11mm Quick-Change Insert SES 9mm Square, Adjustable Safety Torque Coupling, L3 24.5mm - TECWERK
Benefit from an adjustable safety clutch that limits torque to avoid tap breakage and a secure 9 mm square shank torque transmission compatible with DIN 374/376 M14; order the quick-change insert directly via Metav Werkzeuge or consult our specialists for integration advice. Quick-change insert SES 11 mm × 9 mm Gr.1 – adjustable safety clutch for DIN 374/376 M14 (TECWERK) The Quick-change insert SES 11 mm × 9 mm Gr.1 is a compact torque-limiting interface designed for M14 thread taps, enabling safer tapping operations and rapid tool exchange in production and workshop environments. Adjustable safety clutch for torque control Prevents thread tap breakage 9 mm square shank torque transmission Compatible with DIN 374/376 M14 taps Reduce tap breakage and keep production running The most immediate gain from an insert with an adjustable safety clutch is a measurable reduction in tap failures. By limiting the transmitted torque, the module protects the tap at the moment of thread jamming or sudden load peaks; this reduces unscheduled downtime and the need for costly rework. The torque is transferred via a square shank, ensuring a positive mechanical drive that minimises slippage and wear on the drive interface. For machine shops that run high volumes of tapping operations, the safety clutch converts into fewer production interruptions and more predictable cycle times. Seamless integration with standard tap toolchains Designed for compatibility with taps conforming to DIN 374/376 M14, this quick-change coupling slots into existing toolholders without major rework of the set-up. The insert’s modular approach means different shank sizes use matching inserts, preserving a standardised tool inventory while allowing the workshop to adapt to varying shank dimensions. Installation and replacement are straightforward, so the insert supports lean workflows and helps maintain throughput. The combination of precise torque limitation and a standardised interface enables controlled machining results and a consistent thread quality. Compact construction that speeds changeovers and protects tools A compact form factor reduces interference and simplifies handling during tool changes, which shortens non-productive time at the spindle. The design focuses on rapid exchange and robust torque transfer: the square drive transmits force reliably while the clutch disengages under overload, prolonging both tap life and the life of sockets and drive tools. The result is higher uptime, reduced tooling costs over time and a calmer planning horizon for maintenance cycles — benefits that add up in busy workshops and production lines. For a tailored recommendation on the TECWERK SES quick-change insert and assistance with selecting the correct shank size, contact Metav Werkzeuge — phone +49 2822 7131930 or email info@metav-werkzeuge.com Technical data Article number: 4000832673NW Product: Quick-change insert SES Label: Quick-change insert SES 11 mm × 9 mm Gr.1 for DIN 374/376 M14 Manufacturer: TECWERK Facts Diameter: 11 mm Square shank: 9 mm L3: 24.5 mm L4: 21.5 mm L5: 25.5 mm D: 32 mm L1: 18.5 mm D1: 19 mm Packaging unit: 1 Special features Adjustable safety clutch for torque limitation Prevents thread tap breakage Torque transmission via shank square For use with DIN 374/376 M14 thread taps Different inserts required for other shank sizes FAQ Is the insert compatible with M14 taps to DIN 374/376? Yes. The Quick-change insert SES 11 mm × 9 mm Gr.1 is specified for taps conforming to DIN 374/376 M14 and transmits torque through a 9 mm square shank. How does the adjustable safety clutch reduce tap failures? The clutch disengages or slips at a preset torque, interrupting peak loads before a tap fractures; this mechanism on the SES insert protects the tap and connected drive components. Can the torque limit be adapted to different materials or tap sizes? Torque settings can be adjusted to suit common tapping scenarios, allowing optimisation for softer or harder workpiece materials and for varying thread sizes used with the SES insert. Are different inserts needed for other shank dimensions? Yes. The SES system uses inserts matched to the shank dimension; different square-shank sizes require the corresponding insert to ensure correct torque transmission. What dimensions should be checked before ordering? Verify the drive square (9 mm), the nominal diameter (11 mm), and the relevant length dimensions (L1, L3, L4, L5) to ensure compatibility with the toolholder and tap depth. Manufacturer / Responsible: NORDWEST Handel AG, Robert-Schuman-Straße 17, 44263 Dortmund
11mm Quick-Change Insert SES 9mm Square, Adjustable Torque-Limit Coupling for DIN 374/376 M14 - TECWERK
Take advantage of precise torque control and a compact, service-friendly design to protect taps and reduce downtime; order directly via Metav Werkzeuge or consult the team for application advice. Quick-change insert SES 11 mm x 9 mm, Size 2 – adjustable safety coupling (TECWERK) Quick-change insert SES 11 mm x 9 mm Size 2 provides a torque-limiting adapter for thread tapping applications, designed for use with DIN 374/376 M14 taps and workshop toolholders Adjustable safety coupling for torque limitation Prevents tap breakage during threading Compatible with DIN 374/376 M14 taps 9 mm square drive for positive torque transfer Reduce tool breakage and maintain production flow The adjustable safety coupling built into this quick-change insert limits torque transmission when resistance rises unexpectedly, significantly reducing the risk of tap breakage. As a result, thread production becomes more reliable and less prone to costly stoppages; the mechanism disengages before a tap sustains irreversible damage, protecting consumables and avoiding rework. This measurable reduction in scrap and downtime translates into better throughput and lower total operating cost per threaded component. Precise torque control for consistent threads Torque is transferred through the 9 mm square drive, ensuring a positive, backlash-free connection between driver and tap shank; the torque-limiting element is adjustable to suit the thread size and material conditions. Because the torque is controlled mechanically rather than electronically, the system reacts instantly to overloads and maintains thread quality across batches. The result is repeatable, consistent threads with fewer rejects and a predictable process window for production planners and workshop engineers. Compact design that integrates with existing tooling With a compact footprint (D 50 mm, D1 31 mm, L1 32 mm) and a nominal diameter of 11 mm, the insert fits into common toolholders while keeping the working envelope small. The torque is transmitted over the shaft square, so different shank dimensions require corresponding inserts; this modular approach lets maintenance teams replace only the worn insert instead of the entire driver assembly. The compact size and standard interface simplify storage and logistics in busy workshops. Engineered for workshop practicality and safety The unit is supplied as a single-piece package and is intended for quick replacement when wear occurs. The mechanical limiting principle provides a clear operational advantage: fast recovery after an overload without complex reset procedures. Documentation and simple adjustment make the insert suitable for both production environments and skilled maintenance teams that demand robust, service-friendly components from a recognised supplier. For tailored advice on integrating the TECWERK SES quick-change insert into existing tapping stations, contact Metav Werkzeuge for specification support and ordering assistance. Product data Article number: 4000832679NW Product type: Quick-change insert SES Size: Size 2 Brand: TECWERK Suitable for: DIN 374/376 M14 Dimensions & core data Diameter: 11 mm Square drive: 9 mm L1: 32 mm L3: 30.5 mm L4: 35 mm L5: 34 mm D: 50 mm D1: 31 mm Packaging unit: 1 Special features Adjustable safety coupling for torque limitation Torque transfer via shaft square Prevents tap breakage Requires matching inserts for other shaft sizes FAQ Which tap types are compatible with this quick-change insert? The quick-change insert SES 11 mm x 9 mm Size 2 is compatible with taps to DIN 374/376 M14 and designed to interface with standard tap shanks using the 9 mm square drive. How does the adjustable safety coupling work? The adjustable safety coupling in the TECWERK SES insert mechanically limits torque transmission; when the set torque is exceeded, the coupling slips to prevent damage to the tap and driver. Is a special driver required to use this insert? No special driver is required beyond a matching toolholder that accepts the SES interface and the 9 mm square drive; different shank sizes call for the corresponding insert variant. Can the torque setting be changed during operation? Torque adjustment is performed using the coupling mechanism; settings should be adjusted when the tool is stationary and according to workshop safety procedures. What dimensions should be checked before ordering? Verify the square drive (9 mm), the overall diameter (11 mm) and the key envelope dimensions (D 50 mm, L1 32 mm) to ensure compatibility with existing holders and clearance conditions. Manufacturer/Responsible: NORDWEST Handel AG, Robert-Schuman-Straße 17, 44263 Dortmund
120mm Machine Foot Size 2 Zinc-Plated, M16 x 1.5 x 120 Thread - TECWERK
Take advantage of a zinc-plated levelling mount with a M16 x 1.5 x 120 mm threaded stud and a Ø 120 mm support plate for secure, vibration-isolating support; suitable for lathes, milling machines and saws. Order the part directly via Metav Werkzeuge or consult the advisors for sizing and supply. ALBRECHT machine foot Size 2 – zinc-plated levelling mount, M16 thread (TECWERK) The ALBRECHT machine foot Size 2 is a zinc-plated levelling mount designed to provide stable support and vibration isolation for heavy workshop machinery such as lathes and milling equipment Zinc-plated for corrosion protection Threaded stud M16 x 1.5 x 120 mm Ø 120 mm base with 18 mm levelling travel Max static load 400–1000 kg per foot Secure levelling and dual vibration isolation The zinc-plated mount provides a dependable support platform, combining a M16 x 1.5 x 120 mm threaded stud with a Ø 120 mm base to distribute loads evenly across the shop floor. The specification lists a max static load of 400–1000 kg per foot and an overall installed height of 49 mm, delivering the mechanical stability required for precision operations. By isolating vibrations from the machine to the environment and shielding precision machines from external disturbances, this levelling mount helps preserve component tolerances and maintain consistent machining results. Correct sizing and straightforward installation for reliable operation Determining the right mount is a simple, rational process: establish the total machine mass, divide by the number of fixing points and compare the result with the foot’s rated load. The unit’s 18 mm levelling travel allows for fine adjustment on uneven floors, while the threaded stud simplifies secure attachment to machine bases. Proper selection and installation reduce wear on bearings and guides, lower the risk of misalignment and support uninterrupted production by preventing micro-movements and tilt during machining cycles. Durable finish and workshop-ready versatility A corrosion-resistant finish and a broad bearing surface make this levelling mount suitable for heavy-duty workshop environments where coolant, dust and humidity