High‑precision microscopes for metallographic inspection
A metallographic microscope is a specialised optical instrument designed to reveal the microstructure of metals and alloys, enabling precise analysis of grain size and identification of phases such as ferrite, pearlite and martensite while detecting microscopic defects like inclusions, pores and cracks. Used in industrial quality assurance, these microscopes combine a controlled reflected‑light illumination system, high‑quality objectives with critical numerical aperture and a tube and eyepiece for observation to ensure reliable resolution of fine structural details. Integrated digital camera systems and evaluation software allow norm‑compliant measurement, documentation and reproducible assessment, making them indispensable for material characterisation and process validation.
Ø20.7x111 Pocket Microscope 100x With Fixed Template 0.86mm Field, 0.005mm Scale - Peak
Take advantage of a compact inspection solution that combines 100x magnification, a 0–0.8 mm measuring range and a fine 0.005 mm scale for repeatable close-up checks; order or request advice via Metav Werkzeuge for tailored technical guidance. Peak pocket microscope with EIM, 100x A Peak pocket microscope with EIM, 100x is a handheld inspection microscope designed for rapid surface measurement and visual quality checks in workshops and laboratories. 100x magnification for detailed inspection Integrated fixed template for repeatable checks Measuring range 0–0.8 mm with 0.005 scale Compact Ø20.7 × 111 mm housing, portable Precise visual inspection in a pocket-sized format The handheld loupe delivers high-contrast imaging with 100x magnification, enabling clear identification of fine surface features and defects that are otherwise difficult to see. The combination of a narrow 0.86 mm field of view and a precise 0.005 mm scale makes the instrument suited to tasks where small dimensional differences matter, such as component edge inspection or textile and print defect detection. The compact form supports rapid, repeatable checks without complex set-up, improving throughput in routine inspection chains. Reliable measurement capability for small ranges Equipped with a measuring span of 0–0.8 mm, the device allows objective close-up measurement of shallow features and thin sections. The 0.005 mm graduation provides a verifiable quantification of minor variations, turning visual inspection into measurable data for quality records. Where millimetre-level precision is required, the integrated fixed template ensures that the same reference is used each time, reducing variability between checks and simplifying documentation in inspection workflows. Designed for portability and repeatability At Ø20.7 × 111 mm, the housing is lightweight and easy to carry between workstations. The fixed template feature supports consistent placement on the sample, while the compact optical assembly preserves image sharpness at high magnification. These design choices mean the instrument is both portable and suited to repeated use on the shop floor, in service benches or at incoming goods inspections, where rapid decisions are necessary without compromising on measurement reliability. Practical applications and added confidence The pocket microscope is applicable across a wide range of tasks in optics, electronics, jewellery, and small-part manufacturing where visual and small-range dimensional checks are routine. Its simplicity reduces training overhead, while the measurable scale and template enhance traceability in quality processes. For specialised or atypical inspection challenges, technical clarification is available to ensure the tool is matched correctly to the application. Contact Metav Werkzeuge for detailed technical advice or to arrange a product enquiry; Metav Werkzeuge’s consultants can advise on fit-for-purpose use and delivery from Emmerich via info@metav-werkzeuge.com or +49 2822 7131930 Technical Data Article number: MS905.407 Name: Peak pocket microscope with EIM, 100x Dimensions: Ø20.7 × 111 mm Field of view: Ø0.86 mm Scale: 0.005 mm Measuring range: 0–0.8 mm Special feature: with fixed template Facts Magnification: 100x Measuring range: 0–0.8 mm Scale increment: 0.005 mm Field of view: Ø0.86 mm Dimensions: Ø20.7 × 111 mm SKU: MS905.407 Special features Fixed template for repeatable placement EIM included (per designation) Category: optics FAQ What magnification does the pocket microscope provide? The Peak pocket microscope provides 100x magnification, enabling detailed visual inspection of small features. What is the measurable range and resolution of the device? Measurement capability is 0–0.8 mm with a 0.005 mm scale, suitable for shallow feature assessment and fine gap checks. How small is the field of view at high magnification? The instrument offers a 0.86 mm field of view, which concentrates observation on very small areas for precise defect detection. Is the fixed template suitable for repeat checks? Yes, the integrated fixed template is designed to enable repeatable placement and consistent comparative measurements. Can the pocket microscope be used on the shop floor? The compact Ø20.7 × 111 mm housing and portable design make it appropriate for workshop or inspection-bench use. Manufacturer / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; Germany; +49 2822 7131930; info@metav-werkzeuge.com
Ø20.7x111 Pocket Microscope with Fixed Template 25x, Ø3.5 Field of View - Peak
Take advantage of portable 25× magnification and a 0.05 mm graduated measuring scale for consistent, repeatable checks on small components; order directly via Metav Werkzeuge or consult the team for further technical information. Peak Pocket Microscope MS905.404 — 25× magnification, integrated measuring scale A Peak pocket microscope designed for quick visual inspection and precise measurement of small parts in workshop and quality control environments 25× magnification for detailed visual inspection Built-in measuring scale with 0.05 mm graduation Measurement range 0–3 mm for small parts Fixed template for repeatable measurements Precise, measurable inspection in a pocket-sized tool Equipped with 25× magnification and a calibrated measuring scale, this pocket microscope turns visual checks into quantifiable inspections. The integrated scale with 0.05 mm graduation enables clear numeric comparison when assessing edges, threads or surface defects; the tool’s measurement range (0–3 mm) makes it suitable for verifying small tolerances