Filter products
1000mm Beam Divider With Carbide Marking Tips, Ø25x100 Tips, Stainless Steel - Metav IndustryLine
Take advantage of a durable, stainless steel beam and wear‑resistant carbide scribing tips to achieve repeatable large‑diameter layout across the workshop; order directly from Metav Werkzeuge or consult our specialists for application guidance. Beam Trammel M201.275 – 1,000 mm Rod Divider with Carbide Scribing Tips (Metav IndustryLine) The Beam Trammel M201.275 is a precision rod divider designed for marking and measuring large diameters in metalworking, fabrication and jig construction. 1,000 mm measuring range for large components Carbide scribing tips for durable marking Stainless steel construction for corrosion resistance Compatible with calipers for diameters up to 2,000 mm Precise layout over a long working radius improves throughput The M201.275 is designed as a Large‑range measuring and marking tool, covering the 500–1,000 mm classification so common in heavy‑duty workshop tasks. With a 1,000 mm effective reach, the beam trammel enables transfer of centre points and scribed lines without repeated re‑set operations, which reduces set‑up time and minimises cumulative error. The robust beam geometry maintains alignment over the full span, supporting reproducible diameter settings and a smoother production flow. Durable materials and tips cut downtime Constructed from stainless steel (INOX), the trammel resists corrosion and retains straightness under typical workshop conditions. The solid rod (19 mm diameter) and a total mass of 3 kg provide stable handling and reduced flex during scribing. Equipped with carbide scribing tips sized Ø25×100 mm, the device delivers long service life and consistent, sharp layout marks on a variety of surfaces, lowering the frequency of maintenance interventions and ensuring clean, repeatable results. Straightforward integration into existing measuring routines The analogue design avoids electronic complexity while offering dependable repeatability for fabrication, tooling and jig work. When used alongside compatible calipers, the trammel supports measurements and marking for diameters up to 2,000 mm, allowing large and awkward components to be measured and laid out with workshop‑grade accuracy. Routine cleaning and careful storage preserve the beam’s straightness and the tips’ cutting edge, keeping the tool ready for daily use. Contact Metav Werkzeuge in Emmerich for tailored application advice or to arrange procurement of the M201.275 beam trammel Technical data Article number: M201.275 GTIN: 4054469182766 Weight: 3 kg Material: Stainless steel (INOX) Facts Measuring range: 0–1,000 mm Suitable diameter with calipers: up to 2,000 mm Rod diameter: 19 mm Tip size: Ø25 x 100 mm Instrument type: Analog trammel Special features Carbide scribing tips Robust beam construction Compatible with workshop calipers Ideal for large‑diameter marking FAQ What measuring range does the trammel cover? The M201.275 covers a measuring range of 0–1,000 mm and is classified for large‑range layout tasks. Are the scribing tips durable for continuous workshop use? The carbide scribing tips fitted to the M201.275 are designed for extended service life and produce consistent scribed lines; tips can be re‑sharpened or renewed as part of normal workshop maintenance. Is the tool suitable for heavy fabrication and jig making? Yes. The trammel’s rigid beam and stable mass make it well suited to fabrication, jig construction and other applications requiring repeatable large‑diameter marking. How heavy is the trammel and how does that affect handling? The instrument weighs 3 kg; this mass contributes to stability during scribing while remaining manageable for single‑person operation in typical workshop environments. Can this trammel be used with calipers to measure large diameters? Yes. In combination with compatible calipers the device supports measurement and marking for diameters up to 2,000 mm. Manufacturer / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; Germany; +49 2822 7131930; info@metav-werkzeuge.com
100mm Precision Caliper 0.02mm Nonius, Locking Screw, Depth Rod, 4‑Function, Chrome Matt Finish - Metav IndustryLine