are present. The Ø 120 mm support plate resists indentation and spreads load over a larger area, reducing point loading on shop floors. Maintenance is minimal: scheduled inspections of the levelling plate and thread ensure ongoing performance, while the robust design contributes to long service life and dependable machine placement in both general engineering and precision workshops. For reliable levelling and effective vibration control, choose the TECWERK ALBRECHT machine foot Size 2 and contact Metav Werkzeuge for expert advice and dependable supply from Emmerich: info@metav-werkzeuge.com | +49 2822 7131930 Technical data Article number: 4000832073NW Label: Maschinenschuh Gr. 2 ALBRECHT Product type: Maschinenschuh Manufacturer: TECWERK Packaging unit: 1 Facts Ø D: 120 mm Height incl. levelling plate H: 49 mm Levelling travel N: 18 mm Threaded stud G: M16 x 1.5 x 120 mm Max static load per foot: 400–1000 kg Special features Zinc-plated finish Suitable for lathes, milling machines, saws and other machines Dual vibration isolation (machine-to-environment and external-to-machine) Simple sizing via weight divided by number of fixing points FAQ What static load can each mount support? The ALBRECHT machine foot Size 2 is rated for a max static load of 400–1000 kg per foot; the allowable load per mounting depends on the machine’s total weight and the number of fixing points. How much levelling adjustment is available? This levelling mount offers 18 mm of levelling travel and an installed height of 49 mm, allowing for fine height correction on uneven floors. Is the finish suitable for humid or coolant-prone environments? The zinc-plated finish on the ALBRECHT mount provides increased resistance to corrosion, making it appropriate for workshop conditions with occasional coolant exposure or higher humidity. Which machine types are appropriate for this levelling mount? The levelling mount is suitable for heavy workshop equipment such as lathes, milling machines and saws, where stable positioning and vibration isolation improve process stability. TECWERK: Manufacturer / Responsible: NORDWEST Handel AG, Robert-Schuman-Straße 17, 44263 Dortmund
12mm Clamping Screw M10 for 10mm Chuck - TECWERK
Take advantage of the M10 threaded interface and a compact 12 mm overall length for secure, space-saving clamping; ideal for 10 mm chucks and tools conforming to DIN 1835-B. Order the clamping screw directly via Metav Werkzeuge or ask our consultants for application advice. Spannschraube M10 L.12mm f.Spannfutter-D.10mm TECWERK — clamping screw with M10 thread for 10 mm chucks The Spannschraube M10 L.12mm f.Spannfutter-D.10mm TECWERK is a precision clamping screw intended for face clamping chucks and for securing tools with a cylindrical shank and lateral drive face according to DIN 1835-B, optimised for compact toolholding assemblies M10 threaded clamping screw Compact 12 mm overall length Compatible with 10 mm chuck diameters Suitable for tools to DIN 1835-B Precise thread engagement for repeatable setups The M10 thread offers secure mechanical engagement with standard clamping bodies, reducing axial play and helping to maintain repeatable positions across production runs. With adherence to DIN 1835-B for tools with a lateral drive face, the design ensures a reliable interface between the tool shank and the chuck, which translates into consistent concentricity and predictable machining outcomes. This controlled connection reduces setup variability and supports stable running conditions for short, frequent tool changes. Space-saving length that suits compact toolholders A total length of 12 mm keeps the clamping element compact without compromising its clamping function, making it particularly suitable where installation depth is limited. For chucks with a 10 mm bore diameter, this compact profile permits close tool spacing and improves accessibility in tight spindle or turret arrangements. The reduced projection minimises collision risk during tool indexing and contributes to a neater tool assembly that supports faster changeover cycles. Broad compatibility to simplify workshop logistics Designed for use with face clamping chucks, the component accommodates tools featuring a cylindrical shank and lateral drive face, facilitating straightforward integration into existing fixtures. Compatibility with common chuck systems lowers the need for special adaptors and helps standardise spares across a fleet of machines. The clear conformity to established standards makes this clamping element a pragmatic choice for workshops seeking to reduce part variety while maintaining operational flexibility. Practical benefits for production efficiency Choosing a compact, standardised clamping screw improves uptime through quicker installation and dependable clamping force, which in turn reduces rework and inspection effort. The simple geometry and standard M10 interface support fast replacement and interchangeability, helping to keep machine downtime to a minimum. For further clarification on suitability for a particular chuck or application, technical advice is available to ensure correct selection and integration. For tailored advice on integrating this TECWERK clamping screw into existing toolholding systems, contact Metav Werkzeuge for expert guidance and sourcing assistance Technical Data Article number: 2000834136NW Label: Spannschraube M10 L.12mm f.Spannfutter-D.10mm TECWERK Brand: TECWERK Facts Thread: M10 Overall length: 12 mm Recommended chuck Ø: 10 mm Packaging unit: 1 Special features For face clamping chucks For clamping tools with cylindrical shank with lateral drive face Conforms to DIN 1835-B Suitable for compact toolholding assemblies FAQ What thread does the clamping screw use? The clamping screw uses an M10 thread, matching standard clamping bodies for stable engagement. Is this component suitable for a 10 mm chuck? Yes, the clamping screw is designed for 10 mm chuck diameters and compact assemblies. Which tool shank standard is supported? The component supports tools with a cylindrical shank and lateral drive face in accordance with DIN 1835-B. Can this part be used across different face clamping chucks? It is intended for use with face clamping chucks and is compatible with systems that accept an M10 clamping element for 10 mm bores. Manufacturer/Responsible: NORDWEST Handel AG, Robert-Schuman-Straße 17, 44263 Dortmund
12mm Coolant Supply Tube HSK 63 DIN 69893 Form A M18 x 1.0, L34.5mm - TECWERK
Reliable coolant delivery for precision HSK setups is achieved by the combination of a 12 mm internal bore and an M18 x 1.0 threaded connection with an integrated sealing ring; order the part directly via Metav Werkzeuge or contact our consultants for fitment advice. Coolant transfer pipe HSK 63 – M18 x 1.0 thread, 12 mm bore (TECWERK) A coolant transfer pipe HSK 63 engineered for secure coolant routing in hollow-shank taper tool systems, compliant with DIN 69893 Form A and intended for precise machining environments For HSK 63, DIN 69893 Form A 12 mm internal bore for steady coolant flow M18 x 1.0 external thread with sealing ring Length 34.5 mm, compact installation Consistent coolant flow to protect cutting edges and tool life A stable supply of cutting fluid directly to the tool is a decisive factor for tool life and process stability. The 12 mm internal bore is calculated to maintain a continuous flow rate under pressure, reducing thermal peaks at the cutting edge and lowering the risk of premature wear. Conformity with DIN 69893 Form A ensures mechanical compatibility with standardised holders, while the functionality of internal coolant routing supports higher metal removal rates and improved surface finish. These performance advantages translate into fewer tool changes and steadier cycle times on the shop floor. Compact, secure installation that minimises downtime The external M18 x 1.0 connection and included sealing ring provide a straightforward mechanical interface for assembly into HSK tool holders. With a total length of 34.5 mm, the component fits compact toolholder geometries without creating interference, enabling quick replacement or retrofitting in confined spindle environments. The threaded connection guarantees repeatable positioning and leak-free operation once fitted correctly, which reduces the need for frequent maintenance interventions and supports continuous production runs. Industry-compliant design and supply reliability Manufactured for hollow-shank taper applications in line with ISO 12164 standards, this transfer tube is tailored for precision tool systems where standard conformity matters. The compact design facilitates integration into existing coolant circuits while retaining measurable, comparable specifications for procurement and inspection. For buyers seeking reliable sourcing, TECWERK supplies the part with clear identification, and Metav Werkzeuge acts as a trusted distribution partner, offering consolidated procurement and dependable delivery from Emmerich. For a precise fit in HSK 63 holders and reliable coolant routing, request technical advice or availability from Metav Werkzeuge; Metav’s team can confirm compatibility and dispatch the part promptly from Emmerich. Technical data Article number: 4000832712NW Manufacturer: TECWERK Product type: Coolant transfer pipe Tool interface: HSK 63 Standard: DIN 69893 Form A Core specifications Internal diameter: 12 mm Total length: 34.5 mm Thread: M18 x 1.0 Packaging unit: 1 Special features For hollow shank taper tools ISO 12164 (DIN 69893) Form A Supplied with sealing ring Compact design for tight toolholder geometries FAQ Is this part compatible with HSK 63 toolholders? Yes. The coolant transfer pipe is made for HSK 63 interfaces and complies with DIN 69893 Form A; the SKU is 4000832712NW for reference. What are the thread and internal bore sizes? The component features an M18 x 1.0 external thread and a 12 mm internal bore, with a total length of 34.5 mm. Does the delivery include a sealing ring? Yes. The transfer pipe is supplied with a sealing ring to ensure leak-free installation when fitted into a compliant holder. Can this be used with hollow-shank taper tools to feed internal coolant? Yes. It is designed specifically for hollow shank taper tools in accordance with ISO 12164 (DIN 69893) Form A. Is the material of the component specified? No material information is provided for this SKU; refer to the supplier for material confirmation if required. Manufacturer / Responsible: NORDWEST Handel AG, Robert-Schuman-Straße 17, 44263 Dortmund
12mm ER 25-GB Collet 9mm Square For Threading, 15 µm Runout · 40mm Length - TECWERK
