High-precision micrometers for exact external diameter measurement
Bügelmicrometers, also known as micrometers or outside micrometers, are engineered for the precise determination of external diameters, material thicknesses and shaft dimensions in metalworking and quality assurance, delivering repeatable results down to 0.001 mm with a defined measuring force. Their robust frame prevents deflection while the integrated ratchet ensures consistent contact pressure, making them ideal for in-process checks at the machine or final inspection in the metrology lab; available variants include analogue, digital and carbide-tipped measuring faces for different surfaces and applications. The design enables one-handed operation via the frame while the thimble and ratchet provide fine adjustment and secure locking of the spindle, supporting efficient handling of small or awkward parts. Suitable for toolmaking, automotive production and industrial quality control, these micrometers combine stiffness, ease of use and data-capable digital options for seamless documentation.
50-75mm Thread Measuring Micrometer With Colour 2.4" Touchscreen, Wireless/USB, ISO 17025 Calibrated - Microtech Metrology
High-precision measurement meets modern connectivity: the micrometer offers 0.004 mm accuracy, an ultra-fine 0.0001 mm display resolution and Wireless + USB data output for fast documentation, while delivery includes an ISO 17025 calibration certificate for traceability. Order the micrometer directly via Metav Werkzeuge or consult our specialists for application guidance. Micrometer Whitworth 55 – digital thread micrometer by Microtech Metrology Micrometer Whitworth 55 is a digital thread micrometer engineered for precise Whitworth-thread checks and small-component metrology, combining compact range with modern data transfer options. Wireless + USB data output 2.4" colour touchscreen display ISO 17025 calibration certificate included Precise measuring performance for demanding thread work The instrument delivers an industrial-grade 0.004 mm accuracy with a high-resolution readout of 0.0001 mm, making it suitable where repeatable, documented results are essential. The design features a non-rotating spindle, reducing thread damage during contact and improving measurement consistency. With a measuring span classified as Mikro (50–75 mm), this compact format focuses on fine mechanical and thread inspection tasks where rigidity and short jaw length minimise torsion and enable steady handling in the workshop or inspection bench. Modern connectivity and application-ready accessories Data capture is simplified by the 2.4" colour touchscreen and dual output channels (Wireless + USB), supporting rapid transfer into measurement software or quality logs. The device is supplied with 10x anvils 60-3.5 TPI (Whitworth 55), allowing direct comparison and efficient batch checks for Whitworth-threaded components. The digital interface reduces transcription errors and speeds up throughput, turning manual inspection steps into a faster, auditable workflow for production control or incoming inspection. Traceable calibration and partner support for quality assurance Delivered fully calibrated to ISO 17025, the micrometer includes an official calibration certificate, providing documented traceability for quality systems and audits. Manufactured by Microtech Metrology, the instrument combines proven engineering with Metav’s commitment to democratising precision: a broad selection, reliable stock and technical support from Metav Werkzeuge ensure this measuring solution integrates smoothly into both small workshops and larger quality departments. For specialised metrology tasks, this micrometer bridges hands‑on usability and documented measurement confidence. Request specific calibration data or application advice from Metav Werkzeuge—email info@metav-werkzeuge.com or call +49 2822 7131930 to discuss the Microtech Metrology micrometer (SKU 110720758) and its ISO 17025 calibration certificate Technical data Article number: 110720758 GTIN: 4061905457258 Manufacturer: Microtech Metrology Type: Whitworth 55 Facts Measuring range: 50–75 mm Resolution (display): 0.0001 mm Accuracy: 0.004 mm Display: 2.4" colour touchscreen Data output: Wireless + USB eClass: 21170328 SKU: 110720758 Special features ISO 17025 calibrated with certificate Non-rotating spindle Digital micrometer with touchscreen Includes 10x anvils 60-3.5 TPI (Whitworth 55) Designed for Whitworth-thread measurement FAQ Is the instrument supplied with an official calibration certificate? The micrometer is supplied fully calibrated to ISO 17025 and includes the corresponding calibration certificate for traceability. What data interfaces are available for measurement logging? Measurements can be exported via Wireless and USB connections from the Microtech Metrology micrometer (SKU 110720758) to compatible data‑collection systems. What accuracy and resolution can be expected during routine checks? The device provides an accuracy of 0.004 mm with a display resolution of 0.0001 mm, suitable for high-precision thread inspection and quality control tasks. Are the included anvils suitable for Whitworth threads? Yes, the delivery contains 10x anvils 60-3.5 TPI (Whitworth 55), enabling direct measurement and comparison of Whitworth-threaded parts. For which applications is this micrometer best suited? The micrometer is optimised for fine mechanical and thread measurement in workshops and inspection benches, classified in the Mikro range for compact, high‑precision tasks. Manufacturer / Responsible: Microtech, Nizhneyurkovska str., 45a, 04080 Kyiv, Ukraine, tool@microtech.tools
50-75mm Tolerance Bore Gauge With Digital Fine Indicator, IP54 - Filetta
The combination of high-resolution readout, reliable IP54 protection and an included adjustment gauge supports consistent tolerance checks and faster inspection cycles; order the Filetta Tolerance Micrometer MS910.504 directly via Metav Werkzeuge or consult our advisers for application-specific guidance. Tolerance Micrometer MS910.504 — Digital micrometer with IP54 protection The Tolerance Micrometer MS910.504 is a precision outside micrometer designed for workshop inspection and quality control across a 50–75 mm measuring range with fine digital readout. High precision ±0.005 mm accuracy Resolution 0.001 mm (1 µm) display Digital mm/inch display and rechargeable battery IP54 protection and supplied in transport case Reliable metrology for shop-floor quality control The MS910.504 offers an industrial-grade mix of high resolution and repeatable accuracy: a 0.001 mm display combined with a stated ±0.005 mm accuracy makes it suitable for routine dimensional control and pass/fail verification in small-batch production. The nominal measuring range of 50–75 mm covers typical components, fixtures and turned parts encountered in mechanical workshops. By converting fine numerical resolution into tangible process reliability, the instrument reduces rework and inspection uncertainty during assembly and finishing. Designed for robust use and simple handling Built for active workshop conditions, the instrument carries an IP54 rating that resists dust ingress and splashing, while a rechargeable lithium battery and a clear mm/inch display simplify repeated checks across shifts. The micrometer features Ø6.5 mm measuring faces and a measured 5–10 N measuring force to balance contact stability with surface protection; this combination helps to minimise operator-induced variation. An adjustment gauge included ensures the device can be verified and set up quickly after transport, and the supplied transport case protects the instrument between uses. Practical benefits for inspection routines and traceable workflows Integrating the instrument into inspection routines shortens measurement cycles: the digital readout accelerates data capture compared with mechanical scales, while the compact range and sturdy frame make handling straightforward. The device is particularly well suited for component shops, toolrooms and final inspection benches where consistent tolerance checks are required. For applications that demand traceable set-up, the included gauge and clear specification of measuring force help establish repeatable measurement conditions and support documented quality procedures. For application advice or to arrange procurement of the Filetta Tolerance Micrometer MS910.504 with IP54 protection and rechargeable power, contact Metav Werkzeuge for tailored guidance and prompt delivery from Emmerich. Technical Data Article number: MS910.504 Manufacturer: Filetta Product: Tolerance micrometer IP protection: IP54 Facts Measuring range: 50–75 mm Resolution: 0.001 mm Accuracy: ±0.005 mm Measuring faces diameter: Ø 6.5 mm Special features Digital display with mm/inch and On/Off Rechargeable lithium battery Measuring force 5–10 N Adjustment gauge included Supplied in transport case FAQ What measuring range does this micrometer cover? The Filetta Tolerance Micrometer MS910.504 covers a measuring range of 50–75 mm and is intended for precision outside measurements within that span. How accurate and precise is the instrument? The MS910.504 provides a display resolution of 0.001 mm and a stated accuracy of ±0.005 mm, suitable for routine workshop inspection and dimensional checks. Is the micrometer suitable for shop-floor use? Yes, the Filetta micrometer is rated IP54 for protection against dust and splashes and includes a rechargeable lithium battery for continuous use on the shop floor. Does the delivery include any accessories for setup? The micrometer is supplied with an adjustment gauge included and comes in a transport case to protect the instrument during storage and transport. Can measurements be read in imperial units? Yes, the digital readout on the MS910.504 supports both mm and inch displays and includes an On/Off button for simple operation. Manufacturer / Responsible: Schut Geometrische Meettechniek bv; Duinkerkenstraat 21; 9723 BN Groningen; The Netherlands; +31 50 5877877; schutnl@schut.com
50-75mm Tube Wall Thickness Micrometer Colour Touchscreen, Wireless+USB, IP65, ISO 17025 - Microtech Metrology
High-resolution measurement capability, robust ingress protection and plug‑and‑play data transfer make this micrometer an efficient choice for tube wall inspection; its ISO 17025 calibration certificate ensures traceable results straight from delivery. Order via Metav Werkzeuge or contact the consultants for application advice. Microtech Tube Wall Thickness Micrometer with Microcomputer — 0.0001 mm resolution, Wireless+USB The Microtech tube wall thickness micrometer is a digital instrument designed for precise measurement of tube walls across the 50–75 mm diameter range. 0.0001 mm reading resolution ISO 17025 calibration certificate included Wireless HID and USB HID data output IP65 protection with 2.4" colour touchscreen Precision that delivers reproducible thickness control High-resolution sensing combined with industrial-grade accuracy reduces measurement uncertainty during routine inspections. The instrument reads to 0.0001 mm (0.1 µm) and specifies an accuracy of ±0.003 mm, which supports reliable process control for tube wall checks. The measuring range of 50–75 mm targets medium-sized tubes while being suitable for wall thicknesses from 4.7 mm upwards. This performance profile is particularly useful where repeatable, comparable thickness values are required for quality reports and batch acceptance. Seamless data transfer to quality systems Integrated Wireless HID and USB HID connectivity allow direct transfer of measured values into spreadsheets, inspection apps or quality databases on Windows, Android, iOS, macOS and Linux systems. Long‑range wireless options and standard USB HID reduce manual transcription and accelerate data capture during batch checks, supporting faster inspection cycles and lower administrative overhead. The 2.4" colour touchscreen provides immediate readout and menu navigation before data export. Robust, ergonomic design for workshop use A protective IP65 enclosure shields electronics from chips and coolant, while the friction ratchet and rotating spindle ensure uniform measuring force and repeatable seating on curved surfaces. The tactile feedback of the ratchet and the spindle rotation improve operator consistency, reducing influence from variable hand pressure. The colour touchscreen and balanced handle design support comfortable, single‑hand operation during repetitive checks. Traceable calibration and compliance ready Delivered with an ISO 17025 calibration certificate, the instrument is ready for use in accredited inspection processes. The included calibration certificate documents traceability and measurement uncertainty, easing internal audits and supplier acceptance. Having calibration performed to the ISO 17025 standard removes the immediate need for local re‑calibration and simplifies integration into formal quality systems. Contact Metav Werkzeuge to discuss suitability for specific tube geometries and to secure a Microtech tube wall thickness micrometer with ISO 17025 calibration and Wireless+USB data output Technical data Article number: 110350758 GTIN: 4061905040863 Manufacturer: Microtech Metrology Display: Colour 2.4" touchscreen Data output: Wireless+USB Facts Measuring range: 50–75 mm Suitable for tube wall thicknesses from 4.7 mm Resolution: 0.0001 mm Accuracy: ±0.003 mm Protection class: IP65 Calibration: ISO 17025 certificate included Special features Friction ratchet for consistent measuring force Rotating spindle for easy engagement on curved surfaces Long-range wireless and USB HID data transfer Colour 2.4" touchscreen for clear readout and control FAQ What measuring range does the micrometer cover? The micrometer covers a measuring range of 50–75 mm and is intended for tube diameters within that span. Can this instrument measure thin tube walls? Yes, the micrometer is suitable for tube wall thickness measurements from 4.7 mm and above. Is a calibration certificate supplied with the device? A full ISO 17025 calibration certificate is supplied with the instrument, documenting traceability and measurement uncertainty. How are measured values exported to a PC or tablet? Measured values are exported via Wireless HID or USB HID, compatible with Windows, Android, iOS, macOS and Linux platforms. Is the micrometer suitable for workshop environments? Yes, the housing is rated IP65 and the unit features a friction ratchet and rotating spindle to support reliable workshop use. Manufacturer / Responsible: Microtech, Nizhneyurkovska str., 45a, 04080 Kyiv, Ukraine, tool@microtech.tools