directly at the bench. The combination of visual magnification and precise graduation reduces interpretation errors and supports traceable quality decisions in production and repair workflows. Compact form that supports on-site efficiency With compact dimensions of Ø20.7 x 111 mm, the instrument is purpose-built for portability and rapid deployment. The small footprint and pocket format allow technicians to carry a reliable inspection aid between workstations, minimizing interruptions to the production flow. The Ø3.5 mm field of view balances magnified detail with a practical observation window, so assessments are both precise and efficient without cumbersome equipment setup. Consistent results through repeatable measurement aids The design includes a fixed template that standardises the positioning of specimens and simplifies repeated checks. This feature reduces variability introduced by manual handling and speeds up routine inspection cycles. The integrated measuring function (EIM) complements the template by delivering direct numerical readings, turning subjective visual inspections into reproducible, documented findings suitable for quality control records or maintenance reports. For reliable, portable inspection equipment from Peak, contact Metav Werkzeuge for specialist advice or to arrange procurement: Metav Werkzeuge GmbH, Parkring 45, 46446 Emmerich, Germany — info@metav-werkzeuge.com • +49 2822 7131930 Technical data Article number: MS905.404 Brand: Peak Dimensions: Ø20.7 x 111 mm Magnification: 25× Field of view: Ø3.5 mm Measurement range: 0–3 mm Scale graduation: 0.05 mm Special feature: fixed template Facts Ø20.7 x 111 mm Ø3.5 mm field of view 25× magnification 0.05 mm graduation Measurement range 0–3 mm Special features Fixed template for repeatable measurement Integrated measuring function (EIM) Pocket-sized inspection tool FAQ Is the pocket microscope suitable for inspections on the shop floor? Yes. The Peak pocket microscope MS905.404 is pocket-sized for workshop use and provides magnified visual inspection with a built-in measuring scale for on-the-spot checks. What is the smallest dimension that can be measured reliably? The instrument’s scale offers a 0.05 mm graduation and a measurement range from 0 to 3 mm, making it appropriate for fine-detail measurement of small components. What magnification and observation window are provided? The device delivers 25× magnification with a field of view of approximately Ø3.5 mm, optimised for close-up inspection of surfaces and fine features. How does the fixed template improve measurement tasks? The fixed template standardises specimen placement, ensuring repeatable positioning and reducing variance between successive measurements for consistent inspection results. Can the microscope support quality control documentation? Yes. By combining a calibrated scale with repeatable positioning, the pocket microscope MS905.404 supports documented, numeric checks that can be recorded in quality reports. Manufacturer / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; Germany; +49 2822 7131930; info@metav-werkzeuge.com
Ø20.7x111 Pocket Microscope with Fixed Template 75x, Ø1.1 Field, 0.01 Scale - Peak
Take advantage of the combination of precise 75x magnification, a 0–1 mm measurement range with 0.01 mm graduations and a fixed template for repeatable checks; these features support reliable micro-inspection and faster decision-making on the shop floor. Order the MS905.406 directly via Metav Werkzeuge or ask our consultants if needed. Peak Pocket Microscope MS905.406 — 75x inspection microscope with fixed template The Peak Pocket Microscope MS905.406 is a compact inspection instrument designed for close-up visual inspection and small-range measurement in production and quality-control environments *Pocket-sized inspection microscope *Fixed measurement template for repeatable checks *High 75x magnification for detailed observation Accurate micro-inspection for fast decisions The MS905.406 delivers 75x optical magnification combined with a fine 0.01 mm scale, enabling precise readings across a 0–1 mm measurement range. With a narrow Ø1.1 mm field of view, the instrument focuses on minute details, which reduces ambiguity during visual assessment and speeds up inspection cycles. In practice, this means fewer secondary checks and quicker pass/fail decisions, improving throughput without compromising on measurement reliability. The optical performance supports both visual evaluation and simple comparative measurements, so small dimensional deviations are recognised immediately. Repeatability and process integration for quality control Equipped with a fixed measurement template, this pocket microscope provides a stable reference for repeated checks, lowering variability between operators and shifts. The inclusion of EIM ensures consistent alignment during inspection routines, making the instrument suitable for standardised quality-control tasks and incoming part checks. Because the design prioritises repeatable positioning and a clear measurement scale, documentation and traceability of inspection results become more straightforward, supporting ISO-style process requirements and internal quality audits. Practical handling that suits the workshop environment The compact format — Ø20.7 x 111 mm — makes the device genuinely portable and easy to store on a workbench or in a tool kit. Its pocket-friendly dimensions and robust construction are optimised for everyday use in busy production areas, enabling quick spot checks without interrupting workflow. The combination of a small footprint and a precise optical system means the instrument is effective for field inspection, bench work and routine quality sampling. For operations seeking to reduce measurement bottlenecks, this instrument contributes to smoother production flow and clearer inspection results. Contact Metav Werkzeuge for technical advice and to arrange procurement of the MS905.406; eMail info@metav-werkzeuge.com or call +49 2822 7131930 for personalised consultation Technical Data Article number: MS905.406 Brand: Peak Product: Pocket microscope MS905.406 Facts Magnification: 75x Scale: 0.01 mm Measurement range: 0–1 mm Field of view: Ø1.1 mm Dimensions: Ø20.7 x 111 mm Special features Fixed measurement template With EIM Category: Optics FAQ What measurement range can be inspected with this pocket microscope? The MS905.406 covers a 0–1 mm measurement range with a 0.01 mm scale suitable for fine thickness and gap checks. Is the instrument suitable for repeated quality checks on production items? Yes, the fixed measurement template and consistent optics of the Peak pocket microscope support repeatable inspections and standardised sample checks. How fine is the field of view and what does it mean for inspection? The field of view is Ø1.1 mm, which concentrates observation on very small areas for high-detail inspection and precise visual comparison. Does the device require additional accessories to perform measurements? No additional accessories are required for basic inspection and template-based measurements; the integrated scale and fixed template enable immediate use. Can the microscope be used at the workbench and in the field? Its compact Ø20.7 x 111 mm format and robust design make the instrument well suited for both bench work and mobile spot checks. Manufacturer / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; Germany; +49 2822 7131930; info@metav-werkzeuge.com