Take advantage of the compact design, 0–100 mm measuring range and 0.02 mm resolution for precise, repeatable measurements in small-part production. Order the caliper directly via Metav Werkzeuge or contact the consultants for tailored technical advice and availability. Small vernier caliper M201.005 — compact 0–100 mm, 0.02 mm resolution (Metav IndustryLine) Small vernier caliper M201.005: a compact analogue caliper for precise inside, outside, depth and step measurements in fine mechanical workshops and general metalworking Small range, high resolution 0–100 mm 0.02 mm Four-way measurement: outside, inside, depth, step Monoblock stainless steel frame, matt chrome finish Locking screw for stable readings Precise measuring in compact spaces The 0–100 mm measuring range classifies this instrument in the Mikro category, ideal for fine mechanical tasks where compactness and precision matter. With a vernier resolution of 0.02 mm (nonius 1/50), the caliper delivers a level of detail suitable for watch, model and small-component work while remaining easy to handle. Compliance with DIN 862 ensures that the scale and graduation meet recognised workshop standards, providing an objective basis for quality checks and setting a clear expectation of measurement performance. Stable handling for repeatable results A monoblock frame reduces flex and improves repeatability when measuring thin or small workpieces. The integrated locking screw secures the slide for transport or comparative measurements, while the pronounced depth rod allows reliable depth readings without additional tools. As an analogue instrument with a precise nonius, the tool avoids battery dependency and offers tactile feedback preferred in many production environments; the design supports fast, repeatable checks at the machine or bench. Built for workshop reliability and trust Constructed from stainless steel with a matt chrome finish, the caliper resists wear and keeps graduations legible over long service life. The combination of robust materials, a simple mechanical vernier and a compact layout makes this caliper a cost-effective precision instrument for serial inspection and set-up tasks. As part of the Metav IndustryLine offering, the product benefits from Metav’s quality filter and broad supply chain support, reflecting the company’s focus on making high-precision tools accessible to workshops across Europe. Contact Metav Werkzeuge in Emmerich for availability, technical clarification or to discuss suitability for specific applications — phone +49 2822 7131930 or email info@metav-werkzeuge.com Technical Data Article number: M201.005 GTIN: 4054469163833 Label: Klein-Messschieber 100x0,02mm mattverchromt, Feststell Category: Messgeräte > Messschieber Facts Measuring range: 0–100 mm Resolution: 0.02 mm Vernier: 1/50 (nonius) Display: analogue Measuring functions: outside, inside, depth, step Depth gauge: yes Special features Material: stainless steel (inox) Finish: matt chrome plated Monoblock construction Locking screw for slide fixation Standard: DIN 862 Brand: Metav IndustryLine FAQ What measurement tasks can this caliper perform? The small vernier caliper M201.005 (Metav IndustryLine) supports four-way measurement: external diameters, internal bores, depth measurements and step heights, making it versatile for small-part inspection. Is this caliper suitable for precision workshop use? Yes. The instrument falls into the Mikro class (0–100 mm) with a vernier resolution of 0.02 mm and is manufactured to the requirements of DIN 862, so it is appropriate for precise workshop and assembly tasks. What material and finish does the caliper have? The M201.005 features a stainless steel body with a matt chrome finish and a monoblock frame for increased rigidity and long-term legibility of the graduations. Is the caliper analogue or digital? This is an analogue vernier caliper with a nonius (1/50) reading; it provides mechanical, battery-free operation and tactile measurement feedback. What identifiers are useful for ordering or inventory? Use SKU M201.005 or GTIN 4054469163833 when ordering or cataloguing this caliper. Manufacturer / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; Germany; +49 2822 7131930; info@metav-werkzeuge.com
100mm Precision Caliper 0.05mm Vernier With Pointed Beak, Monoblock, 4-Function, Chrome Matt - Metav IndustryLine