50-75mm Tube Wall Thickness Micrometer Digital Friction Thimble IP65, ISO 17025 Calibrated - Microtech Metrology
Take advantage of a rugged, IP65-rated digital instrument with 0.001 mm resolution and accuracy ±0.003 mm for reproducible wall‑thickness checks on tube assemblies; delivered with an ISO 17025 calibration certificate for traceable quality control. Order the CertiMet TUBE directly via Metav Werkzeuge or ask our consultants if needed. CertiMet TUBE digital micrometer – tube wall thickness micrometer, IP65, ISO 17025 (Microtech Metrology) The CertiMet TUBE digital micrometer is a purpose‑built instrument for measuring tube wall thickness between 50–75 mm, combining a sealed aluminium housing with a precision friction thimble for consistent results in production and inspection environments Digital display, mm/inch and hold function IP65 aluminium housing for harsh environments ISO 17025 calibration certificate included Friction thimble for reproducible measuring force Reliable results under production conditions The sealed IP65 housing and robust aluminium construction make the instrument suitable for workshop and site use where splash, coolant or dust are present. A clear digital display with selectable mm/inch readout and a hold function speeds up throughput at inspection stations, while the integrated origin feature simplifies repetitive checks. The combination of environmental protection and intuitive functions reduces re‑measurements and supports consistent sampling routines. Reproducible measurement force for traceable checks A calibrated friction thimble ensures a consistent contact force on each measurement, which is crucial when verifying thin tube walls. With a resolution of 0.001 mm and accuracy ±0.003 mm, the instrument delivers the quantitative certainty required for in‑process quality control and conformity testing. This precision helps to reduce scrap and rework by catching deviations earlier in the production cycle, turning measurement data into actionable decisions. Traceable calibration and customisation for specialised tasks The instrument is supplied with an ISO 17025 calibration certificate (Ilac MRA), making results auditable and suitable for regulated production environments. For unusual profiles or non‑standard tube diameters a custom tube anvil can be requested to adapt the contact geometry, ensuring correct seating and repeatability on curved surfaces. These options support integration into formal quality systems and reduce uncertainty in acceptance testing. Contact Metav Werkzeuge to discuss the Microtech Metrology CertiMet TUBE, request a customised anvil or receive the ISO 17025 calibration documentation from our Emmerich quality team Technical data Article number: 110350751 GTIN: 4061905040559 Manufacturer: Microtech Metrology Category: Messschrauben Core specifications Measuring range: 50–75 mm Resolution: 0.001 mm Accuracy: ±0.003 mm Protection class: IP65 Features & materials Friction thimble micrometer head Functions: mm/inch, origin, hold Aluminium housing Calibration: ISO 17025 certificate included Custom tube anvil on request FAQ What measuring range does the micrometer cover? The instrument covers a measuring range of 50–75 mm, which is intended for tube wall thickness checks on small to medium‑diameter tubing. Is a calibration certificate supplied with the device? Yes, the micrometer is delivered with an ISO 17025 calibration certificate (Ilac MRA), providing traceability for audit‑ready quality control. How consistent are repeated measurements? Repeatability is supported by the friction thimble and digital readout; combined resolution of 0.001 mm and accuracy of ±0.003 mm ensures high reproducibility for serial inspections. Can the micrometer be used in wet or dusty environments? The IP65 rated aluminium housing protects the instrument from jets of water and ingress of dust, making it suitable for many production environments. Is it possible to adapt the contact for specialised tube profiles? Yes, a custom tube anvil can be supplied on request to match specific tube curvature and ensure correct seating during measurement. Manufacturer / Responsible: Microtech, Nizhneyurkovska str., 45a, 04080 Kyiv, Ukraine, tool@microtech.tools
50-75mm Universal Micrometer With 7 Pair Measuring Inserts, Color 2.4" Touchscreen, IP65, ISO 17025 - Microtech Metrology
The combination of ISO 17025 traceable calibration, robust IP65 protection and flexible Wireless+USB data transfer provides reliable measurement results and smooth integration into digital workflows. Benefit from the instrument’s high 0.004 mm accuracy and the included set of 7 pairs of measuring inserts to cover a wide range of workshop tasks. Order the micrometer directly via Metav Werkzeuge or ask the consultants for application advice. Universal micrometer — Digital 50–75 mm range, IP65 protection (Microtech Metrology) Universal micrometer is a compact digital micrometer for precise external measurements in the 50–75 mm range, suited to production control and workshop inspection. ISO 17025 calibrated with certificate IP65 protection for shop-floor reliability Wireless+USB data transfer for traceability Colour 2.4" touchscreen for intuitive operation Traceable precision for production control The instrument delivers a stated accuracy of 0.004 mm, giving a clear quantitative basis for process decisions and quality documentation. Supplied calibrated to ISO 17025, the device is delivered with a formal calibration certificate, enabling immediate use in traceability chains and internal quality systems. The high reproducibility supports consistent part acceptance limits and shortens inspection cycles. Robust design and easy data integration Equipped with IP65 protection, the digital unit withstands coolant sprays and typical workshop contaminants while maintaining measurement stability. Data export over Wireless+USB simplifies transfer to SPC or measurement software, reducing manual transcription and associated errors. The 2.4" colour touchscreen provides direct readout and menu control, speeding up routine checks and enabling faster operator throughput. Non-rotating spindle and versatile measuring inserts A non-rotating spindle reduces frictional wear on the anvil and measuring faces, improving long-term repeatability. The delivery includes 7 pairs of measuring inserts, allowing adaptation to different workpiece geometries without changing the entire instrument. This versatility reduces fixture changes and supports diverse inspection tasks across batches and setups. Practical benefits in everyday metrology Built as a digital micrometer for shop and lab use, the unit combines traceability, connectivity and practical ergonomics to support lean inspection routines. The compact footprint and clear display make it suitable for bench-side quality checks as well as for integration into measurement stations. The instrument’s specifications align with typical industrial needs for fast, documented and auditable measurements. Contact Metav Werkzeuge to discuss how the Microtech Metrology digital micrometer can be integrated into existing inspection routines and to request the ISO 17025 calibration certificate from our Emmerich quality hub Technical Data Article number: 110750758 GTIN: 4061905040351 Manufacturer: Microtech Metrology Digital display: Colour 2.4" touchscreen Data output: Wireless+USB Protection class: IP65 Included: 7 pairs of measuring inserts Delivered calibrated to ISO 17025 with certificate Facts Measuring range: 50–75 mm Accuracy: 0.004 mm Category: Micrometers (messschrauben) SKU: 110750758 Special features Non-rotating spindle Digital instrument for external measurements Suitable for workshop and process control applications Wireless and USB connectivity for data capture FAQ What measurement range does this micrometer cover? The micrometer covers an external measurement range of 50–75 mm, suitable for medium-sized workpieces and production control. Is the instrument supplied calibrated? Yes, the device is delivered calibrated to ISO 17025 and includes a calibration certificate for traceability and documentation. How can measurement data be transferred to quality systems? Data export is available via Wireless+USB, enabling direct capture into SPC software or measurement databases. Are measuring inserts included and what do they offer? The delivery contains 7 pairs of measuring inserts, which expand the micrometer’s adaptability to different geometries without replacing the whole unit. Is the micrometer suitable for workshop conditions? With IP65 protection and a robust design, the micrometer is intended for regular workshop use and resists spray and dust typical in production environments. Manufacturer / Responsible: Microtech, Nizhneyurkovska str., 45a, 04080 Kyiv, Ukraine, tool@microtech.tools
500-600mm Digital Micrometer Caliper With Friction Ratchet, IP65, ISO 17025 Calibrated - Microtech Metrology
Combining robust IP65 protection, traceable ISO 17025 calibration and a fine 0.001 mm reading creates a dependable solution for large-format dimensional control; the integrated friction ratchet and Ø25 mm measuring faces ensure repeatable contact pressure and stable readings. Order the device directly via Metav Werkzeuge or consult our specialists for application advice. Digital outside micrometre by Microtech Metrology — 500–600 mm, IP65 A digital outside micrometre designed for large-range industrial measurement up to 600 mm, combining rugged protection, traceable calibration and high-resolution display for consistent production and inspection workflows. IP65-rated digital measuring head ISO 17025 calibration certificate included 0.001 mm display resolution, 0.008 mm accuracy Ø25 mm hardened measuring faces Consistent large-range capability for heavy components The instrument is built for measurements in the 500–600 mm class, a range where rigidity and repeatability become decisive. The long spindle geometry and substantial measuring faces deliver stable contact over extended spans, reducing flex and operator-induced error when inspecting housings, fixtures or large shafts. The integrated friction ratchet standardises contact force on each measurement, which, combined with the broad Ø25 mm measuring faces, translates into reliable readings across long inspection runs and reduces rework in production. Traceable accuracy that supports quality systems Traceability is front and centre: the micrometre is supplied with an ISO 17025 calibration certificate (Ilac MRA), making it suitable for accredited test labs and internal quality audits. The digital head offers a 0.001 mm display resolution while the verified instrument accuracy of 0.008 mm ensures measurements meet rigorous tolerances. For quality managers and inspection engineers this means fewer disputes over measurement data and straightforward integration into control plans and documentation chains. Robust construction and practical features to cut downtime Designed for workshop use, the digital micrometre combines an IP65-protected readout with a durable frame that withstands coolant spray and dusty environments. The digital head is sealed and the supplied setting rods facilitate in-situ verification and quick zeroing, saving time during shift changes. At approximately 2.6 kg the instrument balances mass for stability with manageable handling during two-person tasks. These practical design choices reduce the frequency of recalibration cycles and keep inspection stations productive. Discuss the Microtech digital outside micrometre with Metav Werkzeuge to confirm suitability for specific large-part applications and to arrange calibrated delivery from Emmerich. Technical data Article number: 110176001 GTIN: 4061905040221 Manufacturer: Microtech Metrology IP rating: IP65 Digital display: yes Calibration: ISO 17025 certificate included Core measurements Measuring range: 500–600 mm Resolution (reading): 0.001 mm Accuracy: 0.008 mm Measuring faces: Ø25 mm Weight: 2.6 kg Features Friction ratchet Setting rods included Digital micrometre head (IP65) Calibration certificate ISO 17025 (Ilac MRA) ECLASS: 21170328 ETIM: EC003590 FAQ What calibration documentation is supplied with the micrometre? The micrometre is delivered with an ISO 17025 calibration certificate (Ilac MRA), confirming traceability and suitability for laboratory and audit requirements. What resolution and accuracy can be expected from this instrument? The digital display shows 0.001 mm steps while the instrument’s verified accuracy is 0.008 mm, making the device appropriate for precise large-part inspections. How does IP65 protection benefit workshop use? An IP65 rating means the digital head is dust-tight and protected against water jets, so the micrometre’s electronics remain reliable in coolant-splashed or dusty production environments. Are accessories included to set or check the micrometre? Yes, the delivery includes setting rods for quick verification and zero checks, enabling fast on-site validation before measurement tasks. Is the friction ratchet applicable for repeatable measurements? The integrated friction ratchet provides consistent contact force and helps produce repeatable results across multiple measurements, particularly useful on larger components Manufacturer / Responsible: Microtech, Nizhneyurkovska str., 45a, 04080 Kyiv, Ukraine, tool@microtech.tools
500-600mm External Micrometer With Colour Touchscreen, ISO 17025 Calibration Included - Microtech Metrology