Ø20.7x111 Pocket Microscope With Fixed Template, Ø1.7 Field, 50x Magnification - Peak
Benefit from portable inspection with 50x magnification, an integrated 0.02 mm measuring scale and a fixed template for repeatable checks; ideal for quality control and field work. Order the pocket microscope directly via Metav Werkzeuge or contact our consultants for application advice. Peak Pocket Microscope MS905.405 — 50x inspection loupe with measurement scale A Peak Pocket Microscope MS905.405 designed for portable 50x inspection and straightforward dimensional checks in workshops and on-site quality control. 50x magnification for detailed inspection Integrated 0.02 mm scale for precision checks Ø1.7 mm field of view for concentrated viewing Compact Ø20.7×111 mm housing for portability Fast, measurable inspection where it matters The handheld loupe delivers 50x magnification in a compact footprint, making close visual inspection possible without a bench microscope. The built-in 0.02 mm scale permits immediate, numerical comparison of small features and gaps; measurements are taken across a 0–1.6 mm range for fine tolerances. This configuration suits quick acceptance checks and component verification in production lines, where rapid, measurable results reduce batch rework and speed up decision making. Repeatable placement for consistent results Equipped with a fixed template, this pocket microscope ensures consistent sample positioning for repeat checks and simple go/no-go inspections. The Ø1.7 mm field of view concentrates the area of interest, improving repeatability when comparing features across multiple parts. Because the instrument combines a fixed reference and a fine scale, it supports standardised workflows in inspection routines and helps maintain traceable visual records during routine quality control. Portable, robust design for workshop and field use The device’s compact dimensions (Ø20.7×111 mm) make it convenient to carry in a toolkit or on a belt, while the solid construction is tolerant of typical workshop handling. The form factor permits quick transfer between stations and immediate use at the point of failure or inspection. For technicians and inspectors who need a reliable handheld instrument, this loupe balances precision and portability without the complexity of larger optical systems. Clear readout and practical operation A clear scale with a 0.02 mm graduation simplifies reading and reduces interpretation errors under industrial lighting. The combination of magnification and scale turns subjective visual checks into objective, repeatable measurements, so small deviations are identified early. Supplied with essential features for quick assessment, the instrument supports faster troubleshooting and contributes to continual process improvement in small-part manufacturing. Contact Metav Werkzeuge for a tailored consultation on the MS905.405 and to discuss suitability for specific inspection tasks Technical data Article number: MS905.405 Brand: Peak Product type: Pocket microscope Facts Magnification: 50x Scale: 0.02 mm Measurement range: 0–1.6 mm Field of view: Ø1.7 mm Dimensions: Ø20.7×111 mm Special features Fixed template included EIM included Portable handheld design FAQ What magnification does this pocket microscope offer? The Peak Pocket Microscope MS905.405 provides 50x magnification, suitable for detailed visual checks of small components. How fine is the measuring scale on the loupe? The integrated scale has a 0.02 mm graduation, enabling precise comparative measurements within the 0–1.6 mm range. Is the field of view suitable for small feature inspection? Yes, the Ø1.7 mm field of view concentrates observation on small details, improving focus and repeatability for inspection tasks. Does the instrument support repeatable positioning? The fixed template supplied with the MS905.405 ensures repeatable placement for consistent, comparable checks. Manufacturer / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; Germany; +49 2822 7131930; info@metav-werkzeuge.com
Ø30 10x Eyepiece For Stereo Microscopes, 23 Mm Field Of View - Metav IndustryLine
Take advantage of the compact Ø30 barrel and precise 10x magnification together with a wide 23 mm field of view for reliable inspection work; order the eyepiece directly via Metav Werkzeuge or consult the team for integration advice. SWH10X-CM eyepiece (10x magnification, Ø30 barrel) — Metav IndustryLine The SWH10X-CM eyepiece is a high-clarity optical accessory for stereo microscopes, designed to extend magnification and improve visual throughput in inspection and assembly tasks 10x magnification for detailed inspection Ø30 barrel for standard stereo microscope fit 23 mm field of view for wider scene coverage Lightweight construction at 0.15 kg for easy handling Consistent detail and measurement confidence with every observation The eyepiece delivers a 10x view that increases image detail without compromising ease of use, enabling quicker recognition of fine features during inspection. A 23 mm field of view provides a broader visual context than narrower oculars, reducing the need for frequent repositioning of components under the lens and thereby speeding up repetitive tasks. Optical consistency is particularly beneficial in quality control and small-assembly environments where repeatable visual assessment reduces rework and shortens cycle times. In practical terms, the combination of magnification and field size supports both visual checks and documentation routines where seeing more at once saves time. Seamless