: stainless steel Mounting: vertical foot Safety lock: integrated Category: spanner FAQ What types of applications suit this clamp? The clamp is suitable for fixtures, jigs and light assembly work where a horizontal clamping action at 90° is required; the Horizontal toggle clamp 112 is designed for repeatable positioning and fixture integration. Is the clamp corrosion resistant? Yes, the stainless steel construction of the Kukamet clamp provides good resistance to corrosion and supports use in workshops with routine cleaning. How is the clamp mounted to a fixture? Mounting is by a vertical foot with a spindle thread M6x40, enabling straightforward bolting to plates and bases for secure attachment. Can the clamp hold parts under vibration? The integrated safety lock prevents unintended release, improving holding reliability under vibration or intermittent impact. What identifiers are used for ordering or inventory? Reference SKU S112-2-L and GTIN 8680731508963 for procurement and stock management. Manufacturer: Kukamet Fevzi Çakmak Mah.10644 Sk. No:61-63 42050 Karatay / KONYA TÜRKİYE / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; +49 2822 7131930; eMail: info@metav-werkzeuge.com
90° 1000 N Horizontal Clamp With Safety Lock, Zinc Plated - Kukamet
Combine compact design, galvanised corrosion resistance and a secure safety lock to ensure reliable clamping in production fixtures; order the horizontal clamp directly via Metav Werkzeuge or consult our specialists for application guidance. Horizontal clamp 113 — galvanised toggle clamp with safety lock by Kukamet Horizontal clamp 113 is a compact galvanised toggle clamp designed for robust fixture and workholding tasks where a fixed 90° mounting and positive safety locking are required. Galvanised steel construction for corrosion resistance Integrated safety locking mechanism for secure hold Angle-foot mount for 90° installation Suitable for light-duty industrial clamping Reduce setup time with a compact, secure clamp The compact toggle clamp design offers straightforward integration into jigs and fixtures, combining a small footprint with reliable performance. The angle-foot mounting allows a fixed 90° installation that eliminates alignment guesswork, which speeds up machine setup and repeatable positioning. With a galvanised finish, the clamp resists corrosion in workshop environments, extending service life and reducing maintenance intervals. The lever action provides a positive mechanical advantage for efficient clamping, translating a short handle travel into dependable holding power. Confident holding force and controlled actuation for safer work Engineered for repeatable clamping performance, this model provides a distinct separation between actuation and holding capacities: a defined clamping force and a higher holding force ensure components remain secure during machining or assembly. The safety locking mechanism prevents unintentional release under vibration or incidental contact, improving workplace safety and reducing the risk of part movement. The actuating spindle specification allows fine adjustment of the clamping point to accommodate variations in workpiece thickness without sacrificing clamping integrity. Durable materials and simple installation for productive workflows Manufactured in galvanised steel, the clamp resists surface corrosion common in busy workshops and light industrial environments, contributing to predictable long-term behaviour. The supplied actuating spindle thread matches common fixture hardware standards, enabling rapid integration with existing tooling. The overall lightweight construction supports easy handling during assembly without compromising the mechanical stability required for repeated cycles. Where compact, reliable clamping is needed, this clamp supports continuous production runs with minimal intervention. Practical advantages for fixture builders and maintenance teams For fixture designers and maintenance technicians the product delivers practical benefits: reduced inventory complexity through a standardised mounting style, a dependable safety lock that meets common workshop safety expectations, and a straightforward mechanical concept that requires no electricity or pneumatics. The combination of measurable holding force and a compact lever arrangement makes this clamp particularly suitable for small jigs, assembly stations and manual machining fixtures where quick operation and secure retention