Take advantage of high‑capacity data handling, reliable sub‑10 µm accuracy and a robust CNC‑machined aluminium frame for consistent measurements of large components. The calibrated instrument comes with an ISO 17025 certificate and wireless plus USB data transfer, allowing immediate integration into inspection workflows. Order directly via Metav Werkzeuge or contact the consultants for application advice. Outside micrometer — Microtech Metrology with wide range and digital MICS control The outside micrometer combines a large measuring span with a colour touchscreen and wireless data transfer for measurement tasks on medium to large assemblies. Large 500–600 mm measuring span Colour 1.5" touchscreen display Wireless and USB data transfer ISO 17025 calibration certificate included Precision across a large measuring span for repeatable assemblies This micrometer is engineered for applications that demand reach without sacrificing repeatability: the instrument covers the 500–600 mm measuring span and therefore sits in the large‑range class suitable for heavy components, fixtures and housings. The specified accuracy 0.006 mm delivers reliably small measurement uncertainty across the entire span, which makes this tool appropriate for quality control tasks where tolerance stacks matter. The relatively compact weight and Ø25 mm measuring faces ensure stable contact and avoid excessive local deformation on workpieces while providing consistent results. Seamless data workflows to speed up inspection and reporting Connectivity is a core advantage: the unit offers wireless data output alongside USB, four transfer modes and HID compatibility, enabling direct logging into measurement software or spreadsheets. The integrated memory manager holds 2,000 values with folder and statistics support, reducing manual recording and speeding up batch inspections. For automated environments the device supports the MICS system and optional Modbus RTU, so measurement data can be routed to production databases or SPC systems without additional converters, improving traceability and reducing transcription errors. Robust construction and calibrated traceability for shop‑floor confidence The frame is a CNC‑machined aluminium housing, designed for structural rigidity and long service life under workshop conditions. The colour 1.5" touchscreen display provides clear readouts and access to functions such as max/min, formula inputs and temperature correction, helping to convert instrument capabilities into usable results. The micrometer is delivered fully calibrated according to ISO 17025 (Ilac MRA), and a calibration certificate is included, which supports supplier audits and documented quality processes on the shop floor. Practical benefits for production and tooling departments With a broad measuring range and integrated data management the instrument shortens inspection cycles and reduces handling. The combination of a tactile measuring frame and electronic data output cuts recording errors and speeds up part sign‑off. The design is particularly well suited where assembly or fixture dimensions must be validated repeatedly and where documented, calibrated measurement records are required for quality assurance. Contact Metav Werkzeuge today for a tailored consultation and secure a calibrated Microtech Metrology outside micrometer with ISO 17025 certificate and industrial data connectivity Technical data Article number: 110186008 GTIN: 4061905039584 Manufacturer: Microtech Metrology Key measurements Measuring range: 500–600 mm Measuring faces: Ø25 mm Accuracy: 0.006 mm Weight: 2.6 kg Display: Colour 1.5" touchscreen Features & functions Wireless + USB data output Memory manager, 2,000 values CNC‑machined aluminium housing Calibration certificate ISO 17025 (Ilac MRA) included MICS system for advanced measurement modes 4 modes data transfer (Wireless MDS app, Wireless HID, Wireless HID+MAC, USB HID) Optional Modbus RTU for industrial connections FAQ How is traceability ensured for calibration? The micrometer is delivered fully calibrated with an ISO 17025 certificate (Ilac MRA), which documents traceability and supports quality audits. Can measurement data be integrated into company SPC software? Yes, the unit supports wireless and USB transfer, HID modes and optional Modbus RTU, enabling direct integration into SPC or factory data systems. What makes this instrument suitable for larger components? The 500–600 mm measuring span and rigid CNC‑machined housing provide the reach and stability required for medium to large assemblies and fixtures. How many readings can be stored on the device? The internal memory manager stores up to 2,000 values with folder organisation and basic statistics, reducing manual logging. Is the touchscreen usable in a busy workshop environment? The colour 1.5" touchscreen offers clear visibility and straightforward access to functions such as temperature correction, formulas and max/min recording. Manufacturer / Responsible: Microtech, Nizhneyurkovska str., 45a, 04080 Kyiv, Ukraine, tool@microtech.tools
5000-6000mm Modular Bench Micrometer Colour Touchscreen, Wireless, IP65, ISO 17025 - Microtech Metrology
Take advantage of modular construction, Industry 4.0 connectivity and an ISO 17025 calibration certificate to bring reproducible large‑scale measurement into production. Order the device directly via Metav Werkzeuge or consult our specialists for system integration and transport planning. Frame micrometer — modular C‑frame micrometer with wireless and USB data output A modular frame micrometer designed for ultra‑long measurements and industrial digitisation, ideal for large components and integration into automated data systems. Modular construction for easy transport ISO 17025 calibration certificate included Wireless and USB HID data transfer CNC-machined aluminium C‑frame housing Precision for very large components and heavy industry This measuring instrument is engineered for an ultra‑long measuring range of 5,000–6,000 mm, making it suitable for large shafts, housings and heavy machinery components where reproducibility over long spans is essential. The substantial C‑frame and CNC‑machined aluminium housing keep the structure stable under load; combined with Ø50 mm measuring faces and a multi‑module build, the system maintains alignment across its length. The design therefore reduces rework and measurement variability when handling oversized parts. Industry 4.0 ready: fast, error‑proof data flow Equipped with a Colour 1.5" touchscreen and multiple data modes, the instrument supports wireless and wired workflows to reduce manual entry and traceability gaps. Native Wireless HID, USB HID and optional MODBUS RTU interfaces allow direct connection to PCs, tablets and PLCs; a Memory Manager stores 2000 values with folder organisation and statistical summaries. These features speed up quality loops and simplify process documentation, helping to cut cycle times and to feed measurement data directly into production control systems. Delivered calibrated for reliable results The device is supplied fully calibrated and includes an ISO 17025 calibration certificate, so the measuring chain can be validated immediately after installation. Readout resolution is 0.0001 mm, while the stated measurement accuracy is listed as 0.09. Together with a comprehensive calibration protocol, this guarantees a defined uncertainty budget for incoming inspection and in‑process checks. The calibration documentation supports quality audits and simplifies adherence to internal inspection plans. Modular handling and on‑site adaptability Patented modular construction enables disassembly for transport and reassembly on site within a short timeframe, making the instrument practical for workshops that need a portable yet high‑capacity measuring solution. The measuring hub supports wireless MICROTECH instrument connections, synchronization, 2D graphing and probe modes for specialised tasks. IP 65 protection ensures resilience against chips and coolant in heavy‑duty environments, while the robust build and transportable modules ease logistics for large‑scale metrology operations. Contact Metav Werkzeuge for a tailored integration proposal, technical consultation or to discuss factory acceptance testing for the Microtech Metrology frame micrometer—call +49 2822 7131930 or eMail info@metav-werkzeuge.com Technical data Article number: 110160605 GTIN: 4061905040290 Manufacturer: Microtech Metrology IP protection: IP 65 Digital display: Colour 1.5" touchscreen Core figures Measuring range: 5000–6000 mm Measuring range (max): 6000 mm Measuring range (min): 5000 mm Resolution (reading): 0.0001 mm Accuracy: 0.09 Weight: 79 kg Modules: 6 Measuring faces: Ø50 mm Memory capacity: 2000 values Special features Modular construction for transport and assembly Wireless + USB data output (Wireless HID, USB HID) Optional MODBUS RTU (RS‑485) for industrial networks CNC‑machined aluminium C‑frame housing Calibration certificate ISO 17025 included Industry 4.0 MICS system with online graphic, Go/NoGo and statistics Wireless MICROTECH instrument connection and 2D graph modes IP 65 rated for harsh workshop environments FAQ What size of components is this instrument intended for? The frame micrometer from Microtech Metrology is designed for very large components with a measuring range of 5,000–6,000 mm, making it appropriate for heavy machining, pipe and vessel work and large bearing assemblies (SKU 110160605). Is the device ready for integration into existing measurement systems? Yes — the instrument supports Wireless HID, USB HID and an optional MODBUS RTU output; built‑in memory and the MICS system permit straightforward data transfer and integration into production networks. Does the instrument arrive calibrated and documented? Delivery includes an ISO 17025 calibration certificate, so the measuring chain is documented and auditable as soon as the instrument is put into service. Which environmental conditions can the instrument withstand? The measuring system is rated IP 65, protecting it against dust ingress and water jets commonly encountered in industrial workshops. How does the modular design benefit workshop logistics? The patented modular construction allows the large‑format instrument to be disassembled for transport and reassembled on site, simplifying logistics for customers who need a high‑capacity measuring solution without specialised freight arrangements. Manufacturer / Responsible: Microtech, Nizhneyurkovska str., 45a, 04080 Kyiv, Ukraine, tool@microtech.tools
500mm Micrometer With 35mm Anvil Plate, Touchscreen Digital Readout, Wireless/USB, ISO 17025 Calibrated - Microtech Metrology
Benefit from high repeatability, ISO 17025 calibration and seamless data transfer via Wireless+USB for reliable inspection results; order the micrometer directly via Metav Werkzeuge or consult our advisors for specification support. Digital Micrometer — 475–500 mm range, 1.54" touchscreen & Wireless+USB (Microtech Metrology) A Digital Micrometer designed for precise thickness and depth checks on medium‑sized components in workshop and inspection environments. ISO 17025 calibrated with certificate Wireless and USB data output 475–500 mm measuring range 1.54" touchscreen display 35 mm plate measuring faces Precise measurement where reach and stiffness meet The large‑format measuring range of 475–500 mm places this instrument in the medium category for workshop metrology, offering a pragmatic balance between reach and rigidity. With a stated accuracy of 0.01 mm, the device suits routine quality control and assembly checks where reproducible results are required across larger fixtures or housings. The broad measuring span reduces the need for multiple instruments, streamlining inspection setups and saving handling time; when measuring larger parts, consistent stiffness and a clear readout deliver dependable decisions at production pace. Fast digital capture and documented traceability Data capture is simplified by the combination of Wireless+USB connectivity and a 1.54" touchscreen, enabling direct transfer of readings into inspection software or spreadsheets and eliminating transcription errors that slow workflow. Supplied fully calibrated to ISO 17025 with a calibration certificate, the instrument supports audit trails and regulatory compliance. This combination of traceable calibration and digital output increases confidence in batch acceptance and provides clear evidence for quality records, helping to shorten approval cycles and reduce rework. Stable contact design for repeatable results The measuring faces are large Teller Ø35 mm plates and the spindle is designed as a non‑rotating spindle, which together give uniform contact and reduce surface wear during measuring. Such features help to maintain consistent measuring force and contact geometry, so readings remain repeatable even on uneven or coated surfaces. The result is a robust measuring routine: fewer adjustments, reduced scrap risk and more predictable inspection throughput for machine shops and toolrooms that demand reliability from each check. Built for integration into inspection routines Beyond individual readings, the instrument functions as a practical element of modern shopfloor metrology. The digital interface and data ports enable connection to data loggers and quality-management systems, while the compact touchscreen provides intuitive operation for operators and inspectors alike. The solid construction and straightforward control scheme mean short training times and immediate value in production monitoring; paired with Metav’s application support, the device becomes part of a controlled measurement chain that improves process capability and reduces uncertainty. Discuss the Microtech Metrology ISO 17025‑calibrated digital micrometer with Metav Werkzeuge — contact info@metav-werkzeuge.com or call +49 2822 7131930 for tailored advice and delivery options Technical data Article number: 110785007 GTIN: 4061905457630 Manufacturer: Microtech Metrology Core technical data Measuring range: 475–500 mm Resolution / accuracy: 0.01 mm Display: 1.54" touchscreen Measuring face diameter: Ø35 mm Special features Digital micrometer with touchscreen Wireless+USB data output Non‑rotating spindle Delivered calibrated to ISO 17025 with certificate Suitable for medium‑range component inspection FAQ What measuring range does this micrometer cover? The instrument covers a measuring span of 475–500 mm, suitable for medium‑sized components and fixtures. Is the micrometer delivered calibrated? Yes, this Microtech Metrology digital micrometer is supplied fully calibrated to ISO 17025 and includes a calibration certificate. How are readings transferred to inspection software? Readings can be exported via Wireless+USB connections for direct integration into quality systems and spreadsheets. Manufacturer / Responsible: Microtech, Nizhneyurkovska str., 45a, 04080 Kyiv, Ukraine, tool@microtech.tools