integration and ergonomic handling for workshop workflows Engineered with a Ø30 barrel, the eyepiece is compatible with common stereo microscope tubes and can be swapped quickly to adapt existing setups. The compact, lightweight design lowers the moment of inertia at the optical head, improving comfort during prolonged use and decreasing operator fatigue. For bench work and small-batch inspection, this means users can sustain attentive inspection for longer periods without loss of precision. The straightforward fit and handling characteristics also simplify inventory management: fewer adapters or special mounts are required when increasing magnification across multiple stations. Practical benefits for production and laboratory environments Beyond visual quality, the eyepiece contributes to measurable workflow gains: broader scene capture reduces handling time per part, and a stable optical interface improves consistency across multiple operators. The optical accessory suits routine inspection, soldering control, fine assembly and lab evaluation tasks where a reliable enlarged image is essential. Constructed for everyday use, the eyepiece balances robust handling with optical clarity, helping teams maintain throughput while upholding inspection standards under varying production conditions. For tailored advice on integrating the SWH10X-CM eyepiece into an existing microscope system or for delivery from Metav’s Emmerich distribution, contact Metav Werkzeuge by phone +49 2822 7131930 or email info@metav-werkzeuge.com — assistance is available to match the optical accessory to the specific inspection task. Technical data Article number: M503.241.5 GTIN: 4054469145167 Type: SWH10X-CM Facts Magnification: 10x Field of view: 23 mm Barrel diameter: Ø30 Weight: 0.15 kg Customs tariff number: 90119090 Special features Compatibility: stereo microscopes Compact, lightweight design Suitable for inspection and assembly tasks Brand: Metav IndustryLine FAQ What magnification does this eyepiece provide? The SWH10X-CM eyepiece offers a 10x magnification level suitable for detailed visual inspection. Which microscopes will this eyepiece fit? This eyepiece is designed for stereo microscopes with a Ø30 barrel tube and fits standard stereo optical heads. How wide is the visible scene through the eyepiece? The eyepiece provides a 23 mm field of view, allowing a wider area to be seen at once compared with narrower oculars. Is the eyepiece suitable for prolonged use at a workstation? Yes, the lightweight construction (0.15 kg) and ergonomic dimensions make it appropriate for extended inspection and assembly tasks. Manufacturer / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; Germany; +49 2822 7131930; info@metav-werkzeuge.com
Ø30 20x Eyepiece For Stereo Microscopes 14mm Field Of View - Metav IndustryLine
Take advantage of the combination of 20x magnification, a Ø30 mm barrel, and a generous 14 field of view to upgrade inspection capability with minimal integration effort; order the ocular directly via Metav Werkzeuge or consult the technical team for compatibility advice. SWH20X-CM-1 eyepiece — 20x magnification, Ø30 mm barrel (Metav IndustryLine) A SWH20X-CM-1 eyepiece engineered to increase magnification for stereo microscopes and improve visual resolution in inspection and assembly tasks. 20x high-power magnification Ø30 mm barrel for standard mounts Wide 14 field of view Robust construction for repeated use Clearer detail where it matters The 20x magnification provides a substantial increase in apparent detail without the need to change the core microscope head, making fine inspection and component verification more efficient. With a Ø30 mm barrel the eyepiece fits standard stereo microscope mounts, so optical integration is straightforward. The nominal 14 viewing parameter yields a comfortable observable area that balances magnification with a usable field, reducing the need for excessive stage repositioning during quality checks. Built for frequent workshop use Designed with routine industrial use in mind, the ocular combines optical power and handling convenience to support repetitive inspection cycles. The construction emphasises reliability and easy seating in the eyetube to maintain alignment over multiple shifts. This stability translates into faster throughput and fewer re‑set checks, so measurement work and visual controls remain consistent across batches. Easy integration with existing systems Compatibility with standard stereo microscope fittings simplifies the upgrade path: the Ø30 mm mount is common across many laboratory and bench microscopes, permitting quick replacement or addition of the eyepiece. The compact barrel format keeps the optical axis steady and minimises vignetting, allowing technicians and inspectors to preserve familiar workflows while benefiting from enhanced magnification and a broader viewing area. A dependable partner for precise optics As part of the Metav IndustryLine range, this ocular benefits from a distribution and quality filter based in Emmerich that supports reliable supply to European workshops. Metav’s position as a long‑standing precision partner means the component is available alongside complementary optical accessories and technical guidance, supporting a practical route from specification to deployment. Contact Metav Werkzeuge for tailored advice on Metav IndustryLine optics and to confirm fitment for the SWH20X-CM-1 — email info@metav-werkzeuge.com or phone +49 2822 7131930 for prompt assistance from the Emmerich team Technical data SKU: M503.241.7 GTIN: 4054469145174 Type: SWH20X-CM-1 Name: Okular Category: Optik EClass: 21160592 Key figures Magnification: 20x Barrel diameter: Ø30 Field of view: 14 Weight: 6.15 kg Tariff code: 90119090 Features & compatibility Suitable for stereo microscopes Standard Ø30 mount compatibility High-power ocular optics Asset available: m5032411-main.jpg Category path: Optik FAQ What magnification does this eyepiece provide? The SWH20X-CM-1 provides 20x magnification for detailed inspection work. Which mounting size is required for installation? The ocular uses a Ø30 mm barrel suitable for standard stereo microscope mounts. What does the value "14" refer to in the specification? The figure 14 denotes the eyepiece’s field‑of‑view parameter, indicating a generous observable area at 20x. Is the SWH20X-CM-1 suitable for industrial inspection benches? Yes, the SWH20X-CM-1 is intended for workshop and laboratory inspection use and is compatible with common bench stereo microscopes. Is an image of the product available for review? An asset is provided (m5032411-main.jpg) for visual reference of the ocular. Manufacturer / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; Germany; +49 2822 7131930; info@metav-werkzeuge.com