Compact precision in a compact format: a mechanical vernier with 0–100 mm range and 0.05 mm graduation, featuring pointed jaws for narrow contours and a built‑in depth gauge. Supplied ready for workshop use in a protective transport case. Order directly via Metav Werkzeuge or ask our consultants for application advice. Compact caliper M201.003 — small mechanical caliper, 0–100 mm, 0.05 mm (Metav IndustryLine) The M201.003 is a compact mechanical caliper for fine measurements up to 100 mm, designed for precise workshop and fine‑mechanical tasks where access is restricted Mechanical vernier with 0.05 mm reading Pointed jaws for narrow features Depth gauge and step measurement Delivered in protective transport case Precision where space is limited The compact vernier delivers reliable readings across a 0–100 mm span with a 0.05 mm graduation, placing it in the workshop micro class for fine mechanical work. The analogue scale and mechanical vernier give tactile feedback and immediate results without electronics, which benefits shops that value simplicity and robustness. For inspection tasks where fast, repeatable checks matter, the small format keeps reach and control in one hand while maintaining industry‑standard resolution for many production and quality routines. Durable build for repeatable measurements Constructed from stainless steel with a matt chrome finish, the caliper is designed to resist corrosion and surface wear in everyday use. A monoblock frame reduces play and maintains jaw parallelism, so measurements stay consistent over repeated use. The combination of a rigid carrier and precise mechanical guidance reduces measurement scatter that can arise from loose assemblies, making the tool suited to routine shop verification and to applications where component handling is frequent. Flexible measurement options for workshop needs Equipped for fourfold measurement, the instrument covers external and internal diameters, steps and depth with a single tool; the integrated depth gauge expands the range of tasks that can be solved at the bench. The pointed jaws allow access to small recesses and profiled edges, while the analogue design eliminates battery dependency and simplifies maintenance. Supplied in a protective case for secure transport, the caliper is ready to be carried between workstations without additional packaging. Built for precision trades and production support This compact caliper is ideal for fine assembly, small series production and workshop metrology where space and access are restrictive. The M201.003 from Metav IndustryLine combines a short jaw length with high mechanical stiffness to suit delicate components, micro parts and precision fixtures. Metav’s offering is backed by a broad distribution and product support network in Europe, reflecting a practical approach to making precision tools accessible across industry and craft. For tailored advice on using the M201.003 in specific production scenarios, contact Metav Werkzeuge for ordering and technical consultation from their Emmerich team. Technical data Article number: M201.003 GTIN: 4054469100050 Brand: Metav IndustryLine Facts Measurement range: 0–100 mm Graduation / reading: 0.05 mm Type: Analog vernier caliper Fourfold measurement: external, internal, depth, step Zolltarifnummer: 90173000 Special features Material: stainless steel (inox) Matt chrome finish Pointed jaws for narrow features Monoblock construction Integrated depth gauge Supplied in protective transport case FAQ What measurement range does the caliper cover? The caliper covers a 0–100 mm range suitable for small components and fine mechanical tasks. What resolution and reading type does it offer? Readings are mechanical via a vernier with 0.05 mm graduation for reliable analogue measurement. Can this caliper measure depth, steps and internal dimensions? Yes — the instrument supports external and internal measurements plus step and depth measurement via the integrated depth gauge. Is the instrument suitable for precision micro work? The compact format and fine graduation place it in the micro category, making it well suited to watchmaking, small assemblies and precision fixtures. Does the caliper require batteries or electronics? No — the analogue vernier operates without batteries, offering maintenance‑free measurement for routine workshop use. Manufacturer / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; Germany; +49 2822 7131930; info@metav-werkzeuge.com
1500mm Rod Compass With Tungsten Carbide Scribing Tips, Ø25x100 Tips - Metav IndustryLine