500–600mm Digital Bore Micrometer With Carbide Measuring Faces, Ratchet Stop, Plastic Case - Metav IndustryLine
Take advantage of a robust workshop instrument that combines a wide 500–600 mm measuring band, high-resolution digital readout and carbide measuring faces for long-term wear resistance; the result is fast, repeatable external measurements and seamless data transfer. Order the micrometer directly via Metav Werkzeuge or consult our technical advisors for application-specific guidance. M302.028.C — Digital outside micrometer 500–600 mm with carbide measuring faces (Metav IndustryLine) The M302.028.C is a high-range digital outside micrometer engineered for accurate external measurements of sizeable components in production and workshop environments. Digital display with ABS/INC and UNIT keys Carbide measuring faces for extended wear resistance Integrated ratchet stop for consistent contact force Measuring range 500–600 mm with fine spindle pitch Accurate measurement for large external dimensions The instrument delivers dependable results across a broad measuring span, combining a digital display with a fine 0.5 mm spindle pitch to support controlled, gradual adjustments. The readout resolution of 0.001 mm provides micron-level increments, while the specified accuracy of ±0.015 mm reflects a realistic repeatability expectation for workshop instruments in this size class. This balance of resolution and accuracy makes the micrometer suitable for routine quality checks on large shafts, housings and assemblies where clear numeric readouts reduce interpretation errors and speed up inspection cycles. Streamlined data capture and process integration Equipped with RB 4.1 data output and a user-friendly control array (ON/OFF/SET, ABS/INC and UNIT), the device supports straightforward transfer of measurement results into digital quality workflows. The measurement capture features enable faster logging and minimise transcription mistakes during batch inspections, contributing to improved traceability and simplified reporting. Incorporating digital transfer into existing SPC or data-logging setups reduces manual rework and helps maintain consistent production tolerances. Durable mechanics and ergonomic handling for daily use Wear-prone contact areas are protected by carbide measuring faces, extending service life under frequent use. The matt chrome-plated measuring drum offers a tactile, low-glare grip surface for fine adjustments, while the ratchet stop ensures consistent contact force and reduces operator-induced variance. Built for workshop conditions, the construction supports robust everyday handling without sacrificing measurement fidelity; routine maintenance is limited to periodic cleaning and spindle lubrication to keep accuracy stable over time. For reliable external measurements across the 500–600 mm range with stable data output, choose the Metav IndustryLine M302.028.C — contact Metav Werkzeuge in Emmerich for detailed technical advice or to request a quotation via info@metav-werkzeuge.com Technical data Article number: M302.028.C GTIN: 4054469163017 Category: Messschrauben (outside micrometer) Brand: Metav IndustryLine Facts Measuring range: 500–600 mm Resolution (display): 0.001 mm Specified accuracy: ±0.015 mm Spindle pitch: 0.5 mm per revolution Spindle diameter: 8 mm Tariff number: 90173000 Standard: Werksnorm Special features Carbide measuring faces (HM) Digital display with ON/OFF/SET, ABS/INC and UNIT keys Data output: RB 4.1 Integrated ratchet stop for consistent measuring force Matt chrome-plated measuring drum FAQ What measurement range does this micrometer cover? The M302.028.C covers an external measuring band from 500 to 600 mm, making it suitable for larger shafts and housings where precise external dimensions are required. What resolution and accuracy can be expected from this instrument? This digital micrometer offers a display resolution of 0.001 mm and a specified accuracy of ±0.015 mm, providing micron-scale readability with realistic workshop-level repeatability. How are results transferred to a PC or data-logging system? Data export is provided via the RB 4.1 interface; the M302.028.C can feed captured measurements into compatible SPC or logging systems for traceable records. Are the measuring faces wear-resistant for production use? Yes—the measuring faces are made of carbide (HM), which increases wear resistance and prolongs the service life under frequent measurement cycles. Does the instrument include features to reduce operator-induced variation? The built-in ratchet stop ensures a repeatable contact force for each measurement, while the fine spindle pitch allows controlled approach to the workpiece, reducing variability between operators. Manufacturer / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; Germany; +49 2822 7131930; info@metav-werkzeuge.com
50mm Bore Gauge Micrometer With Microcomputer Wireless/USB Output ISO 17025 Calibrated - Microtech Metrology
Benefit from traceable calibration and integrated data transfer: ISO 17025 calibration certificate plus reliable 0.003 mm accuracy ensure measurements are ready for quality documentation and process control. The compact digital design with Wireless and USB outputs speeds up data capture and reduces transcription errors. Order the micrometer with microcomputer directly via Metav Werkzeuge or ask our consultants if needed. Micrometer with microcomputer — digital outside micrometer, Wireless + USB (Microtech Metrology) The micrometer with microcomputer is a compact digital outside micrometer designed for precision workshop and laboratory measurement up to 50 mm, combining certified calibration and modern data transfer for streamlined quality workflows. Digital display, 0.0001 mm resolution Delivered with ISO 17025 calibration certificate Wireless and USB data output Measuring range 0–50 mm, Ø8 mm anvils Traceable accuracy for production and inspection The enclosed calibration certificate (issued to ISO 17025 standards) confirms that measurement results meet laboratory-grade traceability and can be used directly for quality records. The instrument’s stated 0.003 mm accuracy is suitable for demanding inspection tasks and provides a verifiable tolerance basis for pass/fail decisions. The combination of a high-resolution display (0.0001 mm) and a robust error specification supports reproducible checks in incoming inspection, in-process control and final inspection routines, reducing the need for repeat measurements and thereby improving throughput. Seamless data capture and process integration Equipped with both Wireless and USB data outputs, the device transfers readings directly into inspection software or spreadsheet workflows, eliminating manual entry and the associated error risk. The digital readout and integrated microcomputer enable straightforward interfacing with standard data loggers and SPC systems; this facilitates automated documentation and archive creation. Connectivity options support modern shop-floor layouts where remote collection and centralised data handling accelerate decision-making and corrective-action loops. Compact form factor for fine engineering With a measuring range of 0–50 mm, the instrument falls into the compact micrometer class suitable for precision tasks in toolmaking, small-part assembly and microengineering. The Ø8 mm measuring faces and measuring depth 18 mm are designed to offer stable contact geometry on small diameters and thin-walled components, while keeping the frame short for minimal flex. The compact footprint simplifies handling in tight fixtures or bench-top jigs and supports repeatable clamping for series checks. Built for repeatability and workshop reliability The digital micrometre’s solid measurement concept, combined with microcomputer control, prioritises consistent results and operator efficiency. The ready-to-use delivery, including the calibration certificate, removes setup ambiguity and accelerates integration into quality procedures. Robust data output and a clear, fast display reduce measurement cycle time and help maintain traceability; this makes the instrument a practical choice for inspection labs, maintenance departments and precision workshops looking to modernise measurement routines with minimal disruption. For a certified measurement solution from Microtech Metrology and expert procurement support, contact Metav Werkzeuge: phone +49 2822 7131930 or e-mail info@metav-werkzeuge.com — Metav consultants will advise on integration and delivery options Technical data Article number: 115050507 GTIN: 4061905041129 Manufacturer: Microtech Metrology Facts Measuring range: 0–50 mm Accuracy: 0.003 mm Display resolution: 0.0001 mm Measuring faces: Ø8 mm Measuring depth: 18 mm Special features Digital readout with integrated microcomputer Wireless + USB data output Delivered with ISO 17025 calibration certificate eClass: 21170328 ETIM: EC003590 FAQ Is the device supplied calibrated and with a certificate? Yes. The micrometer from Microtech Metrology is delivered fully calibrated and includes an ISO 17025 calibration certificate suitable for laboratory documentation. What data interfaces are available for integration? Readings can be exported via Wireless or USB; the digital output supports connection to standard inspection software and data loggers for automated documentation. What measurement range and contact geometry does it offer? Measurement is 0–50 mm with Ø8 mm measuring faces and a measuring depth of 18 mm, making it suitable for small to medium precision components. Can this instrument be used for in‑process checks on production lines? Yes. The combination of 0.003 mm accuracy, high display resolution and wireless/USB output makes it appropriate for regular in‑process verification and serial inspection tasks. Which industries are best served by this instrument? Applications include toolmaking, precision engineering, laboratory inspection and quality control where compact, traceable measurements up to 50 mm are required. Manufacturer / Responsible: Microtech, Nizhneyurkovska str., 45a, 04080 Kyiv, Ukraine, tool@microtech.tools
50mm Gauge Block Thread Setting 55° For Whitworth Or Metric Inserts 0.02kg - Metav IndustryLine
Take advantage of a compact 50 mm reference that delivers reproducible thread checks and simplifies set-up for thread micrometers; choose the 55° profile for Whitworth applications or the 60° option for standard inserts. Order the setting gauge directly via Metav Werkzeuge or consult the specialists for application advice. Setting gauge 50 mm — 55° thread micrometer accessory (Metav IndustryLine) The Setting gauge 50 mm is a compact reference standard designed to reproduce thread profiles for thread micrometers, suitable for Whitworth (55°) and ISO-style (60°) thread inserts in workshop and inspection environments. 55° profile for Whitworth thread inserts 50 mm gauge length, compact and stable Precision reference for thread micrometers Workshop accessory for thread verification Ensure reproducible thread checks with a compact reference A compact 50 mm reference block provides a stable datum for setting and checking thread-measuring inserts. By using a fixed profile rather than a temporary workpiece, set-up variation is reduced and the thread micrometer can be aligned more quickly and consistently. This benefit translates into shorter set-up times at the bench and fewer scrap parts during initial trials, supporting efficient small-batch and series production. Accurate profile geometry for reliable measurements The profile geometry is available as 55° for Whitworth-type inserts or as a 60° option for common metric profiles. This tailored geometry ensures that the measuring insert contacts the gauge in the same manner as the actual thread form, producing a precision reference that helps avoid systematic measurement offsets. The result is greater confidence in inspection reports and improved process control in the workshop. Practical design that fits routine metrology workflows With a compact footprint and robust form, the gauge integrates easily into ordinary inspection routines. The modest size supports rapid handling and keeps the measuring faces free from accidental deformation during use. As an accessory for dedicated thread micrometers, the gauge supports quick verification cycles and reduces downtime between measurements, contributing to a smoother production flow. Suitable applications and typical use cases Ideal for toolrooms, QC benches and maintenance departments, this gauge is intended for verifying thread-measuring inserts, setting micrometer anvils and performing quick functional checks before measuring critical components. The accessory is particularly useful where repeatability is required across multiple operators, as the fixed profile reduces the influence of individual handling on the measurement outcome. For a reliable workshop standard, request the Metav IndustryLine setting gauge via Metav Werkzeuge in Emmerich or consult our specialists by email at info@metav-werkzeuge.com or by phone on +49 2822 7131930 Technical data SKU: M309.091.1 GTIN: 4054469118116 eClass: 21170102 Customs tariff number: 90173000 Facts Gauge length: 50 mm Profile angle: 55° Category: Accessory (Zubehör) Story trigger: Zubehör Special features 55° for Whitworth thread inserts or 60° for standard thread inserts Suitable as reference for thread micrometers Compact design for workshop and inspection use FAQ What is the primary purpose of this setting gauge? The setting gauge serves as a precision reference for aligning and checking thread-micrometer inserts; it reproduces the required profile so the instrument can be set up reproducibly. Which profile does the gauge provide? The delivered version features a 55° profile suitable for Whitworth-type inserts; a 60° option is available for standard metric-style thread inserts. Can this gauge be used for routine verification on the shop floor? Yes—its compact form and stable profile make it suitable for regular verification and quick functional checks on the shop floor with thread micrometers. Is the gauge compatible with all thread micrometer brands? The gauge is intended as a profile reference for inserts and is compatible wherever the insert geometry matches 55° (Whitworth) or 60° profiles; integration depends on matching insert form rather than micrometer brand. Manufacturer / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; Germany; +49 2822 7131930; info@metav-werkzeuge.com