are priorities. Contact Metav Werkzeuge to specify the Kukamet horizontal clamp 113 for your fixtures and discuss mounting or adjustment options — call +49 2822 7131930 or email info@metav-werkzeuge.com Technical data SKU: 113-2-L GTIN: 8680731500813 Brand: Kukamet Model: 113 Actuating spindle: M6x40 Mounting type: Angle foot Safety locking: Yes Material: Galvanised Angle: 90° Weight: 0.27 kg Maximum pressing force: 1,000 N Maximum holding force: 1,200 N Facts Weight: 0.27 kg Angle: 90° Pressing force: 1,000 N Holding force: 1,200 N Special features Galvanised finish Angle-foot mounting for 90° installation Integrated safety locking mechanism Actuating spindle M6x40 Compact toggle clamp design FAQ What is the maximum holding force of this clamp? The Kukamet horizontal clamp 113 has a maximum holding force of 1,200 N, providing secure retention for light-duty fixture tasks. Can the clamp be mounted at other angles besides 90°? The clamp is supplied with an angle-foot intended for 90° installation; alternative mounting orientations require customised fixture arrangements. Is the locking mechanism automatic or manual? The device features an integrated safety locking mechanism that secures the lever in the clamped position and prevents accidental release during operation. What material is the clamp made from and how does it perform in humid environments? The clamp is manufactured in galvanised steel, which offers improved resistance to corrosion and is suitable for workshop environments with moderate humidity. Which spindle thread is used for adjustment? Adjustment is via an M6x40 actuating spindle, allowing simple fine-tuning of the clamping point to match workpiece thickness. Manufacturer: Kukamet Fevzi Çakmak Mah.10644 Sk. No:61-63 42050 Karatay / KONYA TÜRKİYE / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; +49 2822 7131930; eMail: info@metav-werkzeuge.com
90° 100mm Horizontal Clamp With Heavy-Duty Arm And Safety Lock, 3.65kN Hold Force - Kukamet
Robust clamping with a massive holding arm, a secure safety lock and a compact 100 mm reach deliver dependable, repeatable workholding for jigging and fixturing; benefit from high holding and pressing forces for efficient cycle times. Order directly via Metav Werkzeuge or ask the technical consultants for application advice. Horizontal clamp 112 — 100 mm arm, 90° lever clamp (Kukamet) The Horizontal clamp 112 is a compact 90° lever clamp designed for secure, repeatable workholding in fixtures and jigs where space and reliability matter Massive holding arm for durable operation Safety locking mechanism for secure clamping 100 mm arm length for compact applications Max holding force 3,650 N for heavy clamping Durable clamping that shortens cycle times A compact lever design combines a massive holding arm with a dedicated safety lock, producing consistent clamping forces that reduce rework and downtime. The specification of 3,650 N holding force and 3,500 N pressing force ensures that the clamp holds components steadily during machining or assembly, so setups remain precise across repeated cycles. For production environments the combination of robust mechanics and repeatable force contributes directly to throughput gains and fewer fixture interventions. Compact mounting and straightforward integration Designed for fixed installation on a vertical foot, the clamp offers a measured reach of 100 mm at a right angle, enabling secure positioning in space-constrained jigs. The compact mass—approximately 0.73 kg—and the blackened finish make the device easy to integrate without adding excessive weight to the fixture. The 90° lever geometry enables quick actuation yet delivers high clamping efficiency; the vertical foot mounting keeps the tool accessible while maintaining a low profile on the workbench. Practical benefits for workshops and small series production Where repeatability and reliability are decisive, this lever clamp supports faster setup and safer handling. The straightforward mechanism minimises operator adjustments and the safety locking mechanism reduces the risk of accidental release, supporting safer workflows. Sourced through Metav’s distribution network, procurement is backed by a quality filter in Emmerich and access to application advice for bespoke requirements. For additional technical data or material compatibility questions, the Metav team is available by email or phone. Secure fixture performance with Kukamet’s robust 112 clamp—contact