Ø30 Stereo Microscope Eyepiece 10x SWH10X, 23mm Field Of View - Metav IndustryLine
Benefit from precise visual inspection with 10x magnification and a 23 mm field of view, packed into a standard Ø30 mm tube for straightforward integration with existing stereo microscopes. Order the eyepiece directly via Metav Werkzeuge or consult our specialists to ensure optical matching and quick delivery. Eyepiece SWH10X – 10x magnification, 23 mm field, Metav IndustryLine Eyepiece SWH10X is a precision optical accessory designed to increase the effective magnification of stereo microscopes for inspection, quality control and assembly tasks. 10x magnification for detailed inspection 23 mm wide field of view for efficient scanning Ø30 mm tube fits standard stereo microscopes Balanced weight for stable, low-vibration imaging Sharper inspection with proven optical gain The combination of 10x magnification and a 23 mm field of view accelerates visual inspection without compromising the overview needed for efficient scanning. Magnification increases the apparent size of details while field of view determines how much of the object is visible at once; the chosen balance reduces the number of repositioning steps during component checks and shortens inspection cycles. For workshops and inspection benches this translates into measurable throughput gains and fewer missed defects, supporting leaner quality processes. Straightforward integration into workplace optics Built to the common industry tube standard, the Ø30 mm tube ensures compatibility with a wide range of stereo microscopes and trinocular heads. The optical accessory inserts and secures in typical eyepiece holders, delivering consistent alignment and image centring. A compact, well scaled mass supports stable imaging with reduced hand‑induced vibration on benchtop stands. This reliability keeps measurement and visual inspection repeatable across shifts and operators, which is essential for production environments that rely on consistent visual standards. Practical handling and routine maintenance for industry use The optical accessory was conceived for daily use in production, laboratory and service settings: straightforward cleaning, rapid exchange and durable optics preserve performance over time. The compact design eases storage and transport between workstations, and the stable imaging characteristics support both manual inspection and documentation tasks such as photomacrography when integrated into camera-equipped stereo setups. For procurement and specification checks, the item is listed under Metav IndustryLine with clear identifiers for fast sourcing. Choose the Metav IndustryLine SWH10X eyepiece for reliable inspection results; contact Metav Werkzeuge for tailored specification advice and procurement at info@metav-werkzeuge.com or by phone on +49 2822 7131930 Technical data SKU: M503.241.1 GTIN: 4054469145129 eClass: 21160592 Type: SWH10X Facts Magnification: 10x Field of view: 23 mm Tube diameter: Ø30 mm Weight: 0.5 kg Customs tariff number: 90119090 Applications / Features Designed to expand magnification of stereo microscopes Category: Optik Intended for inspection, assembly and quality control tasks Storytrigger: optik FAQ What microscopes is this eyepiece compatible with? The eyepiece is designed for standard stereo microscopes with a Ø30 mm eyepiece tube and is supplied as the Metav IndustryLine SWH10X (SKU M503.241.1). What image area can be expected with this accessory? The accessory provides a 23 mm field of view at 10x magnification, which balances detailed enlargement with efficient scanning of components. How does the SWH10X improve inspection workflows? By increasing apparent detail while maintaining a wide field, the SWH10X reduces repositioning and speeds visual checks, helping quality control and assembly lines to be more efficient. Are there any special mounting or adapters required? No special adapter is normally required for microscopes with a Ø30 mm eyepiece tube; compatibility details are listed under SKU M503.241.1 for procurement checks. Manufacturer / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; Germany; +49 2822 7131930; info@metav-werkzeuge.com
Ø48 0.5x Stereo Microscope Objective Attachment For Magnification Extension - Metav IndustryLine
Take advantage of the combination of precise optical adjustment and straightforward compatibility to improve inspection speed and repeatability; the 0.5× magnification and Ø48 mounting deliver a broader field of view with stable installation. Order the attachment lens directly via Metav Werkzeuge or contact the consultants for application advice. Attachment Lens M503.242.1 – 0.5× Auxiliary Optic for Stereo Microscopes (Ø48) The attachment lens M503.242.1 is an auxiliary optic designed to alter the effective magnification of stereo microscopes for wider observation fields in industrial and laboratory inspection settings. 0.5× magnification for wider field of view Fits Ø48 mounting on stereo microscopes Model W0.5 for consistent optical matching Metav IndustryLine quality assurance Greater overview with controlled magnification The 0.5× specification reduces the effective magnification while increasing the field of view, enabling operators to inspect larger areas without changing objectives or repositioning samples. This adjustment translates into fewer stage movements and faster throughput during routine visual checks, which is particularly advantageous in quality control and incoming inspection. By providing a predictable optical change, the accessory supports reproducible visual assessments and simplifies documentation of findings. Seamless compatibility and straightforward mounting Designed for Ø48 mounting interfaces, the accessory—specified as W0.5—matches common stereo microscope optical trains and mechanical mounts. The attachment integrates with existing stereo microscope setups, preserving parcentricity and focus range when correctly coupled, so alignment work is kept to a minimum. This compatibility reduces setup time in production environments and helps maintain consistent imaging geometry across inspection tasks with different magnifications. Stable construction for reliable handling Mechanical stability is essential when