50mm Micrometer Caliper, Antimagnetic, Hardened Measuring Faces, Friction Ratchet, Case - Metav IndustryLine
Take advantage of accurate, repeatable external measurements thanks to hardened measuring faces and a friction ratchet that prevents over‑torque. The anti‑magnetic construction and matt chrome‑plated thimble ensure dependable performance in metalworking environments. Order the micrometer directly via Metav Werkzeuge or ask our consultants if needed. Micrometer M304.709 — analog micrometer with friction ratchet and anti‑magnetic design (25–50 mm) A Micrometer M304.709 for precise external diameter measurements in mechanical engineering and fine workshop applications. Anti‑magnetic body for interference‑free measuring Hardened special steel measuring faces for durability Friction ratchet for consistent measuring pressure Matt chrome‑plated thimble for clear reading and wear resistance Precision and repeatability for production work The micrometer combines a fine reading of 0.01 mm with a spindle pitch of 0.5 mm, which yields reliable graduations on the thimble and enables fast, exact readings on the analogue scale. The hardened measuring faces in special steel preserve true contact geometry over many cycles, reducing wear‑induced error and keeping measurements within the repeatability demanded in production. Compliance with DIN 863 underlines suitability for workshop quality control, where reproducible external measurements are essential for assembly and inspection tasks. Consistent handling and long‑term robustness Built for repeated use on the shop floor, the instrument’s friction ratchet delivers a constant contact force to avoid measurement scatter caused by varying operator torque. The matt chrome‑plated measuring drum resists glare and surface wear, allowing clear observation of the scale during routine checks. The anti‑magnetic attribute protects the measuring process from magnetic interference in environments with electric motors or magnetic materials, while the compact, balanced form factor supports steady one‑hand operation and reliable ergonomics during serial measuring. Workshop advantage and Metav reliability As part of the Metav IndustryLine, this measuring screw is engineered for practical workshop integration: low maintenance, durable materials and a handling concept that reduces operator‑related variability. The combination of hardened faces, anti‑magnetic construction and a tactile friction mechanism makes it a sensible choice where reliable external measurement and operational consistency outweigh cosmetic features. Metav’s long experience in metrology and a broad product range provide a dependable supply chain and technical competence for industrial customers. For traceable workshop precision, select the Metav IndustryLine micrometer M304.709 and contact Metav Werkzeuge in Emmerich for individual advice and rapid delivery: info@metav-werkzeuge.com | +49 2822 7131930 Technical Data SKU: M304.709 GTIN: 4054469167039 Tariff number: 90173000 Facts Measuring range: 25–50 mm Resolution / reading: 0.01 mm Spindle pitch: 0.5 mm Measuring spindle diameter: 6.5 mm Weight: 0.3 kg Standard: DIN 863 Special features Anti‑magnetic Hardened special steel measuring faces Friction ratchet for uniform measuring force Matt chrome‑plated measuring drum Analogue thimble reading FAQ What measuring range does this micrometer cover? The micrometer covers the 25–50 mm measuring range and is supplied as the analogue workshop instrument M304.709. How fine is the reading on the scale? The instrument provides a 0.01 mm reading on the thimble, offering the resolution commonly required for standard workshop inspections. Does the friction ratchet improve measurement consistency? Yes, the friction ratchet ensures a uniform contact force, reducing operator‑induced variation and improving repeatability for serial measurements. Are the measuring faces wear‑resistant? The measuring faces are made of hardened special steel, which maintains contact geometry and resists wear under frequent use. Manufacturer / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; Germany; +49 2822 7131930; info@metav-werkzeuge.com
50mm Setting Gauge Whitworth 55 Thread Standard - Microtech Metrology
Built for dependable Whitworth thread set-up, the compact 50 mm gauge pairs accurate 55° thread geometry with workshop-ready robustness for consistent results. Order the setting gauge directly via Metav Werkzeuge or consult our advisors for specification support. Thread setting gauge — 50 mm Whitworth 55° by Microtech Metrology A compact, workshop-ready thread setting gauge with Whitworth 55° geometry for rapid, repeatable thread set-up and inspection. 50 mm compact setting gauge Whitworth 55° thread geometry For thread set-up and inspection Microtech Metrology SKU 110720005 Reduce set-up time with repeatable geometry The compact tool is engineered to provide a consistent reference for thread preparation and verification. Using a precisely formed Whitworth 55° profile, the gauge removes guesswork during machine set-up and hand-fitting operations, enabling faster cycle starts and fewer trial cuts. As a workshop accessory it supports predictable results, which translates into reduced rework and improved production throughput. The 50 mm length keeps handling simple without compromising the defined thread profile. Compact shape that suits tight fixtures and benches Designed for constrained spaces, the 50 mm form factor makes the gauge easy to position in vises, chucks or bespoke fixtures. The small footprint helps when working on subassemblies or when access is limited, while retaining the full thread geometry required for reliable alignment. This compactness also aids storage and transport between workstations, making the instrument a practical reference for both maintenance and series production environments. Built for practical inspection and workshop use Delivered as a straightforward accessory, the unit complements thread-cutting and inspection workflows by providing a fixed reference rather than a variable measurement. Traceable identification via SKU and GTIN supports inventory and quality records, while the association with Microtech Metrology signals a focus on metrology-grade manufacturing. The gauge is intended to integrate into existing setup routines, helping technicians achieve consistent thread form without additional calibration steps specified in the product data. For reliable Whitworth thread set-ups and to discuss compatibility with existing tooling, contact Metav Werkzeuge in Emmerich or request advice from our technical consultants at info@metav-werkzeuge.com Technical Data Article number: 110720005 GTIN: 4061905459313 Brand: Microtech Metrology Core data Length: 50 mm Thread angle: 55° Special features Whitworth 55° thread geometry Category: Zubehör Image available: 110710005-main.png FAQ What is the primary purpose of this gauge? The thread setting gauge is a dedicated reference for establishing and checking Whitworth 55° thread form during machine set-up and inspection, ensuring consistent thread geometry. Which thread standard does it match? This item reproduces the Whitworth 55° profile; it is suited to applications that require that specific thread angle and form and is listed under Microtech Metrology SKU 110720005. Can the gauge be used in confined spaces? Yes, the 50 mm length is intentionally compact to facilitate positioning in tight fixtures, chucks and on small workpieces while maintaining the full thread profile. Is additional calibration required before use? The product is supplied as a reference accessory; customers should follow internal quality procedures to determine whether a supplementary calibration certificate is required for their traceability records. Manufacturer / Responsible: Microtech, Nizhneyurkovska str., 45a, 04080 Kyiv, Ukraine, tool@microtech.tools
50mm Thread Gauge Setting Tool 60° For Thread Micrometer, 0.02kg - Metav IndustryLine
Take advantage of a compact, workshop-ready reference that ensures consistent thread micrometer settings and clear compatibility with both 60° and Whitworth geometries; order directly via Metav Werkzeuge or ask the consultants for application advice. Setting gauge 50 mm for thread micrometer – Metav IndustryLine accessory (60° geometry) A Setting gauge 50 mm for thread micrometer serves as a precise reference standard for setting and verifying thread micrometers and thread inserts in a production or inspection environment, suitable where repeatable adjustment and clear angle compatibility are required. 50 mm reference for thread micrometers 60° geometry; 55° option for Whitworth Compact and lightweight at 0.1 kg Accurate reference that reduces set-up error A calibrated reference dimension is the most effective way to limit operator-induced variation during micrometer setup. The 50 mm datum on this accessory provides a measurable, repeatable standard that simplifies comparison readings and shortens adjustment cycles. With a defined 60° flank angle (or 55° for Whitworth-type inserts), the gauge matches common thread form geometries so that adjustments on thread micrometers are directly comparable to the intended thread profile. This measurable approach translates into fewer reworks and a more consistent first-pass yield. Designed for practical workshop use Small, robust and easy to handle, the gauge’s compact footprint and 0.1 kg mass make it convenient to store alongside hand tools and measuring equipment without adding significant handling time. The accessory format supports quick insertion into routine checks and set-up sequences, enabling faster throughput on production lines and in inspection bays. Clear geometry marking reduces interpretation time and supports operators with varying experience levels, creating operational efficiency without relying on additional consumables. Traceable identification and integration into existing workflows The setting gauge is identifiable by SKU M309.097.1 and GTIN 4054469118246, facilitating inventory control and traceability in quality documentation. As a specialist accessory for thread micrometers, it dovetails with standard inspection routines and works alongside existing measurement equipment to establish a reproducible baseline. Metav IndustryLine’s supply chain in Emmerich acts as a quality filter for the European market, offering the reliability and product range that support workshop consolidation and long-term availability. Contact Metav Werkzeuge GmbH in Emmerich to confirm the correct angle variant (60° or 55° Whitworth) and to secure the M309.097.1 setting gauge for immediate integration into inspection and set-up procedures; phone +49 2822 7131930 or email info@metav-werkzeuge.com Technical data Article number: M309.097.1 GTIN: 4054469118246 Label: Einstellmaß 50 mm für Gew.-Mikro, 60° 0,02 kg Weight: 0.1 kg Setting dimension: 50 mm Angle: 60° Facts Customs tariff number: 90173000 SKU: M309.097.1 Mass value: 50 Special features 60° for thread inserts or 55° for Whitworth thread inserts Accessory for thread micrometers Category path: Messgeräte > Zubehör FAQ What is the primary use of this setting gauge? The setting gauge M309.097.1 is used as a precise reference to set and verify thread micrometers, ensuring correct alignment with the intended thread flank geometry. Does the gauge support Whitworth thread forms? Yes, the item is available with a 55° variant for Whitworth thread inserts; the standard version is 60° for common thread inserts. What are the physical dimensions and weight of the gauge? The gauge provides a 50 mm reference dimension and weighs 0.1 kg, designed for compact workshop handling. Is the gauge suitable for routine inspection workflows? The accessory is intended for integration into standard set-up and inspection procedures, offering a repeatable baseline for micrometer adjustments and traceability. How is the product identified for inventory and traceability? Identification is via SKU M309.097.1 and GTIN 4054469118246, which supports documentation and inventory control. Metav IndustryLine: Manufacturer / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; Germany; +49 2822 7131930; info@metav-werkzeuge.com
50–75 mm Dial Thickness Gauge Ø60 mm Anvil, Painted Frame, Matt Chrome Measuring Drum, Factory Standard, Supplied in Case - Metav IndustryLine