Fast, precise clamping with 15 µm runout and a 12 mm bore delivers consistent concentricity and reliable thread-cutting performance; the ER‑GB design to DIN 6499 with an internal square helps secure taps and cutters for repeatable results. Order the ER‑GB collet directly via Metav Werkzeuge or ask our consultants if needed. ER‑GB collet (ER 25‑GB) — 12 mm bore, 15 µm runout | TECWERK A ER‑GB collet designed for precision clamping in thread‑cutting and general ER chuck applications, complying with DIN 6499 for professional workshop use ER‑GB design to DIN 6499 Internal square for thread‑cutting High runout accuracy 15 µm 12 mm bore, 40 mm length Maintain concentricity for consistent part quality The primary advantage of this clamping sleeve is its runout accuracy: at 15 µm the collet ensures the tool axis remains highly concentric to the spindle, which directly reduces wobble and improves surface finish. For processes such as tapping or small‑diameter milling, this level of precision minimises thread errors and reduces scrap rates. In practical terms, better concentricity prolongs cutter life and lowers rework, supporting a smoother production flow. Secure thread‑cutting and straightforward compatibility Equipped with an internal square specifically to accommodate taps, the collet streamlines thread‑cutting operations and prevents slippage during torque transfer. Built to DIN 6499 standards, the clamping sleeve fits ER‑type holders and is suitable for use in thread‑cutting and ER collet chucks. Key dimensions — 12 mm bore, 9 mm internal square and 40 mm length — provide a compact, robust interface that integrates easily into existing tooling systems without extensive setup changes. Practical benefits for the workshop and process reliability With its compact 40 mm length and standard ER‑GB geometry, the component is easy to handle, replace and stock. The precise fit reduces setup time and helps maintain repeatability across batches, while the standardised form factor makes it compatible with a wide range of ER chucks and toolholders. This combination of precision and practicality supports efficient machining cycles and dependable results in daily shopfloor use. For secure thread‑cutting and reliable clamping choose the TECWERK ER‑GB collet via Metav Werkzeuge — expert advice and fast supply from Emmerich are available at info@metav-werkzeuge.com or by phone on +49 2822 7131930 Technical data Article number: 2000834976NW Type: ER 25-GB Product: GB collet Brand: TECWERK Core dimensions Clamping range: 12 mm Bore (d): 12 mm Length (L): 40 mm Internal square: 9 mm Runout: 15 µm Special features DIN 6499 construction Internal square for thread‑cutting Suitable for thread‑cutting and ER chucks Precise toolholding for repeatable results FAQ What spindle runout can be expected with this collet? The listed runout for the ER‑GB collet is 15 µm, which indicates the concentricity you can expect when the collet is combined with a properly prepared ER holder and spindle. Is this collet suitable for tapping operations? Yes. The internal square is intended for thread‑cutting applications so taps can be held securely during torque transmission. Which ER holders are compatible with this collet? The collet follows DIN 6499 geometry and is compatible with standard ER collet chucks and thread‑cutting collet holders designed for ER‑GB series parts. What are the key dimensions to check during tool setup? Important dimensions include the 12 mm bore, 9 mm internal square and 40 mm length; these determine fit, engagement and axial support in the holder. How does this collet improve tool life? By reducing runout and improving concentricity, the ER‑GB collet lowers lateral loads on cutters and taps, which typically extends tool life and helps maintain consistent part quality. Manufacturer / Responsible: NORDWEST Handel AG, Robert‑Schuman‑Straße 17, 44263 Dortmund
12mm ER 40 Collet Precision Clamping, 5 µm Runout, L46mm - TECWERK
Achieve consistent tool concentricity and reliable holding with this ER 40 collet: 5 µm runout, full‑length gripping and a precise 12 mm nominal clamping diameter. Order the collet directly via Metav Werkzeuge or consult our specialists for application advice and selection support. Collet ER 40/472 E — ER 40 collet, 12 mm clamping, TECWERK The Collet ER 40/472 E is a precision ER 40 collet designed for secure 12 mm tool clamping in standard ER collet chucks for milling and turning applications. ER 40 collet for 12 mm clamping Conforms to DIN 6499-B Excellent runout accuracy 5 µm Full-length clamping including chamfer Consistent concentricity for machining accuracy A reliable clamping system reduces scrap and rework. The ER 40 collet is manufactured to DIN 6499‑B tolerances and delivers a typical runout of 5 µm, ensuring high concentricity for cutters and toolholders. This level of precision translates into improved surface finish and extended tool life, because consistent gripping reduces vibration and heat build‑up. The collet’s design guarantees that tools are held along their full clamping length, which improves axial stability and reduces the need for repeated re‑alignment when changing tools. Fast integration and compatibility with ER chucks Designed to fit standard ER type collet chucks, the component supports immediate integration into existing toolholding systems. The 12 mm nominal clamping diameter and the specified clamping diameter bridging (nominal minus 1.0 mm) permit small diameter adjustments without intermediate sizes. With a total length L: 46 mm, external diameter D: 41 mm and internal bore d: 12 mm, the collet is compact yet robust, offering a simple replacement option for workshops seeking dependable repeatability and reduced setup times. Practical benefits for daily workshop use Operational advantages include full‑length gripping capability and the option to clamp on the chamfer, which simplifies handling of short‑shank tools. The construction supports repeatable positioning, making the collet suitable for production environments where cycle‑to‑cycle consistency matters. Clear mechanical specifications and conformity to established standards make selection straightforward for purchasing and engineering teams, and the minimal requirement for intermediate sizes lowers inventory complexity while maintaining flexibility across a range of tooling tasks. For tailored advice or to secure this TECWERK ER 40 collet for immediate use, contact Metav Werkzeuge for expert guidance and order placement — Metav Werkzeuge provides direct supply from Emmerich and application support to ensure the correct fit for the intended machining task. Technical data Article number: 2000832972NW Type: ER 40 Product: Collet ER Clamping diameter: 12 mm Packaging unit: 1 Facts Length (L): 46 mm Bore (d): 12 mm Outer diameter (D): 41 mm Runout / repeatability: 5 µm Clamping diameter bridging: nominal minus 1.0 mm Special features Conforms to DIN 6499‑B Suitable for ER collet chucks Held along full clamping length Can be clamped on the guiding chamfer No intermediate sizes required FAQ What nominal clamping diameter does this collet provide? The collet is specified for a nominal clamping diameter of 12 mm; the design allows a clamping diameter bridging of nominal minus 1.0 mm. Is the collet compatible with standard ER 40 chucks? Yes, the Collet ER 40/472 E from TECWERK is made to fit ER 40 collet chucks and follows DIN 6499‑B specifications. What runout can be expected in service? Typical runout and repeatability is stated as 5 µm, which supports high concentricity for precision machining using the ER 40 collet. Can tools be clamped on the chamfer with this collet? Yes, the design permits clamping on the guiding chamfer as well as along the full clamping length for short‑shank tools. What is the article number for ordering and reference? The article number for the TECWERK Collet ER 40/472 E is 2000832972NW. Manufacturer/Responsible: NORDWEST Handel AG, Robert‑Schuman‑Straße 17, 44263 Dortmund
12mm ER Collet 40mm Length, DIN 6499-B Accuracy 5 µm - TECWERK
Combining reliable runout accuracy and secure full‑length holding, this ER collet delivers repeatable clamping for workshop and CNC applications. Benefit from DIN 6499‑B conformity and a 5 µm runout specification for consistent part quality; order via Metav Werkzeuge or consult our specialists for fitment and availability. TECWERK ER 32 Collet (Clamping Ø 12 mm, L 40 mm) The TECWERK ER 32 collet is a precision clamping component for ER collet chucks, engineered to maintain concentricity and hold tools along the full clamping length in milling and turning setups DIN 6499‑B standard compliance Held along entire clamping length Runout and repeatability: 5 µm Clamping range bridging: nominal −1.0 mm Improved process reliability through tight runout control The primary benefit of this ER collet is consistent concentricity, demonstrated by a 5 µm runout and repeatability figure. Such precision reduces part rework and scrap in production environments where tight tolerances matter. Because the clamping element is designed to be held along the entire clamping length, axial and radial stability are improved, so machining cycles remain predictable and tool life is extended. For workshops and small series production, this stability translates directly into fewer rejects and smoother downstream processes. Straightforward integration with ER chucks and standard tooling Compliance with DIN 6499‑B ensures the collet fits standard ER systems without the need for intermediate adapters, which simplifies tooling logistics and reduces setup time. The component accepts clamping on the pilot chamfer and can bridge the diameter by nominal −1.0 mm, allowing flexible use with slightly undersized shanks. Specified dimensions (L 40 mm, Ø 12 mm, outer D 33 mm) enable easy comparison with existing holders and ensure predictable compatibility across ER 32 collet chucks. Practical benefits for workshop efficiency and handling Manufactured to perform in everyday shop conditions, the collet’s design supports quick changeovers and precise reclamping, improving throughput on both CNC machines and manual equipment. Retaining tools over the full clamping length means the workpiece or cutter is guided more securely, lowering vibration and producing a cleaner surface finish. The construction makes it suitable for repeated use without complex maintenance routines, supporting long service cycles and reliable production output. For reliable clamping precision with TECWERK components, contact Metav Werkzeuge for availability and tailored technical advice from our Emmerich location. Technical data Article number: 2000832948NW Type: ER 32 Product: ER collet Packaging unit: 1 Facts Clamping diameter: 12 mm Length (L): 40 mm Inner diameter (d): 12 mm Outer diameter (D): 33 mm Runout / repeatability: 5 µm Clamping range bridging: nominal −1.0 mm Special features Conforms to DIN 6499‑B Suitable for ER collet chucks Held along entire clamping length Can be clamped on pilot chamfer Label: Spannzange Typ ER 32/470 E Spann‑D.12mm TECWERK FAQ What level of concentricity can be expected from this collet? The TECWERK ER 32 collet is specified with a 5 µm runout and repeatability, offering high concentricity for precision machining. Is the collet compatible with standard ER 32 chucks? Yes. Conformity to DIN 6499‑B means the collet fits standard ER 32 collet chucks without intermediate adapters. Can slightly undersized tool shanks be clamped securely? The collet allows a clamping range bridging of nominal −1.0 mm, enabling secure clamping of slightly smaller shanks. Which dimensions should be checked to ensure fitment? Compare the collet’s L 40 mm, inner Ø 12 mm and outer D 33 mm with the holder and tools to confirm compatibility. Manufacturer / Responsible: NORDWEST Handel AG, Robert‑Schuman‑Straße 17, 44263 Dortmund
12mm ER16-GB Collet With 9mm Internal Square For Threading, 15µm Runout · 34mm Length - TECWERK
Data inconsistency detected: the product is identified as "ER 16-GB" in one entry while another entry describes it as "ER25-GB". Please clarify the correct ER size so a complete and accurate product description can be provided, ensuring that all relevant details are consistent across records to avoid confusion or errors in documentation, inventory management, or customer communication, as discrepancies like this can lead to misunderstandings, incorrect orders, or delays in processing, which could ultimately impact the overall efficiency and reliability of the system, so it is crucial to verify and confirm the accurate ER size designation for the product in question.