Take advantage of a long-range 1,500 mm measuring span combined with stainless steel robustness and carbide scribing tips for repeatable layout work; order directly via Metav Werkzeuge or ask our consultants for application advice. Beam compass 1,500 mm with carbide scribing tips (Metav IndustryLine) — long-range analogue layout tool Beam compass 1,500 mm with carbide scribing tips is a mechanical layout instrument designed for precise scribing and diameter transfer in workshop and tooling environments, offering a stable long-span solution for large-format components. Long-range 1,500 mm span Stainless steel construction Carbide scribing tips for durability Precision for diameters up to 3,000 mm Stable long-span measuring for large components The 1,500 mm span places this instrument in the Long class of beam compasses, where rigidity and reproducible results are essential. Built from stainless steel, the device resists bending and maintains alignment over its full length, which reduces measurement scatter on large parts. As an analogue instrument with a solid rod profile, it offers a straightforward setup for layout tasks where electrical components or displays are unnecessary, enabling reliable transfers and scribed reference lines across large faces and circumferences. Durable scribing tips for consistent marks Equipped with carbide scribing tips, the compass produces durable, well-defined scribe lines on workshop materials. The tips are specified at Ø25×100 mm, providing a robust contact area that stands up to repeated use and retains shape under normal workshop forces. This hard-metal tip arrangement reduces wear and keeps the marking point consistent over time, which improves repeatability when multiple parts require identical reference marks. Practical handling and workshop integration With a rod diameter of 19 mm and a mass of 4 kg, the tool balances stiffness with manageable handling for single-operator layout tasks. It is suitable for transferring diameters and scribing on assemblies and blanks, and it is listed as compatible with diameter measurement requirements up to 3,000 mm, making it a useful companion for large-jig and fixture work. The mechanical design requires minimal maintenance and integrates easily into standard marking workflows on the shop floor. Contact Metav Werkzeuge in Emmerich for ordering and technical guidance on the Metav IndustryLine beam compass; our consultants can advise on suitability for specific layout and marking tasks Technical data Article number: M201.276 GTIN: 4054469182773 Brand: Metav IndustryLine Facts Weight: 4 kg Measuring range: 0–1,500 mm Suitable for diameters up to 3,000 mm Rod diameter: 19 mm Tip size: Ø25×100 mm Special features Stainless steel construction Carbide scribing tips Analogue (mechanical) operation Category: measuring instruments, calipers FAQ How precise is this beam compass for layout work? The beam compass from Metav IndustryLine provides consistent reproducibility across its 1,500 mm span owing to its stiff stainless steel beam and secure tip mounting; it is intended for reliable workshop layout rather than laboratory-grade micro-measurement. Can the scribing tips be replaced or resharpened? Yes, the carbide scribing tips are replaceable; their hard-metal design is chosen for longevity and consistent scribe quality across repeated use with the Metav IndustryLine beam compass (SKU M201.276). Is this instrument suitable for marking large diameters and round workpieces? The tool is designed to handle diameter transfers and scribing tasks for components up to 3,000 mm, making it appropriate for large rings, flanges and similar workpieces in fabrication and tooling shops. What materials will the carbide tips work on? The carbide tips are intended for durable marking on typical workshop materials; their wear resistance maintains a precise scribe for repeated layout operations with the Metav IndustryLine compass. Manufacturer / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; Germany; +49 2822 7131930; info@metav-werkzeuge.com
2000 mm Stangen‑Zirkel mit HM‑Anreiß‑Spitzen, Ø25x100, INOX‑Stahl – Metav IndustryLine