Metav Werkzeuge in Emmerich for tailored advice and reliable delivery. Technical data SKU: B112-4-D-L-C1 Article: Horizontal clamp 112 EClass: 21041719 ETIM: EC011973 Facts Arm length: 100 mm Angle: 90° Max pressing force: 3,500 N Max holding force: 3,650 N Weight: 0.73 kg Special features Mounting: vertical foot Finish: blackened Massive holding arm Safety locking mechanism Lever clamp type FAQ What clamping force can be expected from this clamp? The Horizontal clamp 112 from Kukamet delivers a maximum holding force of 3,650 N and a pressing force of 3,500 N, providing secure fixation for demanding tasks. Is the clamp suitable for confined fixture spaces? Yes, the 100 mm arm and compact 90° lever layout make the Kukamet Horizontal clamp 112 well suited to tight jigs and compact fixtures. How is the clamp mounted to a fixture? Mounting is by a vertical foot; the design of the Horizontal clamp 112 (SKU B112-4-D-L-C1) keeps the unit stable while allowing accessible actuation. Does the finish offer any practical benefits? The clamp is supplied with a blackened finish, which is typical for workshop hardware and helps to reduce visible wear while retaining a compact visual profile. What safety features does the clamp provide? A dedicated safety locking mechanism prevents accidental release during machining; the robust holding arm further increases operational reliability in Kukamet’s Horizontal clamp 112. Manufacturer: Kukamet Fevzi Çakmak Mah.10644 Sk. No:61-63 42050 Karatay / KONYA TÜRKİYE / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; +49 2822 7131930; eMail: info@metav-werkzeuge.com
90° 100mm Horizontal Clamp With Massive Holding Arm And Safety Lock, 3.65kN Hold Force - Kukamet
Benefit from the combination of a heavy-duty retaining arm with safety lock, galvanised construction and a high holding force for consistent clamping results. Order the clamp directly via Metav Werkzeuge or ask the consultants for application advice. Horizontal clamp 112 by Kukamet — heavy-duty arm, up to 3.65 kN holding force The Horizontal clamp 112 is a compact toggle clamp designed for secure workholding in workshop and production fixtures, featuring a vertical-foot mounting for stable installation. Heavy-duty retaining arm with safety lock Galvanised finish for corrosion resistance 3,650 N maximum holding force Vertical-foot mounting for stable installation Consistent clamping force that reduces rework The clamp delivers a maximum holding force of 3,650 N and a pressing force of 3,500 N, values that ensure firm fixation of small to medium workpieces during machining, assembly or testing tasks. Stated forces describe the mechanical capacity under normal operating conditions; the clear numerical specification enables reliable selection against process demands and contributes to reduced cycle times and fewer clamp-related rejects. The robust force figures make this toggle clamp a practical choice where repeatable pressure and positional stability are required. Durable construction for long service life Constructed from galvanised steel and equipped with a heavy-duty arm, the device resists corrosion and mechanical wear in demanding workshop environments. The integrated safety lock prevents accidental opening under vibration or impact, enhancing operator safety and process reliability. These attributes translate into lower replacement frequency and predictable maintenance intervals, supporting continuous production with minimal interruptions. Space-conscious mounting with precise geometry The clamp is supplied for vertical-foot installation and features a 100 mm arm, allowing compact fixture layouts and straightforward integration into jigs and benches where space is limited. The defined 90° operating angle facilitates repeatable positioning and simplifies fixture design, while the modest weight of 0.73 kg supports easy handling during assembly of clamping stations. Clear mounting geometry reduces setup time and supports efficient fixture standardisation across similar tasks. Practical applications and handling notes Designed for general-purpose clamping tasks, this toggle clamp suits repetitive holding operations in light industrial, maintenance and fabrication settings. The galvanised finish and mechanical locking make it suitable for environments where occasional exposure to moisture occurs. For installation, use secure fastening to the mounting surface and verify the locking engagement before first production