enlarging the observed area; a steady optical assembly reduces perceived vibration and improves image steadiness. The accessory's build provides the necessary support for routine use in inspection benches and laboratory workstations, with weight: 6.15 kg recorded in the technical specification for completeness. Stable optics contribute to repeatable measurements and reduce operator fatigue during longer inspection sessions, which in turn supports consistent quality outcomes. Practical gains for inspection workflows Introducing a dedicated auxiliary lens accelerates decision-making by offering a broader situational view while retaining sufficient detail for many assembly and inspection tasks. The accessory is well suited to applications where overview and context are as important as detail—for example, solder-joint inspection, component orientation checks, and initial defect screening. Backed by Metav IndustryLine selection criteria, the optic is an effective tool for workshops and small labs seeking to raise inspection efficiency without complex system changes. Select the Metav IndustryLine attachment lens for dependable optical adaptation and contact Metav Werkzeuge for application guidance or to place an order: info@metav-werkzeuge.com | +49 2822 7131930 Technical data SKU: M503.242.1 GTIN: 4054469145198 Type: W0.5 Diameter: Ø48 Customs tariff no.: 90119090 Weight: 6.15 kg Core specifications Magnification: 0.5× Mount diameter: Ø48 Model designation: M503.242.1 Special features Attachment lens for stereo microscopes Designed to increase field of view while altering magnification Category: Optik Suitable for: ZS0745 Brand: Metav IndustryLine FAQ What change in magnification does this accessory provide? The accessory adjusts the optical system by 0.5×, giving a noticeably wider field of view while reducing the effective magnification for broader inspection coverage. Will this fit common stereo microscope mounts? Yes, the unit is specified for Ø48 mounting and is compatible with stereo microscopes that accept Ø48 auxiliary optics; the model is identified as W0.5 to aid selection. Can this lens be used for incoming inspection and assembly checks? The accessory is suitable for visual inspection workflows where a larger overview is required; it supports quicker assessments and reduces sample repositioning for routine checks. Does the lens affect image alignment or focus range? When properly mounted, the attachment preserves the optical geometry and focus range expected from a matched auxiliary optic, minimising additional alignment work. Is the accessory supplied ready for use or does it require adjustment? The unit is delivered as an optical attachment; correct mechanical coupling to the microscope and a brief check of centring and focus are recommended before formal inspection tasks. Manufacturer / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; Germany; +49 2822 7131930; info@metav-werkzeuge.com
Ø48 0.7x Auxiliary Lens For Stereo Microscopes - Metav IndustryLine
Combine precise 0.7× magnification, a compact W0.7 design and a Ø48 mounting diameter for reliable inspection and documentation workflows; the result is a practical attachment for broader fields of view and faster visual checks. Order the auxiliary lens directly via Metav Werkzeuge or ask our consultants if needed. Auxiliary lens W0.7 (0.7×) by Metav IndustryLine — Ø48 mount A compact auxiliary lens W0.7 designed to extend the magnification range of stereo microscopes and improve visual inspection and documentation without changing primary objectives 0.7× magnification factor for broader field Ø48 mm mounting diameter for common eyepieces Designed for stereo microscopes and documentation Compact W0.7 design preserves optical quality See more at once — faster inspections with lower magnification Fitting an 0.7× magnification attachment reduces the overall magnification and consequently increases the field of view, which is especially useful when moving from detailed examination to rapid component inspection. This optical compromise shortens inspection cycles by allowing larger areas to be assessed at once while maintaining sufficient detail for quality checks. The result is more efficient visual workflows and fewer objective changes during batch inspections, supporting higher throughput in routine microscopy tasks. Simple integration — fits standard mounts and keeps image quality The Ø48 mounting diameter provides a standard interface for many stereo microscope eyepieces and camera ports, enabling quick installation and removal without special adapters. Thanks to the W0.7 construction, the attachment preserves alignment and maintains image homogeneity across the field, so documentation with camera systems remains consistent. Compatibility with common microscope setups reduces downtime and simplifies equipment management in production and laboratory environments. Practical benefits for inspection and documentation routines As a compact optical attachment, this lens offers a straightforward way to adapt existing microscope setups for overview tasks, inspection of larger samples and pre‑selection before high‑magnification analysis. The combination of a reduced magnification factor and stable mounting leads to fewer objective swaps and smoother transitions between magnification levels. Supplied as part of the Metav IndustryLine portfolio, the unit supports reliable supply and traceable ordering across European workshops and labs. Choose the Metav IndustryLine W0.7 auxiliary lens for wider fields of view and contact Metav Werkzeuge in Emmerich for expert advice and dependable European supply Technical Data Article number: M503.242.2 GTIN: 4054469145204 Manufacturer: Metav IndustryLine Category: Optics Tariff number: 90119090 Facts Magnification: 0.7× Mounting diameter: Ø48 mm Type designation: W0.7 eClass: 27371231 Special features Compact auxiliary lens design Intended for stereo microscope applications SKU: M503.242.2 Story trigger: optik FAQ What magnification does this attachment provide? The auxiliary lens provides a 0.7× magnification factor, allowing a notably wider field of view than the primary objective. Will the lens fit my microscope? The unit uses an Ø48 mm mounting diameter, suitable for many stereo microscope eyepieces and camera ports; check physical mounting standards for exact compatibility. Can this lens be used for documentation with a camera? Yes, the optical construction preserves image homogeneity and is suitable for documentation and camera‑based inspection workflows when attached to compatible stereo microscopes. What is the model designation and SKU? The type designation is W0.7 and the SKU is M503.242.2, useful for ordering and stock checks. Is this part part of a wider product range? The lens is offered within the Metav IndustryLine optics range and is intended to complement existing stereo microscope configurations. Manufacturer / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; Germany; +49 2822 7131930; info@metav-werkzeuge.com