Stangen-Zirkel 2000 mm mit Hartmetallspitzen von Metav IndustryLine Stangen-Zirkel 2000 mm mit Hartmetallspitzen – Präzises Anreißwerkzeug für große Bauteile und Rohrdurchmesser, entwickelt für robuste Werkstatt- und Fertigungsumgebungen. Stangen-Zirkel 2000 mm von Metav IndustryLine Hartmetallspitzen für kratzgenaue Markierungen INOX-Stahl: korrosionsbeständig und langlebig Analoger Nonius für robuste Werkstattmessungen Geeignet für Durchmesser bis 4000 mm Präzision und Langlebigkeit für anspruchsvolle Anreißarbeiten Robuste Materialien und durchdachte Konstruktion machen diesen Stangen-Zirkel zu einem verlässlichen Helfer bei Mess- und Anreißarbeiten. Die Hartmetallspitzen gewährleisten saubere, dauerhafte Markierungen selbst auf harten Oberflächen, während INOX-Stahl Korrosionsschutz und lange Standzeit bietet. Anwender profitieren von konstanter Präzision, weil Materialwahl und Spitze auf wiederholte Beanspruchung ausgelegt sind und somit Stillstandszeiten reduziert werden. Messbereich 2000 mm: Einsatzvorteile im Lang‑Segment Mit einem Messbereich bis 2000 mm zählt dieses Gerät zur Kategorie Lang-Bereich, die ideal für großformatige Komponenten in Formenbau, Rohrbearbeitung und Vorrichtungsbau ist. Die Länge bietet ein optimales Verhältnis aus Reichweite und Handhabung, sodass lange Linien und große Radien ohne Hilfsaufbauten angezeichnet werden können. Für Anwendungen, bei denen Bauteile groß und dennoch reproduzierbar zu markieren sind, bietet dieser Zirkel klare Effizienzvorteile. Bedienung und technische Details, die den Arbeitsalltag erleichtern Der Stangen-Zirkel nutzt einen analogen Nonius, der sich in rauen Werkstattumgebungen bewährt hat und eine einfache, robuste Ablesung ermöglicht. Die Messspitzen Ø25x100 sorgen für stabile Auflage und exakte Kraftübertragung beim Anreißen. Mit einem Gesamtgewicht von 5 kg liegt das Gerät satt in der Hand, was Verwacklungen reduziert und die Wiederholgenauigkeit erhöht. Für Anwender ohne spezielle Messtechnik‑Kenntnisse ist der Nonius ein leicht erlernbares System zur präzisen Längenbestimmung. Für wen dieses Werkzeug konzipiert ist Dieses Werkzeug richtet sich an Fachkräfte aus Werkstatt, Maschinenbau, Rohrleitungsbau und Vorrichtungsbau, die große Bauteile sicher markieren müssen. Durch die Konstruktion und die Materialwahl eignet sich der Zirkel für den Alltag in Produktionslinien ebenso wie für spezielle Montageeinsätze. Nutzer, die auf wiederholbare Markierungen und hohe Standzeit Wert legen, finden hier eine robuste Lösung mit klar messbaren Produktivitätsvorteilen. Für präzise Anreißarbeiten empfehlen wir den Erwerb des Stangen-Zirkels 2000 mm mit Hartmetallspitzen von Metav IndustryLine direkt über den Vertrieb anzufordern – per eMail an info@metav-werkzeuge.com oder telefonisch unter +49 2822 7131930. Produktmerkmale Artikelnummer: M201.277 Marke: Metav IndustryLine Bezeichnung: Stangen-Zirkel 2000 mm mit Hartmetallspitzen GTIN: 4054469182780 Daten Messbereich: 0-2000 mm Messbereich maximal: 2000 mm Gewicht: 5 kg Durchmesser: 19 mm Messspitzen: Ø25x100 Besonderheiten Material: INOX-Stahl Mit HM-Anreiß-Spitzen: Hartmetallspitzen für dauerhafte Markierungen Analoger Nonius: robuste mechanische Ablesung Geeignet für Durchmesser bis 4000 mm FAQ Wie robust sind die Hartmetallspitzen bei häufiger Nutzung? Der Stangen-Zirkel 2000 mm mit Hartmetallspitzen von Metav IndustryLine ist für dauerhaften Einsatz ausgelegt; die HM-Spitzen behalten Schnittkante und Markierfähigkeit auch bei wiederholtem Anreißen auf harten Werkstücken. Ist das Gerät für Außenmessungen an Rohren geeignet? Ja, der Stangen-Zirkel M201.277 eignet sich durch die robuste Konstruktion und die Eignung für Durchmesser bis 4000 mm besonders für Außenmessungen an Rohren und Zylindern. Wie wird der Nonius abgelesen und ist er wartungsintensiv? Der analoge Nonius des Stangen-Zirkels 2000 mm mit Hartmetallspitzen ist einfach abzulesen und benötigt im Normalfall nur geringe Wartung; regelmäßige Reinigung und Schutz vor starker Korrosion reichen für langfristige Funktion. Welche Vorteile bietet INOX-Stahl in diesem Werkzeug? INOX-Stahl sorgt beim Stangen-Zirkel von Metav IndustryLine für Korrosionsbeständigkeit und Stabilität, wodurch die Lebensdauer erhöht und die Präzision über lange Zeit erhalten bleibt. Kann das Gerät in der Großserienfertigung eingesetzt werden? Der Stangen-Zirkel 2000 mm (SKU M201.277) ist durch Materialwahl und Konstruktion für den anspruchsvollen Werkstattalltag geeignet und bietet die Wiederholgenauigkeit, die in vielen Fertigungsprozessen benötigt wird. Hersteller: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; Germany; +49 2822 7131930; info@metav-werkzeuge.com
200mm Precision Caliper Analog 0.01mm, Four-Point Measurement, DIN 862, Calibrated in Case - Metav IndustryLine