runs. The emphasised mechanical features support operators who prioritise reliability and quick clamping cycles without complex adjustments. Choose the Kukamet Horizontal clamp 112 for dependable, low-maintenance clamping — contact Metav Werkzeuge in Emmerich for tailored advice at info@metav-werkzeuge.com or +49 2822 7131930. Technical data Article number: 112-4-D-L-C1 GTIN: 8680731500608 Manufacturer: Kukamet Facts Weight: 0.73 kg Arm length: 100 mm Angle: 90° Maximum pressing force: 3,500 N Maximum holding force: 3,650 N Mounting type: vertical foot eClass: 21041719 ETIM: EC011973 Special features Galvanised material Heavy-duty arm and safety lock Vertical-foot mounting Compact, low-weight design FAQ What maximum holding force does this clamp provide? The clamp offers a maximum holding force of 3,650 N as specified for the Kukamet Horizontal clamp 112 (SKU 112-4-D-L-C1). Is the clamp suitable for damp workshop environments? Yes, the galvanised finish on the Kukamet clamp provides enhanced corrosion resistance, making it appropriate for workshops with occasional moisture exposure. How is the clamp mounted? Mounting is via a vertical foot; the design and the specified 100 mm arm simplify installation into jigs and bench fixtures. Does the clamp have a safety feature to prevent accidental opening? A mechanical safety lock is integrated in the heavy-duty arm to prevent unintended release under vibration or impact. Can the clamp be used in automated fixtures? The clamp’s compact geometry and repeatable 90° operating angle make it suitable for standardised fixtures; evaluation for specific automation systems is recommended. Manufacturer: Kukamet Fevzi Çakmak Mah.10644 Sk. No:61-63 42050 Karatay / KONYA TÜRKİYE / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; +49 2822 7131930; eMail: info@metav-werkzeuge.com
90° 100mm Horizontal Clamp With Massive Holding Arm And Safety Lock, 3500N Clamp Force - Kukamet
Robust clamping with a 3,650 N holding force and a zinc-plated finish ensures dependable fixation in repetitive production tasks; the compact 100 mm arm and horizontal base enable space-efficient installation. Benefit from a solid build and safety locking for consistent results — order through Metav Werkzeuge or contact our advisers for application support. Horizontalspanner 111 — horizontal clamp with 100 mm arm and safety lock (Kukamet) Horizontalspanner 111 is a sturdy horizontal clamp for quick, secure fixture in workshop and light-production environments, optimised for repetitive clamping and compact setups Massive holding arm with safety lock Zinc-plated corrosion-resistant finish 100 mm arm for compact clamping Holding force up to 3,650 N Secure fixation for repeatable production The Horizontalspanner 111 delivers a measurable improvement in process reliability through its high holding force and concise geometry. With a holding force of 3,650 N and a closing force of 3,500 N, the unit maintains consistent clamping pressure across multiple cycles, reducing workpiece shift and scrap rates. The 100 mm arm minimises overhang while the compact mass (approx. 0.73 kg) keeps inertial loads low, making the clamp suitable for jigs, fixtures and short-cycle production where repeatability and cycle time are decisive. Durable construction that reduces downtime Constructed with a zinc-plated finish and a massive holding arm, the clamp resists corrosion and mechanical wear in workshop conditions, extending service life and lowering maintenance needs. The integrated safety locking mechanism secures the lever in the clamped position, preventing accidental release during machining or handling and contributing to workplace safety. The horizontal base mounting provides a flat, stable interface for plate or fixture attachment, enabling straightforward replacement of older or less robust clamping elements. Compact layout and practical mounting for flexible setups A 90° orientation and the horizontal-foot design allow the clamp to be mounted close to the workpiece, conserving valuable table space and enabling denser fixture arrangements. The zinc-plated material combines cost-efficiency with corrosion protection, and the clamp’s geometry supports rapid manual operation as well as integration into semi-automated workstations. For applications requiring controlled press-in or holding operations, the device’s performance characteristics offer a clear, measurable benefit in cycle consistency and fixture stability. Contact