12mm ER25 Collet 34mm Clamping Length, 5 µm Runout, DIN 6499-B - TECWERK
Take advantage of the collet's compliance with DIN 6499-B, its 5 µm runout and repeatability, and the secure full‑length tool grip for consistent machining results; order the TECWERK ER 25 collet directly via Metav Werkzeuge or ask our consultants if needed. TECWERK ER 25 Collet — ER 25/430 E, 12 mm clamping diameter The TECWERK ER 25/430 E is a precision ER collet for reliable tool holding in standard ER collet chucks, designed for workshop and light industrial machining. DIN 6499‑B standardised design Full‑length tool grip for stable clamping Runout and repeatability 5 µm Clamping diameter 12 mm Consistent precision for accurate machining Compliance with DIN 6499‑B and a measured 5 µm value for runout and repeatability make this ER collet a dependable choice where dimensional accuracy matters. The standardised geometry ensures predictable behaviour across setups, reducing scrap and rework. The narrow tolerance on concentricity translates into tighter toolpaths and more consistent part quality, which benefits serial production and precision prototypes alike. Secure grip across the entire clamping length The collet holds tools along the full‑length grip, so cutters and drills are supported more evenly than with end‑only clamping. This design enables clamping on the lead chamfer as well, simplifying setups for short shank tools. The capacity to bridge gaps up to nominal minus 1.0 mm increases flexibility for slightly undersized tools without the need for intermediate sleeves, contributing to faster changeovers and improved process reliability. Compact form factor for flexible workshop use Built to the ER 25 specification, this collet fits common ER collet chucks while keeping a short overall length for minimal stick‑out and improved rigidity. Key dimensions: L 34 mm, d 12 mm, D 26 mm, supporting a clamping diameter 12 mm for numerous standard tooling applications. The compact footprint reduces overhang, which in turn improves machining stability and surface finish when compared with longer holding solutions. For precision clamping with TECWERK quality and support from Metav Werkzeuge, contact Metav Werkzeuge for ordering and tailored advice at info@metav-werkzeuge.com or +49 2822 7131930 Technical Data Article number: 2000832933NW SKU: 2000832933NW Product type: ER 25 collet Label: Spannzange Typ ER 25/430 E Spann‑D.12mm TECWERK Manufacturer: TECWERK Facts Clamping diameter: 12 mm Runout / repeatability: 5 µm Length (L): 34 mm Inner diameter (d): 12 mm Outer diameter (D): 26 mm Clamping diameter bridging: nominal minus 1.0 mm Special features Complies with DIN 6499‑B Suitable for ER collet chucks Tools held along the entire clamping length Can be clamped on the lead chamfer No intermediate sizes required FAQ What degree of concentricity can be expected from this collet? The collet delivers a measured runout and repeatability of 5 µm, ensuring high concentricity for precision operations with the TECWERK ER 25 collet (SKU 2000832933NW). Is the collet compatible with standard ER chucks? Yes, the item is designed for compatibility with standard ER collet chucks and follows DIN 6499‑B dimensions for ER 25 tooling. Can shorter tools be clamped securely with this collet? The collet holds tools along the full clamping length and can be used on the lead chamfer, improving secure clamping for short shank tools. Manufacturer/Responsible: NORDWEST Handel AG, Robert‑Schuman‑Straße 17, 44263 Dortmund
12mm Quick-Change Insert SE 9mm Square Shank for DIN 374/376 M16, L3 5mm L4 35mm - TECWERK
Take advantage of a compact, quick-change solution that combines fast tool swaps with positive torque transmission via a 9 mm square shank for reliable threading to DIN 374/376 M16. The robust Size 2 insert delivers consistent clamping geometry and clear dimensional data for planning tool setups. Order the quick-change insert directly via Metav Werkzeuge or ask our consultants if needed. Quick-change insert SE 12 mm × 9 mm, Size 2 for DIN 374/376 M16 (TECWERK) The Quick-change insert SE 12 mm × 9 mm, Size 2 is a dedicated holder for tapping applications to DIN 374/376 M16, designed for rapid tool exchange in production and workshop environments Rapid tool changes with quick-change design Torque transmission via 9 mm square shank Compatible with DIN 374/376 M16 threading tools Clear dimensional data for process planning Efficient threading operations through fast changeovers The quick-change insert is engineered to reduce non-productive time by enabling fast replacement of threaded tools. With a defined 12 mm diameter interface and a 9 mm square shank, the insert provides stable seating for taps held by the quick-clamping mechanism. This results in shorter set-up times and higher machine utilisation, making it suitable for repetitive threading tasks in small-batch production as well as larger runs. Secure torque transmission for consistent thread quality Because the torque transmission is effected via the shaft square, the load is transferred positively and predictably to the tap. The design operates without a safety coupling, so torque is transmitted directly through the square shank; this ensures repeatable torque behaviour and consistent thread form when used with compatible tapping tools to DIN 374/376 M16. Users benefit from precise power transfer that supports reproducible quality in each cycle. Clear dimensions and measurable specification for process planning Detailed dimensional values support integration into tool lists and CAD fixtures. Key lengths and diameters are provided to facilitate fixture design, collision checks and inventory management. The compact footprint and the standardised interface simplify spare-part planning and make this insert straightforward to specify alongside existing toolholders and machine setups in workshops and production cells. Designed for workshop compatibility and flexible shank options The insert requires matching shank sizes for different toolholder variants, enabling a modular approach to tap holding. The construction allows taps to be retained by the quick-clamping device, while the square shank provides the positive drive. This modularity supports mixed tooling strategies and reduces the number of complete holders required, improving capital efficiency for maintenance and toolroom planning. For precise threading with TECWERK quick-change inserts, contact Metav Werkzeuge for tailored advice and reliable supply — email info@metav-werkzeuge.com or call +49 2822 7131930 to discuss compatibility with existing tooling and order fulfilment Technical data Article number: 4000832646NW Type: Size 2 Diameter: 12 mm Square shank: 9 mm Suitable for: DIN 374/376 M16 Packaging unit: 1 Numbers / Core technical data L3: 5 mm L4: 35 mm L5: 11 mm D: 48 mm L1: 32 mm D1: 31 mm Special features / Versions without safety coupling inserts held by quick clamping device torque transmission via shaft square different inserts required for different shank sizes FAQ What tap standards is the insert compatible with? The quick-change insert is designed for tapping tools conforming to DIN 374/376 M16 and provides the standard interface for secure clamping and drive. How is torque transmitted to the tap? Torque is transmitted via the 9 mm square shank; the design transfers drive positively without a safety coupling for repeatable torque behaviour. Can the insert be used with different shank sizes? Different inserts are required for different shank sizes; the product supports a modular approach where matched inserts are selected for the corresponding shank. Which dimensions are critical for fixture integration? Key dimensions such as L1, L3, L4, D and D1 are provided to assist with fixture planning and collision checks when integrating the insert into a toolholding system. Is a safety coupling included with this insert? No, this insert is supplied without a safety coupling; torque is delivered directly through the square shank, which should be considered in process risk assessments. Manufacturer/Responsible: NORDWEST Handel AG, Robert-Schuman-Straße 17, 44263 Dortmund
12mm Quick-Change Insert SES 9mm Square, Adjustable Torque Safety Clutch, L3 30.5mm - TECWERK
Take advantage of a combination of precise torque control and rapid tool changes to reduce tap breakage and downtime; the adjustable safety clutch and 9 mm square torque transfer ensure consistent performance—order via Metav Werkzeuge or consult their specialists for fitment advice. Quick-change insert SES 12mmx9mm Size 2 for DIN 374/376 M16 — TECWERK, adjustable safety clutch The Quick-change insert SES 12mmx9mm Size 2 is a compact tap adaptor designed for tapping operations to DIN 374/376 M16, providing torque limitation and fast interchangeability for production and workshop environments. Adjustable safety clutch for torque limiting Prevents tap breakage under load Torque transfer via 9 mm square shank Compatible with DIN 374/376 M16 taps Consistent torque control reduces breakage and waste The central advantage of the insert is its adjustable safety clutch, which provides reliable torque limitation during tapping operations. By disconnecting or slipping at a preset torque threshold, the mechanism protects cutting tools from sudden overloads and the costly consequences of broken taps. This mechanical safeguard translates directly into fewer interrupted production cycles and lower consumable costs. The clutch design transmits rotation through the 9 mm square shank, ensuring predictable power transfer while the torque cap prevents excessive stresses that typically lead to tool failure. Exact fit and clear dimensions for simple integration Compatibility is assured through adherence to DIN standards: the adaptor is intended for taps to DIN 374/376 M16 and matches shafts via the 9 mm square interface. Key measurements support straightforward integration into existing tool sets: L3: 30.5 mm, L4: 35 mm, L5: 34 mm, D: 50 mm, L1: 32 mm, D1: 31 mm. These dimensions permit planners and technicians to verify clearance and reach without lengthy trials. The quick-change format simplifies swapping between holders and spindles, reducing non-productive time and supporting a faster tool-change rhythm on the shop floor. Practical benefits for workshop efficiency and process reliability Designed for repeatable performance, the insert brings measurable gains in workshop efficiency: faster tool changes, reduced scrap from damaged threads, and lower maintenance frequency. The torque is transmitted over the shaft square for a secure drive link, while the clutch function mitigates the risk of tap fracture when encountering misfeeds or hardened inclusions. For varied shank standards, matching inserts are available to maintain the same safety and interchange benefits across different machines. Metav Werkzeuge supplies technical guidance and reliable delivery from Emmerich, helping to ensure the part fits the intended tapping application and production workflow. For tailored advice on compatibility or to secure supply of this TECWERK quick-change insert from Metav Werkzeuge, contact Metav Werkzeuge directly for product matching and guaranteed availability from their Emmerich quality hub Technical data Article number: 4000832680NW Product: Quick-change insert SES Brand: TECWERK Type: Size 2 Diameter: 12 mm Square shank: 9 mm Suitable for: DIN 374/376 M16 Packaging unit: 1 Measurements L3: 30.5 mm L4: 35 mm L5: 34 mm D: 50 mm L1: 32 mm D1: 31 mm Special features Adjustable safety clutch for torque limitation Torque transmission via shaft square Prevents tap breakage Quick-change format for rapid tool swaps Requires matching inserts for different shaft sizes FAQ What is the main function of this quick‑change insert? The quick‑change insert SES 12mmx9mm Size 2 from TECWERK limits torque via its adjustable safety clutch to protect taps and enable rapid tool changes in tapping applications. Which tap standards does this insert support? The insert is designed for tapping to DIN 374/376 M16 and interfaces via a 9 mm square shank for standard drive connections. How does the safety clutch benefit production? By capping torque, the clutch prevents sudden overloads and tap fracture, reducing downtime and consumable costs associated with broken taps. Are the dimensions sufficient for machine integration? The provided dimensions (L3, L4, L5, D, L1, D1) allow verification of clearance and fit; these values support fast integration into existing tooling setups. Is a different insert required for other shaft sizes? Yes, the torque is transferred via the shaft square and different shaft measurements require the corresponding insert size for correct fit and operation. Manufacturer / Responsible: NORDWEST Handel AG, Robert-Schuman-Straße 17, 44263 Dortmund