Take advantage of the combination of fine resolution and large disc measuring faces for reliable measurement of delicate or irregular components. The precisely graduated 0.01 mm steps and robust, painted frame ensure repeatable readings across workshop routines. Order the micrometre directly via Metav Werkzeuge or ask the consultants for tailored advice. Disc‑face micrometre M309.152 – 50–75 mm, Ø 60 mm discs (Metav IndustryLine) The Disc‑face micrometre M309.152 is an analogue micrometre designed for precise external measurements of delicate and irregular parts in fine mechanical and watchmaking environments. Measuring range 50–75 mm Ø 60 mm disc measuring faces Resolution 0.01 mm Supplied in a transport case Precision tailored for fine mechanical work The disc‑face design with Ø 60 mm measuring faces distributes contact pressure over a larger area, reducing local deformation on thin or uneven components and improving repeatability. The analogue spindle provides a tactile feel for setting and a clear 0.01 mm graduation, which suits fine mechanical tasks where visual control and steady throughput matter. This combination supports consistent quality control in assembly and repair operations. Durable build for repeatable results A painted frame gives surface protection against workshop wear, while the matt‑chrome thimble improves scale legibility under varied lighting. The tool weighs 1.4 kg, lending it stable handling during measurement without being cumbersome to operate at a bench. Manufactured to Werksnorm, the instrument delivers practical robustness for daily use and easy integration into existing inspection routines. Practical handling and workshop integration Classified in the micro range for micrometres (max. 100 mm), this instrument is suited to precision tasks in watchmaking, small‑parts machining and detailed quality checks. The large discs simplify alignment on irregular geometries and the analogue format avoids battery dependence while remaining straightforward to read and maintain. For further technical data or to confirm fit with a specific application, Metav Werkzeuge provides direct specialist advice. Contact Metav Werkzeuge for tailored procurement and to discuss how the Metav IndustryLine disc‑face micrometre M309.152 fits specific inspection workflows Technical data Article number: M309.152 GTIN: 4054469118444 Category: Micrometres (Messschrauben) Core measurements Measuring range: 50–75 mm Anvil diameter: Ø 60 mm Resolution/accuracy: 0.01 mm Weight: 1.4 kg Tariff number: 90173000 Materials & features Frame: painted Measuring thimble: matt‑chrome Supply: transport case included Standard: Werksnorm Type: analogue micrometre FAQ What measuring range does this micrometre cover? The disc‑face micrometre M309.152 covers a measuring range of 50–75 mm, suitable for small to mid‑sized components. What accuracy and resolution can be expected? The instrument provides a resolution and stated accuracy of 0.01 mm, which is appropriate for fine mechanical measurement tasks. Is the micrometre suitable for delicate or irregular surfaces? Yes — the Ø 60 mm disc measuring faces are designed to spread contact pressure and improve measurement reliability on uneven or thin parts. Does the delivery include a protective case? The micrometre is supplied in a transport case to protect the instrument during storage and transit. To which standard is the instrument manufactured? The micrometre is produced to Werksnorm, indicating workshop standard manufacturing and testing procedures. Metav IndustryLine: Manufacturer / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; Germany; +49 2822 7131930; info@metav-werkzeuge.com
50–75 mm Digital Micrometer 0.001 mm Resolution With Ratchet, DIN 863, Plastic Case - Metav IndustryLine
Take advantage of a finely tuned combination of digital accuracy and ergonomic handling: the instrument delivers a 0.001 mm readout across a 50–75 mm span and uses a ratchet thimble for reproducible contact pressure. Order the micrometer directly via Metav Werkzeuge or contact our consultants for specification support. Digital Micrometer M302.292 — 50–75 mm, 0.001 mm resolution (Metav IndustryLine) A Digital Micrometer M302.292 designed for precise external measurements in workshop and quality‑control environments, offering a compact measuring range with high-resolution digital readout. Precision 0.001 mm digital resolution Measuring range 50–75 mm Ratchet thimble for repeatable contact Hardened measuring faces for long life Reliable measurements that speed up inspection High-resolution metrology in a compact format reduces rework and inspection time. The instrument combines a 0.001 mm display resolution with a stiff body and a ratchet thimble to ensure constant measuring force; this combination translates directly into repeatable, traceable readings for serial parts and small-batch production. Compliance with DIN 863 underlines suitability for workshop quality control, while the modest measuring span of 50–75 mm keeps the tool easy to handle and quick to align on shafts, journals and small housings. User-friendly digital functions for efficient data capture The display unit is operated via a four-button panel with ON/zero, mm/inch, ABS and HOLD functions, providing straightforward toggling between working modes and fast freezing of values for recording. An RB 4 data output is provided for external readout or integration into data-collection routines, reducing transcription errors and supporting process documentation. Clear, tactile controls and a crisp digital readout make the instrument well suited to repetitive checks in both production and inspection benches. Robust contact surfaces and workshop-ready construction Measuring faces are hardened to resist wear and to preserve accuracy over prolonged use; the ratchet mechanism prevents over‑tightening and protects delicate parts. The instrument is classified among compact, high‑precision micrometers intended for fine mechanical work, where a short measuring spindle and low moment of inertia help maintain measurement stability. Built for routine industrial use, the tool pairs practical durability with the convenience of digital evaluation for faster decision making on the shop floor. For precise external measurement in tight production workflows, contact Metav Werkzeuge to discuss the Metav IndustryLine Digital Micrometer M302.292, request a technical datasheet or arrange purchase advice at info@metav-werkzeuge.com or by phone on +49 2822 7131930 Technical Data Article number: M302.292 GTIN: 4054469146447 Category: Micrometers (Messschrauben) Standard: DIN 863 eClass: 21170328 ETIM: EC003590 Tariff number: 90173000 Core specifications Measuring range: 50–75 mm Resolution: 0.001 mm Display functions: ON/zero, mm/inch, ABS, HOLD Data output: RB 4 Measuring face diameter: 6.5 mm Ratchet: yes Digital: yes Features and materials Hardened measuring faces Compact construction for fine mechanical work Four-button operation for quick mode changes Suitable for workshop and quality control environments FAQ What is the resolution of the micrometer? The micrometer provides a resolution of 0.001 mm, enabling fine differentiation for precision external measurements with the Metav IndustryLine Digital Micrometer M302.292. Which measuring range is covered by this instrument? The instrument covers a measuring range of 50–75 mm, making it suitable for small to medium external features commonly inspected in workshops. Does the micrometer offer data output for traceability? Yes, the micrometer includes an RB 4 data output for external readout and integration into data collection systems, simplifying documentation and SPC routines. Are the measuring faces wear-resistant? The measuring faces are hardened to improve wear resistance and maintain measurement accuracy during repeated use with the Metav IndustryLine micrometer. Is the instrument compliant with recognised standards? The tool is manufactured to meet DIN 863, supporting its use in standard workshop and inspection applications. Manufacturer / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; Germany; +49 2822 7131930; info@metav-werkzeuge.com
50–75 mm Digital Micrometer 0.001 mm Resolution, IP65, Ratchet, Four-Button Display, Plastic Case - Metav IndustryLine
Combine 0.001 mm resolution with an IP65 rating and a ratchet thimble for repeatable measuring force to secure dependable dimensional control in fine‑component work. Benefit from the compact measuring range and robust data output for streamlined quality checks. Order directly via Metav Werkzeuge or consult the Metav team for application advice. Digital Micrometer M302.296 – 50–75 mm, 0.001 mm resolution, IP65 The Digital Micrometer M302.296 is a compact, workshop‑grade outside micrometer designed for precision measurement of small to medium components, ideal for tasks that demand sub‑micron indication and protected operation. Digital micrometer, 0.001 mm resolution IP65 dust and splash protection Ratchet thimble for repeatable force 4-function display with mm/inch selection Precise control for fine components and fixtures This micrometer delivers a 0.001 mm readout within its 50–75 mm measuring span, placing it in the compact "micro" class for highly detailed work. The fine resolution supports precise adjustment and verification of shafts, spindles and small housings without overcomplicating the workflow. Compliance with DIN 863 ensures the instrument meets recognised tolerance and form standards, so measurement results are both traceable and comparable across inspections. The comparatively small anvil and spindle face diameter, specified as 6.5 mm, concentrates contact force and reduces measurement scatter on narrow features, improving repeatability in serial checks and assembly controls. Designed for dependable use in demanding environments Protection to IP65 safeguards internal electronics against dust ingress and low‑pressure water jets, which keeps the instrument operational in busy production or inspection bays. A ratchet thimble provides a consistent measuring force, removing variability caused by operator technique and helping to avoid overloading delicate parts. The solid construction and sealed electronics reduce downtime from contamination and permit confident use at the machine or alongside measuring fixtures. These reliability features translate into fewer retests, less scrap and a more consistent throughput during quality control procedures. Fast readout and data transfer for efficient workflows The large digital display offers four dedicated controls (ON/0, mm/inch, ABS, HOLD) for immediate unit switching and zeroing, enabling rapid changeovers between imperial and metric tasks without additional calculations. Data output via RB 4 supports integration with measurement data collectors or SPC systems, speeding documentation and reducing manual transcription errors. Together, the intuitive interface and available data output improve inspection cycle times and feed quality data directly into process control, supporting rational decisions and traceable records for audits. Contact Metav Werkzeuge for precise availability and tailored advice on using the M302.296 in your inspection process; Metav’s specialists in Emmerich can confirm stock and recommend the best calibration or data‑logging options Technical Data Article number: M302.296 GTIN: 4054469115634 Category: Messschrauben Standard: DIN 863 Facts Measuring range: 50–75 mm Resolution: 0.001 mm Measuring face diameter: 6.5 mm Protection class: IP65 Special features Ratchet thimble for constant measuring force Digital display with ON/0, mm/inch, ABS and HOLD Data output: RB 4 Digital operation (metric/imperial switching) FAQ What measuring range does this instrument cover? The micrometer covers a measuring range of 50–75 mm, making the M302.296 suitable for fine mechanical parts within that span. What resolution and repeatability can be expected? Resolution is 0.001 mm on the display; repeatability is supported by the ratchet thimble that ensures a consistent measuring force during repetitive checks. Is the micrometer suitable for use near production machinery? Yes. The IP65 rating on the M302.296 protects against dust and low‑pressure water jets, so it is suitable for use in many workshop and shop‑floor environments. Can measurement data be exported to a PC or SPC system? The unit is equipped with RB 4 data output, allowing connection to compatible data loggers or SPC interfaces for automated data capture. Are the measuring faces hardened for wear resistance? The instrument features hardened measuring faces with a 6.5 mm diameter that improve wear resistance and preserve measurement integrity over time. Manufacturer / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; Germany; +49 2822 7131930; info@metav-werkzeuge.com
50–75 mm Digital Micrometer With Friction Ratchet 0.001 mm Resolution Data Output RB6 DIN 863 - Metav IndustryLine
Take advantage of the combination of ultra‑fine resolution, a consistent friction ratchet and digital data transfer for dependable shopfloor measurements; the result is faster quality checks and fewer reworks. Order the micrometer directly via Metav Werkzeuge or consult the specialists for integration advice. Digital Micrometer M302.076 — 0.001 mm resolution, RB 6 data output (Metav IndustryLine) The Digital Micrometer M302.076 is a compact, high‑precision measuring instrument for dimensional quality control of small to medium components, designed for workshop and inspection tasks within the 50–75 mm range. Reading 0.001 mm resolution Friction ratchet for repeatable measuring force RB 6 data output for digital recording Measuring faces Ø 6.5 mm, hardened Accurate measurement through controlled contact force The micrometer offers a resolution of 0.001 mm, which enables fine incremental readings for demanding tolerance checks. The integrated friction ratchet ensures a consistent measuring force on every measurement, reducing operator‑induced variance and improving repeatability during serial checks. The large digital display (with ON/OFF/SET, DATA and mm/inch/0 keys) presents values clearly, while the instrument’s geometry and hardened measuring faces minimise wear and help maintain long‑term accuracy for routine inspection tasks. Digital output for traceability and process control Equipped with an RB 6 data interface, the instrument supports straightforward transfer of measurement values into recording systems and statistical process control workflows. This digital connectivity simplifies documentation, reduces transcription errors and accelerates data capture during batch sampling. The combination of precise display and electronic output makes the device suitable for integration into inspection routines where measurement traceability and digital logging are required. Built to industrial standards for dependable workshop use Conforming to DIN 863, the micrometer is built to withstand daily workshop use while delivering consistent performance across its 50–75 mm measuring range. The measuring faces, specified at 6.5 mm diameter, are robust against abrasive wear and maintain contact geometry for trustworthy results. With a compact form factor and balanced weight, the instrument is practical for one‑hand operation during repetitive inspection tasks, offering a reliable bridge between benchtop metrology and production control. For traceable, repeatable measurements, request the Metav IndustryLine Digital Micrometer via Metav Werkzeuge and consult our experts at info@metav-werkzeuge.com or +49 2822 7131930 for application recommendations. Technical data SKU: M302.076 GTIN: 4054469168814 Measuring range: 50–75 mm Resolution: 0.001 mm Display functions: ON/OFF/SET, DATA, mm/inch, zero Core specifications Readout increment: 0.001 mm Measuring faces diameter: 6.5 mm Weight: 1 kg Standard: DIN 863 Tariff number: 90173000 Features Digital display with ON/OFF/SET/DATA/mm/inch/0 keys Friction ratchet for repeatable measuring force Data output: RB 6 Category: Micrometers (Messschrauben) Digital instrument for workshop and inspection use FAQ What is the smallest increment the instrument can display? The Digital Micrometer M302.076 displays increments of 0.001 mm, allowing very fine resolution for precision checks. Does the micrometer provide electronic data output for SPC? Yes. The micrometer features an RB 6 data output suitable for digital recording and integration into process control systems. How does the friction ratchet affect measurements? The friction ratchet ensures a consistent measuring torque on each reading, improving repeatability and reducing operator variation with the Digital Micrometer M302.076. Which standard does the instrument comply with? The device is manufactured in accordance with DIN 863, meeting recognised mechanical metrology requirements. What is the diameter of the measuring faces? The measuring faces are Ø 6.5 mm, designed for stable contact and longevity in routine measuring tasks. Manufacturer / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; Germany; +49 2822 7131930; info@metav-werkzeuge.com