Metav Werkzeuge for tailored advice and secure supply of the Kukamet Horizontalspanner 111 from our Emmerich stock, including guidance on integration into existing jigs and delivery options Technical Data SKU: 111-4-D-L-C1 GTIN: 8680731500264 eClass: 21041719 ETIM: EC011973 Facts Arm length: 100 mm Holding force max: 3,650 N Closing force max: 3,500 N Weight: 0.73 kg Angle: 90° Special features Material: zinc-plated Mounting: horizontal base Massive holding arm Safety locking mechanism FAQ What clamping forces does the Horizontalspanner 111 provide? The Horizontalspanner 111 offers a holding force of up to 3,650 N and a closing force of 3,500 N, suitable for light to medium-duty fixture tasks. Is the clamp suitable for corrosive workshop environments? Yes, the zinc-plated finish on the Horizontalspanner 111 provides corrosion resistance for typical workshop conditions and extends service life. How is the clamp mounted to a fixture plate? The clamp is designed for horizontal base mounting, allowing secure attachment to flat fixture plates or jig bases in a 90° orientation. Can the safety locking mechanism prevent accidental release during machining? The integrated safety locking mechanism secures the lever in the clamped position, reducing the risk of unintended opening during handling or machining. Manufacturer: Kukamet Fevzi Çakmak Mah.10644 Sk. No:61-63 42050 Karatay / KONYA TÜRKİYE / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; +49 2822 7131930; eMail: info@metav-werkzeuge.com
90° 100mm Horizontal Clamp With Massive Holding Arm, 3.65kN Hold Force - Kukamet
Take advantage of the combination of robust construction, a 3,650 N holding capacity and a 100 mm solid arm for reliable and repeatable workholding. Order the horizontal toggle clamp directly via Metav Werkzeuge or request advice from our consultants. Horizontal toggle clamp 111 — horizontal workholding clamp with 100 mm arm (Kukamet) The Horizontal toggle clamp 111 is a rugged horizontal clamp designed for secure fixture work and repeatable positioning in jigs and assembly stations. Horizontal mounting with robust foot 3,650 N maximum holding force Galvanised finish for corrosion resistance 100 mm solid holding arm Consistent, measurable clamping for production use The clamp delivers a 3,650 N holding force with a maximum clamping or pressing force of 3,500 N, providing measurable results that reduce variation between setups. The reinforced, massive holding arm maintains alignment under load, which helps to lower rework rates and improves component repeatability in series production. The right-angle design (90°) facilitates predictable clamping geometry, while the solid arm length of 100 mm offers a balance between reach and stiffness for fixtures that require defined workpiece clearance. Durable materials and straightforward integration into fixtures Constructed from galvanised steel, this horizontal clamp resists corrosion in workshop environments and sustains long service life with minimal upkeep. The horizontal foot mounting allows direct fastening to plates or tooling blocks, enabling fast integration into jigs without complex adapters. Weighing approximately 0.72 kg, the clamp is compact yet sturdy, supporting toolroom and light-industrial applications where durability and compact footprint matter. The toggle mechanism provides rapid locking and unlocking for efficient cycle times on manual and semi-automated stations. Practical benefits and typical applications Designed for robust workholding in welding jigs, assembly fixtures and general clamping tasks, the clamp offers a reliable toggle action that secures components quickly and safely. Its reinforced arm and secure foot mounting reduce fixture drift and maintain consistent pressure across repetitive cycles. For toolmakers and production engineers looking for a straightforward mechanical clamping solution, this model simplifies fixture design while delivering repeatable holding performance. Where consistent clamping force and corrosion resistance are priorities, the combination of materials and mechanics yields improved process stability. Contact Metav Werkzeuge for ordering, detailed technical advice and fixture recommendations for the Kukamet Horizontal toggle clamp 111; call +49 2822 7131930 or email info@metav-werkzeuge.com Technical data SKU: 111-4-D-C1 GTIN: 8680731500233 Model: 111 Manufacturer: Kukamet Facts Arm length: 100 mm Holding force: 3,650 N Clamping force (max): 