136mm HSK 63 Coolant Transfer Tube Key, Total Length 136mm - TECWERK
Robust engagement for HSK 63 connections and a 136 mm working length deliver reliable handling and improved service times; order supply or request advice directly through Metav Werkzeuge for fast fulfilment. Key HSK 63 for coolant transfer pipes, 136 mm — TECWERK Key HSK 63 for coolant transfer pipes is a precision service key designed to engage and secure coolant transfer pipes in HSK 63 tool holders, offering a compact 136 mm overall length suited to maintenance and workshop servicing. Compatible with HSK 63 tool holders Designed for coolant transfer pipes Overall length 136 mm for accessible reach Reduced downtime through precise engagement A correctly matched engagement tool minimises the risk of misalignment and wear when handling coolant lines in tool holders. The HSK 63 interface ensures a consistent contact geometry, which reduces slippage and the chance of damaging the transfer connection. By using a dedicated service key, maintenance operations become more predictable and repeatable, so machining cycles return to normal faster and costly interruptions are less frequent. This benefit is especially relevant in production environments that demand tight tolerances and steady coolant delivery. Better access and ergonomics for routine servicing With an overall length of 136 mm, the service key provides enough reach to work comfortably within the recesses of HSK tool holders while remaining compact for quick tool changes. The length balances accessibility and control, allowing technicians to manipulate coolant transfer pipes with minimal repositioning. Improved handling reduces task time and physical strain during repetitive servicing procedures, supporting efficient workshop workflows and safer operation around spindle areas. Seamless integration into maintenance workflows The tool is specified for the engagement of coolant transfer pipes and fits the HSK 63 standard, enabling straightforward incorporation into existing tool sets. Packaged as a single unit, it complements other HSK service items and helps standardise the maintenance kit for machines using this interface. Standardisation lowers training effort and streamlines spare-part management, contributing to a leaner inventory and fewer procurement steps across the workshop. For procurement teams requiring precise HSK 63 engagement and reliable handling of coolant transfer pipes, contact Metav Werkzeuge for supply and application advice — email info@metav-werkzeuge.com or call +49 2822 7131930 Technical data Article number: 4000832716NW Product type: Key Manufacturer: TECWERK SKU: 4000832716NW Facts Overall length: 136 mm Key size: HSK 63 Packaging unit: 1 Special features For coolant transfer pipes Suitable for HSK 63 tool holders Service key for maintenance applications FAQ Is the key compatible with standard HSK 63 tool holders? The key is specified for HSK 63 connections and is compatible with standard HSK 63 tool holders; reference SKU 4000832716NW for ordering. What is the working length and why does it matter? The overall length is 136 mm, which provides access into the tool-holder recess while keeping handling compact for routine servicing. Can this tool be used for coolant line replacement and adjustment? Yes, the service key is designed to engage coolant transfer pipes for secure handling during replacement or adjustment operations. How is the item supplied for inventory management? The tool is supplied as a single unit (packaging unit 1), making it easy to add to maintenance kits and spares lists. Who manufactures the key and where can further product details be found? The product is offered under the brand TECWERK; use article number 4000832716NW for precise identification and procurement. Manufacturer / Responsible: NORDWEST Handel AG, Robert-Schuman-Straße 17, 44263 Dortmund
13mm Spannzange ER 25 Rundlaufgenau 5 µm L40 D33 Spanndurchmesserüberbrückung Nennmaß minus 1,0 mm - TECWERK
Fehlinformation: Widersprüchliche Typangaben erkannt (ER 25 versus ER 32). Bitte Daten prüfen und korrigieren, damit eine korrekte Produktbeschreibung erstellt werden kann, da ungenaue oder fehlerhafte Angaben zu Missverständnissen führen können und die Qualität der Produktinformationen sowie die Zufriedenheit der Kunden beeinträchtigen könnten. Eine sorgfältige Überprüfung der Typangaben ist daher unerlässlich, um sicherzustellen, dass die bereitgestellten Informationen sowohl präzise als auch konsistent sind und den Anforderungen der Nutzer entsprechen. Nur durch eine genaue und fehlerfreie Datenpflege kann gewährleistet werden, dass die Produktbeschreibung den tatsächlichen Spezifikationen entspricht und keine Verwirrung entsteht.
140mm Thread Cutting Holder M14–M36 With Quick-Change, Axial Compensation, Ball Guide, DIN 69871 Form A - TECWERK
Take advantage of a compact, standards-compliant design combined with axial length compensation and a quick-change torque transfer system for reliable tapping across a wide thread range. Order the tool or consult Metav Werkzeuge for integration and supply. Threading chuck DIN 69871 Form A M14–M36 SK50 A‑L 140 mm (TECWERK) A threading chuck by TECWERK for secure tap holding and versatile use in CNC and toolroom applications Steep taper DIN 69871 Form A Axial length compensation on push and pull Ball guide bushing for controlled movement Quick-change insert for torque transfer Consistent tapping performance for demanding production The TECWERK threading chuck (SKU 2000832249NW) is engineered for repeatable results when machining threads from M14–M36. Its compliance with DIN 69871 Form A ensures compatibility with standard toolholders and machine spindles, while the SK50 shank provides robust connection to the spindle. The combination of a steep taper and a precisely guided bushing reduces runout and maintains tap alignment, which in turn minimises thread errors and rework. This yields a measurable increase in process stability and shorter cycle variability. Built-in axial compensation reduces tap breakage and downtime Featuring axial length compensation on push and pull, the chuck absorbs small axial misalignments that occur during tapping cycles. This function protects taps from excessive bending forces and sudden axial loads, lowering the risk of breakages in interrupted or deep-thread operations. As a result, tool life is extended and maintenance intervals are lengthened, delivering clear economic benefits in high-volume and batch-change settings. Secure guidance and reliable torque transmission Guidance is provided by a ball guide bushing, which ensures that the tap runs true and that axial movement remains controlled. Torque is transmitted via a quick-change insert, enabling efficient replacement without special tools and ensuring positive engagement during rotation. Together these features support both hand-tap and machine-tap styles, allowing flexible use across varied tapping tasks while keeping set-up times short. Practical dimensions and workshop integration The chuck’s measurable parameters — d 48 mm, A 140 mm, D 78 mm — make it straightforward to verify fitment in existing tool chains. Its execution with a quick-change mechanism simplifies retrofit into modular tooling systems and quickholder arrangements. Where machine uptime and predictable thread quality are priorities, this tap holder supplies a coherent balance of compact form, mechanical security and compatibility with established spindle tapers. Discuss integration and availability with Metav Werkzeuge — technical advice and delivery coordinated from our Emmerich site, eMail: info@metav-werkzeuge.com, Tel: +49 2822 7131930 Technical data SKU: 2000832249NW Designation: Threading chuck DIN 69871 Form A M14–M36 SK50 A‑L 140 mm Product type: Threading chuck Core specifications Suitable for: M14–M36 Taper standard: DIN 69871 Form A Shank diameter d: 48 mm Length A: 140 mm Maximum diameter D: 78 mm Packing unit: 1 Features & functions Steep taper DIN 69871 Form A Axial length compensation on push and pull Ball guide bushing Quick-change execution for torque transmission SK50 shank FAQ Which thread sizes are supported by this chuck? The threading chuck supports thread taps from M14 to M36 and is specified as suitable for M14–M36 applications. How is torque transmitted to the tap? Torque is transmitted via a quick-change insert integrated into the toolholder; the quick-change execution enables secure torque transfer while simplifying insert replacement. Is the chuck compatible with standard DIN 69871 spindles? Yes. The chuck conforms to DIN 69871 Form A and is designed for machines accepting that taper, combined with an SK50 shank for robust spindle connection. What protection against axial load does the holder provide? The holder incorporates axial length compensation on both push and pull, which reduces stress peaks on the tap and lowers the likelihood of breakage in demanding cycles. Which guidance mechanism ensures accurate tapping? A ball guide bushing provides controlled guidance and improved concentricity during tapping, helping to maintain thread accuracy and reduce scrap rates. Manufacturer/Responsible: NORDWEST Handel AG, Robert‑Schuman‑Straße 17, 44263 Dortmund
14mm ER 16-GB Collet With 11mm Internal Square For Thread Cutting, 15 µm Runout - TECWERK
Data inconsistency detected: the fields 'typ' (ER 16-GB) and 'label' (Spannzange ER32-GB) contradict each other. Please verify the product data for SKU 2000834977NW; a product description cannot be generated from inconsistent information, as this issue may lead to confusion or errors in the product catalogue, potentially affecting customer understanding and purchase decisions. It is essential to ensure that all fields in the database are accurate, consistent, and aligned with the product specifications to maintain data integrity and avoid complications during the listing or sales process. Kindly review and correct the discrepancies to ensure the information provided is both reliable and precise.