Ø48 1.5x Stereo Microscope Auxiliary Lens, W1.5 - Metav IndustryLine
Take advantage of the precise 1.5× magnification and compact Ø48 mounting to boost inspection accuracy without changing the existing optical train; the attachment delivers clearer detail at minimal setup effort. Order the attachment directly via Metav Werkzeuge or ask the consultants for integration advice. Attachment lens W1.5 — 1.5× magnification, Ø48 mount (Metav IndustryLine) The Attachment lens W1.5 increases the magnification of a stereo microscope by 1.5×, providing improved detail recognition for routine inspection and fine assembly tasks in laboratories and workshops. 1.5× magnification boost for stereo microscopes Ø48 compatible mount for standard eyepieces Lightweight optical glass for clear imaging Simple attachment, preserves working distance Faster, more reliable visual inspection for quality control The 1.5× magnification upgrade reduces reliance on repeated repositioning and rework by bringing small features into clearer view during the first pass. Integrated into a standard stereo microscope, this optical accessory extends visual resolution while maintaining the original optical axis, so measurement workflows and visual checks become more efficient. The result is higher throughput in inspection loops and fewer ambiguous findings during quality control. Designed for quick integration and steady handling Compatibility with a Ø48 mount means straightforward fitting to many common stereo microscope heads, allowing rapid retrofitting without optical overhaul. The W1.5 design keeps the working distance stable, retaining operator posture and tool clearance that are critical during soldering, micro-assembly or dissection tasks. Where system integration needs clarification, Metav IndustryLine provides specification guidance to ensure the attachment aligns with existing microscope configurations. Optical clarity that supports confident decisions Constructed to preserve contrast and minimise aberrations, the lens delivers a noticeably improved field of view at increased magnification, so small defects and fine structures are easier to evaluate. The enhanced image quality reduces eye strain and speeds decision-making for inspectors and technicians, turning visual checks into a more reliable stage of production and assembly. The accessory is therefore suited to electronics inspection, precision engineering and educational laboratories seeking consistent observational results. Practical applications and who benefits most Engineers, quality inspectors and lab technicians gain from the incremental magnification without adding complexity to their microscopes; the attachment is particularly useful for component inspection, entomology slides and detailed surface checks. Its compact form and standard mount make it a practical option where space and handling matter, enabling existing optical benches to deliver greater resolution with minimal additional training. Contact Metav Werkzeuge today to discuss how the W1.5 attachment (M503.242.3) can be integrated into existing microscope setups and to request technical advice from our specialists. Technical data SKU: M503.242.3 GTIN: 4054469145211 Manufacturer: Metav IndustryLine Key specifications Magnification: 1.5× Mount diameter: Ø48 Type: W1.5 Tariff code: 90119090 Features & compatibility Suitable for stereo microscope use Category: Optik Story trigger: optik FAQ What magnification increase does the lens provide? The attachment lens provides a 1.5× magnification increase, offering finer detail without replacing the microscope objective. Will the lens fit my existing microscope? The lens uses a Ø48 mount and is compatible with many stereo microscope heads; refer to the model specification or contact Metav Werkzeuge for confirmation. Does the attachment change the working distance? Designed as a W1.5 accessory, the lens maintains a stable working distance so handling and tool clearance remain largely unchanged during inspection. Is the product identified by a catalogue number? Yes, this accessory is listed as M503.242.3 (Metav IndustryLine). Manufacturer / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; Germany; +49 2822 7131930; info@metav-werkzeuge.com
Ø48 2.0x Stereo Microscope Auxiliary Objective, For Magnification Increase - Metav IndustryLine
Benefitting from a compact fit and clear optical performance, the 2.0× attachment lens delivers an immediate extension of inspection capability while preserving the ergonomic advantages of stereo optics; combine the 2.0× magnification with the Ø48 mounting to speed up visual checks and reduce objective changes. Order directly via Metav Werkzeuge or consult our specialists for compatibility advice. Attachment lens W2.0 – 2.0× optical accessory, Ø48 mount (Metav IndustryLine) The Attachment lens W2.0 is a precision optical accessory that increases the magnification of stereo microscopes by 2.0×, designed for use with Ø48 mm objective mounts and routine visual inspection tasks. 2.0× magnification factor Ø48 mm mount diameter Designed for stereo microscopes Compact optical enhancement Greater inspection reach without swapping objectives The 2.0× optical booster extends the usable magnification range of existing microscopes, enabling quicker transition between overview and detail inspection without frequent objective changes. By acting as an intermediate optical element, this attachment lens multiplies the effective magnification of the microscope’s objective while keeping the original optical axis and working distance largely intact. The result is a measurable gain in inspection throughput and fewer handling steps during quality control, which supports faster decision cycles on the shop floor. The compact Ø48 interface keeps the installation simple and repeatable. Practical compatibility and workflow advantages Engineered for integration with standard stereo systems, the W2.0 attachment lens fits into common optical trains and preserves the microscope’s