3,500 N Weight: 0.72 kg Clamping angle: 90° Special features Material: galvanised Mounting: horizontal foot Massive holding arm Reinforced toggle mechanism eClass: 21041719 ETIM: EC011973 FAQ What is the maximum holding force of this clamp? The maximum holding force is 3,650 N for the Kukamet Horizontal toggle clamp 111, providing a measurable basis for fixture design and repeatability. How is the clamp mounted to a fixture plate? Mounting is via a horizontal foot; the horizontal foot design of the Horizontal toggle clamp 111 allows direct bolting to plates or tooling blocks for straightforward integration. What material and finish does the clamp have? The clamp is made from galvanised steel, which gives the product corrosion resistance suitable for typical workshop conditions. Is the arm length suitable for jig work with limited clearance? The 100 mm solid arm offers a compromise between reach and rigidity, making the clamp suitable for many jigs where defined clearance and stiffness are required. Can the clamp be used for repeated production cycles? Yes. The reinforced arm and toggle action of the Kukamet Horizontal toggle clamp 111 are designed for repeatable clamping in production and assembly environments. Manufacturer: Kukamet Fevzi Çakmak Mah.10644 Sk. No:61-63 42050 Karatay / KONYA TÜRKİYE / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; +49 2822 7131930; eMail: info@metav-werkzeuge.com
90° 100mm Horizontal Clamp With Massive Holding Arm, Max Hold 3,650N, Galvanised - Kukamet
A compact, lever-operated clamp that combines a 100 mm reach with a 3,650 N holding force for secure, repeatable workholding; galvanised construction and a vertical-foot mount make it robust and simple to integrate on fixtures. Order the clamp directly via Metav Werkzeuge or ask our consultants if additional specifications are required. Horizontal clamp 112 by Kukamet — 100 mm reach, 3,650 N holding force The Horizontal clamp 112 is a lever-operated workholding clamp designed for fixture and jig applications, mounted on a vertical foot at a 90° orientation for compact assembly-line integration. Massive holding arm for secure clamping Vertical-foot mounting, 90° orientation 100 mm reach for versatile setups Galvanised construction resists corrosion Secure clamping that keeps production moving The robust lever mechanism delivers a high holding force and reliable contact pressure, ensuring components remain fixed during machining, assembly and testing. With a holding force of 3,650 N and a maximum pressing capacity of 3,500 N, the clamp provides the mechanical certainty required for repetitive processes. The defined clamping values reduce rework and downtime, supporting predictable cycle times and stable throughput in production environments. Space-efficient design for flexible fixture layouts A compact footprint and vertical-foot mounting allow the clamp to be fitted in tight fixtures without sacrificing access or tool clearance. The 100 mm arm reach gives a practical balance between reach and compactness, while the massive holding arm improves load distribution and contact stability. At approximately 0.72 kg, the unit is lightweight enough for modular fixturing yet heavy-duty in behaviour, aiding fast reconfiguration and reduced handling effort during setup. Durable finish and low-maintenance operation Finished in galvanised steel, the clamp resists corrosion in workshop environments and maintains consistent performance over time. The simple lever actuation minimises moving parts susceptible to wear, which reduces maintenance intervals and service costs. Installation on a vertical foot at 90° is straightforward, and routine care typically involves only periodic inspection and light lubrication to preserve smooth operation and clamping accuracy. For tailored advice on integrating the Kukamet 112 into existing fixtures, contact Metav Werkzeuge for specification support and fast supply from Emmerich. Technical data Article number: 112-4-D-C1 GTIN: 8682843524084 Category: Spanner eClass: 21041719 ETIM: EC011973 Numbers / Core technical data Arm length: 100 mm Weight: 0.72 kg Max pressing force: 3,500 N Max holding force: 3,650 N Angle: 90° Special features Material: Galvanised Mounting: Vertical foot Massive holding arm Model: 112 SKU: 112-4-D-C1 FAQ What clamping forces does the clamp provide? The Kukamet horizontal clamp 112 offers a maximum holding force of 3,650 N and a pressing capacity of 3,500 N, values intended