14mm ER Collet ER40 Clamping Range Nennmaß Minus 1.0mm, L46mm - TECWERK
High-precision clamping with a 14 mm nominal bore and a guaranteed 5 µm runout provides consistent tool performance; the compact 46 mm length enables flexible mounting in tight assemblies. Order the TECWERK ER 40 collet directly via Metav Werkzeuge or ask our consultants if needed. Collet ER 40/472 E — ER 40 collet, 14 mm clamping diameter (TECWERK) The Collet ER 40/472 E by TECWERK is a precision ER 40 collet designed for secure clamping of tools in standard ER collet chucks across machining centres and toolholders. *Conforms to DIN 6499‑B standard *Precision runout of 5 µm *Full-length tool support for stable clamping *Compatible with ER 40 collet chucks Consistent concentricity for repeatable machining The collet delivers a runout of 5 µm, ensuring that cutters and toolholders run concentrically under load. This level of accuracy reduces vibration and tool wear, which leads to fewer rejects and longer tool life. The design permits clamping over the full length of the tool shank, so radial support is maximised; smaller-diameter tools can be clamped securely because the span bridging is nominal minus 1.0 mm, allowing safe gripping of slightly undersized shanks without loss of stability. Faster set-up and broad compatibility save cycle time Built to DIN 6499‑B, the clamping sleeve mates reliably with standard ER chucks, eliminating guesswork when replacing or upgrading holders. No intermediate sizes are required, which simplifies inventory and reduces changeover complexity on the shop floor. The ability to clamp on the lead chamfer as well as the straight shank shortens set-up procedures and keeps spindle downtime to a minimum, supporting efficient production runs. Compact form and robust holding for everyday workshop use With a length of 46 mm, an outer diameter of 41 mm and a clamping bore of 14 mm, this ER 40 collet offers a compact footprint while maintaining high clamping force. The geometry holds tools securely across the entire clamping surface, which helps to prevent slippage under heavy cutting conditions. The solid construction and standardised dimensions make the sleeve straightforward to fit into existing tool management processes, providing a dependable component for precision work. Discuss workshop compatibility and availability with Metav Werkzeuge: email info@metav-werkzeuge.com or call +49 2822 7131930 for tailored technical advice on the TECWERK ER 40 collet (SKU 2000832974NW) Technical data Article number: 2000832974NW Type: ER 40 Label: Collet ER 40/472 E — clamping diameter 14 mm Product type: ER collet Manufacturer: TECWERK Packaging unit: 1 Core specifications Clamping diameter: 14 mm Length L: 46 mm Inner diameter d: 14 mm Outer diameter D: 41 mm Runout / repeatability: 5 µm Span bridging: nominal minus 1.0 mm Special features According to DIN 6499‑B Compatible with ER collet chucks No intermediate sizes required Tools held over the full clamping length Can be clamped on the lead chamfer FAQ What tolerance can be expected for concentricity with this collet? The TECWERK Collet ER 40/472 E is specified with a runout/repeatability of 5 µm, which supports high-precision machining and reduced tool wear in demanding operations. Is the collet compatible with standard ER 40 chucks? Yes — the sleeve conforms to DIN 6499‑B and is designed for use with standard ER 40 collet chucks, ensuring straightforward interchangeability in existing toolholding systems. What does “span bridging: nominal minus 1.0 mm” mean for clamping smaller shanks? The specification "nominal minus 1.0 mm" indicates that the collet can securely bridge and clamp shafts up to 1.0 mm below the nominal diameter, allowing slightly undersized tools to be gripped safely without additional adaptors when using the TECWERK ER 40 collet. Can the tool be clamped on the chamfer or only on the straight shank? The design permits clamping on the lead chamfer as well as on the straight section of the shank, enabling flexible set-up options and improved holding for tapered or chamfered tool ends with the TECWERK ER 40/472 E collet. Manufacturer/Responsible: NORDWEST Handel AG, Robert-Schuman-Straße 17, 44263 Dortmund
14mm ER25 Collet, 34mm Length, 5 µm Runout Accuracy - TECWERK
High-precision clamping with reliable repeatability and full-length tool support ensures consistent machining results; the ER 25 collet delivers 5 µm runout accuracy and secure holding over the entire clamping length, reducing setup time and scrap. Order the collet directly via Metav Werkzeuge or contact our consultants for application advice. TECWERK ER 25 Collet (Type ER 25/430 E) — 14 mm clamping diameter, DIN 6499‑B The TECWERK ER 25 Collet (Type ER 25/430 E) is a precision ER collet designed for secure clamping of 14 mm tool shanks in ER 25 collet chucks, suitable for production and workshop environments Precision runout ≤ 5 µm Clamping diameter 14 mm Holds tools along full clamping length Compatible with ER 25 collet chucks Reliable precision for demanding machining The ER 25 collet is manufactured to DIN 6499‑B, delivering a runout and repeatability of 5 µm, which translates into noticeably better surface finish and reduced tool wear in high-precision operations. Such tolerance stability ensures that concentricity is maintained across repeated setups, helping to lower scrap rates and increase first-pass yield. The standardised specification also simplifies quality documentation and process validation in industrial environments. Secure holding along the entire clamping length This clamping sleeve holds cutting tools along the full clamping length, which reduces the risk of axial or radial slip during operation and improves dynamic stability at higher spindle speeds. The ability to clamp on the guiding chamfer further enhances versatility: shorter shanks or slightly chamfered tools remain securely seated, so changeover is faster and fixturing becomes more predictable. The result is consistent cutting performance and lower tool-change downtime. Compact dimensions and straightforward compatibility With compact external and internal dimensions — L: 34 mm, d: 14 mm, D: 26 mm — the collet fits seamlessly into standard ER 25 chucks without the need for intermediate adapters. The collet permits a clamping diameter bridging of nominal −1.0 mm, meaning it can accommodate small deviations in tool shank diameter without requiring a secondary size, which simplifies inventory and reduces the number of items held in stock. Compatibility with common ER systems ensures straightforward integration into existing tooling setups. Designed for efficient workshop and production use Engineered for repeatable performance, the collet supports streamlined workflows in both single-machine shops and production lines. The ER 25 geometry and DIN conformity reduce decision time for procurement and make inventory management easier, while its robust clamping behaviour supports longer uninterrupted runs. For maintenance and reconditioning, the standard format allows easy replacement, keeping machines productive and maintenance cycles predictable. For secure, repeatable clamping choose the TECWERK ER 25 collet and contact Metav Werkzeuge for prompt supply and technical guidance — email info@metav-werkzeuge.com or call +49 2822 7131930 Technical Data Article number: 2000832935NW Type: ER 25 Product: ER collet Brand: TECWERK Facts Clamping diameter: 14 mm L: 34 mm d: 14 mm D: 26 mm Runout/repeatability: 5 µm Clamping diameter bridging: nominal −1.0 mm Special features Standard: DIN 6499‑B Compatible with ER collet chucks Tools held along full clamping length Can be clamped on guiding chamfer Packaging unit: 1 FAQ What runout tolerance can be expected from this collet? The TECWERK ER 25 collet (SKU 2000832935NW) offers a runout and repeatability of 5 µm when used with a correctly mounted ER 25 chuck and properly prepared toolholders. Is the collet compatible with standard ER 25 chucks? Yes — the collet is made to the ER 25 specification and is compatible with ER 25 collet chucks conforming to DIN 6499‑B. Can tools be clamped on the chamfer or only on the cylindrical shank? The collet is designed so that tools can be held along the full clamping length and may also be clamped on the guiding chamfer for shortened or chamfered shanks. What are the key dimensions to check before ordering? Check the essential dimensions: L 34 mm, d 14 mm, D 26 mm, and the clamping diameter 14 mm; the collet allows bridging down to nominal −1.0 mm. Which standard does this collet conform to? This collet conforms to DIN 6499‑B, ensuring standardised interface and interchangeability with ER 25 systems. Manufacturer / Responsible: NORDWEST Handel AG, Robert-Schuman-Straße 17, 44263 Dortmund
14mm ER32 Collet Precision Clamping Capacity Nennmaß Minus 1.0mm, L 40mm - TECWERK
Take advantage of the combination of standardised compatibility, high runout accuracy and secure full‑length clamping for consistent machining results; order the TECWERK ER 32 collet directly via Metav Werkzeuge or consult our specialists for tailored advice. TECWERK ER 32 collet – clamping diameter 14 mm, runout 5 µm TECWERK ER 32 collet for ER collet chucks, designed to provide rigid tool retention and precision clamping in workshop and production environments DIN 6499‑B compatibility for ER chucks Full-length clamping for secure tool retention Runout and repeatability: 5 µm Clamping diameter bridging: nominal −1.0 mm Precision standards that reduce setup time and scrap The TECWERK ER 32 collet is manufactured to DIN 6499‑B dimensions, ensuring straightforward interchangeability with standard ER collet chucks. Adherence to the standard simplifies spindle tooling management and reduces the need for special adaptors. The specified runout and repeatability of 5 µm translate into tighter tolerances on finished components, fewer rejects and more consistent batch quality. For operations where repeatability and predictable tool behaviour are essential, the standard compliance delivers measurable production benefits. Improved rigidity and tool life through full‑length clamping Because the insert holds tools along the full clamping length, cutting forces are distributed more evenly and lateral play is minimised. This full‑length clamping capability, together with the option to clamp on the lead‑in chamfer, reduces vibration and tool deflection during milling, drilling and finishing passes. The result is prolonged cutter life and more stable machining, which supports higher material removal rates and lower total tool costs over time. Flexible handling of tool diameter variations and compact dimensions The collet allows clamping diameter bridging of nominal −1.0 mm, so small mismatches between nominal tool shank sizes can be accommodated without intermediate sizes. This feature streamlines tooling inventories and quickens changeovers. Compact physical dimensions (L: 40 mm, d: 14 mm, D: 33 mm) make the insert suitable for standard ER 32 applications where space is limited but precision is required. The compact design supports straightforward storage and fast replacement in a production setting. Practical advantages for procurement and workshop workflows Standardisation with the ER system reduces supplier complexity and eases procurement: the collet fits established ER fixtures and can be stocked as a modular component. The clear technical specification and measurable tolerances support purchasing decisions based on performance metrics rather than subjective claims. For workshops seeking to democratise precision—achieving dependable measurement and clamping quality without excessive overhead—the use of standard, well‑specified components contributes directly to operational reliability. Choose the TECWERK ER 32 collet for dependable 5 µm runout and robust full‑length clamping, and contact Metav Werkzeuge for supply and expert advice from Emmerich. Technical data Article number: 2000832951NW Type: ER 32 Product designation: ER 32 collet (clamping diameter 14 mm) Brand: TECWERK Core technical data Clamping diameter: 14 mm Length (L): 40 mm Internal diameter (d): 14 mm Outer diameter (D): 33 mm Runout / repeatability: 5 µm Clamping diameter bridging: nominal −1.0 mm Special features Compatibility with DIN 6499‑B Fits ER collet chucks Holds tools along entire clamping length Can be clamped on the lead‑in chamfer No intermediate sizes required FAQ What level of precision can be expected from this collet? The TECWERK ER 32 collet is specified with runout and repeatability of 5 µm, providing stable concentricity for high‑precision machining tasks. Is this collet compatible with standard ER chucks? Yes; the collet conforms to DIN 6499‑B and is designed for use in standard ER collet chucks. Can the collet accommodate slightly undersized tool shanks? The collet allows clamping diameter bridging of nominal −1.0 mm, permitting minor size variations without the need for intermediate inserts. What are the physical dimensions of the clamping sleeve? Key dimensions are L: 40 mm, internal diameter d: 14 mm and outer diameter D: 33 mm. Does the collet support clamping on the lead‑in chamfer? Yes; the design permits clamping on the lead‑in chamfer, enabling secure retention even when the shank is engaged on the guide bevel. Manufacturer / Responsible: NORDWEST Handel AG, Robert‑Schuman‑Straße 17, 44263 Dortmund