Take advantage of precise analogue readout and 0.01 mm graduation for dependable workshop measurements; the instrument’s four measurement functions and DIN 862 conformity support repeatable checks on components. Order the caliper directly via Metav Werkzeuge or consult our specialists in Emmerich for application advice. Metav IndustryLine Dial Caliper TOP 200 × 0.01 mm — analogue dial with four measurement functions Metav IndustryLine Dial Caliper TOP 200 × 0.01 mm is a workshop-grade dial caliper designed for versatile dimensional checks in metalworking and maintenance tasks Dial readout with 0.01 mm graduation Four measurement functions: inside, outside, depth, step Compliant with DIN 862 Dependable precision for everyday workshop control The instrument delivers a finely graduated 0.01 mm dial readout that allows for controlled, repeatable measurements on parts where consistent tolerances matter. As an analogue dial caliper, it combines the tactile feedback of mechanical measurement with a fine resolution, making it suitable for quality checks in production and maintenance. Conformity to DIN 862 ensures the caliper meets recognised tolerancing and construction standards, which supports reliable cross-checking against specifications and reduces uncertainty in acceptance procedures. Practical handling and measurement versatility A compact form and a smooth sliding action allow fluid single-handed operation; the integrated locking screw secures the jaws for stable readings during transfer or marking tasks. The instrument’s four measurement functions cover inside, outside, depth and step measurements without additional tools, shortening inspection cycles and simplifying workflow. A clearly marked dial (diameter 38 mm) gives immediate visual feedback, which can speed up series inspections compared with slower micrometre operations. Classification and typical workshop applications With a measuring range of 0–200 mm, this caliper falls into the Standard class, the most versatile group for machine shops and general metalworking. That range is the common basis for everyday tasks — from component verification to setup checks on jigs and fixtures — where reach and stiffness are balanced for single-handed use. The device is therefore well suited for maintenance teams, toolrooms and small-batch production where dependable, repeatable measurements are required without specialised metrology equipment. Useful details that support reliable results Design features include an analogue dial mechanism that provides precise incremental readings and a thread chart on the reverse face to aid fast reference for screw dimensions. The instrument’s construction follows workshop expectations for rugged handling and direct readout simplicity, helping to reduce operator-induced variability. For traceable verification, the caliper is supplied with standard calibration documentation in line with shop-floor quality routines. For reliable workshop precision order the Metav IndustryLine dial caliper via Metav Werkzeuge and contact our Emmerich team for tailored advice at info@metav-werkzeuge.com or by phone — our specialists will help select the right measuring tool for the task. Technical data Article number: M202.144 GTIN: 4054469102382 eCl@ss: 21170344 Standard: DIN 862 Facts Measuring range: 0–200 mm Resolution / graduation: 0.01 mm Dial diameter: 38 mm Measuring functions: 4 (inside, outside, depth, step) Special features Analogue dial readout Locking screw for jaw fixation Thread chart on reverse side Suited to standard workshop metrology FAQ How accurate is the dial readout on this caliper? The dial readout provides a graduation of 0.01 mm, enabling fine incremental readings suitable for workshop control and repeatable inspection tasks with the Metav IndustryLine dial caliper. What types of measurements can be performed with this caliper? The instrument supports four measurement types: outside, inside, depth and step measurements, making it a flexible choice for typical machine‑shop checks. Which measuring range does the caliper cover and what does that imply? With a 0–200 mm range the caliper is in the Standard class, offering a practical compromise between reach and stiffness for general metalworking and fixture checks. Does the caliper meet any standards? Yes, the caliper is specified to DIN 862, reflecting conformity with established caliper construction and tolerancing requirements. Manufacturer / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; Germany; +49 2822 7131930; info@metav-werkzeuge.com
500mm Rod Divider With Carbide Scribing Tips, Ø25x100 Points, Stainless Steel - Metav IndustryLine