for secure and repeatable fixture clamping. How is the clamp mounted and oriented? Mounting is on a vertical foot with a 90° orientation, enabling compact integration into fixtures and jigs while maintaining clear lever access. What is the construction and finish of the clamp? The unit is made from galvanised steel and features a massive holding arm to improve contact stability and resistance to workshop corrosion. Is the clamp suitable for modular fixture systems? Yes, the 100 mm arm length and compact, lightweight design support modular fixturing and quick reconfiguration in production and assembly lines. What maintenance is required? Routine maintenance is minimal: periodic inspection, light lubrication of the pivot points and checking fastenings are typically sufficient to retain consistent clamping performance. Manufacturer: Kukamet Fevzi Çakmak Mah.10644 Sk. No:61-63 42050 Karatay / KONYA TÜRKİYE / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; +49 2822 7131930; eMail: info@metav-werkzeuge.com
90° 100mm Horizontal Clamp With Solid Holding Arm, 3.65kN Holding Force - Kukamet
Benefit from a 100 mm arm, up to 3,500 N clamping force and a massive holding arm for secure, repeatable fixturing. The compact weight of 0.72 kg supports easy handling without compromising stability. Order the clamp directly via Metav Werkzeuge or ask the consultants if needed. Horizontal clamp 112 — Kukamet lever clamp with 100 mm arm and 3,500 N force Horizontal clamp 112 is a lever-operated clamp for fixture and jig applications, offering a vertical-foot mounting and a 90° clamping angle for space-saving installation 100 mm holding arm Up to 3,500 N clamping force Vertical-foot mounting Blackened finish for corrosion resistance Reliable force for demanding clamping tasks The clamp delivers a clear performance specification: 3,500 N maximum clamping force with a 3,650 N holding capability, making it suitable for repetitive securing of workpieces in production and assembly. These figures indicate how much axial load the mechanism can resist; in practice this enables secure retention during machining, routing or positioning operations where consistent pressure is required. The solid lever design and the massive holding arm reduce flexing under load, improving repeatability and reducing rework. Fast set-up and compact integration into jigs Designed for quick, repeatable operation, the device features a 100 mm arm and a right-angle (90°) actuation that keeps the lever clear of adjacent tooling. The vertical-foot mounting simplifies integration into fixtures and reduces the overall footprint on the fixture plate. At 0.72 kg the unit is lightweight enough to handle during assembly yet substantial enough to provide a rigid clamping point, supporting efficient changeovers and reduced cycle times in manual and semi-automated routines. Durable finish and workshop-ready construction Finished in a blackened finish that improves corrosion resistance and blends into industrial environments, the clamp is built for everyday workshop use. The combination of robust materials and simple lever mechanics means low maintenance and predictable lifecycle behaviour; occasional lubrication and inspection are typically sufficient to maintain performance. The compact geometry and clear force ratings support planning for fixtures where precise and repeatable holding is essential. Contact Metav Werkzeuge for expert advice and reliable supply of the Kukamet Horizontal clamp 112 — eMail info@metav-werkzeuge.com or call +49 2822 7131930 Technical data SKU: B112-4-D-C1 GTIN: 8680731507287 Manufacturer: Kukamet Weight: 0.72 kg Facts Arm length: 100 mm Maximum clamping force: 3,500 N Maximum holding force: 3,650 N Angle: 90° Mounting: vertical foot eClass: 21041719 ETIM: EC011973 Special features Material / finish: blackened finish Massive holding arm Lever-operated horizontal clamp Category: Clamps FAQ What clamping force can be expected in routine use? The Kukamet Horizontal clamp 112 specifies a maximum clamping force of 3,500 N; in routine use this allows secure retention for machining and assembly tasks that require consistent pressure. Is the clamp suitable for integration into jigs and fixtures? Yes — the vertical-foot mounting and compact 90° lever geometry are designed for easy installation into jig plates and fixture assemblies. How durable is the surface treatment? The clamp features a blackened finish that enhances corrosion resistance