14mm Quick-Change Insert SE 14mm x 11mm Gr.2 for DIN 374/376 M18, 5mm L3, 35mm L4 - TECWERK
Reliable tap retention combined with precise torque transfer and compact sizing ensures stable thread production and quicker changeovers; the quick‑change insert is therefore a pragmatic choice for workshops seeking consistent results. Benefit from its compatibility with DIN 374/376 M18, the 14 mm seat and 11 mm square shank for secure torque transmission. Order the insert directly via Metav Werkzeuge or ask the consultants if needed. Quick‑change insert SE 14 mm × 11 mm, size 2 — TECWERK (for DIN 374/376 M18) The Quick‑change insert SE 14 mm × 11 mm, size 2 is a precision adapter designed to hold thread taps in quick‑clamping systems for efficient tapping operations in workshop and industrial settings Compact size for tight tool setups Secure torque transfer via 11 mm square shank Compatible with DIN 374/376 M18 taps Straightforward changeover for higher uptime Reliable tap retention and consistent torque transmission Engineered to hold thread taps securely in a quick‑clamping device, this insert delivers direct torque transfer through the 11 mm square on the shank, reducing the risk of slippage under load. The absence of a safety coupling (listed as no safety coupling) means torque is transmitted without an intermediate release mechanism, which supports repeatable torque behaviour in controlled production environments. For workshops that prioritise predictability during tapping, the robust mechanical connection between tap and drive reduces variability and supports consistent thread quality across batches. Space‑saving design that improves process stability The size 2 format and 14 mm seat diameter make the adapter suitable where compact tool arrangements are necessary. A precise fit minimises radial runout and helps maintain concentricity between the toolholder and the tap, which directly benefits thread accuracy and surface finish. Key dimensional references such as L1: 32 mm, L4: 35 mm and D: 48 mm reflect a design intended for tight integration into common quick‑change systems while retaining sufficient engagement length to ensure secure seating during machining. Easy integration into existing quick‑clamping workflows The insert is intended for use with taps specified to DIN 374/376 M18 and relies on the quick‑clamping mechanism to retain the tap body. Different shank measures require corresponding inserts, so workshop planners can assemble a matched set for varied tap sizes without modifying the primary quick‑clamp tooling. This compatibility simplifies inventory of adapters and reduces setup time during tool changes, supporting higher machine availability and faster throughput in serial or batch production. Contact Metav Werkzeuge for application advice or to request this TECWERK quick‑change insert for immediate dispatch; Metav’s specialists can confirm fitment and recommend compatible inserts for other shank sizes Technical data Article number: 4000832647NW Product: Quick‑change insert SE 14 mm × 11 mm, size 2 Manufacturer: TECWERK Product type: Quick‑change insert SE SKU / UID: 4000832647NW Facts Seat diameter: 14 mm Shank square: 11 mm Suitable for: DIN 374/376 M18 Size: 2 L1: 32 mm L3: 5 mm L4: 35 mm L5: 11 mm D: 48 mm D1: 31 mm Packaging unit: 1 Special features No safety coupling Thread taps held by quick‑clamping device Torque transmission via shank square Different inserts required for different shank sizes FAQ How does the insert secure the thread tap during tapping? The insert secures the tap in the quick‑clamping device and transfers torque via the 11 mm square shank, ensuring a positive mechanical drive for stable tapping with the TECWERK quick‑change insert (SKU 4000832647NW). Is this insert compatible with other tap standards? This adapter is specified for taps to DIN 374/376 M18; adapters for other standards or shank sizes should be selected to match the clamp and tap dimensions. What does "no safety coupling" mean for everyday use? A designation of no safety coupling indicates that the insert does not include a torque‑release mechanism; torque is transmitted directly, which suits controlled production where predictable torque behaviour is required. Will the insert reduce setup times in a production cell? Yes, the quick‑change format and compact size 2 geometry facilitate faster tool exchanges and reduce machine downtime when matched with a compatible quick‑clamping system. Which dimensions are most relevant when checking fitment? Primary dimensions to verify are the 14 mm seat diameter, the 11 mm square shank and the overall engagement lengths such as L1 and L4 to ensure correct seating and clamp compatibility. Manufacturer/Responsible: NORDWEST Handel AG, Robert‑Schuman‑Straße 17, 44263 Dortmund
14mm Quick-Change Insert SES 11mm Square For DIN 374/376 M18, Adjustable Safety Clutch - TECWERK
Take advantage of the combination of secure torque control, compact size and straightforward interchangeability to reduce tap breakage and downtime in production. Benefit from a quick-change solution that transmits torque via a robust 11 mm shaft square and is designed for taps to DIN 374/376 M18 — order through Metav Werkzeuge or request guidance from our consultants. Quick-change insert SES 14mm x 11mm, Size 2 – with adjustable safety coupling (TECWERK) The Quick-change insert SES 14mm x 11mm, Size 2 is a replaceable insert for tap holders and hand taps made to fit DIN 374/376 M18, featuring an adjustable safety coupling that limits torque to avoid tap breakage. Adjustable safety coupling for torque limitation Minimises tap breakage during threading Torque transmission via 11 mm shaft square Compatible with DIN 374/376 M18 taps Safe threading through controlled torque The insert is centred on an adjustable safety coupling that performs torque limitation to protect taps during interrupted cuts or misalignment. By limiting peak torque, the device prevents sudden overloading and therefore significantly reduces the risk of tap breakage, which in turn lowers scrap rates and maintenance interventions. This engineered protection is particularly valuable in repetitive production environments where tool failure causes costly stoppages. Reliable fit and efficient torque transfer Designed for precision engagement, the unit transmits drive forces over an 11 mm shaft square, ensuring direct and wear-resistant torque transfer to the tap. Compatibility with DIN 374/376 M18 means straightforward integration into existing tap holders and hand-tapping fixtures. The compact footprint and carefully specified interface dimensions contribute to consistent centring and repeatable thread quality across runs, improving process stability and reducing rework. Fast changeover and application flexibility The quick-change concept allows fast replacement of worn or differently sized inserts so that different shank measurements can be accommodated by swapping the unit. The insert’s construction supports efficient workshop workflows and lowers setup time for maintenance or batch changes. For specialised applications where shank variants are in use, matching the correct SES insert size maintains torque control and protects high-value taps — assistance for selection is available from Metav Werkzeuge’s specialist team. Contact Metav Werkzeuge for expert advice on selecting the right TECWERK quick-change SES insert; call +49 2822 7131930 or email info@metav-werkzeuge.com for tailored assistance Technical data Article number: 4000832681NW Product: Quick-change insert SES Type: Size 2 Suitable for: DIN 374/376 M18 Packaging unit: 1 Manufacturer: TECWERK Numbers / Core technical data Diameter: 14 mm Square drive: 11 mm L3: 30.5 mm L4: 35 mm L5: 34 mm D: 50 mm L1: 32 mm D1: 31 mm Special features Adjustable safety coupling for torque limitation Prevents tap breakage during threading Torque transmission via shaft square Requires matching inserts for different shank sizes SES quick-change system FAQ What is the main purpose of the adjustable safety coupling? The adjustable safety coupling in the Quick-change insert SES 14mm x 11mm, Size 2 limits peak torque to protect taps and reduce the likelihood of tap breakage during threading operations. Which tap standards does this insert support? The insert is designed for use with taps conforming to DIN 374/376 M18 and mates with compatible tap holders and hand-tapping fixtures. How is torque transferred from the driver to the tap? Torque is transmitted via the 11 mm shaft square, providing a direct and robust drive interface that minimises slippage and wear. Are different shank sizes supported by the SES system? Yes, the SES quick-change concept requires different inserts for varying shank measurements; swapping the insert adapts the system to the required shank size while maintaining torque control. What dimensions should be checked for compatibility with existing holders? Check the core dimensions such as diameter 14 mm, square drive 11 mm and the overall interface lengths (L1, L3, L4, L5) to ensure correct seating and centring in the tap holder. TECWERK: Manufacturer/Responsible: NORDWEST Handel AG, Robert-Schuman-Straße 17, 44263 Dortmund
150mm Axial Tool Holder C2 DIN 69880 Left-Hand Outer Coolant Feed, H1 20mm - TECWERK