Take advantage of the combination of robust INOX steel, carbide scribing tips and a practical 500 mm range for reliable marking and transfer tasks in the workshop. Order the tool directly via Metav Werkzeuge or consult our specialists for application advice. Bar Compass 500 mm with Carbide Scribing Tips — Metav IndustryLine The Bar Compass 500 mm with Carbide Scribing Tips is a mechanical workshop divider designed for precise scribing and diameter transfer up to 500 mm, ideal for toolrooms, jig making and general metalworking. Robust INOX steel construction 500 mm measuring range Carbide scribing tips for wear resistance Compatible with calipers to 1000 mm Precision marking with a stable, mid‑range tool This mechanical bar divider offers precision for repetitive marking tasks thanks to its solid construction and defined measuring span. Classified in the mid range (300–500 mm), the instrument bridges the gap between compact fine‑work tools and long‑reach beam compasses, making it particularly suited to fixture and mould work where reach and rigidity must be balanced. The combination of a corrosion‑resistant INOX steel beam and a weight that gives tactile stability ensures that marks remain consistent, reducing rework and saving time on the shop floor. Durable carbide tips for long service life Equipped with carbide tips, the instrument is built for longevity under frequent use. Carbide maintains a sharp contact point much longer than standard steels, which means scribed lines stay crisp and repeatable over extended production runs. The tip geometry (Ø25 x 100) provides a secure contact area while resisting deformation; this supports reproducible results on a range of surfaces and contributes directly to lower tooling costs over time through reduced tip replacement. Practical handling tuned to workshop workflows The design of this workshop divider emphasises straightforward, reliable operation: a clear 0–500 mm range gives immediate orientation when laying out circles or transferring measurements, and the effective mass of the tool helps keep the beam steady during scribing. As a mechanical instrument it is easy to integrate into standard marking routines without the need for power or electronics, which simplifies maintenance and training. For applications requiring larger diameters, the device is compatible with caliper setups up to 1000 mm, enabling flexible use across different tasks. Why Metav IndustryLine adds value to daily measurement tasks Sourcing this instrument from Metav IndustryLine means access to a supplier that focuses on making precision affordable and dependable. Metav’s inventory and logistic base in Emmerich act as a quality filter for the European market, supporting consistent supply and straightforward procurement for workshops and specialist suppliers. The result is a practical tool that addresses everyday marking demands while being backed by a partner experienced in precision equipment distribution. For robust, repeatable marking in production, request the Metav IndustryLine Bar Compass 500 mm with Carbide Scribing Tips from Metav Werkzeuge or contact our consultants for tailored application support. Technical data Article number: M201.274 GTIN: 4054469182742 Brand: Metav IndustryLine Numbers / core technical data Measuring range: 0–500 mm Weight: 2 kg Diameter (shaft): 19 mm Special features Material: INOX steel Carbide scribing tips (HM-Anreiß‑Spitzen) Tip dimensions: Ø25 x 100 mm Suitable for calipers to 1000 mm FAQ What is the maximum measuring range of the tool? The Bar Compass 500 mm with Carbide Scribing Tips covers a measuring span of 0–500 mm, making it a mid‑range divider for workshop marking. Are the scribing tips replaceable and what material are they? The tool is supplied with carbide scribing tips; the use of carbide gives high wear resistance and long service life for the marking points. Which materials is the instrument suitable for marking? The Bar Compass 500 mm with Carbide Scribing Tips is fashioned from INOX steel and the carbide points are suitable for durable marking across common workshop materials where scribing is required. Is this a mechanical or electronic instrument? This is a mechanical (analog) bar compass, intended for straightforward scribing and measurement transfer without the need for electronics. Can the tool be used together with calipers for larger diameters? Yes, the divider is compatible with caliper setups up to 1000 mm, which helps when transferring larger diameters or using the device in conjunction with other measuring aids. Manufacturer / Responsible: Metav Werkzeuge GmbH; Parkring 45; 46446 Emmerich; Germany; +49 2822 7131930; info@metav-werkzeuge.com