50–75 mm Thread Micrometer With 50 mm Setting Gauge 60° Calibration Certificate, In Case - Metav IndustryLine
Take advantage of precise thread inspection with a 0.01 mm graduation and a practical 50–75 mm measuring range; the integrated 50 mm 60° setting gauge simplifies setup and speeds quality checks. Order the instrument via Metav Werkzeuge or consult our specialists for application advice. Metav IndustryLine Thread Micrometer M309.093 — 50–75 mm with 60° Setting Gauge Metav IndustryLine Thread Micrometer M309.093 is a purpose-built instrument for accurate external thread measurement in production and inspection environments Precision 0.01 mm graduation Thread measurement range 50–75 mm Non-rotating 6.5 mm spindle Includes 50 mm 60° setting gauge Consistent thread verification for fewer rejects The thread micrometer delivers 0.01 mm resolution across a 50–75 mm range, providing the numerical control that modern production demands. A finer graduation means repeatable readings when assessing thread peak-to-peak dimensions or pitch diameters, reducing the need for corrective rework. By translating the mechanical graduation into reliable process control, the instrument supports faster decision-making on the shop floor and tighter quality gates in final inspection. Stable mechanics that preserve accuracy over time A non-rotating 6.5 mm spindle and a robust analogue screw mechanism ensure low wear on contact faces and stable measurement behaviour during routine use. The spindle design minimises marking and slippage, which helps maintain repeatable calibration intervals. At approximately 0.7 kg, the instrument balances portability and mass damping, making it comfortable for handheld checks while remaining steady enough for bench measurements in serial inspection. Practical accessories and workshop compatibility The micrometer is supplied with a 50 mm 60° setting gauge, enabling quick instrument setup and verification of the measuring faces before sampling a batch. This combination shortens setup time in inspection protocols and fits naturally into incoming goods checks, bench testing and production stop-and-go measurements. As part of the Metav IndustryLine, the device benefits from the supplier’s focus on accessible precision: straightforward tooling, clear specifications and a stock range that supports many workshops and small-scale manufacturers. For reliable thread measurement in production or inspection, choose the Metav IndustryLine Thread Micrometer M309.093 — contact Metav Werkzeuge for ordering and application guidance at info@metav-werkzeuge.com or by phone on +49 2822 7131930. Technical data Article number: M309.093 GTIN: 4054469118185 Label: Thread micrometer 50 - 75 mm incl. setting gauge 50 mm 60° Manufacturer: Metav IndustryLine Core data Measurement range: 50–75 mm Resolution / graduation: 0.01 mm Spindle diameter: 6.5 mm Weight: 0.7 kg Customs tariff number: 90173000 Special features Analog reading Non-rotating spindle Includes 50 mm 60° setting gauge Category: Thread micrometer (measuring screw) FAQ What measurement range does this micrometer cover? The Thread Micrometer M309.093 by Metav IndustryLine measures externally from 50–75 mm, suitable for medium-sized threaded parts. What resolution and precision can be expected? This instrument provides a 0.01 mm graduation; as an analogue micrometer this gives reliable shop-floor precision for thread inspections. Is a setting gauge included with the micrometer? Yes, the Metav IndustryLine thread micrometer is supplied with a 50 mm 60° setting gauge for quick verification and setup. Why is the non-rotating spindle important for thread measurement? The non-rotating 6.5 mm spindle reduces marking and improves repeatability when the measuring faces contact threaded profiles, supporting consistent comparisons across samples. Is this instrument suitable for production and incoming inspection? The M309.093 is designed for routine production and inspection tasks where clear graduations and robust mechanics speed decision-making and help enforce quality standards. Manufacturer / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; Germany; +49 2822 7131930; info@metav-werkzeuge.com
50–75mm Left-Hand Thimble Micrometer 0.01mm Resolution Ratchet, Matt Chrome Thimble, DIN 863 - Metav IndustryLine
Take advantage of precise mechanical measurement, robust handling and a left‑hand configuration that improves workflow where required; the combination of a 50–75 mm measuring range, 0.01 mm graduation and a ratchet stop supports consistent, repeatable external measurements — order the M304.530 directly via Metav Werkzeuge or consult our specialists for procurement advice. M304.530 — Metav IndustryLine outside micrometre, 50–75 mm, 0.01 mm The M304.530 is a left‑hand outside micrometre tailored for accurate external diameter measurement in workshop and production settings, offering a 50–75 mm range with fine 0.01 mm indication for routine quality control. Precise 0.01 mm graduation Left‑handed spindle arrangement Ratchet stop for consistent force Matt‑chrome thimble for low glare Repeatable precision for routine inspections The micrometre delivers mechanical reading with a standard 0.01 mm graduation, combining a fine spindle pitch 0.5 mm with a clearly marked thimble to make single‑operator measurements fast and reliable. The ratchet stop ensures a constant measuring force, reducing operator‑dependent variance and improving reproducibility for batch checks and incoming inspection tasks. Compliance with DIN 863 confirms suitability for general workshop calibre work where robust, verifiable results are required. Ergonomic handling and left‑hand configuration Designed as a left‑hand version, this outside micrometre relocates the thimble and lock so that handling and reading are more comfortable for left‑handed operators, improving workflow in mixed‑handed teams. The matt‑chrome finished thimble reduces reflections under shop lighting, and the ratchet mechanism provides tactile feedback at the end of travel, helping maintain consistent contact and protecting delicate surfaces from over‑pressure. Such features shorten inspection cycles while protecting components. Construction, measurement faces and delivery condition The instrument is built with hardened measuring faces for wear resistance and stable results across shifts; measuring faces are present and prepared for long service life. A robust spindle with a diameter of 6.5 mm and a 0.5 mm lead per revolution gives tactile control and fine linear translation for micro‑adjustments. Delivered in a transport case to protect the tool between uses, the instrument is ready for workshop deployment and safe storage during transport. For procurement or technical clarification regarding the Metav IndustryLine left‑hand outside micrometre (M304.530), contact Metav Werkzeuge in Emmerich for specification sheets or purchasing assistance — info@metav-werkzeuge.com | +49 2822 7131930 Technical Data Article number: M304.530 GTIN: 4054469117119 Customs tariff number: 90173000 Facts Measuring range: 50–75 mm Resolution: 0.01 mm Spindle pitch: 0.5 mm Measuring spindle diameter: 6.5 mm Standard: DIN 863 Analog reading Special features Ratchet stop for constant measuring force Matt‑chrome thimble Left‑hand version Hardened measuring faces Delivered in transport case Category: Micrometre (outside) FAQ What measuring range does this micrometre cover? The M304.530 covers a measuring range of 50–75 mm, suitable for small to medium external diameters in workshop and production environments. How fine is the graduation and what accuracy can be expected? The instrument has a 0.01 mm graduation; the combination of a 0.5 mm spindle pitch and ratchet stop enables consistent, repeatable readings aligned with DIN 863 practice. Is this instrument suitable for left‑handed operators? Yes, the M304.530 is a left‑hand version with a repositioned thimble and locking arrangement to suit left‑handed handling and reading comfort. How is the micrometre supplied for transport and storage? The product is supplied in a protective transport case to safeguard the micrometre during transit and when not in use. Metav IndustryLine: Manufacturer / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; Germany; +49 2822 7131930; info@metav-werkzeuge.com
50–75mm Universal Micrometer With Interchangeable Inserts, Friction Ratchet, 7 Inserts, Transport Case - Metav IndustryLine
Benefit from high reproducibility and a compact design: the combination of a 0.01 mm graduation and a friction ratchet ensures repeatable external measurements, while seven interchangeable inserts extend application versatility. Order directly via Metav Werkzeuge or consult our advisors for specification support. Universal Micrometer M309.082 — 50–75 mm, 7 interchangeable inserts (Metav IndustryLine) A Universal Micrometer M309.082 for precise external measurements of shafts, small components and inspection tasks in workshops and inspection labs. 50–75 mm measuring range 0.01 mm graduation for fine reading Seven interchangeable measuring inserts Friction ratchet for constant measuring force Precision where it counts for repeatable results The instrument delivers accurate external measurements across a 50–75 mm span, with a mechanical reading resolution of 0.01 mm that suits detailed workshop and inspection work. The friction ratchet stabilises contact force to reduce operator influence, improving reproducibility on turned shafts and precision parts. The spindle is non-rotating, which prevents twisting of the workpiece and simplifies alignment during measurement. Robust build and ergonomic handling for daily use A painted frame combined with a matt-chromed measuring drum provides corrosion resistance and low-reflection handling in production environments. The 6.5 mm measuring spindle balances stiffness and sensitivity to ensure steady contact and long-term wear resistance. The micrometer’s form and weight make it comfortable for frequent use while maintaining the stability required for precise readings. Versatile accessories and delivery suited to the workshop Supplied with seven pairs of special measuring inserts, the micrometer adapts to a range of shaft profiles and surface types without the need for additional tooling. A setting gauge is included for quick verification of zero and basic adjustment. The instrument is delivered in a sturdy transport case and conforms to factory standard quality (Werksnorm), supporting safe storage and simple handling between inspection points. For application advice or to confirm suitability for specific materials and tasks, contact Metav Werkzeuge to discuss the Metav IndustryLine micrometer and arrange prompt delivery from Emmerich. Technical data Article number: M309.082 GTIN: 4054469117812 Customs tariff number: 90173000 Facts Measuring range: 50–75 mm Resolution / graduation: 0.01 mm Accuracy: 0.01 mm Measuring spindle diameter: 6.5 mm Weight: 0.8 kg Display type: Analog Special features Friction ratchet Seven interchangeable measuring inserts included Non-rotating measuring spindle Painted frame and matt-chromed measuring drum Supplied in a transport case Factory standard: Werksnorm Includes setting gauge FAQ Is the micrometer suitable for measuring shafts and turned parts? Yes. The Universal Micrometer M309.082 is designed for external measurements on shafts and turned components; the non-rotating spindle and friction ratchet support secure contact and repeatable readings. What inserts are supplied and how do they expand capability? The micrometer is supplied with seven pairs of special measuring inserts that allow adaptation to varied profiles and surface geometries, extending the instrument’s application range without additional tooling. Does the instrument come with a case for transport? Yes. The micrometer is supplied in a transport case to protect the gauge during transfer and storage between inspection stations. How is measurement consistency ensured during repetitive checks? Consistency is achieved via the friction ratchet, which applies a controlled measuring force, together with the non-rotating spindle that reduces specimen disturbance during contact. Which quality standard applies to this micrometer? The instrument is supplied to factory standard (Werksnorm) and includes a setting gauge for fast verification; traceable laboratory calibration details are provided on request where applicable. Metav IndustryLine: Manufacturer / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; Germany; +49 2822 7131930; info@metav-werkzeuge.com