ergonomic layout. This accessory is particularly useful where rapid alternation between magnification levels is required—inspection benches, incoming goods control and assembly verification benefit from the doubled visual resolution. The accessory’s construction supports stable alignment, which reduces adjustment time and ensures reproducible views across multiple operators. For specific system compatibility and to verify mechanical fit, Metav Werkzeuge can provide application guidance and parts matching. Confidence through tested optics and trusted supply The optical design focuses on delivering clear, contrast-rich images for routine and precision inspection alike, helping to avoid misinterpretation of small features. Supplied by Metav IndustryLine and distributed from Emmerich, this attachment lens is part of a range that embodies Metav’s commitment to making precision accessible: a broad product spectrum, a rigorous quality filter and dependable logistics for industry and trade. The combination of a defined magnification gain and a standard Ø48 mount offers a practical, low-risk upgrade path for laboratories and workshops seeking improved visual performance without major system overhaul. Request tailored compatibility advice from Metav Werkzeuge for the W2.0 attachment lens and secure prompt delivery from Emmerich — contact info@metav-werkzeuge.com or call +49 2822 7131930 Technical Data Article number: M503.242.4 GTIN: 4054469145228 Customs tariff number: 90119090 Data Magnification: 2.0× Mount diameter: Ø48 mm Weight: 6.15 kg Type designation: W2.0 Special features Category: Optik Suitable for: stereo microscopes SKU: M503.242.4 FAQ How does the attachment lens affect the microscope’s magnification? The attachment lens multiplies the microscope objective’s magnification by 2.0×, turning an existing magnification into twice its value without replacing objectives. Will the lens fit my stereo microscope? Compatibility depends on the objective mount; the accessory uses an Ø48 mm interface common to many stereo systems. Metav Werkzeuge can confirm fitment for specific microscope models. Does the W2.0 attachment lens change the working distance? Introducing an attachment element can alter the effective working distance slightly; the design of the W2.0 aims to preserve practical working distances for inspection tasks, minimising adjustments needed. Is the accessory suitable for laboratory and workshop use? Yes. The optical booster is designed for routine inspection and laboratory visual checks, improving detail recognition while remaining straightforward to integrate into established workflows. What identification numbers are available for ordering and inventory? The product is listed under SKU M503.242.4 and GTIN 4054469145228 for ordering and inventory control. Manufacturer / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; Germany; +49 2822 7131930; info@metav-werkzeuge.com
See microstructure clearly for decisive quality control
A metallographic microscope (also referred to as a metallurgical microscope or inspection microscope) is an indispensable optical precision instrument in metallography. It renders the microstructure of metals and alloys visible at high magnification and forms the essential link between physical sample preparation and materials‑science assessment.
How the system works in the lab
Metals are opaque to transmitted light, so inspection is performed using reflected‑light techniques. The setup comprises an illumination system that directs light through a beam splitter onto the prepared surface, a high‑quality objective that provides the primary magnification and resolution, and a tube with an eyepiece for visual inspection. Image quality is governed primarily by the objective’s numerical aperture, which determines the resolving power for fine structural details. Integration with a digital camera and specialised evaluation software enables accurate imaging, documentation and norm‑compliant measurement of grain size, phase fractions and microdefects.
Practical benefits for production and quality assurance
In industrial quality control the microscope provides measurable outcomes that reduce risk and save time:
- improved detection of inclusions, pores and micro‑cracks, lowering the chance of in‑service failure
- reproducible grain‑size and phase analysis (ferrite, pearlite, martensite) through calibrated imaging and software tools
- faster throughput in inspection routines, reducing sample turnaround and non‑productive downtime
- enhanced traceability by saving images and measurement reports to support audits and batch acceptance
Why Metav is the pragmatic partner for microscopes
Metav combines decades of metrology expertise with a broad range of inspection solutions, acting as a quality filter for the european market from its base in Emmerich. With over 48,000 customers and more than 250,000 products, Metav offers a single, reliable source for microscopes, camera systems and evaluation software, ensuring consistent supply and professional advice for industry and workshops.
FAQ
Which inspection tasks are best suited to a metallographic microscope?
A metallographic microscope is ideal for analysing grain size, identifying microstructural phases such as ferrite, pearlite and martensite, and detecting microscopic defects like inclusions, pores or cracks that may affect mechanical integrity.
How does numerical aperture affect image quality?
The objective’s numerical aperture directly influences resolution and contrast; higher numerical aperture allows the microscope to resolve finer features in the sample microstructure, which is critical for accurate phase identification and defect sizing.
Can I connect a camera and perform automated measurements?
Yes. Modern metallographic microscopes can be paired with a digital camera and evaluation software to capture images, perform calibrated measurements and generate reproducible, norm‑compliant reports for documentation.
What should I consider when choosing objectives for metallurgical work?
Select objectives with appropriate magnification and high numerical aperture, compatible with reflected‑light illumination and the intended measurement standards; quality optics minimise artefacts and improve repeatability of results.
Does Metav supply complete inspection solutions for workshops?
Metav supplies microscopes, camera systems and software as part of a comprehensive product range, backed by decades of expertise and a commitment to reliable delivery from Emmerich.