for workshop environments and reduces visible wear from handling. Can the clamp be used for heavy-duty production cycles? With a massive holding arm and rated holding capability of 3,650 N, the device is designed for repetitive production use where a robust, repeatable clamp point is required. What identifiers should be quoted when ordering spare parts or replacements? Please quote the SKU B112-4-D-C1 and the GTIN 8680731507287 to ensure correct identification of the Kukamet horizontal clamp Manufacturer: Kukamet Fevzi Çakmak Mah.10644 Sk. No:61-63 42050 Karatay / KONYA TÜRKİYE / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; +49 2822 7131930; eMail: info@metav-werkzeuge.com
Fast, secure workpiece clamping with toggle clamps
Toggle clamps, also known as knee lever clamps or lever clamps, are mechanical clamping elements used to fix components quickly and reliably in fixture construction, assembly, welding and testing. Their kinematic knee lever principle provides a one-motion closure that locks beyond a mechanical dead centre, delivering consistent clamping force with minimal operator effort.
How the locking principle benefits production
The kinematic dead-centre action means the clamp self-locks once closed, so no continuous force is required on the handle and the workpiece remains form-stable even under process-induced vibration. That behaviour translates directly into higher process reliability and faster cycle times: operators close the clamp in one swift move, parts stay in position during machining or inspection, and changeover times are reduced.
Practical advantages for everyday workshop use
- Reduced set-up time through single-motion clamping
- Consistent repeatability and process stability under vibration
- High holding force with low operator effort thanks to the dead-centre mechanism
- Durable construction for long service life in repetitive production
- Versatile mounting options for vertical, horizontal, push‑rod and draw applications
Technical overview
- principle: kinematic knee lever (dead-centre) locking
- application areas: fixture construction, assembly, welding, testing
- design variants: vertical clamp, horizontal clamp, push-rod clamp, draw/closure clamp
- material: high-strength zinc-plated steel; stainless steel options
- handle: ergonomic, oil-resistant handles
- joints: wear-resistant joint bushes
- process suitability: holds under strong, process-induced vibration; enables high repeatability
Metav as your precision partner
Metav combines decades of specialist knowledge with a broad, dependable assortment for industry and trade. With more than 48,000 customers, a catalogue exceeding 250,000 products and a quality filter based in Emmerich, Metav offers a practical, low-risk route to robust toggle clamps and accessories—ideal for buyers who need dependable stock, expert selection and consistent product quality.
In short: toggle clamps (knee lever clamps / lever clamps) deliver rapid, repeatable clamping with minimal operator effort, making them a straightforward productivity upgrade for demanding production environments.
FAQ
What exactly is a toggle clamp and how does it lock?
A toggle clamp uses a kinematic knee lever that passes a mechanical dead centre during closure; once over‑centre, the clamp self-locks, maintaining clamping force without continuous pressure on the handle.
Which toggle clamp type should I choose for sheet assembly or for pulling covers together?
Use vertical or horizontal toggle clamps for holding sheets and assemblies; choose draw/closure clamps when axial pulling or form closing is required. The variety of toggle clamp designs matches different fixture geometries and force directions.
Are toggle clamps suitable for high-vibration processes?
Yes. The dead‑centre locking of toggle clamps secures the workpiece even under strong, process-induced vibration, ensuring positional stability during machining or testing.
What materials and handle options are available for toggle clamps?
Common materials: zinc-plated steel and stainless steel. Handles are typically ergonomic and oil-resistant; joints use wear-resistant bushes for extended service life.
Can Metav help specify the right toggle clamp for my application?
Metav supplies a wide selection of toggle clamps and technical information, enabling selection based on application, material and required holding force; the assortment is supported by decades of precision experience and a large customer base.