525mm Setting Gauge for Micrometers With Thermal Shielding, Ball-Ended Measuring Faces Accuracy ±0.006mm - Metav IndustryLine
Take advantage of the combination of high repeatability, robust thermal protection and a long 525 mm nominal length for reliable micrometer setting in production and service routines; the precise ±0.006 mm tolerance supports fine adjustment tasks with industrial consistency. Order the setting gauge directly via Metav Werkzeuge or ask our consultants if needed. Setting Gauge for Micrometers M304.320.6 — 525 mm, ±0.006 mm accuracy The Setting Gauge for Micrometers M304.320.6 is a precision reference rod designed for the calibration and adjustment of outside micrometers in workshop and laboratory environments 525 mm nominal length for extended reach Accuracy ±0.006 mm for high-precision setting Thermal protection reduces heat transfer errors Ball-ended measuring faces for repeatable contact Precision where measurement stability reduces rework The gauge provides ±0.006 mm accuracy (equivalent to 6 µm), a level of precision that removes guesswork when setting or checking outside micrometers. This resolution translates into measurable improvements in process control: a stable reference at this tolerance allows repeat adjustments to be made with confidence and reduces the need for corrective machining. The long nominal span of 525 mm supports applications beyond small parts, enabling checks on longer components or assemblies while maintaining a compact handling profile. The specified tolerance is expressed in absolute terms so that decision-making for quality control can be based on objective criteria rather than operator feel. Stable results in workshop conditions through thermal and contact design The instrument incorporates thermal protection, which limits heat transfer from hands and the environment and so reduces systematic measurement drift during repeated use. Combined with ball-ended measuring faces, this design ensures a single, well-defined contact point that reduces variability caused by slight angular misalignment. The listed mass of 0.8 kg provides enough inertia for steady placement while keeping the gauge easily manoeuvrable for one-person operation. Together, these elements support reproducible setups and faster throughput in routine inspection or during tool calibration cycles, emphasising reliable results under normal shop-floor conditions. Efficient calibration workflow and practical compatibility Designed as an accessory for setting outside micrometers, the reference rod streamlines the calibration workflow and simplifies the transfer of a length standard into hand-held instruments and comparators. The combination of length, contact geometry and thermal control reduces setup time and the number of iterative checks before sign-off. The model is supplied as a ready accessory with the commercial identification M304.320.6 and is suitable for use where a stable, long reference is required to align micrometric measuring tools or to verify linear adjustments on fixtures and gauges. Choose the Metav IndustryLine setting gauge M304.320.6 for dependable micrometer adjustment — contact Metav Werkzeuge in Emmerich for specialist advice and local supply via info@metav-werkzeuge.com or +49 2822 7131930 Technical data Article number: M304.320.6 GTIN: 4054469116754 Customs tariff number: 90173000 Facts Nominal length: 525 mm Accuracy: ±0.006 mm (6 µm) Weight: 0.8 kg Diameter D: 16 mm Special features Thermal protection (mit Wärmeschutz) Ball-ended measuring faces (ballig) Accessory for setting outside micrometers Category: Zubehör Manufacturer: Metav IndustryLine FAQ What accuracy can be expected from this setting gauge? The setting gauge provides an accuracy of ±0.006 mm (6 µm), which is suitable for high-precision adjustment and verification tasks where micrometric tolerances are required. Which nominal length does the gauge offer and what is it used for? The nominal length is 525 mm; the gauge is intended as an accessory for setting and checking outside micrometers and for transferring a stable length reference in workshop or laboratory contexts. How do the ball-ended measuring faces influence measurement repeatability? The ball-ended measuring faces create a defined point contact that compensates for minor angular misalignment and improves repeatability by reducing the contact variability typical of flat or irregular contact surfaces. What is the role of the thermal protection feature? The thermal protection reduces heat transfer from hands and the environment to the reference body, lowering systematic drift during repetitive handling and improving consistency in successive measurements. Is this model identified by a specific SKU or code? Yes, the product is listed under the article number M304.320.6 and carries GTIN 4054469116754 for unambiguous procurement and inventory tracking. Manufacturer / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; Germany; +49 2822 7131930; info@metav-werkzeuge.com
575mm Setting Gauge For Micrometre, Ball Contact, Thermal Protection, Accuracy ±0.006mm - Metav IndustryLine
Take advantage of the combination of ±0.006 mm accuracy, thermal protection and a 575 mm nominal length to achieve repeatable micrometer settings across a wide range of workshop tasks; order the setting gauge directly via Metav Werkzeuge or contact our consultants for detailed application advice. Setting gauge for micrometers M304.320.7 — 575 mm, ±0.006 mm accuracy (Metav IndustryLine) The Setting gauge for micrometers provides a rigid 575 mm reference length designed for precise adjustment of external micrometers and repeatable workshop checks. 575 mm nominal length, rigid reference ±0.006 mm (6 µm) measurement accuracy Spherical measuring faces with thermal protection Consistent precision for production and inspection The gauge delivers highly repeatable readings thanks to an accuracy of ±0.006 mm (6 µm) and a long, stable reference length of 575 mm. This level of precision supports quality-assurance routines where micrometers must be set to a known standard prior to batch inspection or process checks. By providing a clear nominal length and defined tolerance, the gauge reduces variability that would otherwise arise from informal setting methods, improving throughput in calibration and measurement loops while maintaining compliance with typical workshop tolerances. Thermal stability and reliable contact geometry Built with thermal protection, the gauge minimises the influence of ambient temperature changes on the reference length, which is particularly important at longer sizes. The spherical measuring faces ensure consistent point contact with micrometer anvils, lowering the risk of misalignment or edge contact that can bias a setting. A compact stem of 16 mm diameter aids in guided contact and repeatability, while the overall design prioritises stable seating during adjustment operations. Suited to larger workshop ranges and streamlined workflows Classified as a Large-range gauge (500–1,000 mm), the reference length covers larger micrometer ranges and simplifies inventory by replacing multiple shorter standards. At a weight of 0.9 kg, the gauge is manageable for single-person handling while still providing the mass necessary for steady placement. Integrating the gauge into routine setup reduces adjustment time for production lines and supports consistent measurement practices across shifts, contributing to faster machine changeovers and fewer rejected parts. Practical handling, traceability and workshop use The accessory is intended as a calibrated reference length for setting external micrometers and for regular bench checks. The combination of 575 mm nominal length, defined ±0.006 mm tolerance and pragmatic handling features supports traceability in inspection logs and can be incorporated into existing calibration routines. The compact footprint and straightforward geometry make it a practical addition to the metrology bench where dependable, repeatable micrometer settings are required. For tailored advice on how the Metav IndustryLine setting gauge M304.320.7 can be integrated into existing calibration and inspection workflows, contact Metav Werkzeuge in Emmerich — email info@metav-werkzeuge.com or call +49 2822 7131930 for specialist guidance and delivery arrangements. Technical Data Article number: M304.320.7 GTIN: 4054469116761 Customs tariff number: 90173000 eClass: 21170102 Brand: Metav IndustryLine Facts Nominal length: 575 mm Accuracy: ±0.006 mm (6 µm) Diameter: 16 mm Weight: 0.9 kg Special features Spherical measuring faces Thermal protection Category: Accessory for measuring instruments FAQ Is the gauge suitable for setting all external micrometers? The setting gauge for micrometers is intended as a 575 mm reference standard and is suitable for setting external micrometers whose range or anvils can be referenced to that length; consult the specification of individual micrometers for compatibility. What level of precision does the reference provide? The Metav IndustryLine setting gauge M304.320.7 provides an accuracy of ±0.006 mm (6 µm), which supports fine adjustment and repeatable reference points for workshop and inspection uses. How does the thermal protection affect measurements? Thermal protection reduces the impact of ambient temperature changes on the reference length, helping to maintain the 575 mm nominal value within the specified ±0.006 mm tolerance during routine bench operations. What advantages do spherical measuring faces offer? Spherical measuring faces provide consistent point contact with micrometer anvils, lowering alignment errors and improving repeatability when establishing reference settings. Is calibration documentation included with the gauge? Product data does not specify an ISO 17025 certificate by default; for information on calibration documentation and available certification options, please contact Metav Werkzeuge. Manufacturer / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; Germany; +49 2822 7131930; info@metav-werkzeuge.com
Measure external diameters to micrometre precision
Outside micrometers (also known as micrometer screw gauges) are the reference tool when dimensional tolerances leave no room for compromise. With measurement accuracy down to 0.001 mm, these instruments determine outside diameters, material thicknesses and shaft sizes with repeatable results, whether at the machine, on the shop floor or in a controlled metrology room.
How these micrometers deliver reliable readings in practice
Technically, an outside micrometer uses a finely threaded spindle and a fixed anvil; the spindle advance is controlled by a thimble and a ratchet stop, which together ensure a consistent measuring force. The robust frame resists bending during use, while a spindle lock fixes the measured value for reading. Variants range from classic analogue models with vernier or nonius scales to digital versions with IP protection against coolants and an integrated data interface for wireless transfer of quality data. Options include models with tungsten carbide measuring faces, interchangeable spindles and specialised sizes for hard-to-fix components.
Practical advantages that save time and reduce scrap
- Consistent, repeatable measurements thanks to the ratchet stop and rigid frame.
- High resolution of 0.001 mm for micrometre-level quality control.
- One-handed operation via the frame allows simultaneous handling of awkward or small parts (one-handed operation).
- Quick data capture and traceability with digital models featuring a data interface.
- Durable measuring faces and spindle lock for long-term stability (tungsten carbide measuring faces).
Why Metav is the practical choice for your workshop
Metav combines decades of precision expertise with a comprehensive range for industry and trade. From analogue micrometers to advanced digital versions, the Metav assortment acts as a quality filter for the European market, supplying reliable instruments from stock in Emmerich. With a broad catalogue and proven service, Metav reduces supplier complexity while ensuring parts arrive ready for immediate use.
In short: precise, repeatable and ready for industry
Outside micrometers deliver micrometre-level accuracy for external measurements, offering durable construction, ergonomic one-handed handling and modern digital options for straightforward data capture. Metav’s selection covers the spectrum from workshop checks to final inspection.
FAQ
What accuracy can I expect from outside micrometers?
Outside micrometers in this category provide measurement resolution and repeatability down to 0.001 mm, making them suitable for high-precision tasks in toolmaking, automotive and quality assurance.
When should I choose a digital micrometer over an analogue one?
Choose a digital micrometer if you require fast data logging and traceability; digital models in the Metav assortment often include IP protection against coolants and a data interface for wireless quality-data transfer.
Are there micrometers suitable for soft or delicate surfaces?
Yes. Models with specialised anvils and adjustable measuring faces—some fitted with tungsten carbide measuring faces or interchangeable spindles—allow measurement of delicate surfaces while maintaining accuracy.
Can outside micrometers be operated with one hand on the shop floor?
Many outside micrometers are designed for one-handed operation, using the frame and thumb control on the thimble so the other hand can stabilise the workpiece during measurement.
How does the ratchet stop improve measurement consistency?
The ratchet stop ensures a uniform measuring force for each reading; combined with the rigid frame and spindle lock, this produces highly reproducible results across different operators.