Take advantage of the combination of industrial compatibility, reliable coolant management and compact dimensions for smooth tool changeovers and consistent process results. Benefit from the left‑hand orientation and Form C2 interface when setting up for specialised turning tasks. Order the axial tool holder directly via Metav Werkzeuge or ask our consultants if needed. Axial tool holder C2 DIN 69880 VDI30 (left‑hand) by TECWERK — Form C2, external coolant supply A Axial tool holder C2 DIN 69880 VDI30 (left‑hand) by TECWERK engineered for precision turning and automated lathe setups, providing external coolant supply and a DIN‑standard interface for secure mounting. Form C2 compatibility with DIN 69880 Left‑hand orientation for reverse operations External coolant supply for improved cooling VDI30 taper for standardised tool mounting Stable interface and predictable machining results The VDI30 taper and adherence to DIN 69880 ensure a repeatable and secure connection between turret and holder, reducing run‑out and vibration during machining. With Form C2 geometry the holder provides a defined seating face and clamping surface, which simplifies changeover procedures and maintains concentricity at the tool tip. The combination of standardised taper and form means compatibility with a wide range of tool bodies and adapters used in industrial turning centres, supporting consistent surface finish and dimensional accuracy across production batches. Improved cooling flow for longer tool life and consistent finishes An external coolant supply (outer coolant feed) directs cutting fluid close to the cutting zone, supporting chip evacuation and heat control even at higher spindle speeds. This targeted coolant delivery improves edge stability and can reduce thermal expansion effects on the tool and workpiece, which in turn helps to preserve tool geometry and prolong service intervals. For operations where material removal rates and surface integrity matter, the coolant routing reduces thermal load and contributes to repeatable part quality. Compact dimensions that aid rigidity and repeatability Key measures such as d1: 30 mm, h1: 20 mm and l1: 70 mm define the holder’s compact profile and effective overhang, influencing stiffness and deflection under cutting forces. Additional dimensions (b4: 76 mm, h5: 28 mm, b5: 41 mm, b6: 23 mm, h6: 38 mm, l2: 10 mm) describe the mounting geometry that determines clearance, tool projection and turret compatibility. These specifications help planners and machinists assess whether the holder meets the required setup envelope and whether the chosen insert and tool body will retain the necessary rigidity for stable cuts. Integration into workshop workflows and practical advantages Designed for standard turret systems, the holder supports predictable setup times and repeatable alignment that benefit small series and industrial production alike. The left‑hand orientation caters to reverse‑hand tools or specific contouring tasks without the need for complex retooling. The standardised interface and coolant provision simplify integration, helping to reduce downtime during tool changes and making the holder a pragmatic choice for workshops seeking reliable, industrial‑grade tooling components. For precise left‑hand turning operations, ask Metav Werkzeuge for the TECWERK axial tool holder with Form C2 and external coolant supply — contact Metav Werkzeuge by e‑mail at info@metav-werkzeuge.com or by phone at +49 2822 7131930 to discuss suitability and availability. Technical data SKU: 2000833655NW Label: Axialwerkzeughalter C2 DIN 69880 VDI30 li.TECWERK Manufacturer: TECWERK Product type: Axial tool holder Packaging unit: 1 Dimensions & key measures h1: 20 mm b4: 76 mm d1: 30 mm h5: 28 mm b5: 41 mm b6: 23 mm h6: 38 mm l2: 10 mm l1: 70 mm Special features Form C2 left‑hand orientation outer coolant feed (external coolant supply) DIN 69880 compliance VDI30 taper FAQ What standard interface does this holder use? The axial tool holder uses the DIN 69880 standard with a VDI30 taper for secure turret mounting. Is the coolant delivered internally or externally? Coolant is supplied externally; the holder features an outer coolant feed directed towards the cutting zone. For which hand orientation is the holder designed? This tool holder is manufactured as a left‑hand variant, suitable for reverse‑hand or specific turning tasks. Which dimensions determine its overhang and rigidity? Key measures such as d1: 30 mm, h1: 20 mm and l1: 70 mm characterise overhang and stiffness for setup and process planning. Manufacturer / Responsible: NORDWEST Handel AG, Robert‑Schuman‑Straße 17, 44263 Dortmund
150mm Axial Tool Holder C4 Left Overhead External Coolant, DIN 69880 - TECWERK
A robust combination of Form C4 geometry, left‑hand orientation and external coolant feed delivers repeatable clamping, efficient cooling and dependable performance for overhead machining; order the axial tool holder directly via Metav Werkzeuge or request specialist advice from their consultants. Axial Tool Holder C4 DIN 69880 VDI40 – left‑hand, overhead (TECWERK) The Axial Tool Holder C4 DIN 69880 VDI40, left‑hand overhead is a VDI40 toolholder designed for secure mounting in spindle systems, offering external coolant supply for improved chip control and machining stability Form C4 for compact axial positioning Left‑hand orientation for specific tooling External coolant feed for improved cooling DIN 69880 compliant for VDI40 spindles Stable, repeatable mounting for VDI40 spindles Engineered to the DIN 69880 specification and compatible with VDI40 interfaces, this toolholder provides a stable connection between spindle and cutting tool. The Form C4 geometry ensures axial positioning with minimal runout, which increases repeatability during serial production. Reduced radial movement translates into consistent component tolerances and less rework, making the holder suitable for demanding turning and milling operations where positioning accuracy is essential. Effective cooling and cleaner chip flow for longer tool life The overhead configuration with external coolant feed directs cutting fluid close to the cutting zone while preserving the holder’s clamping integrity. Supplying coolant externally supports efficient heat removal and improved chip evacuation in interrupted cuts or difficult materials. The result is extended tool life and a more consistent surface finish, particularly when machining alloys where thermal control prevents premature wear and built‑up edge formation. Compact dimensions for easy integration and fast setup With measured dimensions such as h1 25 mm, b4 90 mm, d1 40 mm and l1 85 mm, the holder fits standard VDI40 tool turrets and reduces installation time during tool changes. The overhead design and precise contours help maintain clearance in constrained setups while keeping the coolant channel accessible. Standardised mounting and the clear technical specification facilitate part interchangeability across machines and support efficient workshop logistics. Contact Metav Werkzeuge for tailored integration advice or request the Axial Tool Holder directly from Metav Werkzeuge for immediate supply and technical consultation Technical Data Article number: 2000833660NW Label: Axialwerkzeughalter C4 DIN 69880 VDI40 li.Überkopf TECWERK Product type: Axial tool holder Manufacturer: TECWERK Packaging unit: 1 UID: 2000833660NW Dimensions & measurable data h1: 25 mm b4: 90 mm d1: 40 mm h5: 48 mm b5: 47.5 mm b6: 25.5 mm h6: 42.5 mm l2: 12.5 mm l1: 85 mm Special features Form: C4 Left‑hand orientation Overhead configuration External coolant feed Standard: DIN 69880 Interface: VDI40 FAQ What spindle interface does this holder use? The axial tool holder is designed for the VDI40 interface and conforms to DIN 69880, ensuring compatibility with VDI40 turret systems. Is coolant supplied internally or externally with this holder? Coolant is provided via an external coolant feed; the holder is configured for overhead coolant routing to support effective heat control. Which dimensions are relevant for machine fitting? Key dimensions include h1 25 mm, d1 40 mm and l1 85 mm, which determine axial position and clearance in the turret. Can this holder handle right‑handed and left‑handed tooling? This variant is left‑hand oriented; right‑hand tooling requires the corresponding right‑hand version or alternative orientation. What is the SKU for ordering and reference? Reference SKU 2000833660NW for procurement and technical documentation when sourcing the TECWERK axial tool holder. Manufacturer / Responsible: NORDWEST Handel AG, Robert‑Schuman‑Straße 17, 44263 Dortmund
150mm Collet Chuck ER25 1-16mm Clamping Range Cylindrical Shank 42mm - TECWERK
Benefit from a compact solution that combines a wide clamping range (1–16 mm) and a stable 42 mm body with a cylindrical shank for reliable toolholding; the construction supports DIN 6499 collets and keeps changeover times low. Order the ER collet chuck directly via Metav Werkzeuge or consult our specialists if further adaptation is required. TECWERK ER25 Collet Chuck – Clamping Range 1–16 mm, 20 mm Shank The TECWERK ER25 collet chuck for secure clamping of tools with cylindrical shanks in ER collets, suitable for workshop and light industrial toolholding applications. ER 25 collet system compatibility Clamping range 1–16 mm Cylindrical shank with lateral clamping face 42 mm body diameter for stable mounting Consistent clamping for efficient production The ER collet chuck is engineered to provide repeatable clamping when changing tools frequently. With a clamping range of 1–16 mm and compatibility with the ER25 interface, the holder reduces downtime and supports predictable machining cycles. The cylindrical shank and lateral clamping surface contribute to axial stability, while adherence to DIN 6499 ensures compatibility with standard collets. This results in improved process reliability and fewer interruptions in daily workshop operations. Easy integration and practical handling on the shop floor Designed as a compact, straightforward toolholder, this collet chuck fits into existing setups without complex adaptations. The 20 mm shank suits common machine spindles and fixtures, and the 42 mm body diameter provides a steady seating in the spindle or arbor. Clear mechanical design lowers the learning curve for operators and simplifies routine tool changes, which helps to raise throughput and keeps handling consistent across different operators and shifts. Durable design meets standardised tooling requirements Built with a focus on mechanical integrity, the chuck’s geometry supports secure clamping of cylindrical-shank tools and long-term stability under load. Compatibility with standard ER collets to DIN 6499 makes the system flexible for a wide range of cutters and reamers. The robust body and lateral clamping face contribute to vibration dampening and consistent concentricity, which assists in maintaining surface finish and dimensional accuracy during repeated machining tasks. For a dependable ER25 solution from TECWERK, contact Metav Werkzeuge in Emmerich for tailored advice and reliable supply – phone +49 2822 7131930 or e‑mail info@metav-werkzeuge.com Technical data Article number: 2120620190NW SKU / UID: 2120620190NW Manufacturer: TECWERK Product type: ER collet chuck Collet interface: ER 25 Facts Body diameter: 42 mm Clamping range: 1–16 mm Shank diameter: 20 mm Special features Cylindrical shank design Lateral clamping face Suitable for clamping cylindrical-shank tools Compatible with DIN 6499 collets FAQ What collet system does this chuck use? The TECWERK ER25 collet chuck uses the ER25 collet system, compatible with standard ER collets to DIN 6499 for tools with cylindrical shanks. Which clamping range is covered by the holder? The holder supports a clamping range of 1–16 mm, enabling use with a broad set of small to medium shank tools in the ER25 range. Is the shank suitable for common spindles and arbors? Yes, the chuck features a 20 mm cylindrical shank, making the TECWERK ER25 collet chuck straightforward to integrate into many spindles and arbors used in workshops. Can this chuck be used for precision finishing operations? The design emphasises stability and concentricity; when paired with suitable ER collets, the TECWERK ER25 collet chuck supports finishing operations that require consistent tool runout and surface quality. What standards ensure compatibility with collets and tooling? Compatibility is based on DIN 6499 for ER collets, ensuring the chuck functions with standardised tooling kits and collet sets. TECWERK: Manufacturer / Responsible: NORDWEST Handel AG, Robert-Schuman-Straße 17, 44263 Dortmund
